Impulse IT9022 User manual

ITEM NO. DESCRIPTION QTY ITEM NO. DESCRIPTION QTY
1 Weight Stack Frame 1 19 Upholstered Roller Pad 2
2 Seated Frame 1 20 Guide Rod 2
3 Front Frame 1 21 Side Cover 2
4 Foam Support Frame 1 22 Support Hook 1
5 Pop Pin 1 23 Support Hook 1
6 Long Foam Tube 1 24 U Bracket 2
7 Adjustable Foot plate 4 25 PU Antiskid 1
8 Top Plate 1 26 Aluminium tube Ring 4
9 Weight Plate 10LBS 2 27 Aluminium Cap 2
10 Weight Plate 15LBS 3 28 Aluminium Grip Cap 2
11 Weight Plate 20LBS 10 29 Connect Button 4
12 Cable_1 1 30 Shroud Retainer Plate 2
13 Cable_2 1 31 Pulley Bracket 1
14 Seat Pad 1 32 L Bracket 2
15 4.5" Pulley 8 33 Adjustable Stopper 1
16 Selector Pin W/Coil 1 34 Plastic Block 14
17 Long Lat Bar 1 35 Plug RT50*100 1
18 Lat Bar 1 36 Plastic Tube Guide 2

ITEM NO. DESCRIPTION QTY ITEM NO. DESCRIPTION QTY
37 Plug 2 55 Button Head Cap Screw M10*70 3
38 Shroud 1 56 Button Head Cap Screw M10*30 2
39 Top Rear Shroud 1 57 Button Head Cap Screw M10*25 2
40 Top Front Shroud 1 58 Flat Head Cap Screw M10*30 4
41 Support 1 59 Socket Head Cap Screw M8*30 1
42 Weight Rubber Bumper 2 60 Button Head Cap Screw M6*12 2
43 Gear Hook 4 61 Socket Set Screw M8*10 2
44 Cable Adaptor 1 62 Hex Nut M6 2
45 Arc Bracket 1 63 Hex Nut 16 1
46 Button 9 64 Flat Philips Screw M5*15 11
47 Plastic Washer 4 65 Self-Tapping Screw ST4.2*10 4
48 Plastic Cover 4 66 Flat Washer φ11*φ20*2 37
49 Button Head Cap Screw M10*95 2 67 Nylon lock Nut M10 16
50 Button Head Cap Screw M10*75 2 68 Hex Key s=4 1
51 Button Head Cap Screw M10*70 2 69 Hex Key s=5 1
52 Button Head Cap Screw M10*65 2 70 Hex Key s=6 1
53 Button Head Cap Screw M10*50 6 71 Wrench 1
54 Button Head Cap Screw M10*35 2 72 Lube 1

ROUTINE COMMERCIAL
MAINTENANCE
HOME
MAINTENANCE
Inspect;
Links, Pull Pins, Snap Locks,
Swivels, Weight Stack Pins
DAILY WEEKLY
Clean;
Upholstery DAILY WEEKLY
Inspect;
Cables or Belts and their tension DAILY WEEKLY
Inspect;
Accessory Bars, and Handles WEEKLY 3 MONTHS
Inspect;
All Decals WEEKLY 3 MONTHS
Inspect;
All Nuts and Bolts, Tighten if
needed
WEEKLY 3 MONTHS
Inspect;
Anti-Skid Surface WEEKLY 3 MONTHS
Clean & Lubricate;
Guide Rods with a Teflon (PTFE)
based lubricant (Superlube)
MONTHLY 3 MONTHS
Lubricate;
Seat Sleeves, Turcite Bushings,
Linear Bearing
MONTHLY 3 MONTHS
Clean and Wax;
All Glossy Finishes 6 MONTHS YEARLY
Repack with Grease;
Linear Bearings 6 MONTHS YEARLY
Replace;
Cables, Belts and Connecting
Parts
YEARLY 3 YEARS
LATEST DATE ENTRY
