J&M Trail-Blazer TB-6000 User manual

J&M Manufacturing Co, Inc
284 Railroad Street - P.O. Box 547 | Fort Recovery, OH 45846 | Ph: [phone] | Fax: [phone]
www.jm-inc.com
Rev. 5.4.2023
Tr a i l -Blazer
HEADER TRANSPORT
Operator’s Manual
TB-8000Trail-Blazer
HeavyDuty18,500lb.NetCarryingCapacity

3
Table Of Contents
To the Dealer ................................................................................... 4
General Information ............................................................................ 5
Safety Rules .................................................................................... 6
Dimensions & Specications..................................................................... 7
Decals .......................................................................................... 8
Bolt Torque Specications ....................................................................... 9
Stud and Wheel Nut Torque Specications ....................................................... 9
Operations/Maintenance.......................................................................10
Standard Dolly .................................................................................12
Torsion Dolly...................................................................................13
TB-6000 Dolly Hubs ............................................................................14
TB-8000 Dolly Hubs ............................................................................16
TB-6000 Rear Axles.............................................................................18
TB-8000 Rear Axles.............................................................................20
Header Mounts and Tie-Down Assembly........................................................22
Rear Upper Bar Support ........................................................................23
MacDon FD2 Extensions .......................................................................24
Lifting Arms & Props ...........................................................................25
Front Fender...................................................................................26
Fender.........................................................................................27
Upper Bar......................................................................................28
Wire Conduit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Highway Light Bar .............................................................................29
Lights and Wiring on Telescoping Lightbar - Ag, No Brakes ......................................32
Lights and Wiring on Pivoting Lightbar- Ag, No Brakes...........................................33
Lights and Wiring on Telescoping Lightbar - Ag, with Brakes .....................................34
Lights and Wiring on Pivoting Lightbar - Ag, with Brakes ........................................35
Lights and Wiring on Telescoping Lightbar - Highway ...........................................36
Lights and Wiring on Pivoting Lightbar- Highway ...............................................37

4
TO THE DEALER
Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists are completed
before releasing equipment to the owner.
The dealer must complete the Warranty Registration found on the Dealer Portal website located at dealer.jm-inc.com and return it to J&M
Mfg. Co., Inc. at the address indicated on the form. Warranty claims will be denied if the Warranty Registration has not been submitted.
EXPRESS WARRANTY:
J&M Mfg. Co. Inc. warrants against defects in construction or materials for a period of ONE year. We reserve the right to inspect and
decide whether material or construction was faulty or whether abuse or accident voids our guarantee.
Warranty service must be performed by a dealer or service center authorized by J&M Mfg. Co., Inc. to sell and/or service the type of
product involved, which will use only new or remanufactured parts or components furnished by J&M Mfg. Co., Inc. Warranty service will
be performed without charge to the purchaser for parts or labor based on the Warranty Labor Times schedule. Under no circumstance
will allowable labor times extend beyond the maximum hours indicated in the Warranty Labor Times schedule for each warranty
procedure. The purchaser will be responsible, however, for any service call and/or transportation of the product to and from the dealer
or service center’s place of business, for any premium charged for overtime labor requested by the purchaser, and for any service and/or
maintenance not directly related to any defect covered under the warranty. Costs associated with equipment rental, product down time,
or product disposal are not warrantable and will not be accepted under any circumstance.
Each warranty term begins on the date of product delivery to the purchaser. Under no circumstance will warranty be approved unless (i)
the product warranty registration card has been properly completed and submitted to the equipment manufacturer, and (ii) a warranty
authorization number has been issued by the equipment manufacturer. This Warranty is eective only if the warranty registration card is
returned within 30 days of purchase.
This warranty does not cover a component which fails, malfunctions or is damaged as a result of (i) improper modication or repair, (ii)
accident, abuse or improper use, (iii) improper or insucient maintenance, or (iv) normal wear or tear. This warranty does not cover
products that are previously owned and extends solely to the original purchaser of the product. Should the original purchaser sell or
otherwise transfer this product to a third party, this warranty does not transfer to the third party purchaser in any way. J&M Mfg. Co.,
Inc. makes no Warranty, express or implied, with respect to tires or other parts or accessories not manufactured by J&M Mfg. Co., Inc.
Warranties for these items, if any, are provided separately by their respective manufacturers.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS, IMPLIED OR STATUTORY, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE.
In no event shall J&M Mfg. Co., Inc. be liable for special, direct, incidental or consequential damages of any kind. The exclusive remedy
under this Warranty shall be repair or replacement of the defective component at J&M Mfg. Co., Inc’s. option. This is the entire agreement
between J&M Mfg. Co., Inc. and the Owner about warranty and no J&M Mfg. Co., Inc. employee or dealer is authorized to make any
additional warranty on behalf of J&M Mfg. Co., Inc.
The manufacturer reserves the right to make product design and material changes at any time without notice. They shall not incur any
obligation or liability to incorporate such changes and improvements in products previously sold to any customer, nor shall they be
obligated or liable for the replacement of previously sold products with products or parts incorporating such changes.
SERVICE:
The equipment you have purchased has been carefully manufactured to provide dependable and satisfactory use. Like all mechanical
products, it will require cleaning and maintenance. Lubricate the unit as specied. Observe all safety information in this manual and
safety signs on the equipment.
For service, your authorized J&M dealer has trained mechanics, genuine J&M service parts, and the necessary tools and equipment to
handle all your needs.
Use only genuine J&M service parts. Substitute parts may void warranty and may not meet standards required for safety and satisfactory
operation. Record the model number and serial number of your equipment in the spaces provided:
Model No: TB-6000H or TB-8000H Serial No: ________________________ Date of Purchase: ______________________
Purchased From: ________________________________________________________________________________
Provide this information to your dealer to obtain correct repair parts.
To the Dealer

5
General Information
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Safety is a primary concern in the design and manufacture of our products. Unfortunately, our eorts to provide safe equipment can
be erased by an operator’s single careless act. In addition, hazard control and accident prevention are dependent upon the awareness,
concern, judgment, and proper training of personnel involved in the operation, transport, maintenance and storage of equipment.
Make certain that the operator(s), prior to operating is instructed in safe and proper use and reviews and understands the manual(s)
pertaining to this machine. Also make certain that the operator(s) reviews and understands the operator’s manual of the tow vehicle
prior to hooking up or operating the SpeedTender.
Read this manual before you operate this machine. If you do not understand any part of this manual, or need more information, contact
the J&M or your authorized dealer.
Safety Rules Continued on Next Page
SAFETY RULES:
TO THE OWNER:
The purpose of this manual is to assist you in operating and maintaining your header transport in a safe manner. Read it carefully. It
furnishes information and instructions that will help you achieve years of dependable performance and help maintain safe operating
conditions. If this machine is used by an employee or is loaned or rented, make certain that the operator(s), prior to operating:
1. Is instructed in safe and proper use.
2. Reviews and understands the manual(s) pertaining to this machine.
Throughout this manual, the term IMPORTANT is used to indicate that failure to observe can cause damage to equipment. The terms
CAUTION, WARNING and DANGER are used in conjunction with the Safety-Alert Symbol, (a triangle with an exclamation mark), to indicate
the degree of hazard for items of personal safety. When you see this symbol, carefully read the message that follows and be alert to the
possibility of personal injury or death.
DANGER
WARNING
CAUTION
This Safety-Alert symbol indicates a hazard and means
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Indicates an imminently hazardous situation that, if not avoided, will result in death or serious injury.
Indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury,
and includes hazards that are exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate injury.
Indicates that failure to observe can cause damage to equipment.
Indicates helpful information.
IMPORTANT
NOTE

6
Safety Rules
1. Understand that your safety and the safety of other persons are measured by how you service and operate this machine. Know the
positions and functions of all controls before you try to operate them. Check all controls in a safe area before starting your work.
2. The safety information given in this manual does not replace safety codes, federal, state, or local laws. Ensure your machine has the
proper equipment as designated by local laws and regulations.
3. A frequent cause of personal injury or death is from persons falling o equipment and being run over. Do not permit persons to ride
on this machine.
4. Secure safety chain to towing vehicle before transporting. Do not transport without safety chains being attached to tow vehicle.
IMPORTANT: USE ONLY 2-5/16” BALL HITCH TO TRANSPORT UNIT.
5. Use good judgment when transporting on a highway. Always maintain complete control. Regulate speed to road conditions.
WARNING: BE SURE ALL LIGHTS ARE WORKING PROPERLY BEFORE HIGHWAY TRAVEL.
6. Travel speeds should be such that complete control and machine stability is maintained at all times.
7. Where possible, avoid operating near ditches, embankments and holes. Reduce speed when turning, crossing slopes and rough, slick
or muddy surfaces.
8. Make sure that the header is fastened securely to the transport before moving.
9. Make sure that everyone is clear of equipment before applying power or moving the machine. NEVER position yourself under or near
header when mounting on header transport.
10. Never adjust, service, clean or lubricate the header transport until all power is shut o.
11. Ensure the implement is fastened securely to the towing unit.
12. Before unhooking the implement from the towing unit, properly block the wheels to prevent the implement from moving.
13. Never overload the header transport. Overloading the header transport is dangerous and can cause extensive damage.
14. Use caution when transporting. Be alert of the transport unit’s overall width when approaching obstacles, such as post signs and
poles, along the road. Check the transport width of the unit to ensure clearance before entering bridges.
15. COMPLY WITH ALL SAFETY WARNINGS AND CAUTIONS IN THIS MANUAL AND IN THE COMBINE OPERATOR’S MANUAL.

7
Dimensions & Specications
Extra low pro
mount
weldment for
4” x 6” tube
4-1/2” lip
Low pro base
weldment for
4“ x 6” tube and
upper mount
with 4-1/2” lip
High pro base
weldment for
4” x 6”tube and
upper mount
with 4-1/2” lip
26”
0”
4” or 6”
8” or 10”
High Prole
Mount
Standard
Low Prole
Mount
Extra
Low Prole
Mount
Measurement for“Ground to Top of Bar Height” is based on
standard tires and apex of the crown of the bar.
4-Wheel Steer Mount Options
TB-6000-32 TB-6000-38 TB-6000-42 TB-6000-48 TB-8000-32 TB-8000-38 TB-8000-42 TB-8000-48
A45’-6” 46’-8” 53’-9” 59’-9” 45’-6” 46’-8” 53’-9” 59’-9”
B6’-0”
C32’-9”
D2’-10”
E6’-0”
Weight 3800 lbs. 3,890 lbs. 3,950 lbs. 4,160 lbs. 3,850 lbs. 3,940 lbs. 4,000 lbs. 4,215 lbs.
Spindle Size Front (2) 2-1/4” Diameter
Spindle Size Back (4) 2-1/2” Diameter
Wheel Size 16” x 6” - 6 Bolt 16” x 6” - 8 Bolt
Tire Size 235/85R16E 235/85R16F
Steel Upper Bar 4” x 8”
Upper Bar Length 32’ 38’ 42’ 48’ 32’ 38’ 42’ 48’
Arched Main Frame 4” x 8” 1/4”Tubing
Capacity for
Ag
Capacity for
Highway
TB-6000-32 20,224 lbs. 18,040 lbs.
TB-6000-38 20,134 lbs. 17,950 lbs.
TB-6000-42 20,074 lbs. 17,890 lbs.
TB-6000-48 19,864 lbs. 17,680 lbs.
TB-8000-32 22,286 lbs. 19,910 lbs.
TB-8000-38 22,196 lbs. 19,820 lbs.
TB-8000-42 22,136 lbs. 19,760 lbs.
TB-8000-48 21,921 lbs. 19,545 lbs.

8
Decals
Description Part No.
1 HT - Knee Brace Set Up Decal JM0026114
2 Warning, Tire Wheel or Lug Nut Failure Decal JM0014996
3 Warning - Fasten Header Securely To Transport Before Moving Decal JM0039381
4 J&M Oval Decal (Small) 3-5/8” x 5-1/4” JM0015150
5 TB-6000 Decal JM0040063
6 Warning, Always Use Safety Chains Decal JM0014995
7 Warning, Uncoupling Will Cause Trailer Decal JM0058889
8 Warning, Trailer Can Roll Decal JM0014997
9 Warning, Lights Can Prevent Decal JM0058890
1
2
34
6
5
7
8
9
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Replace Immediately If Damaged or Missing

9
Bolt Torque Specications
TIGHTENING WHEEL NUTS: Torque 9/16”-18 lug nuts on wheels to 170 ft-lbs during initial operation of the header wagon. Check
for proper torque after every 10 hours of use. Failure to do so may damage wheel nut seats. Once seats are damaged it will become
impossible to keep nuts tight.
Always tighten hardware to these values unless a dierent torque or tightening procedure is listed for specic application. Fasteners must
always be replaced with the same grade as specied in the manual parts list. Always use the proper tool for tightening hardware. Make
sure fastener threads are clean and you start thread engagement properly. Use these values when tightening all bolts and nuts with
the exception of wheel nuts.
Stud and Wheel Nut Torque Specications
Stud Tightening Torque
1/2”-20 120 ft-lbs
9/16”-18 170 ft-lbs
5/8”-18 350 ft-lbs
3/4”-16 400 ft-lbs
20mm 475 ft-lbs
22mm 640 ft-lbs
Always tighten hardware to these values unless a dierent torque or tightening procedure is listed for specic application. Fasteners must
always be replaced with the same grade as specied in the manual parts list. Always use the proper tool for tightening hardware. Make
sure fastener threads are clean and you start thread engagement properly. Use these values when tightening all studs and wheel
nuts.
SAE Fasteners
Coarse Thread Series
Grade 5 Grade 8
Diameter and Pitch (Inches) Dry Oiled Dry Oiled
1/4”-20 8 ft-lbs 6 ft-lbs 12 ft-lbs 9 ft-lbs
5/16”-18 17 13 25 18
3/8”-16 31 23 44 33
7/16”-14 49 37 70 52
1/2”-13 75 57 106 80
9/16”-12 109 82 154 115
5/8”-11 150 113 212 159
3/4”-10 267 200 376 282
7/8”-9 429 322 606 455
1”-8 644 483 909 681
Fine Thread Series
Diameter and Pitch (Inches) Dry Oiled Dry Oiled
1/4”-28 10 ft-lbs 7 ft-lbs 14 ft-lbs 10 ft-lbs
5/16”-24 19 15 27 20
3/8”-24 35 26 49 37
7/16”-20 55 41 78 58
1/2”-20 85 64 120 90
9/16”-18 121 91 171 128
5/8”-18 170 127 240 180
3/4”-16 297 223 420 315
7/8”-14 474 355 669 502

10
Operations/Maintenance
DANGER: BE CERTAIN THAT ALL POWER IS SHUT OFF BEFORE SERVICING THE HEADER TRANSPORT.
Before the Header Transport is Put into Service:
• Has the Slow-Moving Vehicle sign been properly positioned at the rear of the header transport?
• Have all danger, warning, caution and important signs on the equipment been read and understood? If employees or others use or
are near this equipment, make sure that they also have read and understood all danger, warning, caution and
important signs on the equipment and have also read the operator’s manual.
• Are all braces, bolts, nuts, studs and lug nuts properly fastened?
• Has the header transport been properly fastened to the towing unit? Use a good quality hitch pin with clip and safety chains.
• Are the rear amber extremity lights properly positioned? Extend lights within 16”of the left and right extremities of the header.
Safety Chain User Instructions
• Secure the safety chain by looping it around the tongue support located on the underside of the hitch tongue and connect to the
towing machine’s attaching bar.
• Do not allow more slack than necessary for articulation.
• Do not use an intermediate support as the attaching point.
• Store the safety chain by securing it around the tongue.
• Replace the safety chain if one or more links or end ttings are broken, stretched or otherwise damaged or deformed.
WARNING: Check safety chains for broken, stretched or damaged link or end ttings. Replace chains if found to be
damaged. Do not weld safety chains.
Operating Instructions/Maintenance
• Adjust the brackets on the header transport to best t your make and model header.
Note: When mounting the header, NEVER position yourself under or near the header. Securely fasten the header to the
header transport.
• Do not exceed the load and size limits of the unit.
• Keep the tires properly inated. Both under ination and over ination can greatly reduce tire life. Inate 235-85 R16 tires to 80 psi.
• Inspect bracing and welds periodically and repair immediately, if needed. Failure to repair could cause extensive damage and
greatly reduce the life of the unit.
• Repack the bearings in the hub assembly once a year or as needed. Use a good quality LS EP2 severe duty, high shock load, lithium-
based grease.
• Grease the ball using the zerk on the front gooseneck assembly every 8 hours or as needed.
• Check the wheel nuts often and keep them properly tightened.
Braking System Requirements
• Stopping distance increases with speed and weight of towed loads and on slopes. Towed loads with or without brakes that are too
heavy for the tractor or are towed too fast can cause loss of control. Consider the total weight of the equipment and its load.
Note: Observe these recommended maximum road speeds, or local speed limits which may be lower.
• If towed equipment does not have brakes, do not travel more than 20 mph (32 km/h) and do not tow loads more than 1.5 times the
tractor weight.
• If towed equipment does have brakes, do not travel more than 25 mph (40 km/h) and do not tow loads more than 4.5 times the
tractor weight.
• Ensure the load does not exceed the recommended weight ratio. Use additional caution when towing loads under adverse surface
conditions, when turning, and on inclines.
DANGER: Tow loads safely.

11
This page intentionally left blank.

12
Standard Dolly
16
15
17
14
13
10
9
11
8
12
3
1
7
2
456
Description Part No.
1 Trail-Blazer Inner Tongue Pintle Hitch Assembly JM0075569
2 Torsion Flex Trail-Blazer Inner Tongue Ball Hitch JM0028697
3 Torsion Flex Trail-Blazer Inner Tongue Clevis JM0030636
4 .625-11 x 4.5 G8 Zinc Finish hex bolt JM0075570
5 Lunette Eye (30,000# 3”Forged Eye) JM0015884
6 5/8”-11 Gr2 Z Centerlock Hex Nut JM0002146
7 Trail-Blazer Inner Tongue Pintle Hitch Weldment JM0075567
8 Compression Spring (1” x 1-3/4”) for Door Assembly & Tongue Latch JM0001688
9Flapper Weldment (10T) JM0030414
10 1”x 5-3/4” Flapper Pivot Shaft (LS-610) JM0027732
11 Spacer Blocks, 2-1/2”, 6-15 Ton (SB-212) JM0003032
12 1/4” x 1-3/8” Roll Pin JM0009896
13 1/2”x 7” Lynch Pin JM0030476
14 Trail-Blazer - Outer Hitch Tongue Weldment JM0077195
15 1/2”-13 x 4-1/2”Gr5 Z Hex Bolt JM0008548
16 1/2”-13 Gr2 Z Hex Nut JM0002124
17 2-1/4”Double Ended Spindle - Trail-Blazer Dolly JM0030465
18 3/4”-10 Gr2 Z Centerlock Hex Nut JM0002147
19 3/4”-10 x 6”Gr8 Z Hex Bolt JM0037185
20 Safety Chain 34” (12,600 lb) JM0078441
19
18
20

13
Torsion Dolly
1
17
16
15
8
9
13
12
11
14
10
24
21
19 20
22 23
18
3
7
2
456
Description Part No.
1 Trail-Blazer Inner Tongue Pintle Hitch Assembly JM0075569
2 Torsion Flex Trail-Blazer Inner Tongue Ball Hitch JM0028697
3 Torsion Flex Trail-Blazer Inner Tongue Clevis JM0030636
4 .625-11 x 4.5 G8 Zinc Finish hex bolt JM0075570
5 Lunette Eye (30,000# 3”Forged Eye) JM0015884
6 5/8”-11 Gr2 Z Centerlock Hex Nut JM0002146
7 Trail-Blazer Inner Tongue Pintle Hitch Weldment JM0075567
8 1-1/4”-12 PN Gr2 Hex Jam Nut JM0001606
9 1-1/4”ID x 2-1/2” OD x 1/8” Z Flat Washer JM0020322
10 Large Tongue Spring 3/8” x 2” x 12-1/2” (GDP) TS-615H JM0014200
11 2”ID x 2-3/8” OD x 1” LG Bronze Bushing (EB-2) JM0027653
12 1/8”NPT Male x 11/16” Straight Grease Fitting JM0009756
13 Trail Blazer Front Torsion Axle Fixed Spool JM0060638
14 6-1/2”x 1-1/4” King Pin Weldment (TB-1082) JM0003036
15 1/2”-13 Gr2 Z Centerlock Hex Nut JM0001511
16 Trail-Blazer Kingpin Locking Ring JM0068859
17 1/2”-13 x 3-1/2”Gr5 Z Hex Bolt JM0009914
18 Compression Spring (1” x 1-3/4”) for Door Assembly & Tongue Latch JM0001688
19 1”x 5-3/4” Flapper Pivot Shaft (LS-610) JM0027732
20 Spacer Blocks, 2-1/2”, 6-15 Ton (SB-212) JM0003032
21 1/4” x 1-3/8” Roll Pin JM0009896
22 1/2”x 7” Lynch Pin JM0030476
23 Flapper Weldment (10T) JM0030414
24 Trail-Blazer - Outer Hitch Tongue Weldment JM0061239

14
3
12
78910
45
11
6
12
21 22 23
21 22 23
21 22 23
TB-6000 Dolly Hubs
12
78
3
910
413
16 17
14 15
18
1
19
2
720 910
413
16 17
14 15
Standard Dolly - No Brakes
Torsion Dolly - No Brakes
Torsion Dolly - Brakes

15
TB-6000 Dolly Hubs
Description Part No.
1 2-1/4”ID Grease Seal (010-036-00) JM0035951
2 Tapered Bearing Cone 25580, 12 Ton JM0018104
3 6k Non-Brake Hub with Inner Outer Races, Studs, and Lug Nuts JM0082504
4 Bearing Cone (15123) JM0019551
5 Spindle Washer (1-1/8”ID, 2”OD, 1/8”) (7k Lb Axle) JM0039543
6 Cotter Pin 1/8”x 1-3/4” JM0039545
7 Cup, Large Inner, 12 Ton, 25520 JM0018102
8 007-122-00, Bolt Press-In, 1/2-20 UNF JM0082456
9 1/2”-20 Lug Nut, 6-8 Ton (5552) JM0003062
10 Race, Outer 15245 (5.2k axle) JM0019548
11 1”-14 Castle Nut JM0035956
12 021-001-00, Grease Cap JM0082423
13 D Washer (1” ID) JM0039578
14 Dust Cap for EZ Grease (5,200lb) JM0039577
15 E-Z Lube Rubber Plug JM0035958
16 Special 1”Jam Nut for 5.2k, 7k Axles JM0035955
17 Spring Steel Retaining Clip JM0051458
18 7K Brake Drum Assembly Right Hand JM0035974
18 7K Brake Drum Assembly Left Hand JM0035973
19 6k Brake Hub with Inner Outer Races, Studs, and Lug Nuts JM0082507
20 1/2”-20 x 2-13/20”Stud JM0039598
21 235-85-R16 Load Range E Tire JM0003232
22 Wheel Rim, 6 Hole, 16”x 6” (16x6-6) JM0030432
23 Wheel & Tire 235-85-R16 Loade Range E - 6 Bolt JM0030433

16
3
12
78910
45
11
6
12
3
12
7 8 9 10
413
16 17
14 15
18
1
2
7
19
8 9 10
413
16 17
15
14
22
20 21
Standard Dolly - No Brakes
Torsion Dolly - No Brakes
Torsion Dolly - Brakes
TB-8000 Dolly Hubs

17
Description Part No.
1 2-1/4”ID Grease Seal (010-036-00) JM0035951
2 Tapered Bearing Cone 25580, 12 Ton JM0018104
3 7k Idler Hub with Studs, Nuts & Races JM0058743
4 14125A Roller Bearing JM0039542
5 Spindle Washer (1-1/8”ID, 2”OD, 1/8”) (7k Lb Axle) JM0039543
6 Cotter Pin 1/8”x 1-3/4” JM0039545
7 Cup, Large Inner, 12 Ton, 25520 JM0018102
8 9/16”x 2-1/2” Stud Silver (WB-41L) JM0037503
9 9/16”-18 Conical Lugnut (4WS) (ST) JM0008525
10 Bearing Cup for Superior Gearbox (14-20”) (414276) JM0025077
11 1”-14 Castle Nut JM0035956
12 Grease Cap (Solid) for 7k Idler Hub JM0058750
13 Spindle washer JM0060784
14 Dust Cap for EZ Grease JM0035957
15 E-Z Lube Rubber Plug JM0035958
16 Special 1”Jam Nut for 5.2k, 7k Axles JM0035955
17 Spring Steel Retaining Clip JM0051458
18 7K Brake Drum Assembly Left Hand JM0035973
18 7K Brake Drum Assembly Right Hand JM0035974
19 7K Hub/Drum w/ Races, Studs, and Lug Nuts JM0041461
20 235-85-R16 Tire Load Range (F) JM0016649
21 Wheel Rim, 8 Hole, 16”x 6” (16x6-8) JM0003233
22 Wheel & Tire (235-85-R16 F Series Tire and 16x6-8 Hole Wheel Rim) JM0016650
TB-8000 Dolly Hubs

18
13
2
7810
9
45
11
6
12
14 15 16
TB-6000 Rear Axles
13
1
2
20
7
19
18
910
4
11 12
56
17
Rear Axle No Brakes
Rear Axle with Brakes

19
TB-6000 Rear Axles
Description Part No.
1 2-1/4”ID Grease Seal (010-036-00) JM0035951
2 Tapered Bearing Cone 25580, 12 Ton JM0018104
3 6k Non-Brake Hub with Inner Outer Races, Studs, and Lug Nuts JM0082504
4 Bearing Cone (15123) JM0019551
5 Spindle D Washer Used For: 5.2K Axle JM0039578
6 Spring Steel Retaining Clip JM0051458
7 Cup, Large Inner, 12 Ton, 25520 JM0018102
8 007-122-00, Bolt Press-In, 1/2-20 UNF JM0082456
9 1/2”-20 Lug Nut, 6-8 Ton (5552) JM0003062
10 Race, Outer 15245 (5.2k axle) JM0019548
11 Special 1”Jam Nut for 5.2k, 7k Axles JM0035955
12 021-001-00, Grease Cap JM0082423
13 A1448211 6k without Brakes JM0077771
14 235-85-R16 Load Range E Tire JM0003232
15 Wheel Rim, 6 Hole, 16”x 6” (16x6-6) JM0030432
16 Wheel & Tire 235-85-R16 Loade Range E - 6 Bolt JM0030433
17 E-2023-17 6k with Brakes JM0077773
18 12 X 2 LH Electric Nev-R-Adjust 6,000 lbs. CSA JM0060760
18 12 X 2 RH Electric Nev-R-Adjust 6,000 lbs. CSA JM0060770
19 6k Brake Hub with Inner Outer Races, Studs, and Lug Nuts JM0082507
20 1/2”-20 x 2-13/20”Stud JM0039598

20
3
12
7 8 9 10
5
4
11
6
1312
14 20
18 19
16
1
17
2
7 8 9 10
45
11
6
1312
15
Rear Axle No Brakes
Rear Axle with Brakes
TB-8000 Rear Axles
