Insignia MC90CQ User manual

www.insigniashowers.com Last Modied: 10/02/2021
INSTALLATION MANUAL
MC90CQ
Monochrome 900mm x 900mm
ATTENTION INSTALLERS:
These instrucons must be
le with the customer
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installaon.
Replacements Parts: Inside of your warranty period visit:
hps://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts: Outside of your warranty period visit
hps://www.insigniashowers.com/replacement-parts.html
WARRANTY REG NO: _______________________
To claim your full 5 year warranty, register your shower within 90 days visit:
hps://www.insigniashowers.com, click support and register for your warranty

www.insigniashowers.com Last Modied: 10/02/2021
02
Contents
Thank you for your purchase 3
Tips for assembly 4
Braided Hose QR Code/Link 5
Pressure/Tool requirements 6
Box contents 7
Screw Pack/Accessory Contents 8
Screw Pack/Accessory Contents Diagrams 9
Box Contents (exploded diagram) 10
Level the Tray and Connecng the Waste 11
Applying RubberGum 12
Installing the Water Valve and Hand Shower Holder 13
Installing the Glass Shelf and Back Panel Seals 14
Installing the Back Panels 15
Installing the Upright Proles 16
Installing the Top & Boom Rails 17
Installing the Front Fixed Glass 18
Installing the Door Wheels, Seals and Handles 19
Installing the Doors 20
Installing the Roof 21
Installing the Water Connecons 22
Signing o your shower 24
Parts list 25
Steam Room and Shower Safety Guide 26
WEEE Compliance Statement 27

www.insigniashowers.com Last Modied: 10/02/2021
03
Thank you for your recent purchase of an Insignia shower. Please read this booklet
with great care to ensure you get the best out of your build and have a shower that
will last for many years to come! Like everything, in order to obtain a rst class
product that will serve you well for many years, the eort and correctness put into the
assembly will reect in the quality of your nish.

www.insigniashowers.com Last Modied: 10/02/2021
04
Before we start, here’s our 4 top ps which may assist you...
TIP 1—Building Your Shower
This product is suitable for a DIY build, providing you are condent in your DIY abilies. Please look through this build guide and decide
on whether you feel condent in undertaking this task. If you are not, seek the services of a professional and show them these
instrucons before hiring.
TIP 2—Hard Water
Due to the nature of this product we highly advise the purchase and ng of a water soener.
(Please note: limescale build up may cause damage to your shower and will not be covered under warranty)
TIP 3—Installaon
These showers are designed to be free standing and movable from their locaon should you have the need to replace anything.
ALWAYS USE Flexible braided water inlet pipes (not supplied) and not central heang plasc type! Get your WRAS Approved Flexible
Braided Hoses here. (www.insigniashowers.com/wras-approved-braided-hoses.html)
NEVER FIX with rigid pipes, NEVER FIX the unit to the wall or oor.
TIP 4—Sealing
When using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the
RubberGum to fail and will not adhere as intended. Rubbergum is immediately waterproof and will gain addional strength over me.

www.insigniashowers.com Last Modied: 10/02/2021
05

www.insigniashowers.com Last Modied: 10/02/2021
06
We recommend a BAR pressure between 2.5 and 3.4 BAR. If
you have a combi boiler system no problem should be
experienced. If you have a gravity feed older type installaon
(hot water tank type usually less than 1 BAR) you will almost
certainly need a pump. We cannot advise on which type of
pump is used, locaon or design because all house plumbing
layouts vary. This is a job for your installer/plumber. The end
delivery however must fall within the scope above.
Important Note Do not exceed 3.4 BAR pressure under any
circumstances. Warranty is void if so as damage will occur. If
you have a combi supply, please use a pressure reducing valve
if required to lower the BAR pressure to the shower.
Please Remember that this product is free standing and is
designed to be pulled away from the wall.
The waste hose must be of a exible type (1m exible waste
supplied).
The water supply pipes must be that of a exible braided type
(not supplied).
DO NOT OVERTIGHTEN THE BRAIDED HOSES AS IT CAN CAUSE
THE CONNECTION TO POP AFTER A FEW WEEKS OF USE.
Always t easy to get to isolaon taps on both hot and cold
water supply (not supplied). Just like a dishwasher or washing
machine, this product MUST be isolated when not in use.
• Scissors
• Knife
• Spirit Level
• Tape Measure
Pressure/Water Requirements Tools Required
• RubberGum (supplied)
• Plumbers Mait (not supplied)
• Hot and cold isolaon valves (not supplied)
• 2x Braided hoses (not supplied) Steam version
requires 3. If you haven’t purchased these already,
simply click the following link below or copy in to
any web browser. For ease we have listed the
required pack below for your install.
• Shower cabins require pack 1
hps://www.insigniashowers.com/wras-approved-
braided-hoses.html
Parts Required
You will require:
• Philips Screwdriver
• Electric Drill
• Safety Gloves
• Safety Glasses

www.insigniashowers.com Last Modied: 10/02/2021
07
What’s in the Boxes?
Box Contents Quanty
Tray Shower Tray
Shower Roof
Boom Rail
Top Rail
Waste + Hose
Glass Shelf
Screw Pack
Hand Shower
Shower hose
Water Valve
Accessories (see next page)
1
1
1
1
1
1
1
1
1
1
1
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
Backwalls Le Back Panel
Right Back Panel
1
1
[ ]
[ ]
Column Column
Upright Proles
Magnec Door Seals
Rear ap Door Seals
Fixed Glass Flap Seals
1
2
2
2
2
[ ]
[ ]
[ ]
[ ]
[ ]
Glass Room Glass Doors
Front Fixed Glass
2
2
[ ]
[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.

www.insigniashowers.com Last Modied: 10/02/2021
08
Screw Pack + Accessory Contents
Product Code Descripon Quanty
AMI01 Jubilee Clip 10
WN25 25mm M5 Wing Nut and Bolt 4
ST18 18mm M4 Screw 4
NB16 16mm M4 Nut & Bolt 6
ST12 12mm M4 Screw 4
ST10 10mm M4 Screw 8
SW9 Small Washers (14 metal, 10 Rubber) 24
SP312 Monochrome Door Handle—Black 2
SP268 Shower Hose 1
SP015 Hand Shower Holder 1
SP057 90 Degree Chrome Water Outlet 1
SP101 PVC Hose (for water connecons) 1
SP009 90 Degree Threaded Elbow Joint 3
SP263A Monochrome Door Wheels (Spring) 4
SP263B Monochrome Door Wheels (Non-Spring) 4
SP314 Monochrome Screw Fixing Block/Wing Bolt (two separate pieces) 12
SP404 Monochrome ‘L’ Bracket Connecon 8
SP402 PRC20 Glass Retaining Clip 4
SP053 T-Piece Ribbed Connector 1
SP403 Monochrome Door Stops 8
AK3 3mm Allen Key 1

www.insigniashowers.com Last Modied: 10/02/2021
09

www.insigniashowers.com Last Modied: 10/02/2021
10

www.insigniashowers.com Last Modied: 10/02/2021
11
Step 1 — Level the Tray and connecng the waste

www.insigniashowers.com Last Modied: 10/02/2021
12
Step 2 — Applying the RubberGum
Apply RubberGum to raised
secons of the tray and remove
backing paper.

www.insigniashowers.com Last Modied: 10/02/2021
13
Step 3 — Installing the Water Valve and Hand Shower Holder

www.insigniashowers.com Last Modied: 10/02/2021
14
Step 3 — Installing the Glass Shelf and Back Panel Seals

www.insigniashowers.com Last Modied: 10/02/2021
15
Step 4 — Installing the Back Panels

www.insigniashowers.com Last Modied: 10/02/2021
16
Step 5 — Installing the Upright Proles

www.insigniashowers.com Last Modied: 10/02/2021
17
Step 6 — Installing the Top & Boom Rails

www.insigniashowers.com Last Modied: 10/02/2021
18
Step 7 — Installing the Front Fixed Glass

www.insigniashowers.com Last Modied: 10/02/2021
19
Step 8 — Installing the Door Wheels, Seals and Handles

www.insigniashowers.com Last Modied: 10/02/2021
20
Step 9 — Installing the Doors
