Impulse IT8009 Total Hip User manual

I Total Hip
Assembly Instructions
T8009

Table of contents
Important Safety Instructions--------------------------------- 1
Exploded View Diagram------------------------------------------ 2
Hardware List-------------------------------------------------- 3
Parts List----------------------------------------------------- 4
Assembly instructions------------------------------------------ 5
------
----------
--

Important Safety Instructions
1
Before beginning any fitness program, you should obtain a complete
physical examination from your physician. When using exercise equip-
ment, basic precautions should always be taken, including the following:
* Read all instructions before using the .
arewrittentoensureyoursafetyandtoprotect
* Do not allow children on or near the equipment.
* Use the equipment only for its intended purpose as described in this
guide. Do not use accessory attachments that are not recommended
by the manufacturer: such attachments might cause injuries.
* Wear proper exercise clothing and shoes for your workout---no loose
clothing.
* Be careful when getting on or off the equipment.
* Do not overexert yourself or work to exhaustion.
* If you feel any pain or abnormal symptoms, stop your workout imme-
diately and consult your physician.
* Never operate the unit when it has been dropped or damaged.
* Never drop or insert anything into any opening in the equipment.
* Always check the unit and its cables before each use. Make sure that
all fasteners and cables are secure and in good working condition.
* Frayed or worn cables can be dangerous and may cause injury.
Periodically check these cables for any indication of wear.
* Keep hands, limbs, loose clothing and long hair well out of the way of
moving parts.
* Do not attempt to lift more weight than you can control safely.
* Do not use the equipment outdoors.
* Read each step in the assembly instructions and follow the steps in
sequence. Do not skip ahead. If you skip ahead, you may learn later
that you have to disassemble compontents and that you may have
damaged the equipment.
* Assemble and operate the equipment on a solid, level surface. Locate
the unit a few feet from walls or furniture to provide easy access.
The is designed for your enjoyment. By
precautions and using common sense, you will have
pleasurable hours of healthfull exercise with the
Total Hip These instructions
the unit.
Total Hip following these
many safe and
equipment.
Personal Safety During Assembly

2
I Total Hip
Exploded View Diagram
T8009

3
Hardware List
0 100
10 20 30 40 50 60 70 80 90 110 120 130 140 150
Inches
0123456
/
12
/
14 /
34 / 34 / 34 / 34 / 34 / 34
/
14 / 14 / 14 / 14 / 14
/
12 / 12 / 12 / 12 / 12
Millimeters

4
Parts List
Item No. Description QTY Item No. Description QTY
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
2
1
1
1
1
1
4
4
1
1
2
2
4
4
1
10
9
1
2
2
16
4
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
4
2
1
1
1
2
2
4
8
6
4
8
2
4
2
5
4
1
16
30
3
4
72
2
14
4
12
1
1
1
1
1
3
4
1
1
1
1
1
1
36
14
1
1
2
Main Upright
Little Main Upright
Swing Tube
Pivot Arm
Cross Base
Adj. Base
Foot Pad
Short Guide Rod
Pop Pin Handle
Right Support
Left Support
Left Rail
Right Rail
Above Cross
Root Base
Thick Pop Pin
Front Decal Plate
Little Cover
Guide Rod
Front Cover
Base Cvoer
Rear Decal Plate
Weight Shroud
Cam
Long Pop Pin
Safety Tube
Spacer
Roller
PVC Tube
Gas Shock
Linear Bearing
Hole Clip
Out Collar
Shaft End
Rubber Cap
"D" End Cap
Adj. Foot Plate
Bearing
Top Plate
5Lbs Weight
10Lbs Weight
Weight Pin
4.5" Pulley
Weight Stack Bumper
Plastic Block
Bolt Cover
Plastic Washer
3.5" Pulley
Cable
Gimbal
Plastic Cap
Plastic Collar
Rear Side Cover
Allen Bolt M12×65
Allen Bolt M10×115
Allen Bolt M10×95
Allen Bolt M10×80
Allen Bolt M10×75
Allen Bolt M10×70
Allen Bolt M10×55
Allen Bolt M10×45
Allen Bolt M10×25
Allen Bolt M10×18
Allen Bolt M8×35
Chamfer Bolt M6×15
Nylon Locknut M10
Nylon Locknut M8
Washer 13× 24×1.5
Washer 11× 20×2
Washer 9× 22×2
Washer 6.6× 18×1.6
Washer 6.6× 12
Washer 6.6× 10
Allen WrenchS6
Decal Warning
Decal Maintence Routine
Decal Pinch Points
Decal Tightening
Square Cap
ΦΦ
ΦΦ
ΦΦ
ΦΦ
ΦΦ
ΦΦ
Φ
44 5
Cap 50
TR Pop and Lock Pin
Chamfer Bolt M4×6
Flange
Decal Weight Numbers
Cap 25
Decal Warning(Knock Head)
Chamfer Bolt M5×10
Button
Grease
Location Number 1-7
Plug 25 50
.



5
Assembly instructions
Assembly of the takes professional installers
hours. If this is the first time you have assembled this type of
equipment, plan to spend more time. It is strongly recom men
ded to assemble the equipment by professional installers.
You may find it quicker, safer, easier to assemble this equipment
with the help of a friend, as some of components may be large,
heavy or awkward to handle alone. It is important that you asse-
mble your product in a clean, clear, uncluttered area. This will
enable you to move around the product while you are fitting com-
onents and reduce the possibility of injury during assembly.
As with any assembled part, proper alignment and adjustment
is critical. While tightening the fasteners, be sure to leave room
for adjustments. Do not fully tighten the fasteners until instructed
to do so. Be careful to assemble the components in the sequence
presented in this guide.
Total Hip about 2
-
p
Note

6
Step1 Install the Adj. Foot Plates
Align the Adj. Foot Plates (#37) to the Main Upright(#01),
Right Support(#10) and Left Support(#11),then secure
thembyhands.

7
Step2 Install the Frame
1)Attach the Left Support(#11) to Main Upright(#01)
using:
2)Attach the Right Support(#10) to Main Upright(#01)
using:
Two Allen Bolts M10×95(#56)
Two Nylon Locknuts M10(#66)
Four Washers 11× 20×2(#69)
Two Allen Bolts M10×95(#56)
Two Nylon Locknuts M10(#66)
Four Washers 11× 20×2(#69)
ΦΦ
ΦΦ

1)Attach the Cross Base(#05) to the Right and Left
Support(#10,#11) and the Main Support(#01) using:
2)Attach the Adj. Base to the Right and Left Support
(#10,#11) using:
Six Allen Bolts M10×75(#58)
Six Nylon Locknuts M10(#66)
Twelve Washers 11× 20×2(#69)
Four Allen Bolts M10×80(#57)
Four Nylon Locknuts M10(#66)
Eight Washers 11× 20×2(#69)
ΦΦ
ΦΦ
Step3 Install the Frame
8

Step4 Install the Weight Plates
1)Insert both the Guide Rods(#19) into the Main Upri-
ght(#01).
2)Slide the Weight Rubber Bumper(#44) down onto
Guide Rod(#19)
3)Carefully begin sliding the Weight Plate one by one
sequence:#41,#40,#39.
4)Align both top ends of the Guide Rods(#27) to the
Upright(#01)andsecuerthemusing:
each
in
Main
Two Allen Bolts M10×75(#58)
Two Spring Washers 10(#73)
Two Washers
Φ
ΦΦ11× 20×2(#69)
TwoRubberCaps(#35)
Note
Make sure that Washer(#69) and Spring Washer
(#73) are on the top side.
9

Step5 Install the Little Main Upright
Attach the Little Main Upright(#02) to the Main Upright
(#01) using:
Four Allen Bolts M10×115(#55)
Four Nylon Locknuts M10(#66)
Eight WashersΦΦ11× 20×2(#69)
10

Step6 Install the Cam and Roller
1)Install the Cam(#24),the Spacer(#27)and the Pivot
Arm(#04) to the Little Main Upright(#02) in sequence,
then secure them using:
2)Insert the Swing Tube(#03) into Pivot Arm(#04),then
secure using:
3)Insert the Plastic Collar(#52),Roller(#28),Out Collar
into the Swing Tube(#03) in sequence,then secure
them using:
One Allen Bolt M10×25(#62)
One Spring Washer 10(#73)
One Washer 11× 20×2(#69)
One Shaft End(#34)
One Allen Bolt M10×25(#62)
One Allen Bolt M10×25(#62)
One Spring Washer
Φ
ΦΦ
Φ
ΦΦ
10(#73)
One Washer 11× 20×2(#69)
11

Step7 Route the Cable
1)Insert the bolt of Cable(#49) to the Top Plate(#39),
make sure the clip of the Weight Pin are on Top Plate
(#39).
2)Route the Cable(#49) up and over the 4.5” and 3.5”
lley,then secure them to the Main Upright(#01) using:
3)Down the Cable to Cam,secure the Gimbal(#50) into
the Cam using:
Pu-
Two Allen Bolts M10×55(#60)
Two Allen Bolts M10×45(#61)
Four Nylon Locknuts M10(#66)
Eight Washers 11× 20×2(#69)
One Allen Bolt M8×35(#64)
One Nylon Locknut M8(#67)
Two Washers 9× 22×2(#70)
ΦΦ
ΦΦ
12

Step8 Install the Foot Pad
1)Attach the Root Base(#15) to the Foot Pad(#07) using:
2)Install both the Root Base(#15) and the Foot Pad(#07)
onto the Adj. Base(#06),insert both Short Guide Rod
(#08) into the Foot Pad(#07) and the the Adj. Base(#06).
Two Allen Bolts M10×70(#59)
Two Nylon Locknuts M10(#66)
Four Washers 11× 20×2(#69)ΦΦ
13

14
Step9 Install the Right/Left Rail
Safety Tube and the Thick Pop Pin
,the
1)Attach the Above Cross(#14) onto the Right/Left
port,then attach the Left Rail(#12) to the Main
(#01) using:
2)Attach the Left Rail(#12),the Above Cross(#14) , the
Left Support(#11) and the Short GuideRod (#8) using:
3)In the same way attach Right Rail(#13).
4)Attach the Safety Tube(#26) to the Left/Right Rail
(#12/#13) using:
5)Attach the Thick Pop Pin(#16) to the Foot Pad(#07),
then adjust the Foot Pad(#07) upto the seventh potion,
then Attach the Gas Shock(#30) to the Foot Pad(#07)
and the Root Base(#15)using:
Sup-
Upright
Two Allen Bolts M10×115(#55)
Two Nylon Locknuts M10(#66)
Four Washers 11× 20×2(#69)
Two Allen Bolts M12×65(#54)
One Allen Bolt M10×25(#62)
Two Spring Washers 12(#72)
One Spring Washer 10(#73)
Two Washers 13× 24×1.5(#68)
One Washer 11× 20×2(#69)
Two Allen Bolts M10×55(#60)
Two Spring Washers 10(#73)
Two Washers 11× 20×2(#69)
Two Nylon Locknuts M8(#67)
ΦΦ
Φ
Φ
ΦΦ
ΦΦ
Φ
ΦΦ
Note Now tighten all bolts.

15
Note
Step10 Install the Covers
1)Attach the Base Cover to the Right/Left Support
#11) using:
2)Attach the Little Cover(#18) to the Above Cross(#14)
and the Right/Left Support(#10/#11) using:
3)Attach the Front Cover(#20) to the Above Cross(#14)
and the Right/Left Support(#10/#11) using:
(#10,
Six Chamfer Bolts M6 15(#65)
Six Washers 6.6 18 1.6(#71)
Four Chamfer Bolts M6 15(#65)
Four Washers 6.6 18 1.6(#71)
Four Chamfer Bolts M6 15(#65)
Four Washers
×
××
×
××
×
6.6× 18×1.6(#71)
ΦΦ
ΦΦ
ΦΦ
Adjust the Front Cover(#20) and the Little Cover
(#18) to the least clearance then fix.

16
Step11 Install the Decal Plates
1)Attach the two Decal Plates(#17,#22) to the Main
right(#01) using:
2)Attach the Weight Shroud(#23) to the Main Upright
(#01) using:
3)Insert one Chamfer Bolt M6×15(#65) into the Main
right then secure the Plastic Cap(#51) to the Main Up
right(#01) using:
Up-
Up-
-
Fourteen Buttons (#88)
Four Bolt Covers (#46)
Four Chamfer Bolts M5×10(#87)
Four Plastic Washers(#47)
One Chamfer Bolt M6×15(#65)
