OTQ80576
Optical sensors
Diffuse reflection sensor with background suppression
Iplastic housing
Isetting via teach-in
Istatus LED as alignment aid
IM8-connecor 4-pin
TECHNICAL DATA
function
diffuse reflection sensor, background suppression
sensing range
3 … 132mm
sensing distance
20 … 120mm
voltage supply +Vs
10 … 30V DC
current consumption (w/o load)
40mA
voltage drop (max. load)
2V
output current (max. load)
50mA
output signal
Push-pull, no/nc
short-circuit protection
+
reverse polarity protection
+
response / delay time (high-speed-mode)
≥0.25ms
sampling frequency (high-speed-mode)
≤ 2kHz
transmitting element (pulsed)
LED, red light, punctiform
wave length
644nm
display (operation)
LED green
display (signal / alignment)
LED yellow
switchpoint setting
teach-in and IO-Link
suppression of reciprocal influence
+
housing material
plastic (ASA, PMMA)
front screen material
PMMA
degree of protection (EN 60529)
IP 67
operating temperature
-25 … +60°C
connection
M8 cable connector, 4-pin, L=200mm
connection accessories
e.g.VK200375
accessories (universal-holder)
AY000116
Connection Dimensional drawing
small light spot thanks to PIN-Point-LED
IO-Link interface

MANUAL •Subject to alteration! Version: November 2019
ipf electronic gmbh
•Rosmarter Allee 14 •58762 Altena
│
Tel [phone] •Fax [phone]
│
[email protected] •www.ipf-electronic.com 2
Beam path Mounting
Description of the LED-display:
LED-indication Legend operating mode
LED on
LED flashing 1Hz
LED flashing 2Hz
LED flashing 8Hz
Description Teach-In Level 1 & 2:
Level 1 = 1-point teach: sets the switchpoint at the position of the object + 10%*
Level 2 = 2-point teach: sets the switchpoint in the middle of position A & B
* This value is adjustable by IO-Link. Please check the IO-Link manual.
The direct reflection from glossy or
reflective objects must not impinge
on the receiver. This can be avoided
by slightly tilting the sensor.
It is recommended that the object
to be detected approaches the
active area of the sensor from the
side, which avoids malfunctions
caused by deflection of the light
beam at edges.
LED-indicators
green
yellow
power on
short-circuit
output 1 active
output 1 signal close to
threshold
teach-in mode
see teach-in instruction

MANUAL •Subject to alteration! Version: November 2019
ipf electronic gmbh
•Rosmarter Allee 14 •58762 Altena
│
Tel [phone] •Fax [phone]
│
[email protected] •www.ipf-electronic.com 3
Optional teach-in methods, configurable via IO-Link:
Window-mode: Level 1 / 1-point teach: set a window of ± 10% around the position of the object.
Level 2 / 2-point teach: set a window within the object is being detected.
Dynamic Teach-In: Available also for window mode. Enter teach level 1 to start the data acquisition and TAP to stop
the data acquisition (duration 2 … 15s). The switchpoint or window is defined by the detected
min & max value.
Teach-in instruction
SAFETY WARNINGS:
Before initial operation, please make sure to follow all safety instructions that may be provided in the product
information!
Never use these articles in applications where the safety of a person depends on their functionality.
Enter teach level
-Place a ferromagnetic tool as
shown right or connect teach-in
wire +Vs.
-Green and yellow LED light up, if
tool / teach-in is recognized
properly.
-Remove tool after n seconds for
desired level
A TAP is a short touch of the tool
as shown right.
General information
-5min after power up the teach with tool
will be locked.
-In teach mode the output changes to
0V.
-During operation the teach wire should
be connected to 0V.
-For external teach-in connect the teach
wire to +Vs.
-External teach-in is always possible (no
locking)
-Place tool > 2sec: Leave teach-in
without changes.
