Intermec EasyCoder PD41 User manual

Installation
Instructions
Cutter Kit
for the EasyCoder®
PD41 and PD42 Printers

ii EasyCoder PD41/PD42 Cutter Kit Installation Instructions
Intermec Technologies Corporation
Worldwide Headquarters
6001 36th Ave. W.
Everett, WA 98203
U.S.A.
www.intermec.com
e information contained herein is provided solely for the purpose of
allowing customers to operate and service Intermec-manufactured equipment
and is not to be released, reproduced, or used for any other purpose without
written permission of Intermec Technologies Corporation.
Information and specifications contained in this document are subject to
change without prior notice and do not represent a commitment on the part
of Intermec Technologies Corporation.
© 2005-2007 by Intermec Technologies Corporation. All rights reserved.
e word Intermec, the Intermec logo, Norand, ArciTech, Beverage
Routebook, CrossBar, dcBrowser, Duratherm, EasyADC, EasyCoder, EasySet,
Fingerprint, INCA (under license), i-gistics, Intellitag, Intellitag Gen2,
JANUS, LabelShop, MobileLAN, Picolink, Ready-to-Work, RoutePower,
Sabre, ScanPlus, ShopScan, Smart Mobile Computing, SmartSystems, TE
2000, Trakker Antares, and Vista Powered are either trademarks or registered
trademarks of Intermec Technologies Corporation.
ere are U.S. and foreign patents as well as U.S. and foreign patents pending.

Two screws Two cable clips
Cutter cover
Cutter spring
Two screws
(for plastic)
Cutter Mechanism
EasyCoder PD41/PD42 Cutter Kit Installation Instructions 3
Installing the Cutter
1Unpack your cutter kit and check that all parts depicted below are included.
If not, contact your Intermec sales representative.
2Make sure the printer is turned off and disconnected from the power
supply. Remove the screw that holds the front cover. Remove the front
cover.

4 EasyCoder PD41/PD42 Cutter Kit Installation Instructions
3Open the side door and remove the tear bar, held by two Phillips
screws.
4Attach the cutter mechanism to the printer using the two Phillips screws
included in the kit.

EasyCoder PD41/PD42 Cutter Kit Installation Instructions 5
Cable clips
Cutter cable
Cutter
connector
5Plug the cutter cable into the connector in the center section as shown.
Secure the cable to the bottom plate using the two cable clips included in
the kit.
6Use the two plastic screws to attach the cutter spring to the cover (1). Hook
the cutter cover onto the cutter mechanism and lock the cover with the
screw at the bottom (2).
12

6 EasyCoder PD41/PD42 Cutter Kit Installation Instructions
Activating the Cutter (PD42 only)
If you are using a PD42 printer you can activate the cutter directly from the
display.
To activate the cutter on a PD42 printer
1Turn the printer on.
2Press Setup ( ).
3Navigate to Configuration > Cutter >Enable.
4Press Acknowledge ( ).
5Press Setup again to exit setup.
Controlling the Cutter (Fingerprint)
e cutter function is controlled with the Fingerprint commands CUT and
CUT ON/OFF. Please refer to the Fingerprint Programmer’s Reference Manual
(P/N 937-005-xxx) for more information.
Controlling the Cutter (IPL)
e cutter function is controlled with the IPL commands listed below. Please
refer to the IPL Programmer’s Reference Manual (P/N 066396-xxx) for more
information.
IPL Cutter Commands
Command Description
<SO> Cut
<SI>c1 Enable cutter
<SI>c0 Disable cutter

EasyCoder PD41/PD42 Cutter Kit Installation Instructions 7
Installing Media
To install media in the printer, follow the instructions provided in the printer’s
user’s guide. e cutter is primarily intended to cut paper-based media in the
form of continuous stock. To obtain optimal use of the cutter, make sure your
media corresponds to the specification below.
Recommended minimum label/paper length 30 mm
Maximum label/paper width 114 mm
Recommended media thickness 78 - 175 μm
Configure your cutter so that it only cuts through the label liner.
If you cut through both label and liner, the adhesive sticks to the
cutting blade and this causes malfunction. Also avoid cutting
soft, plastic-based media.
