INSTALLATION MANUAL
1100L|1200L
Planum Series
ATTENTION INSTALLERS:
These instrucons must be
le with the customer
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installaon.
Replacements Parts: Inside of your warranty period visit:
hps://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts: Outside of your warranty period visit
hps://www.insigniashowers.com/replacement-parts.html
WARRANTY REG NO: _______________________
To claim your full 5 year warranty, register your shower within 90 days visit:
hps://www.insigniashowers.com, click support and register for your warranty

www.insigniashowers.com Last Modied: 17/05/2021
02
Contents
Installaon Assistance (Video Links) 3
Thank you for your purchase 4
Tips for assembly 5
Braided Hose QR Code/Link 6
Electrical/Pressure/Tool requirements 7
Box contents 8
Installing the Waste and Levelling the Tray 9
Connecng the Framework 10
Applying RubberGum 11
Installing the Back Panels 12
Installing the AMI System 13
Installing the Column 14
Installing the Fixed Glass Panels 15
Installing the Glass Seals 16
Installing the Roof 17
Installing the Door Wheels 18
Installing the Accessories 19
Water Valve Connecons 20
Control Panel Connecons 21
Steam Generator Connecons 22
Signing o your shower 23
Control Panel Operang Instrucons 24
Spare Parts List 27
Steam Room & Shower Safety Guide 28
Steam Room Usage Guide 29
How to use AMI System 30
Bathroom Electrical Zones 31
WEEE Compliance Statement 33

www.insigniashowers.com Last Modied: 17/05/2021
03
Installaon Assistance
Looking for assistance with the Install?
GREAT NEWS!
We have our easy to follow Installaon videos
live online NOW to make your installaon
process easier than ever before!
Simply click the link below and watch the
installaon process.
Shower Install

www.insigniashowers.com Last Modied: 17/05/2021
04
Thank you for your recent purchase of an Insignia shower. Please read this booklet
with great care to ensure you get the best out of your build and have a shower that
will last for many years to come! Like everything, in order to obtain a rst class
product that will serve you well for many years, the eort and correctness put into the
assembly will reect in the quality of your nish.

www.insigniashowers.com Last Modied: 17/05/2021
05
Before we start, here’s our 4 top ps which may assist you...
TIP 1—Building Your Shower
This product is suitable for a DIY build, providing you are condent in your DIY abilies. Please look through this build guide and decide
on whether you feel condent in undertaking this task. If you are not, seek the services of a professional and show them these
instrucons before hiring.
TIP 2—Hard Water
Due to the nature of this product we highly advise the purchase and ng of a water soener.
(Please note: limescale build up may cause damage to your shower and will not be covered under warranty)
TIP 3—Installaon
These showers are designed to be free standing and movable from their locaon should you have the need to replace anything.
ALWAYS USE Flexible braided water inlet pipes (not supplied) and not central heang plasc type! Get your WRAS Approved Flexible
Braided Hoses here. (www.insigniashowers.com/wras-approved-braided-hoses.html)
NEVER FIX with rigid pipes, NEVER FIX the unit to the wall or oor.
TIP 4—Sealing
When using Insignia’s RubberGum, please ensure the product does not come in contact with your silicone as this will cause the
RubberGum to fail and will not adhere as intended. Rubbergum is immediately waterproof and will gain addional strength over me.

www.insigniashowers.com Last Modied: 17/05/2021
06

www.insigniashowers.com Last Modied: 17/05/2021
07
We recommend a BAR pressure between 2.5 and 3.4 BAR. If
you have a combi boiler system no problem should be
experienced. If you have a gravity feed older type installaon
(hot water tank type usually less than 1 BAR) you will almost
certainly need a pump. We cannot advise on which type of
pump is used, locaon or design because all house plumbing
layouts vary. This is a job for your installer/plumber. The end
delivery however must fall within the scope above.
Important Note Do not exceed 3.4 BAR pressure under any
circumstances. Warranty is void if so as damage will occur. If
you have a combi supply, please use a pressure reducing valve
if required to lower the BAR pressure to the shower.
Please Remember that this product is free standing and is
designed to be pulled away from the wall.
The waste hose must be of a exible type (1m exible waste
supplied).
The water supply pipes must be that of a exible braided type
(not supplied).
DO NOT OVERTIGHTEN THE BRAIDED HOSES AS IT CAN CAUSE
THE CONNECTION TO POP AFTER A FEW WEEKS OF USE.
Always t easy to get to isolaon taps on both hot and cold
water supply (not supplied). Just like a dishwasher or washing
machine, this product MUST be isolated when not in use.
• Scissors
• Knife
• Spirit Level
• Tape Measure
Pressure/Water Requirements Tools Required
• RubberGum (supplied)
• Plumbers Mait (not supplied)
• Hot and cold isolaon valves (not supplied)
• 2x Braided hoses (not supplied) Steam version
requires 3. If you haven’t purchased these already,
simply click the following link below or copy in to
any web browser. For ease we have listed the
required pack below for your install.
• Shower cabins require pack 1
• Shower cabins with steam require pack 2
hps://www.insigniashowers.com/wras-approved-
braided-hoses.html
Parts Required
STEAM VERSION
Voltage Rang 220-240AC
Frequency Rang 50Hz
Power Rang 3KW
NON-STEAM VERSION
Voltage Rang 100-240AC
Frequency Rang 50/60Hz
Power Rang 12v DC/1500 mA
Your electrical contractor should understand ALL legal
requirements of connecon before undertaking any work
or installaon.
UNDER NO CIRCUMSTANCES UNDERTAKE THIS
YOURSELF!!!
Note for electrician: This product comes with 13 amp plug
(s) ed with an RCD unit (steam version only). We leave it
this way for you to connect it your own way due to
connued addions to current regulaons.
1) Connect within current laws and IP direcves.
2) (Preferred) Wire into isolated fused feed connecng
directly to the house consumer/service box.
Always use protecon against electrical surge. Your shower
should be treated the same as a home computer. A surge
protector should eradicate the possibility of either the
transformer or control panel being burnt out. Electrical
work needs to be signed o by a fully qualied operave by
law. Failure to adhere to this will not only void your
electrical warranty for your shower, but could void your
house insurance too.
Electrical Requirements
You will require:
• Philips Screwdriver
• Electric Drill
• Safety Gloves
• Safety Glasses

www.insigniashowers.com Last Modied: 17/05/2021
08
What’s in the Boxes?
Box Contents Quanty
Tray Shower Tray
Waste + Hose
Glass Shelf
Riser Rail for hand shower
Screw Pack
Flexible seal (12mm)
Flexible seal (7mm)
1
1
1
1
1
1
1
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
Glass Room Glass Doors
Front Fixed Glass
2
2
[ ]
[ ]
Column Complete Column
Hand Shower
1
1
[ ]
[ ]
Backwalls Le Back Panel
Right Back Panel
1
1
[ ]
[ ]
Screw Pack Contents
Product Code Descripon Quanty
SP097 Door Handles 2
SP276
SP276A
SP072
Twin Door Wheels Non-Push
Twin Door Wheels Push buon
Door stops
4
4
8
ST10 10mm Screws 8
ST16 16mm Screws 28
ST20 or WN20 20mm Nut and Bolt or Wing Nut 12
PRC20 Glass Retaining Clips 4
AMI01 Jubilee Clip (For steam version only) 1
SW9 Small Washers 20
DB9 Drill Piece 1
Framework Top Rail
Boom Rail
Outer Fixed Uprights
Magnec door seals
Rear ap door seals
Framework Securing Clips
1
1
2
2
2
4
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
Roof Roof with ngs 1[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.

www.insigniashowers.com Last Modied: 17/05/2021
09
Twist to adjust
Step 1 — Level the Tray and connecng the waste
NOTE: FOR STEAM SHOWERS ONLY:
Check the Spigot is drilled out prior to
ng. If it isn’t ensure you drill it out!

www.insigniashowers.com Last Modied: 17/05/2021
10
Step 2 — Connecng framework
Wider rail on top
Narrow rail at the boom
1
2
3
Internal View
Framework securing clips x4

www.insigniashowers.com Last Modied: 17/05/2021
11
Step 3 — RubberGum the tray
Apply RubberGum to raised
secons of the tray and remove
backing paper.
Step 4 — Fix framework to the tray
PRESS FRAME
DOWN FIRMLY
ONTO THE
RUBBERGUM.
Please Note 2nd Generaon showers lower prole curve is not designed to
fully follow the tray curve. Gap to tray being wider at each end.

www.insigniashowers.com Last Modied: 17/05/2021
12
ST16 x12
Step 5 — Connecng the back panels
DO NOT SCREW BACK PANELS TO THE TRAY.
PRESS PANELS
DOWN FIRMLY
ON TO THE
RUBBERGUM.

www.insigniashowers.com Last Modied: 17/05/2021
13
Step 6—AMI Install—Please note: If supplied with this version, it may already be ed. If it is, please skip this step.
Place in middle hole rst
Turn Tri-Jet to ghten Use Allen key to ghten le chrome outlet Use Allen key to ghten right chrome outlet
Note:
Connect the 1 metre
insulated hose to the
back of the Tri-Jet
outlet to the ‘steam
out’ on the
generator.

www.insigniashowers.com Last Modied: 17/05/2021
14
Step 7 — Column Connecon
NOTE: Column features varies between models
Rear View (aach nuts and bolts or wing nuts from rear)
Below diagram shows the nut/bolt install
————————
SW9 x 12
ST20 x 12
or
WN20 x 12
————————
or

www.insigniashowers.com Last Modied: 17/05/2021
15
Step 8 — Fixed Glass Connecon
ST16 x 4
PRC20 x 4

www.insigniashowers.com Last Modied: 17/05/2021
16
Step 9 — Fing the glass seals
Fit seal inside the shower between the glass and framework
Step 10 — Fing the door stops Internal View — Top Rail
Internal View — Boom Rail
ST10 x8
SP072 x8
1x 12mm Seal
1x 7mm Seal
7mm
12mm

www.insigniashowers.com Last Modied: 17/05/2021
17
Step 11 — Aaching the Roof
ST16 x6
Screw from the rear
Step 12 — Fit door handles, seals
and magnets

www.insigniashowers.com Last Modied: 17/05/2021
18
Step 13 — Fit top door wheels x 4
Slide cover o
Door
Tighten to secure wheels
into door runners.
DO NOT OVERTIGHTEN
Step 14 — Fit boom door wheels x 4
Slide cover o
Door
Step 15 — Fing the doors
Slide covers on

www.insigniashowers.com Last Modied: 17/05/2021
19
Step 16 — Accessory Installaon
Slide cover o
Slide cover o

www.insigniashowers.com Last Modied: 17/05/2021
20
Monsoon Head
Jets
Cold Water Inlet Hot Water Inlet
Step 17 — Valve/Water Connecons
Hand Shower
2 x Washers located on
the back of the valve
Connection for steam generator
(steam version only)
