IHP WS-CI150 User manual

HEARTH PRODUCTS
KITS AND ACCESSORIES
775149M
REV. C 12/2013
Cat. No. Model Description
H0757 WS-CI150 CI1500 Painted Black
H0758 WS-CI152 CI1502 Midnight Blue
H0759 WS-CI154 CI1504 Majolica Brown
H0760 WS-CI156 CI1506 Hunter Green
H0762 WS-CI250 CI2500 Painted Black
H0763 WS-CI252 CI2502 Midnight Blue
H0764 WS-CI254 CI2504 Majolica Brown
H0765 WS-CI256 CI2506 Hunter Green
H2158 WS-CI258-2 CI2508 Ivory White
INSTALLATION INSTRUCTIONS FOR WARMING SHELF KITS
FOR USE WITH SEREFINA CI1500DVF SERIES AND CI2500DVF SERIES GAS STOVES
1
KIT CONTENTS TOOLS REQUIRED
2 ea. Warming Shelves Phillips Screwdriver
4 ea. Decorative Brackets
4 ea. Insets (CI1500 Series) *
6 ea. Insets (CI2500 Series) *
4 ea. Screws, 6mm x 20mm
1 ea. Instruction Sheet
* The CI1500DVF Series Kit includes 4 insets.
The CI2500DVF Series Kit includes 6 insets.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
INSTALLATION INSTRUCTIONS
Step 1. Lift off trivet, then stove top and set aside (see Figure 6).
Step 2. Install decorative brackets to both warmingshelves using the screws
provided.
2 Shelves
GENERAL INFORMATION
These attactive warming shelves are designed to be functional for plac-
ing food to stay warm. The shelves extend on both sides of the stove
top and add an attractive accent.
CAUTION
The cast iron stove top is very heavy and may require
a minimum of two people to lift; one person on each
side (theCI1500 seriescast topweighs ~20pounds and
the CI2500 series cast top weighs ~40 pounds).
4 Brackets 4 Screws
*4 Insets
Figure 1 - Kit Contents
Install Screws Provided
Figure 2 - Assemble Shelves to Brackets
Step 3. Using the existing screws on the stove body, install both warming
shelve assemblies as shown in Figure 3. Tighten screws just enough
to level shelves.
Install, using the
existing screws.
Figure 3 - Installing onto Stove Body
fire-parts.com

Printed in U.S.A. © 2003 IHP LLC
P/N 775149M REV. C 12/2013
IHP reserves the right to make changes at any time, without notice, in design, materials, specifica-
tions, prices and the discontinuance of colors, styles and products. Consult your local distributor
for fireplace code information.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
1508 Elm Hill Pike, Suite 108 • Nashville, TN 37210
2
Step 4. Place the insets (4 ea. for the CI1500 series or 6 ea. for the CI2500
series) into the recessed areas on both warming shelves as shown
in Figures 4 & 5.
NOTE: Common ceramic tiles (4-1/4” square) can be used in place of insets
on the warming shelves (available at most home improvement stores).
Figure 4 - Install Insets
Place insets as
shown here. Figure 5 - Top View of Warming Shelves Installed
Step 5. Reinstall stove top into position.
Proper Use Instructions:
These attractive shelves are designed to be functional for placing food to
stay warm. For cleaning instructions see Cleaning Enamel Surfaces on
Page 4 of the Installation and Operation Manual.
CAUTION
Never place anything on the shelves with a weight
that exceeds 80 pounds (36 kilograms).
Never place food containers or other materials on the
shelves that may be subject to melting.
fire-parts.com
