KW-NT800HDT
Bluetooth®Wireless Technology/HD Radio™with TTN +
DVD/CD/USB/SD Navigation with 7-inch Touch Panel Monitor
KW-NT500HDT
Bluetooth®Wireless Technology/HD Radio™with TTN +
DVD/CD/USB/SD Navigation with 6.1-inch Touch Panel Monitor
20W x 4
RMS
Built-in
Bluetooth
®
Wireless Technology
Recommended Features
MP3/WMA/WAV
GIGA MP3 MULTI
Phone Book
Access Profile
2-Way Control
for iPod/iPhone
iPod Headunit Front AUX
AUDIO
Built-in
HD Radio
Tuner
Touch
Panel
Touch
Panel
External Mode
for
iPod/iPhone
iTunes
Tagging
✹High-Speed Data Processing LSI
New LSI processes data 2 x faster than previous model.
Phone Paring
[Up to 5 Phones]
Multiple
USB
High Speed
1.0A
Support
(Front+Rear+Subwoofer)
3 Pre-Output
Multilingual
Display
Drive
Change
Mode
Audio
Streaming
& Control
Rear-View
Camera
Ready
SiriusXM
Ready
7”
WVGA
7”
WVGA
6.1”
WVGA
6.1”
WVGA
High-Speed
LSI
High-Speed
LSI
Over 8 Million
P.O.I.
Over 8 Million
P.O.I.
Digital Signal
Processor with
Time Alignment
Digital Signal
Processor with
Time Alignment
(KW-NT500HDT)
(KW-NT500HDT)(KW-NT800HDT)
Quick Response and Operation
High Speed CPU, 8G Solid State Drive (SSD), and JVC-original S3 format data
compression all work to create a speedy response for navigation.
Touch semi-outer screen:
moderate-speed map scroll
Touch near center:
slow map scroll to determine destination
Touch outer screen:
fast map scroll
Fast
Moderate
Slow
CPU
8GB
SSD
8GB
SSD SSD
SSD
Junction
View
Junction
View
3D Viewing
3D Viewing
3D Footprint
3D Scroll
3D Landmark
3D Footprint
3D Scroll
3D Landmark
Text-to-
Speech
Text-to-
Speech
Voice
Guidance
Voice
Guidance
English/Spanish/French
Sound Setting
Sound Setting
13EQ/Crossover
Multiple
Destination Serch
Multiple
Destination Serch
POI/Address/Favorites/etc.
✹S3 Format Data Compression System
JVC-original efficient
compression provides
speedy response for
a large database.
Data A
Data B
Data C
Data D
Data E
Data A
Data B
Data C
Data D
Data E
50%
40%
70% 20%
80%
Compression
Decompression
Compression
Optimized storage/compression
for map data etc.
Memory enables specific
output by data type
This HD Radio receiver enables:
✹8GB Solid State Drive (SSD)
SSD provides instant
startup and quick
map display, with
high-durability for
the in-car
environment.
FeRAM
High-Speed Memory Adopts FeRAM,
a reliable memory
often used for
aircraft equipment
Hardware Program
Memory
NOR FLASH
CPU
SSD for Car Spec
NANDrive
Total system structure consisting of SSD, CPU, and various memories
enable speedy processing.
NANDrive is a trademark of Greenliant Systems
DDR2
Main Memory
DDR2

3D Landmark
-1
KW-NT800HDT Bluetooth®Wireless Technology/HD Radio™with TTN + DVD/CD/USB/SD Navigation with 7-inch Touch Panel Monitor
KW-NT500HDT Bluetooth®Wireless Technology/HD Radio™with TTN + DVD/CD/USB/SD Navigation with 6.1-inch Touch Panel Monitor
NTK-0884-01-1
✹Multiple Map Display
Map display options such as Junction View and 3D View are also available.
✹POI Search
Over 8 million POI data from NAVTEQ are available for POI Search.
✹HD Radio (Navigation)
✹NaviBridge (iPhone App)
When you connect your iPhone with the “NaviBridge”
application installed to the system, you can manipulate
the map, search and set destinations on the system
using the iPhone screen.
Junction View
Magnified View Improved Direct Scale3D Scroll & 3D Footprint
Clear and Dynamic Map Display Features
Multiple Search Function
• Traffic & Travel Information
Obtain real-time traffic, local
weather information etc. over HD Radio.
• Total Traffic Connect
The same information is available via 3G network,
even outside HD Radio coverage area.
• iPhone as Navigation’s Remote Control
The app lets you control the unit’s navigation screen from your iPhone.
• Destination Transfer from NaviBridge
Destinations searched on your iPhone can be transferred to the headunit.
✹Multiple Destination Search Functions:
Various options are available for destination
search.
• Search by POI (Name/Vicinity/Phone Number)
• Search by Address
• Search by Coordinates
• Search by Previous
• Search by Favorites
• Search Home
✹Destination Memory:
The unit can memorize destinations and
via points.
• 300 Favorite Destinations
• Last 50 Destinations
✹Multiple Route Options:
Search the route according to your
preference.
• Fastest/Shortest/Freeway Route
• Avoid Freeway/Ferry
• 4 via Points
✹Clear Map Display
The display is optimized for WVGA, with clear
map images and easy-to-read map text.
Clear Map Text
✹Off-Axis Viewing (KW-NT500HDT)
This function provides higher
contrast for better viewing when
the unit is installed at an angle.
Viewing AngleViewing Angle
Setting Screen
<Navigation>
WVGA
WVGA
✹WVGA Monitor
The 6.1-inch/7-inch WVGA LCD panel features 4 times more
pixels than the QVGA, offering comfortable viewing with clear and
bright display for images, GUI, and especially maps.
480
234
QVGA
480
800
More Detailed
WVGA
Included
Included
Lifetime
Subscription
✹2-Way Tilt (KW-NT800HDT)
The screen can be tilted forward or
backward for best view.
Reverse Tilt
Setting Screen
3D Map Display

13-Band EQ
Fine-tune the preset to your taste
KW-NT800HDT Bluetooth®Wireless Technology/HD Radio™with TTN + DVD/CD/USB/SD Navigation with 7-inch Touch Panel Monitor
KW-NT500HDT Bluetooth®Wireless Technology/HD Radio™with TTN + DVD/CD/USB/SD Navigation with 6.1-inch Touch Panel Monitor
✹Pandora Control for iPhone
Enjoy Pandora Radio from your iPhone with smooth control on the headunit.
✹iHeartRadio Link for JVC
Listen to iHeartRadio via the iPod/iPhone app, with control and album artwork
available on the headunit via USB connection.
✹Separate Structure for Amplifier and DVD/Navi
The amplifier and DVD/navigation are housed in separate chassis to prevent
interference, offering clear, rich sound with minimum noise.
✹Customize the Sound for Your Car Environment
JVC-original high-performance Digital Signal Processor (DSP) is designed to
create optimal sound onboard. Fine-tune the sound with Time Alignment,
crossover setting, 13-Band EQ, and other features to best fit your car.
✹High-Grade Parts Used for Quality Sound
Select parts support clear sound and high power for quality audio performance.
Clear and Realistic Sound (DSP)
Internet Radio / HD Radio
✹Built-in HD Radio – iTunes Tagging, Artist Experience, Bookmark, Channel Guide, and Instant Info.
Enjoy a multitude of HD Radio programs in premium digital sound, without external tuners. FM radio sounds equivalent to CD quality, and AM as good as normal FM. Artist
Experience displays song/album title and artwork if available from the radio station. Additionally, iTunes Tagging lets you “tag” songs you hear on HD Radio for easy purchase at the
iTunes Music Store. The new Bookmark feature with QR code displays song information without iPod/iPhone connection. To switch stations, just press the “List” key for the Channel
Guide showing a list of live radio programs with frequency and station name.
How It Works: Bookmark
Read QR code onto
smartphone.
4Song info available on
smartphone.
5
Press “Bookmark Song”
key on headunit.
1
“Bookmark
Song” key
The receivers feature dual HD Radio tuners, letting you access navigation data such as traffic updates and weather conditions,
while you enjoy HD Radio at the same time.
Capture QR code with
QR code reader app.
3
Displays Bookmark Info
screen with QR code.
2
JVC-original back-up
capacitor
50W x 4 MOS-FET amp
for increased power
Original audio capacitor
for bass booster
New DVD mechanism
with reduced noise
New low impedance
amplifier
Preset EQ
6 presets + 4 user settings
Sound Source Level Adjust
Set volume by source
Crossover
High-pass for front/rear, and low-pass for
subwoofer can be controlled separately
Audio Effect
Space Enhancer: Set listening space size
Sound Stage Elevation: Elevate sound image
of lower speakers without the tweeter
Road Noise Compensation: Adjust sound
according to car speed
Audio Contrast/
Digital Track Expander
Audio Contrast: Adjust sound sharpness for
more clarity
Digital Track Expander: Compensate
high-frequency for clear sound
<Audio>
Position: Preset
Optimize the sound field for position
Position: Customize
Fine-tune the preset for your position
1Set vehicle type
2Set listening position
3Can be customized
Custom setting available for
users with particular taste
Time Alignment: User Customization
Separate Chassis
with no interference
Conventional Chassis Structure
Noise from navigation board
affects audio board
Minimum interference with
isolated chassis
2011 2012
2012
High Frequency
Noise
Navigation Board
Audio Board
Bookmark Informatio
Fred Mattrob
Stories of Life
The Perfect Experien
www.hadradio-qrcod
Jazz, 2002 Fred Matt
* Requires app download

✹External Mode for iPod/iPhone
You can listen to the sound of iPod/iPhone apps, such as games, web radio, and
YouTube, with high current power supply.
NTK-0884-01-2
• On-Board SSD Navigation System (Whole map coverage preinstalled)
• High-Sensitivity WAAS Capable GPS • Coverage: United States, Alaska, Hawaii, Canada, and Puerto Rico
• Voice Guidance (English/Spanish/French)• Text-to-Speech (English/Spanish/French)
• NaviBridge (iPhone App) • POI (over 8 million: NAVTEQ) • HD Total Traffic Network+
• Multiple Destination Search Functions:
Search by POI (Category/Name/Vicinity/Phone Number) / Search by Address /
Search by Coordinates / Search by Previous / Search by Favorites / Search Home
• Destination Memory:
300 Favorite Destinations/Last 50 Destinations/4 via Points
• Multiple Route Options:
Fastest/Shortest/Freeway Route, Avoid Freeway/Ferry
• Map Display:
3D Landmark/3D Scroll/3D Footprint/Junction View/Magnified View/Lane Guide/Speed Limit Display
• Quick Menu • Speed Alert • Adaptive Volume Control
Navigation Feature Highlights
• MOS-FET 50W x 4 (20W RMS x 4)
• Built-in 7-inch WVGA Monitor (KW-NT800HDT)/Built-in 6.1-inch WVGA Monitor (KW-NT500HDT)
• Touch Panel • Built-in Bluetooth® Wireless Technology*1 (Easy Connect [SSP], Phone Book Access Profile,
Phone Book Transfer, Hands-Free Call, Audio Streaming, AVRCP, Alphabetical Search for Phone Book)
• USB Audio and Video for iPod/iPhone etc.*2 • 2-Way Control for iPod/iPhone*3 (Headunit/iPod or iPhone)
• External Mode for iPod/iPhone*2 • iTunes Tagging • Pandora Control for iPhone • iHeart Link for JVC
• Rear USB Port (MP3/WMA/WAV/AAC*4/FLAC/WMV/H.264/AVC/MPEG-4/iPod & iPhone Audio)
• USB 2.0 High Speed • USB 1A Power Supply
• Front SDHC/SD (KW-NT800HDT) / microSDHC/SD (KW-NT500HDT) Slot*5
(MP3/WMA/WAV/AAC*4/FLAC/WMV/H.264/AVC/MPEG-4)
• MP3/WMA/WAV/AAC*4 Compatible (DVD/CD) • Built-in HD Radio (with HD TTN+) • SiriusXM Ready*6
• DiAS II Tuner • Dolby Digital
• Sound Settings:
Time Alignment (DSP) / 13-Band iEQ / Preset EQ / Source Link EQ /
Crossover Setting / Audio Effect (Road Noise Compensation etc.) /
Digital Track Expander 2.0 (DSP)
• High-Pass Filter/Low-Pass Filter (30 - 250Hz, Slope -6/-12/-18/-24dB/Octave)
• 2.5V Line and Subwoofer Pre-Output Level • 3 Pre-Output Terminals (Front + Rear + Subwoofer)
• Subwoofer Control • Line Output (Video) • Line Input Terminals (AV + Video for iPod)
• Multilingual Display (English/Spanish/French) • Variable-Color Illumination • Steering Wheel Remote Ready
• Rear-View Camera Ready (Dedicated Terminal)
*1 Available functions depend on cell phone.
*2 KS-U49 cable required for iPod/iPhone video playback and External Mode.
Compatibility depends on iPod/iPhone.
*3 Compatibility with 2-way control for iPod/iPhone differs by model.
*4 Not compatible wth DRM-protected music purchased from iTunes Store.
*5 Compatible with up to 32GB SDHC and up to 2GB SD.
*6 SXV100 required
Audio & Visual Feature Highlights
KW-NT800HDT Bluetooth®Wireless Technology/HD Radio™with TTN + DVD/CD/USB/SD Navigation with 7-inch Touch Panel Monitor
KW-NT500HDT Bluetooth®Wireless Technology/HD Radio™with TTN + DVD/CD/USB/SD Navigation with 6.1-inch Touch Panel Monitor
✹ SDHC (KW-NT800HDT) / microSDHC (KW-NT500HDT) Compatible
The units are compatible with SDHC/microSDHC cards for audio and video playback.
✹USB Hub Compatible
The units are compatible with USB hub for expanded connection.
✹USB Connection (G3 iPod/iPhone)
Enjoy digital audio/video from your iPod, iPhone, or USB devices
with full-speed 1A USB port providing playback and charging.
*1 USB playback not supported for NTFS formatted devices. When partitions are
created, only the first partition can be read.
*2 For iPod/iPhone video playback, KS-U49 cables are required. Please visit
www3.jvckenwood.com/english/car/ for iPod/iPhone compatibility details.
1A Support
Dimensions (W x H x D)
Installation Size 7 3/16” x 3 15/16” x 6 15/16” 182 x 111 x 175 mm
Panel Size 7 7/16” x 4 5/8” x 5/16” 188 x 117 x 7 mm
Detachable Face Plate - -
Key Specifications
Maximum Power Output 50 + 50W (14.4V 4Ω)
Continuous Power Output (RMS) 20 + 20W RMS × 4 Channels at 4Ω
; 1.0% THD* +N
AV Input ✔
Video Input (Camera) ✔
Line Pre-Output Terminals 3 (Front + Rear + Subwoofer)
Center Channel Output -
Subwoofer Output with
Level/Frequency Control
✔
Subwoofer Output Level 2.5V
Subwoofer Gain Control -50 - +10dB
Composite Video Output ✔
Digital Output -
Load Impedance 4Ω(4 - 8Ω)
Pre-Output Level/Impedance 2.5V/20kΩLoad (full scale)
Video Output 1.0Vp-p/75Ω
2nd Audio Output -
Video Input 1.0Vp-p/75Ω
Audio Input 1.5Vrms/20kΩ
* Total Harmonic Distortion
Monitor
Screen Size 7" WVGA (KW-NT800HDT)/
6.1" WVGA (KW-NT500HDT)
Number of Pixels 1,152,000
Color System NTSC/PAL
KW-NT800HDT/NT500HDT
Rear-View Camera
(Optional)
KV-CM20K
ConnectionsConnections
✹Bluetooth®Compatible Functions
• Phone Book Access Profile (PBAP 1.0)
No need to transfer your phone book. Simply call by direct
access to the phone book on your iPhone or mobile phone.
* Only available on Phone Book Access Profile compatible mobile phones.
• Phone Book Transfer
You can transfer 500 numbers to the headunit.
• Alphabetical Search for Phone Book
Easy alphabetical search on a "QWERTY" keyboard even with a large phonebook.
• Audio Streaming & Control (A2DP1.2, AVRCP1.3)
Enjoy streamed music plus control from the headunit.
• Internet Radio via Smartphone (A2DP1.2, AVRCP1.3)
Listen to internet radio programs via your smartphone app,
with control available from the headunit.
• Hands-Free Calls
Receive/reject calls or voice dial while keeping your hands on the wheel.
• Multiple Phone Pairing
You can pair and easily switch between up to 5 phones.
SD Slot
USB Memory
USB Cable
USB
Rear
SXV100V1
SDHC Card
Android*
Mass Storage
Audio Streaming
AVRCP
iPhone
Audio Streaming
AVRCP
Mass Storage
Audio Streaming
AVRCP
BlackBerry®*
* Compatibility
depends on model
for Video Playback (KS-U49)
for iPod/iPhone
for Video Playback (KS-U49)
for iPod/iPhone
KW-NT800HDT
Rear Panel
SXV100V1
Portable
Audio Players
AUX-IN
Front
USB
Rear
USB Memory
USB Cable
iPod
Android*
Mass Storage
Audio Streaming
AVRCP
iPhone
Audio Streaming
AVRCP
Mass Storage
Audio Streaming
AVRCP
BlackBerry®*
* Compatibility
depends on model
KW-NT500HDT
Rear Panel
SD Slot
microSDHC Card
Hands-Free Calls
Audio Streaming
Phone Book
Access
Phone Book
Transfer
Multiple Phone
Pairing
✔
✔
✔
✔
✔
So Many Features!
Wired MIC
included
Speed Trap Area!
