jbc DIU User manual

DIU
1-Tool Control Unit
INSTRUCTION MANUAL

Screen
Menu
Buttons Main Switch
DIU Control Unit ........... 1 unit Manual ...............................1 unit
Ref. 0027025
Packing List
The following items are included:
This manual corresponds to the following references:
DI-9D (100V)
DI-1D (120V )
DI-2D (230V)
Power Cord .................... 1 unit
Ref. 0024092 (100V)
0023715 (120V)
0023714 (230V)
Features
For a basic working system, 1 control unit + 1 stand + 1 tool and 1 cartridge are needed.
USB-B connector
(at front lateral)
Equipotential
connection
Power Socket
Fuse
To Peripherals
To Stand
2

ADS
Stand for
T210 & T245
Handles
T245
General Purpose
Handle
Stand Cable
Ref. 0024227
Connection Example - General Purpose Handle
DIU 1-Tool Control Unit
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

Connection Example - Desoldering Iron
DIU 1-Tool Control Unit
Stand Cable
Ref. 0024227
DRS
Stand for
DR560
Desoldering
Iron
DR560
Desoldering Iron Module Cable
Ref. 0024228
MSE
Electric Desoldering
Module for DDU & DMU
Suction Filter Ref. 0821830
To another Peripheral
To Pedal P005
4

Compatibility
Select the equipment that best suit your soldering or desoldering needs.
Modular System Peripherals
Control
Unit Stand Tool Cartridge Range MS / MV MN P405
DIU
ADS
T210 C210
T245
C245
T470
DNS
T210N C210
T245N C245
APSAP250 C250
AMS
AM120
C120
PA120
ATS AT420
C420
HTS HT420
DSSDS360 C360
DRSDR560 C560
5
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

0
c
P o w er 10%
350
Selected temp 350
o
C
A c t u al t e m p . 180
o
C
Sleep
Tool in the stand
A c t u a l temp. 20
o
C
Tool in the stand after
sleep, Noheat
Hibernation
0
c
Selected temp. 350
o
C
P o w e r 10%
350
4 Counters
5
Program version
Station s etti ng s
1 Temp unit Celsius
2 Maximum temp 4000C
3 Minimum temp 2000C
4 Nitrogen mode OFF
Tool 245
Tool se ttings
1 Fix one temp ----
2 Temp levels set OFF
3 Sleep delay 0 min
Ba ck
5 Help text OFF
6
Beep ON
7 Change PIN
Tool 245
Back
4 Sleep temp 180
0
C
5
Hibern delay 30 min
6 Temp adjust +0
0
C
Ma in menu
Exit
1 Reset settings
2
Station settings
3 Tool settings
Tool 245
Counters
1 Plugged hours 0
2 Working hours 0
3 Sleep hours 0
4 Hibernation hours 0
Ba ck
5 No tool hours 0
6
Sleep cycles 0
7 Desold cycles 0
Menu
Enter
Menu
Enter
Menu
Enter
Menu
Enter
Fixed temp. 350
o
C
Levels ºC 270 350400
Tool 245
Tool se ttings
1 Fix one temp ----
2 Temp levels set OFF
3 Sleep delay
Tool 245
Back
4 Sleep temp 180
0
C
5
6 Temp adjust +0
0
C
4 Counters
5
Program version Hibern delay
Ma in menu
Exit
1 Reset settings
2
Station settings
3 Tool settings
Pedal Set Up P305
0 min
30 min
OK
350 ºC
Port
1
Power
45%
Temp. Levels
T245
250 350 380
17:14
OK
350 ºC
Port
1
Power
45%
Temp. Levels
T245
250 350 380
17:14
OK
350 ºC
Port
1
Power
45%
Temp. Levels
T245
250 350 380
17:14
· Change temperature
(from 90 to 450ºC)
· Select temperature levels
· Fix one temperature
· Change Sleep temperature
· Set Sleep delay
(from 0 to 9 min or no Sleep)
· Change Hibernation delay
(from 0 to 60 min or no
hibernation)
Operation
The JBC Most Efficient Soldering System
Our revolutionary technology is able to recover tip temperature extremely quickly. It means the user
can work at a lower temperature and improve the soldering quality. The tip temperature is further
reduced thanks to the Sleep and Hibernation modes which increase up to 5 times the life of the tip.
3. Hibernation1. Work 2. Sleep
When the tool is lifted from
the stand the tip will heat up
to the selected temperature.
When the tool is in the stand,
the temperature falls to the
preset Sleep temperature.
After longer periods of
inactivity, the power is cut off
and the tool cools down to
room temperature.
Long period
in the stand
6

0
c
P o w er 10%
350
Selected temp 350
o
C
A c t u al t e m p . 180
o
C
Sleep
Tool in the stand
A c t u a l temp. 20
o
C
Tool in the stand after
sleep, Noheat
Hibernation
0
c
Selected temp. 350
o
C
P o w e r 10%
350
4 Counters
5
Program version
Station s etti ng s
1 Temp unit Celsius
2 Maximum temp 4000C
3 Minimum temp 2000C
4 Nitrogen mode OFF
Tool 245
Tool se ttings
1 Fix one temp ----
2 Temp levels set OFF
3 Sleep delay 0 min
Ba ck
5 Help text OFF
6
Beep ON
7 Change PIN
Tool 245
Back
4 Sleep temp 180
0
C
5
Hibern delay 30 min
6 Temp adjust +0
0
C
Ma in menu
Exit
1 Reset settings
2
Station settings
3 Tool settings
Tool 245
Counters
1 Plugged hours 0
2 Working hours 0
3 Sleep hours 0
4 Hibernation hours 0
Ba ck
5 No tool hours 0
6
Sleep cycles 0
7 Desold cycles 0
Menu
Enter
Menu
Enter
Menu
Enter
Menu
Enter
Fixed temp. 350
o
C
Levels ºC 270 350400
Tool 245
Tool se ttings
1 Fix one temp ----
2 Temp levels set OFF
3 Sleep delay
Tool 245
Back
4 Sleep temp 180
0
C
5
6 Temp adjust +0
0
C
4 Counters
5
Program version Hibern delay
Ma in menu
Exit
1 Reset settings
2
Station settings
3 Tool settings
Pedal Set Up P305
0 min
30 min
0
c
P o w er 10%
350
Selected temp 350
o
C
A c t u al t e m p . 180
o
C
Sleep
Tool in the stand
A c t u a l temp. 20
o
C
Tool in the stand after
sleep, Noheat
Hibernation
0
c
Selected temp. 350
o
C
P o w e r 10%
350
4 Counters
5
Program version
Station s etti ng s
1 Temp unit Celsius
2 Maximum temp 4000C
3 Minimum temp 2000C
4 Nitrogen mode OFF
Tool 245
Tool se ttings
1 Fix one temp ----
2 Temp levels set OFF
3 Sleep delay 0 min
Ba ck
5 Help text OFF
6
Beep ON
7 Change PIN
Tool 245
Back
4 Sleep temp 180
0
C
5
Hibern delay 30 min
6 Temp adjust +0
0
C
Ma in menu
Exit
1 Reset settings
2
Station settings
3 Tool settings
Tool 245
Counters
1 Plugged hours 0
2 Working hours 0
3 Sleep hours 0
4 Hibernation hours 0
Ba ck
5 No tool hours 0
6
Sleep cycles 0
7 Desold cycles 0
Menu
Enter
Menu
Enter
Menu
Enter
Menu
Enter
Fixed temp. 350
o
C
Levels ºC 270 350400
Tool 245
Tool se ttings
1 Fix one temp ----
2 Temp levels set OFF
3 Sleep delay
Tool 245
Back
4 Sleep temp 180
0
C
5
6 Temp adjust +0
0
C
4 Counters
5
Program version Hibern delay
Ma in menu
Exit
1 Reset settings
2
Station settings
3 Tool settings
Pedal Set Up P305
0 min
30 min
Menu Screen
Original PIN: 0105
The work screen provides
useful information of tool
status in real time.
Displays a specific fixed temp.
Shown once you have selected
temp. levels.
Work Screen
Control Process
7
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

CD-S
CD-B
CA
CS
CDE-S
CDE-B
CP
OK
TOOL
EARTHING FUSE
AUX
USE ONLYWITH A 250 V FUSE
OK
ºC
ºF
A
OK
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
180
Sleep
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
Selected
Min 200 Max 400
350 º C
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
180
Sleep
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
Selected
Min 200 Max 400
350 º C
0.5s/div
Ok to set up soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to set up soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
2.4s
13W·s
ºC
95%
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.2s
18W·s
2.4s
17W·s
ºC
94%
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
1.3s
8W·s
ºC
38%
19:29
19:29
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
1.3s
8W·s
ºC
38%
19:29
1s/div
150 Time
C210-008 Ref. .
4.5s ---
ºC
SOLDERING JOINT INFO 1/3
Sel. temp.
Cartridge
Time
Max temp
Min temp
Energy
Result
Last Ref. Diff.
350ºC 350ºC
C245907
2.4s
350ºC
335ºC
13W·s
2.3s
C245907
-2%
350ºC +0%
340ºC -1%
14W·s +29%
95%
1s/div
150 Time
C210-008 Ref. .
4.5s ---
ºC
SOLDERING JOINT INFO 1/3
Sel. temp.
Cartridge
Time
Max temp
Min temp
Energy
Result
Last Ref. Diff.
350ºC 350ºC
C210009
2.4s
350ºC
335ºC
13W·s
2.3s
C210009
-2%
350ºC +0%
340ºC -1%
14W·s +29%
95%
Hibernation
Tool in the stand
Actual Temp: 140ºC
25% 75%
Power C245907
50%
19:29
325 º C
Sel. temp.
325ºC
25% 75%
Power C245907
50%
Sleep
Tool in the stand
Actual Temp: 290ºC
Delay to hibernation: 9:43
25% 75%
Power C245907
50%
19:2919:29
Hibernation
Tool in the stand
Actual Temp: 140ºC
25% 75%
Power C210009
50%
19:29
325 º C
Sel. temp.
325ºC
25% 75%
Power C210009
50%
Sleep
Tool in the stand
Actual Temp: 290ºC
Delay to hibernation: 9:43
25% 75%
Power C210009
50%
19:2919:29
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Basic
Soldering-Assistant
Back
Mode
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Basic
Soldering-Assistant
Back
Mode
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
C210009
Cartridge
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
C245907
Cartridge
OK
Back
OK
CD-S
CD-B
CA
CS
CDE-S
CDE-B
CP
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
OK
ºC
ºFA
OK
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
180
Sleep
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
Selected
Min 200 Max 400
350 º C
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
180
Sleep
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
Selected
Min 200 Max 400
350 º C
0.5s/div
Ok to set up soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to set up soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
2.4s
13W·s
ºC
95%
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.2s
18W·s
2.4s
17W·s
ºC
94%
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
1.3s
8W·s
ºC
38%
19:29
19:29
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
1.3s
8W·s
ºC
38%
19:29
1s/div
150 Time
C210-008 Ref..
4.5s ---
ºC
SOLDERING JOINT INFO 1/3
Sel. temp.
Cartridge
Time
Max temp
Min temp
Energy
Result
Last Ref. Diff.
350ºC 350ºC
C245907
2.4s
350ºC
335ºC
13W·s
2.3s
C245907
-2%
350ºC +0%
340ºC -1%
14W·s +29%
95%
1s/div
150 Time
C210-008 Ref..
4.5s ---
ºC
SOLDERING JOINT INFO 1/3
Sel. temp.
Cartridge
Time
Max temp
Min temp
Energy
Result
Last Ref. Diff.
350ºC 350ºC
C210009
2.4s
350ºC
335ºC
13W·s
2.3s
C210009
-2%
350ºC +0%
340ºC -1%
14W·s +29%
95%
Hibernation
Tool in the stand
Actual Temp: 140ºC
25% 75%
Power C245907
50%
19:29
325 º C
Sel. temp.
325ºC
25% 75%
Power C245907
50%
Sleep
Tool in the stand
Actual Temp: 290ºC
Delay to hibernation: 9:43
25% 75%
Power C245907
50%
19:2919:29
Hibernation
Tool in the stand
Actual Temp: 140ºC
25% 75%
Power C210009
50%
19:29
325 º C
Sel. temp.
325ºC
25% 75%
Power C210009
50%
Sleep
Tool in the stand
Actual Temp: 290ºC
Delay to hibernation: 9:43
25% 75%
Power C210009
50%
19:2919:29
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Basic
Soldering-Assistant
Back
Mode
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Basic
Soldering-Assistant
Back
Mode
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
C210009
Cartridge
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
C245907
Cartridge
OK
Back
OK
CD-S
CD-B
CA
CS
CDE-S
CDE-B
CP
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
OK
ºC
ºFA
OK
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
180
Sleep
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
Selected
Min 200 Max 400
350 º C
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
180
Sleep
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
Selected
Min 200 Max 400
350 º C
0.5s/div
Ok to set up soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to set up soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
2.4s
13W·s
ºC
95%
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.2s
18W·s
2.4s
17W·s
ºC
94%
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C245907 Ref.
2.3s
14W·s
1.3s
8W·s
ºC
38%
19:29
19:29
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
---
---
ºC
19:29
0.5s/div
Ok to reset soldering Ref.
20
16
12
8
4
355
350
345
340
335
350
Sel. temp. 350ºC
W% ºC
Time
Energy
C210009 Ref.
2.3s
14W·s
1.3s
8W·s
ºC
38%
19:29
1s/div
150 Time
C210-008 Ref..
4.5s ---
ºC
SOLDERING JOINT INFO 1/3
Sel. temp.
Cartridge
Time
Max temp
Min temp
Energy
Result
Last Ref. Diff.
350ºC 350ºC
C245907
2.4s
350ºC
335ºC
13W·s
2.3s
C245907
-2%
350ºC +0%
340ºC -1%
14W·s +29%
95%
1s/div
150 Time
C210-008 Ref..
4.5s ---
ºC
SOLDERING JOINT INFO 1/3
Sel. temp.
Cartridge
Time
Max temp
Min temp
Energy
Result
Last Ref. Diff.
350ºC 350ºC
C210009
2.4s
350ºC
335ºC
13W·s
2.3s
C210009
-2%
350ºC +0%
340ºC -1%
14W·s +29%
95%
Hibernation
Tool in the stand
Actual Temp: 140ºC
25% 75%
Power C245907
50%
19:29
325 º C
Sel. temp.
325ºC
25% 75%
Power C245907
50%
Sleep
Tool in the stand
Actual Temp: 290ºC
Delay to hibernation: 9:43
25% 75%
Power C245907
50%
19:2919:29
Hibernation
Tool in the stand
Actual Temp: 140ºC
25% 75%
Power C210009
50%
19:29
325 º C
Sel. temp.
325ºC
25% 75%
Power C210009
50%
Sleep
Tool in the stand
Actual Temp: 290ºC
Delay to hibernation: 9:43
25% 75%
Power C210009
50%
19:2919:29
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Basic
Soldering-Assistant
Back
Mode
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Basic
Soldering-Assistant
Back
Mode
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
C210009
Cartridge
Back
Language
Mode
Station Settings
Tool Settings
Counters
Reset
Exit
C245907
Cartridge
OK
Back
OK
Register Settings
Create graphs of the
soldering process in
real time showing power
and temperature data.
Manager Settings
Change settings for a
group of JBC stations at
the same time.
Cable USB A-B
any JBC
station
USB
Hub
JBC Web
Manager
JBC
Updater
Cable USB A-B
USB Connector
Download the latest software from our website to improve your soldering station.
JBC Updater
www.jbctools.com/software.html
Update the station software via USB connection:
JBC Web Manager Lite
www.jbctools.com/manager.html
Manage and monitor as many stations as your PC can handle by using JBC Web Manager Lite.
Data can be exported to another PC.
8

OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
OK
TOOL
EARTHING FUSE
AUX
USE ONLY WITH A 250 V FUSE
Fuse
holder
Before carrying out maintenance, always switch the device off and disconnect it from the mains.
Allow the equipment to cool down.
- Clean the station screen with a glass
cleaner or a damp cloth.
- Use a damp cloth to clean the casing and
the tool. Alcohol can only be used to clean
the metal parts.
- Periodically check that the metal parts of
the tool and stand are clean so that the
station can detect the tool status.
- Maintain tip surface clean and tinned prior
to storage in order to avoid tip oxidation.
Rusty and dirty surfaces reduce heat
transfer to the solder joint.
- Periodically check all cables and tubes.
- Replace any defective or damaged pieces.
Only use original JBC spare parts.
- Repairs should only be performed by a
JBC authorized technical service.
- Replace a blown fuse as follows:
1. Pull off the fuse holder and remove the
fuse. If necessary use a tool to lever it off.
2. Insert the new fuse into the fuse holder
and return it to the station.
Maintenance
- When this warning appears on
the main screen Earthing Fuse must be
replaced
Clean
periodically
EARTH
FUSE
Fuse
holder
clean periodically
Fuse
9
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

Safety
- Do not use the units for any purpose other than soldering or rework. Incorrect use may cause fire.
- The power cord must be plugged into approved bases. Be sure that it is properly grounded before
use. When unplugging it, hold the plug, not the wire.
- Do not work on electrically live parts.
- The tool should be placed in the stand when not in use in order to activate the sleep mode. The
soldering tip or nozzle, the metal part of the tool and the stand may still be hot even when the station
is turned off. Handle with care, including when adjusting the stand position.
- Do not leave the appliance unattended when it is on.
- Do not cover the ventilation grills. Heat can cause inflamable products to ignite.
- Avoid flux coming into contact with skin or eyes to prevent irritation.
- Be careful with the fumes produced when soldering.
- Keep your workplace clean and tidy. Wear appropriate protection glasses and gloves when working
to avoid personal harm.
- Utmost care must be taken with liquid tin waste which can cause burns.
- This appliance can be used by children over the age of eight and also persons with reduced physical,
sensory or mental capabilities or lack of experience provided that they have been given adequate
supervision or instruction concerning use of the appliance and understand the hazards involved.
Children must not play with the appliance.
- Maintenance must not be carried out by children unless supervised.
It is imperative to follow safety guidelines to prevent electric
shock, injury, fire or explosion.
10

Specifications
DIU
1-Tool Control Unit
DI-1D 120V 50/60Hz. Input fuse: T2A. Output: 23.5V.
DI-2D 230V 50/60Hz. Input fuse: T1A. Output: 23.5V.
DI-9D 100V 50/60Hz. Input fuse: T2.5A. Output: 23.5V.
- Output Peak Power CD-BE: 130W
- Temperature Range: 90 - 450 °C / 190 - 840 °F (±5%)
- Idle Temp. Stability (still air): ±1.5 ºC / ±3 ºF
- Tip to Ground Voltage/Resistance: Meets and exceed
ANSI/ESD S20.20-2014 IPC J-STD-001F
- Ambient Operating Temp: 10 - 40 ºC / 50 - 104 ºF
- Connections: USB-B / Peripherals connectors
- Control Unit Dimensions / Weight: 180 x 94 x 106 mm / 2.153 kg
(L x W x H) 7.10 x 3.70 x 4.17 in / 4.75 lb
- Total Package Dimensions / Weight: 220 x 213 x 160 mm / 2.5 kg
(L x W x H) 8.66 x 8.39 x 6.30 in / 5.51 lb
Complies with CE standards.
ESD safe.
11
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm

This product should not be thrown in the garbage.
In accordance with the European directive 2012/19/EU, electronic equipment at the end of its life must
be collected and returned to an authorized recycling facility.
Warranty
JBC’s 2 year warranty covers this equipment against
all manufacturing defects, including the replacement
of defective parts and labour.
Warranty does not cover product wear or misuse.
In order for the warranty to be valid, equipment must
be returned, postage paid, to the dealer where it was
purchased.
Get 1 extra year JBC warranty by registering here:
https://www.jbctools.com/productregistration/
within 30 days of purchase.
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm 130 mm
para manuales - color gris
200 mm
300 mm
0027025-0522
