Talc Applicator
Installation Kit
Hydraulic Talc
Manual
Serial Number 206270 and Higher

2

3
Table of Contents
4....................................................................................To the Dealer
5.............................................................................General Information
5............................................................................... Bolt Torque Chart
6.....................................................................................Safety Rules
7....................................................................... Talc Box Mount Assembly
8.........................................................................Flex Flighting Assembly
9................................................................. Attaching Motor and Door Skirt
10 ........................................................................Talc PVC Tube Assembly
11 ..................................................................Assembly for Aluminum Valve
13 ............................................................Assembly For Black Intercomp Valve
14 ........................Hydraulic Schematic and Repair Parts for Black Intercomp Valve with Talc
15 ........................Hydraulic Schematic and Repair Parts for Aluminum Valve Bank with Talc
16 .................................................................... Talc Parts for LC 290, LC 390
18 .............................................................. Talc Parts for LC 535 SpeedTender
20 .............................................................................Talc Parts for c4•50

4
Read manual instructions and safety rules. Make sure all items on the Dealer’s Pre-Delivery and Delivery Check Lists are completed
before releasing equipment to the owner.
The dealer must complete the Warranty Registration found on the Dealer Portal website located at dealer.jm-inc.com and return it to J&M
Mfg. Co., Inc. at the address indicated on the form. Warranty claims will be denied if the Warranty Registration has not been submitted.
EXPRESS WARRANTY:
J&M Mfg. Co., Inc. warrants against defects in construction or materials for a period of ONE year. We reserve the right to inspect and
decide whether material or construction was faulty or whether abuse or accident voids our guarantee.
Warranty service must be performed by a dealer or service center authorized by J&M Mfg. Co., Inc. to sell and/or service the type of
product involved, which will use only new or remanufactured parts or components furnished by J&M Mfg. Co., Inc. Warranty service will
be performed without charge to the purchaser for parts or labor based on the Warranty Labor Times schedule. Under no circumstance
will allowable labor times extend beyond the maximum hours indicated in the Warranty Labor Times schedule for each warranty
procedure. The purchaser will be responsible, however, for any service call and/or transportation of the product to and from the dealer
or service center’s place of business, for any premium charged for overtime labor requested by the purchaser, and for any service and/or
maintenance not directly related to any defect covered under the warranty. Costs associated with equipment rental, product down time,
or product disposal are not warrantable and will not be accepted under any circumstance.
Each Warranty term begins on the date of product delivery to the purchaser. Under no circumstance will warranty be approved unless (i)
the product warranty registration card has been properly completed and submitted to the equipment manufacturer, and (ii) a warranty
authorization number has been issued by the equipment manufacturer. This Warranty is eective only if the warranty registration card is
returned within 30 days of purchase.
This Warranty does not cover a component which fails, malfunctions or is damaged as a result of (i) improper modication or repair, (ii)
accident, abuse or improper use, (iii) improper or insucient maintenance, or (iv) normal wear or tear. This Warranty does not cover
products that are previously owned and extends solely to the original purchaser of the product. Should the original purchaser sell or
otherwise transfer this product to a third party, this Warranty does not transfer to the third party purchaser in any way. J&M Mfg. Co.,
Inc. makes no Warranty, express or implied, with respect to tires or other parts or accessories not manufactured by J&M Mfg. Co., Inc.
Warranties for these items, if any, are provided separately by their respective manufacturers.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES OR CONDITIONS, EXPRESS, IMPLIED OR STATUTORY, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR PARTICULAR PURPOSE.
In no event shall J&M Mfg. Co., Inc. be liable for special, direct, incidental or consequential damages of any kind. The exclusive remedy
under this Warranty shall be repair or replacement of the defective component at J&M Mfg. Co., Inc’s. option. This is the entire agreement
between J&M Mfg. Co., Inc. and the Owner about warranty and no J&M Mfg. Co., Inc. employee or dealer is authorized to make any
additional warranty on behalf of J&M Mfg. Co., Inc.
The manufacturer reserves the right to make product design and material changes at any time without notice. They shall not incur any
obligation or liability to incorporate such changes and improvements in products previously sold to any customer, nor shall they be
obligated or liable for the replacement of previously sold products with products or parts incorporating such changes.
SERVICE:
The equipment you have purchased has been carefully manufactured to provide dependable and satisfactory use. Like all mechanical
products, it will require cleaning and maintenance. Lubricate the unit as specied. Observe all safety information in this manual and
safety signs on the equipment.
For service, your authorized J&M dealer has trained mechanics, genuine J&M service parts, and the necessary tools and equipment to
handle all your needs.
Use only genuine J&M service parts. Substitute parts may void warranty and may not meet standards required for safety and satisfactory
operation. Record the model number and serial number of your equipment in the spaces provided:
Model No:_____________________ Serial No: ________________________ Date of Purchase: ___________________
Purchased From: ________________________________________________________________________________
Provide this information to your dealer to obtain correct repair parts.
To the Dealer

5
TO THE OWNER:
The purpose of this manual is to assist you in operating and maintaining your Talc Applicator in a safe manner. Read it
carefully. It furnishes information and instructions that will help you achieve years of dependable performance and help
maintain safe operating conditions. If this machine is used by an employee or is loaned or rented, make certain that the
operator(s), prior to operating:
1. Is instructed in safe and proper use.
2. Reviews and understands the manual(s) pertaining to this machine.
Throughout this manual, the term IMPORTANT is used to indicate that failure to observe can cause damage to equipment.
The terms CAUTION, WARNING and DANGER are used in conjunction with the Safety-Alert Symbol (a triangle with an
exclamation mark) to indicate the degree of hazard for items of personal safety. When you see this symbol, carefully read
the message that follows and be alert to the possibility of personal injury or death.
This Safety-Alert symbol indicates a hazard and means
ATTENTION! BECOMEALERT! YOUR SAFETY IS INVOLVED!
Indicates an imminently hazardous situation that, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous situation that, if not avoided,
will result in death or serious injury, and includes hazards that are
exposed when guards are removed.
Indicates a potentially hazardous situation that, if not avoided, may
result in minor or moderate injury.
Indicates that failure to observe can cause damage to equipment.
Indicates helpful information.
DANGER
WARNING
CAUTION
IMPORTANT
NOTE
General Information
Coarse Thread Series
Grade 5 Grade 8
Diameter and Pitch (Inches) Dry Oiled Dry Oiled
1/4”-20 8 ft-lbs 6 ft-lbs 12 ft-lbs 9 ft-lbs
5/16”-18 17 13 25 18
3/8”-16 30 23 45 35
7/16”-14 50 35 70 55
1/2”-13 75 55 110 80
9/16”-12 110 80 150 110
5/8”-11 150 110 220 170
3/4”-10 260 200 380 280
7/8”-9 430 320 600 460
1”-8 640 480 900 680
Fine Thread Series
Diameter and Pitch (Inches) Clamp Load (Lbs.) Tightening Torque Clamp Load (Lbs.) Tightening Torque
1/4”-28 10 ft-lbs 7 ft-lbs 14 ft-lbs 10 ft-lbs
5/16”-24 19 14 29 20
3/8”-24 35 25 50 40
7/16”-20 55 40 80 60
1/2”-20 90 65 120 90
9/16”-18 120 90 170 130
5/8”-18 180 130 240 180
3/4”-16 300 220 420 320
7/8”-14 470 360 660 500
SAE Fasteners
Always tighten hardware to these values unless a dierent torque or tightening procedure is listed for specic application. Fasteners must
always be replaced with the same grade as specied in the manual parts list. Always use the proper tool for tightening hardware. Make
sure fastener threads are clean and you start thread engagement properly. Use these values when tightening all bolts and nuts with
the exception of wheel nuts.
Bolt Torque Chart

6
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
Safety is a primary concern in the design and manufacture of our products. Unfortunately, our eorts to provide safe equipment can
be erased by an operator’s single careless act. In addition, hazard control and accident prevention are dependent upon the awareness,
concern, judgment, and proper training of personnel involved in the operation, transport, maintenance and storage of equipment.
Prior to operating, ensure the operator(s) is instructed in safe and proper use and reviews and understands the manual(s) pertaining to
this machine.
Read this manual before you operate this machine. If you do not understand any part of this manual, or need more information, contact
J&M or your authorized dealer.
SAFETY
Understand that your safety and the safety of other persons is measured by how you service and operate this machine. Know the
positions and functions of all controls before you operate them. Check all controls in a safe area before starting your work.
The safety information given in this manual does not replace safety codes, federal, state or local laws. Make certain your machine has the
proper equipment as designated by local laws and regulations.
• Relieve all pressure, before disconnecting uid lines.
• Before applying pressure, make sure all connections are tight and components are in good condition.
• Never use your hand to check for suspected leaks under pressure. Use a piece of cardboard or wood for this purpose.
• If injured by leaking uid, see your doctor immediately.
• Keep clear of moving parts at all times when operating the talc unit.
• Be sure all safety shields are in place before operation.
Ensure everyone is clear of equipment before applying power or moving the machine.
Place decal on talc box side
most visible to the user.
DECALS
Safety Rules

7
STEP ONE - LC 290 & LC 390
• Bolt the LC 290/LC 390 talc box mounting bracket (JM0037272) to the SpeedTender’s front passenger side leg using two 3/8”x 1” ange
bolt and 3/8”ange nuts. Hand tighten fasteners.
• Fasten the talc box (JM0037538) and talc rotation bracket (JM0038395) onto the LC 290/LC 390 talc box mounting bracket. Hand tighten
fasteners.
STEP ONE - LC 535
• Bolt the LC 535 talc box mounting bracket (JM0037641) to the SpeedTender’s rear driver side leg using ve 3/8”x 1”ange screws and
3/8”ange nuts. Hand tighten fasteners.
• Fasten the talc box (JM0037538) and talc rotation bracket (JM0038395) onto the LC 535 talc box mounting bracket. Hand tighten fasteners.
Talc Box Mount Assembly

8
STEP TWO - All Models
• Insert the ex ighting weldment (LC 390-JM0042587, LC 290-JM0042838, SpeedTender Pro c4·50/LC535-JM0043060) into the talc
box and ensure the nylon washer is seated rmly against the side of the box and the ighting weldment sprocket is meshed with the
agitator sprocket.
Flighting
Flighting Shaft
Sprocket
Flex Flighting Assembly
STEP ONE - SpeedTender Pro c4·50
• Bolt the SpeedTender Pro c4·50 talc box mounting bracket (JM0037645) to the SpeedTender’s front passenger side leg using four 3/8” x 1”
ange screws and 3/8”ange nuts. Hand tighten fasteners.
• Fasten the talc box (JM0037538) to the SpeedTender Pro c4·50 talc box mounting bracket.

9
STEP THREE - All models
• Align the motor shaft key with the keyway in the exible ighting.
• Attach the hydraulic motor (JM0042491) to the talc box using the three 1/4”-28 x 3/8”hex bolts and tighten.
• Install and tighten the 10-32 x 1/4”Cup-Point Set Screw once the motor is in place.
STEP FOUR - All models
• Tap the ighting with a hammer to conrm that the ighting washer is properly seated. Tighten the set screw on the hydraulic mo-
tor shaft.
STEP FIVE - (Skip this step for LC 535 units)
• Remove the rubber door skirt (below doors) from the SpeedTender and fasten the talc spout bracket (JM0042542) and talc rubber door
skirt (JM0042688) to the bottom of the SpeedTender door. Hand tighten fasteners.
Talc Spout Bracket
Rubber Skirt
Attaching Motor and Door Skirt
1/4"-20 x 3/4" Gr5 Z SF Hex Bolt
1/4"-28 x 3/8" Gr5 Z Hex Bolt
1/4"-20 Gr5 Z SF Hex Nut
Install and tighten the 10-32 x
1/4” Cup-Point Set Screw once
the motor is in place.

10
STEP SIX - LC 290, LC 390 & SpeedTender Pro c4·50
• Attach the talc ighting PVC tube (LC 390 - JM0042810, LC 290 - JM0042809, SpeedTender Pro c4·50 - JM0043049) over the ghting with
the 2”exhaust clamp. (JM0037668)
• Before tightening the 2” exhaust clamp, insert the talc ghting PVC tube spout into the talc spout bracket. Ensure the talc box is
oriented so the talc ighting PVC tube is in line with the talc box pipe (as shown below). Tighten the 2”exhaust clamp. Tighten all
fasteners.
STEP SIX - LC 535
• Attach the talc ighting PVC tube (LC 535-JM0043049) over the ghting with the 2”exhaust clamp.
• Before tightening the 2” exhaust clamp ensure the talc box is oriented so the talc ighting PVC tube is in line with the talc box pipe
(shown below) and the spout is hanging over the conveyor hopper inlet. Tighten the 2”exhaust clamp. Tighten all fasteners.
• Use the 2”pipe loop clamp (JM0043498), 3/8”x 1”ange bolt and 3/8” ange nut to fasten the talc ighting PVC tube to the LC 535 tank.
2”Pipe Loop Clamp
Talc PVC Tube Assembly

11
STEP SEVEN - All models
• Mount the ow control valve (JM0026104) using the ow control mounting bracket (LC 290/LC 390/SpeedTender Pro c4·50-JM0043097,
LC 535-JM0025400). Mount in the location shown below by removing the scale box bolts. Remove and attach one bolt at a time to keep
the scale box secure.
STEP EIGHT - All models
• Bolt the ow control valve (JM0026104) to the ow control mounting bracket using (2) 1/4”x 2” hex bolts and (2) 1/4” lock nuts.
• Assemble the ttings to the ow control valve as shown below. Apply Teon tape to pipe thread before assembly.
Pipe threads
Pipe threads
Assembly for Aluminum Valve
If you have a Black Intercomp Valve go to “Assembly For Black Intercomp Valve” on page 13.
If you have an Aluminum Valve, continue with the following instructions:

12
STEP NINE - All models
• Route the talc motor hydraulic hoses (JM0042861) through the conduits on the trailer as shown below. Tighten the hoses to the ow
control valve and hydraulic talc motor.
STEP TEN - All models
• Remove the conveyor motor return hose from the conveyor return port on the seed tender valve bank and attach the 20”supply hose
(JM0042862) to the conveyor motor return hose and to the“IN” port elbow on the ow control valve. See“Hydraulic Schematic and
Repair Parts for Aluminum Valve Bank with Talc”on page 15.
STEP ELEVEN - All models
• Attach the 30”return hose (JM0042863) to the“EX”port elbow on the ow control valve and the“Conveyor Return”port on the SpeedTender
valve bank. See“Hydraulic Schematic and Repair Parts for Aluminum Valve Bank with Talc”on page 15.
Seth
LC 290/LC 390 SpeedTender Pro c4·50
Hoses go straight to valve bank.
Assembly for Aluminum Valve

13
Assembly For Black Intercomp Valve
Talc Hydraulic
Motor
Black Intercomp
Valve Bank
Black Intercomp
Valve Talc Bank
The black intercomp valve bank is
shown on the left.
STEP SEVEN- All models
• Remove the two 90° hydraulic
ttings on the right side shown
on the left.
STEP EIGHT - All models
• Add the black intercomp valve
talc bank using the two o-rings
and three bolts to secure it to the
main valve bank.
STEP NINE - All models
• Add the two 90° hydraulic
ttings into the side of the black
intercomp valve talc bank. Insert
the ttings (coming out of the
front of the bank shown on the
left) to the valve bank. Connect
the hoses and run them to the
talc hydraulic motor. Be sure to
tighten all fasteners.
NOTE: Route the hoses as shown in
image on page 12.

14
Hydraulic Schematic and Repair Parts for Black Intercomp Valve with Talc
4
4
2
13
7
8
10
9
6
5
13 1412
11
Description Part No.
1 3/8” Male JIC x 3/8” Male ORB; Extra Long 90 Degree Elbow (6801-LL-06-06) JM0039050
2 3/8” Male JIC x 3/8” Male ORB; 90 Degree Elbow JM0026121
3 White Drive Hydraulic Motor - 125032JL5C3AAAAA JM0042491
4 1/4” x 84” Hydraulic Hose 84inch4M3K-4G-6FJX-4G-6FJX JM0051419
5 3/8” Male JIC x 3/8” Male ORB; Straight JM0043614
6 Intercomp Talc Block Assembly (FA/VBBA-TA) JM0051361
7 3/8” Male ORB x 3/8” Female ORB; Straight Reducer JM0039051
8 1/2” Male JIC x 3/4” Male NPT; 90 Degree Elbow JM0033775
9 5/16”-18 x 3-1/2” Socket Head Cap Screw JM0051418
10 1/2” Male JIC x 1/2” Male ORB; Extra Long 90 Degree Elbow (6801-LL-08-08) JM0046935
11 Talc O-Ring (FA/VBBA-TA) JM0051416
12 Talc Coil/Solenoid (FA/VBBA-TA) JM0051412
13 Talc Cartridge Proportional (FA/VBBA-TA) JM0051413
14 Talc Pressure Relief Valve (FA/VBBA-TA) JM0051415

15
Hydraulic Schematic and Repair Parts for Aluminum Valve Bank with Talc
8
12
10
6
5
2
3
1
7
9
4
11
4
13
13
11
c4•50 Model
Conveyor
Return Hose
To Conveyor
Return Hose
Aluminum
Valve Bank
Hydraulic
Motor
Flow Control
Description Part No.
1 3/8” Male JIC x 3/8” Male O-ring; Extra Long 90 Degree Elbow (6801-LL-06-06) JM0039050
2 3/8” Male JIC x 3/8” Male O-ring; 90 Degree Elbow (6801-06-06-NWO) JM0026121
3 White Drive Hydraulic Motor - 125032JL5C3AAAAA JM0042491
4 1/4” x 116” Hydraulic Hose 116inch4M3K-4G-6FJX-4G-6FJX JM0042861
5 5 Function Aluminum Manifold Valve Block JM0029973
6 1/2” Female JIC x 3/8”Male JIC Reducer (2406-08-06) JM0026117
7 3/8” Male JIC x 1/2” Male NPT; 90 Degree Elbow (2501-06-08) JM0042849
8 Flow Control Talc Applicator FC51 - .5 (0-2 GPM) JM0026104
9 1/2” Male JIC x 1/2” Male NPT x 1/2” Male JIC Tee (2605-08-08-08) JM0026119
10 1/2” Male JIC x 1/2” Female JIC Swivel; 90 Degree Elbow (6500-08-08) JM0010296
11 1/2” x 30”Hydraulic Hose 30inch8M3K-8G-8FJX-8G-8FJX JM0042863
12 1/2” Male JIC x 1/2” Male NPT; 90 Degree Elbow (2501-08-08) JM0042847
13 1/2” x 20”Hydraulic Hose 20inch8M3K-8G-8MJ-8G-8FJX JM0042862

16
Talc Parts for LC 290, LC 390
22
23
24
2515 2926 2827
9
11 101251314
16
6
5
8
7
3
2
15
17
18
4
20
1
19
21

17
Talc Parts for LC 290, LC 390
Description Part No.
1 3/16” Nylon Rod for Talc Agitator JM0062689
2 3/4” Shoulder Dia x 1” Shoulder Length x 5/8”-11 Hex Head Shoulder Bolt and Nut (SB-34) JM0003181
3 3/4” ID x 7/8” OD x 5/8” LG Bronze Bushing (BB-34) JM0009455
4 Large Talc Box Screen (Electric & Hydraulic Motor) JM0037456
5 3/4” USS Z Flat Washer JM0010006
6 5/8”-18 Gr5 Z SF Hex Nut JM0043101
7 Large Agitator 17 Deg. (Electric & Hydraulic Motor) JM0037241
8 17 Deg. Talc Box Weldment (Electric & Hydraulic Motor) JM0037538
9 White Drive Hydraulic Motor - 125032JL5C3AAAAA JM0042491
10 1/4”-20 x 3/4” Gr5 Z SF Hex Bolt JM0001642
11 Flange Plate for Talc Hydraulic Motor JM0059070
12 1/4”-28 x 3/8” Gr5 Z Hex Bolt JM0043100
13 390 Flex Auger Flighting Weldment JM0042587
14 1/4”-20 Gr5 Z SF Hex Nut JM0001630
15 3/8”-16 Gr5 Z SF Hex Nut JM0002152
16 3/8”-16 x 2” Gr5 Z SF Hex Bolt JM0016070
17 2” Exhaust Clamp with Fasteners (Electric & Hydraulic Motor) JM0037668
18 17 Deg. Talc Box Door (Electric & Hydraulic Motor) JM0037237
19 Chrome T-Handle Non-Locking JM0001911
20 1/2” Shoulder Dia x 3/8” Shoulder Length x 3/8”-16 Socket Shoulder Bolt JM0009998
21 10-32 x 1/4” Cup-Point Set Screw JM0076511
22 SpeedTender Rubber Door Skirt for Standard and Talc JM0048679
23 Hydraulic Talc Spout Door Bracket JM0042542
24 390 Flex Auger Heat Bent PVC Pipe JM0042810
25 3/8”-16 x 1” Gr5 Z SF Hex Bolt JM0002092
26 Talc Mounting Bracket Weldment (Electric & Hydraulic Motor) JM0037272
27 1/2”-13 x 1” Gr5 Z Hex Bolt JM0010225
28 1/2”-13 Gr2 Z Hex Nut JM0002124
29 Talc Rotation Bracket Weldment (Electric & Hydraulic Motor) JM0038395
30 1/4”-20 x 2-1/2” Gr5 Z Hex Bolt JM0001506
31 1/4”-20 Gr5 Z Centerlock Hex Nut JM0001505
32 Hydraulic Talc Flow Control Mounting Bracket JM0043097
31
32
30
Hydraulic Valve
Mount

18
9
11 101251314
16
6
5
8
7
3
2
15
17
18
4
20
1
19
2322
2825 26 2724
29 3130
Talc Parts for LC 535 SpeedTender
21

19
Description Part No.
1 3/16” Nylon Rod for Talc Agitator JM0062689
2 3/4” Shoulder Dia x 1” Shoulder Length x 5/8”-11 Hex Head Shoulder Bolt and Nut (SB-34) JM0003181
3 3/4” ID x 7/8” OD x 5/8” LG Bronze Bushing (BB-34) JM0009455
4 Large Talc Box Screen (Electric & Hydraulic Motor) JM0037456
5 3/4” USS Z Flat Washer JM0010006
6 5/8”-18 Gr5 Z SF Hex Nut JM0043101
7 Large Agitator 17 Deg. (Electric & Hydraulic Motor) JM0037241
8 17 Deg. Talc Box Weldment (Electric & Hydraulic Motor) JM0037538
9 White Drive Hydraulic Motor - 125032JL5C3AAAAA JM0042491
10 1/4”-20 x 3/4”Gr5 Z SF Hex Bolt JM0001642
11 Flange Plate for Talc Hydraulic Motor JM0059070
12 1/4”-28 x 3/8”Gr5 Z Hex Bolt JM0043100
13 9/16” USS Flat Washer JM0050968
14 390 Flex Auger Flighting Weldment JM0042587
15 1/4”-20 Gr5 Z SF Hex Nut JM0001630
16 3/8”-16 Gr5 Z SF Hex Nut JM0002152
17 3/8”-16 x 2”Gr5 Z SF Hex Bolt JM0016070
18 2”Exhaust Clamp with Fasteners (Electric & Hydraulic Motor) JM0037668
19 17 Deg. Talc Box Door (Electric & Hydraulic Motor) JM0037237
20 Chrome T-Handle Non-Locking JM0001911
21 3/8”ID, 1” OD Z Flat Washer JM0003061
22 1/2”Shoulder Dia x 3/8” Shoulder Length x 3/8”-16 Socket Shoulder Bolt JM0009998
23 2”Pipe Loop Clamp JM0043498
24 535/C4-50 Flex Auger Heat Bent PVC Pipe JM0043049
25 3/8”-16 x 1”Gr5 Z SF Hex Bolt JM0002092
26 Talc Rotation Bracket Weldment (Electric & Hydraulic Motor) JM0038395
27 1/2”-13 Gr2 Z Hex Nut JM0002124
28 1/2”-13 x 1”Gr5 Z Hex Bolt JM0010225
29 510, 535 Talc Mounting Bracket Weldment (Chain and Hydraulic) JM0037641
30 1/4”-20 x 2-1/2”Gr5 Z Hex Bolt JM0001506
31 1/4”-20 Gr5 Z Centerlock Hex Nut JM0001505
32 535 Bolt on Plate Talc Valve JM0025400
Talc Parts for LC 535 SpeedTender

20
Talc Parts for c4•50
9
11 101251314
16
6
5
8
7
3
2
15
17
18
4
20
1
19
22
23
24
26
15
25
28
29
27
Hydraulic Valve
Mount
21
