USER MANUAL –EN
IN 9360 Spinning Bike inSPORTline Airin

2
CONTENTS
SAFETY INSTRUCTIONS.................................................................................................................................... 3
PARTS LIST........................................................................................................................................................... 4
HARDWARE AND TOOLS LIST......................................................................................................................... 7
OVERVIEW DRAWING....................................................................................................................................... 8
ASSEMBLY ........................................................................................................................................................... 9
HOW TO USE ...................................................................................................................................................... 13
SPD PEDALS USAGE......................................................................................................................................... 13
MAINTENANCE ................................................................................................................................................. 17
TROUBLESHOOTING........................................................................................................................................ 17
WARM UP ROUTINE ......................................................................................................................................... 17
TERMS AND CONDITIONS OF WARRANTY, WARRANTY CLAIMS ....................................................... 18
Note: Before installation and operation, please read this operation manual carefully and save this manual for
future reference.

3
SAFETY INSTRUCTIONS
Read all the instructions in this manual and do warm up exercises before using this equipment.
Before using this equipment, please consult your physician for a complete physical examination. If you
feel any discomfort while exercising, please stop immediately and consult your doctor.
Before exercising and to avoid injuring your muscles, perform warm-up exercise for each muscle group
is highly recommended. Please refer to Warm Up Routine section of the Owner’s Manual.
Keep the equipment indoors, away from moisture and dust. Place the equipment on a level surface, with
a mat beneath it to protect the floor or carpet. Make sure that there is enough clearance around the
equipment to mount, dismount, and use it.
Inspect and properly tighten all parts regularly. Replace any worn parts immediately.
Ensure that your fingers or clothing do not catch in the equipment moving parts.
Please keep children and pets away from the equipment at all times. It is only suitable for adults.
The equipment should not be used by persons weighting more than 150 kg. Serious injury may occur if
the user’s weight exceeds the limit shown here.
If you hear unusual noise when exercising, please stop your training immediately. Do not use the
equipment until the problem has been resolved.
To prevent injuring you when stop exercising, do not touch the flywheel immediately.
None of the adjustment means should not be left to protrude so could interfere with the movement of
the user
Freestanding unit must be installed on a stable and level surface
Excessive or improper exercise can cause injury
Class - HC (according to EN ISO 20957), intended for home use

4
PARTS LIST
No.
Description
QTY
1
Main Frame
1
2
Front stabilizer bar 40x80x2T
1
3
Rear stabilizer bar 40x80x2T
1
4
Upright post 40x80x2T
1
5
Seat post 40x80x2T
1
6
Handlebar Φ25.4x2T
1
7
Sear moving bracket
1
8
Plastic fastener 50x100x100mml
2
9
Seat VL-6100
1
10
Flywheel Φ468
1
11
Belt wheel Φ260 with Axis
1
12
Belt 1590 PK5
1
13
Main chain cover-R
1
14
Main chain cover-L
1
15
Inner chain cover-R
1
16
Inner chain cover-L
1
17
Side trim cover
1
18R
3PCS Crank-R
1
18L
3PCS Crank-L
1
19
Plastic cap for Crank
2
20R
Pedal JD-304V-R
1
20L
Pedal JD-304V-L
1
21
Spring knob M16x26
2
22
L-knob M10x20
1
23
Knob M10x28
1
24
Lock Nut M10
1
25
Washer 19.5x38x2T
1
26R
Magnet plastic cover-R
1
26L
Magnet plastic cover-L
1
27
Support bar 20x20x1.4T
1
28
Magnet bracket
1
29
Tension control bar
1
30
Fixed cover
1
31
П shape fastener
2
32
Spring washer
1

5
33
Nylon nut M6
2
34
Nylon nut M8
2
35
Cap nut M10
4
36
Carriage bolt M10x55
4
37
Washer 10x19x1.5T
6
38
Hex. Nut M10x6T
4
39
Hex socket head bolt M8x38
2
40
Spring Φ2.6x18
1
41
Adjustment bar Φ6x60
1
42
Compressed spring Φ1.5x9
1
43
Crank plug
2
44
Flange Nut M12x1.5x10.4T
4
45
Hex socket head bolt M8x15
3
46
Washer 10x29x2T
2
47
Self-tapping screw M5x12
5
48
Bottle holder
1
49
Screw M5x10
2
50
Philips screw M3x10
2
51
Steel sleeve Φ12*17*9
1
52
Self-tapping screw M4.5x15
2
53
Self-tapping screw M4.2x10
13
54
Hex. bolt M6x35
1
55
Idle wheel fixture
1
56
Nylon nut M10x9T
2
57
Steel sleeve Φ25.1x32x10T
1
58
Steel bearing 6005-2RS
2
59
C-ring Φ20
2
60
C-ring Φ25
1
61
Idle wheel
1
62
Wave washer 27x34x0.3T
1
63
Plastic washer 10x20x2T
2
64
Wire plug Φ17
1
65
Steel sleeve Φ10.2x15x6T
1
66
Axis Φ20x155mm
1
67
Wave washer 21x27x0.3T
1
68
Washer 20.5x25x0.5T
1
69
Hex. bolt M10x32
1
70
Washer 12x17x1.0T
2

6
71
Plastic bearing Φ12.8x21.4x6.7T
4
72
Plastic sleeve Φ7.9x12.7x23.5mm
2
73
Fixed plate
2
74
Cushion knob M10x25
4
75
Cap Φ76
4
76
Transport wheel Φ70
2
77
Tension control knob M10
1
78
Bolt M5x15
2
79
Bolt M5x10
2
80
Self-tapping screw M4.5x25
5
81
Plastic cap
1
82
Washer 12x24x1.5T
2
83
Washer Φ5
2
84
Plastic cover
1
85
Washer 10x16x1.5T
1

7
HARDWARE AND TOOLS LIST

8
OVERVIEW DRAWING

9
ASSEMBLY
STEP 1
STEP 2

10
STEP 3
STEP 4
