Joie muze User manual

muze™
stroller
gemm™
0+ (0–13kg)
birth to 15kg/birth - 36 months
GB Instruction Manual

12
FIGURE 1–5
FIGURE 6–10
1
NOISE
2
1
3
2
3
4
5
1
10
9
8
7
6

34
FIGURE 11–15
FIGURE 16–20
13
11 12
14
15 20
19
3
1
A
2
B
16 17
1
2
18
1 2 3

56
FIGURE 21–26
FIGURE 27–32
21
1
3
2
24
23
22
26
25
1
2
28
29
1
2
1
30
Accessories (not included in purchase)
27
1
2
31 32

78
GB Welcome to Joie™
Congratulations on becoming part of the Joie family! We are
so excited to be part of your journey with your little one. While
traveling with the Joie MUZE™, you are using a high quality, fully
certified stroller, complies with Australian Trade Practices Act
1974 Consumer Protection Notice No 8 of 2007. This product is
suitable for use with children weighing under 15kg. Please care-
fully read this manual and follow each step to ensure a comfort-
able ride and best protection for your child.
IMPORTANT - Keep these instructions for future reference.
Visit us at Joiebaby.com to download manuals and see more
exciting Joie products!
Contents
Figures 1-6
Warning 9
Stroller Assembly 11
Open Stroller 11
Assemble Front Wheels 11
Assemble Rear Wheels 11
Assemble Parent Tray 11
Assemble Rotating Child's Tray 11
Stroller Operation 12
Adjust Recline 12
Use Rotating Child's Tray 12
Use Buckle 12
Use Shoulder & Waist Harnesses 12
Adjust Calf Support 13
Use Front Swivel Lock 13
Use Brake 13
Use Hood 13
Use Tether Strap 13
Fold Stroller 14
Use Carry Strap 14
Use Accessory 14
Care and Maintenance 15
Emergency
In case of emergency or accident, it is most important to have your child
taken care of with first aid and medical treatment immediately.
Parts List
Make sure all parts are available before assembly. If any part is missing,
please contact local distributor. No tools are required for assembly.
Accessories
(Non-included)
Rain Cover (on certain models)
1234
x2
5
6
x2
x2
x2
7
8
9
x2
10
11
12
13
14
15
16
21
20
19
18
17
28
26
25
24
22
23
27
Product Information
Read all the instructions in this manual before using this product. If you
have any further questions, please consult the retailer. Some features may
vary depending on model.
Product Muze Stroller
Suitable for Child weighing under
15kg (birth - 36 months)
Materials Plastics, metal, fabrics
Patent No. Patents pending
Made in China
Brand Name Joie
Website www.joiebaby.com
Manufacturer Allison Baby UK Ltd
1 Stroller Frame
2 Parent Tray
3 Rotating Child's
Tray
4 Rear Axle
Assembly
5 Front Wheel (x2)
6 Rear Wheel (x2)
7 Cap (x2)
8 Washer (x2)
9 Pin (x2)
10 One-Hand-Fold
Handle
11 Hood
12 Seat Pad
13 Rotating Child's
Tray
14 Buckle
15 Footrest
16 Swivel Lock
17 Front Wheel
18 Storage Latch
Mount
19 Arm Release
20 Storage Latch
21 Secondary Lock
22 Storage Basket
23 Brake Lever
24 Rear Wheel
25 Backrest
26 Tether Strap
27 Parent Tray
28 Handle

910
WARNING
!TO AVOID INJURY OR DEATH: ALWAYS APPLY THE BRAKES
WHENEVER THE STROLLER IS STATIONARY.
!DO NOT LEAVE CHILDREN UNATTENDED. ALWAYS KEEP CHILD IN
VIEW WHILE IN STROLLER.
!ALWAYS USE THE CROTCH COMBINATION WITH THE WAIST BELT.
IT IS SUGGESTED THAT THE SHOULDER HARNESSES BE USED AS
WELL.
!DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS STROLLER.
!MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IF YOU
ADJUST THE STROLLER.
!TO AVOID SERIOUS INJURY FROM FALLING OR SLIDING OUT,
ALWAYS USE SEAT BELT.
!USE THIS TETHER STRAP TO STOP THE STROLLER ROLLING AWAY.
!Ensure that all the locking devices are engaged before use.
!Do not let your child play with this product.
!A warning to never leave the harness buckled when not fitted to a child
in the stroller because the harness can form loops which may pose a
strangulation hazard.
!It is unsafe to use accessories other than those approved by the vehicle
manufacturer.
!Adult assembly required.
!Use the stroller with a child weighing more than 15kg. It will cause
damage to the stroller with an unfitted child.
!To prevent a hazardous, unstable condition, do not place more than
4.5kg in the storage basket.
!Overloading, folding incorrectly, or using component parts from other
manufacturers may cause the stroller to be damaged, broken or unsafe.
Please read the instruction manual carefully.
!Please read all the instructions in the manual before using the product.
Please save instruction manual for future use. Failure to follow these
warnings and instructions may result in serious injury or death.
!Safety belts and restraint system must be used correctly.
!Child may slip into leg openings and be strangled if the harness is not
used.
!Never use stroller on stairs or escalators.
!The stroller not be used near an open fire or exposed flame.
!Do not place any item that may do harm to the baby and stroller in the
parent tray.
!Never allow your child to stand on the stroller or sit in the stroller with
head toward front of stroller.
!Never place the stroller on roads or dangerous area.
!The stroller is designed for use on flat or gently sloping surfaces and
may be unstable on higher sloping and uneven surfaces, and users
should be made aware of the possibility of the stroller tipping over.
!Do make sure all parts are assembled and fastened properly before
using the stroller.
!To avoid strangulation, do not place items with a string around your
child’s neck, suspend strings from this product, or attach strings to
toys.
!To prevent tipping, do not put anything on the handle. Always lift the
child in and out of the stroller.
!Do not lift stroller while child is in stroller.
!Do not use storage basket as a child carrier.
!To prevent tipping, never let child climb the stroller.
!To avoid finger entrapment, use care when folding and unfolding the
stroller.
!Be sure the stroller is fully open or folded before allowing child near the
stroller.
!To ensure your child’s safety, please make sure all parts are assembled
and fastened properly before using the stroller.
!Check that the car seat attachment device is correctly engaged before
use.
!To avoid strangulation, do make sure your child is clear from the hood.
!Discontinue using your stroller if it is damaged or broken.
!Stroller to be used only at walking speed. This product is not intended
for use while jogging.
!To avoid suffocation, remove plastic bag and packaging materials
before using this product. The plastic bag and packaging materials
should then be kept away from babies and children.
!This product is not suitable for running or skating.
!The maximum recommended weight of the parent tray is 1.36kg/3lbs.
!Pushchair designed to be used from birth shall recommend the use of
the most reclined position for new born babies.
!The parking device must be engaged when placing and removing
children.
!For car seats used in conjunction with a chassis, this vehicle does not
replace a cot or a bed. Should your child need to sleep, then it should
be placed in a suitable pram body, cot, or bed.
!Extra Care is needed if used on moving vehicles and child should not be
left unattended, even with brakes engaged.
!

11 12
Stroller Assembly
Please read all the instructions in this manual before assembling and using
this product.
Open Stroller
If the stroller is locked as 2- 1, please separate storage latch 2- 2 from
storage mount 2- 3, and then lift the handle to open the stroller. A click
sound means the stroller is open completely. 2
!Check that the stroller is completely open before continuing.
Assemble Front Wheels
Assemble front wheels to front legs. Check that wheels are securely attached
by pulling on wheel assemblies. 3
The front wheels can be disassembled by pulling the release buttons
backwards. 4
Assemble Rear Wheels
Assemble the rear wheels by following these steps.
1. Remove and discard the two end caps on the rear axle before
assembling the rear wheels. 5- 1
2. Assemble the rear axle assembly to rear legs 5. Check that the rear
axle assembly is securely attached by pulling on the rear axle assembly.
3. Place the rear wheel and washer on one side of the rear axle. 6
4. To secure wheel and washer to axle, push the straight side of pin
through the hole on the axle 7.
The assembled pin is shown as 8.
! The curve side on the pin must curve around the outside of the axle.
! Make sure the washer is between the pin and the wheel.
5. Line up the tabs on the cap with the holes on the wheel, snap the cap
onto the wheel to cover the washer and pin. 9
The completely assembled rear wheels are shown as 10 .
Assemble Parent Tray
To assemble the parent tray, attach the parent tray to the parent tray
mounts on both sides of the handle. 11
To remove parent tray in reverse steps.
!Do not place any item that may do harm to the baby and stroller in the
parent tray.
!The maximum recommended weight of the parent tray is 1.36kg/3lbs.
Assemble Rotating Child's Tray
Align the rotating child's tray end with matching component, and then push
down to assemble. 12
The completely assembled stroller is shown as 13 .
Stroller Operation
Adjust Recline
Recline Backrest
There are 4 angles for the backrest.
To recline the backrest, squeeze the recline handle on the back of the seat
14 , pull down on the backrest. 15 To raise the backrest, push up.
!Make sure the recline is set properly for use.
Use Rotating Child's Tray
The rotating child's tray can be pulled up on both left and right sides.
To open the rotating child's tray, press rotating child's tray release button
16 - 1, and then pull up the rotating child's tray. 16 - 2
Tip Rotating child's tray can be open for easily placing and removing
child.
Use Buckle
Release Buckle
Press the center button to release the buckle. 17
Lock Buckle
Match the waist belt buckle with the shoulder buckle 18 - 1, and click into
the center buckle. 18 - 2 A click sound means the buckle is locked
completely. 18 - 3
!To avoid serious injury from falling or sliding out, always secure your
child with harness.
!Make sure your child is snugly secured. The space between the child
and the shoulder harness is about the thickness of one hand.
!Do not cross the shoulder belts. This will cause pressure on child’s neck.
Use Shoulder & Waist Harnesses
!In order to protect your child from falling out, after your child is placed
into the seat, check whether the shoulder and waist harnesses are at
proper height and length.
19 - 1 Shoulder harness anchor A
19 - 2 Shoulder harness anchor B
19 - 3 Slide adjuster
For larger child, use shoulder harness anchor A and the highest shoulder
slots. For smaller child, use shoulder harness anchor B and the lowest
shoulder slots.

13 14
Use either shoulder harness anchor in the slots that are closest to child's
shoulder height. 20
Use slide adjuster to change the harness length. 21 - 1
Press the button 21 - 2, while pulling the waist harness to proper length 21 - 3
Adjust Calf Support
The calf support has 2 positions.
To adjust the calf support, press the adjustment buttons underneath the calf
support 22 - 1 and rotate the calf support downward or upward. 22 - 2
Use Front Swivel Lock
Pull up the front swivel locks to maintain the moving direction. 23
Tip It is recommended to use swivel locks on uneven surfaces.
Use Brake
To lock wheels, step backwards on either of the brake levers as 24 , Step
forwards on the brake lever to release wheel.
Tip The brake must be engaged when placing and removing children.
Tip Always apply brake when stroller is in stopped position.
Tip To ensure brake is fully engaged, gently rock the stroller backwards
and forwards before releasing the handle.
Tip Clean brake system regularly to ensure fully functional. See care and
maintenance section.
Use Hood
To open the hood, pull hood towards front. 25
To fold the hood, pull hood towards back. 26
Use Tether Strap
Use the tether strap to prevent the stroller inadvertently rolling away.
If you cannot easily control the stroller move the tether to a different
position.
1. To disassemble tether strap. Select a position high up on the handle and
wrap the tether strap around the handle and thread the larger loop
through the smaller loop, pull tight. 27
2. Check that when your hand is through the loop, the position selected
allows you to easily control the stroller.
Fold Stroller
Push secondary lock 28 - 1 and squeeze one-hand fold handle 28 - 2.
Push the stroller forward to fold. Lock the stroller by tucking storage latch
onto the storage mount 29 - 1. The stroller is folded and locked
completely. 29
Use Carry Strap
Securely grab the carry strap for easy transportation. 30
Use Accessory
31 Rain Cover
Accessories may be sold separately or may not be available depending
on region.
Use Rain Cover
To assemble the rain cover, place it over the stroller, and then attach the
10 pairs of hook and loop fasteners on the rain cover. 32
!Before using the rain cover, please make sure the backrest has been
adjusted to the lowest position and the infant car seat has been
fastened.
!After the rain cover is assembled, please reassemble the parent tray on
the handle.
!When using the rain cover, please always check its ventilation.
!When not in use, please check that the rain cover has been cleaned and
dried before folding.
!If the rain cover is on the stroller, always remove rain cover to prevent
ripping and tearing.
!Do not place your child into the stroller assembled with rain cover
during hot weather.
!When using your stroller at the beach, completely clean you stroller after
use to remove sand and salt from mechanisms and wheel assemblies.

15
Care and Maintenance
1. Removable seat pad may be washed in cold water and drip-dried. No
bleach.
2. To clean stroller frame, use only household soap and warm water. No
bleach or detergent.
3. From time to time check your stroller for loose screws, worn parts, torn
material or stitching. Replace or repair the parts as needed.
4. Excessive exposure to sun or heat could cause fading or warping of
parts.
5. If stroller becomes wet, open hood and allow to dry thoroughly before
storing.
6. If wheels squeak, use a light oil (e.g., Silicon Spray, antirust oil, or
sewing machine oil). It is important to get the oil into the axle and wheel
assembly. 1
7. If brake pedal stiff/hard to fully engage, flush any debris from brake
system with clean water first before lubricating.
8. When using your stroller at the beach or areas of high dust/sand,
completely clean your stroller after use to remove sand and salt from
brake mechanisms and wheel assemblies.

JK034_S1035$D
Share the joy at joiebaby.com
gemm™
0+ (0–13kg)
Allison Baby UK Ltd,
Venture Point, Towers Business Park
Rugeley, Staffordshire, WS15 1UZ
