Kärcher Puzzi 10/2 ADV User manual

CARPET & UPHOLSTERY CLEANER - 240V
Model: Puzzi 10/2 ADV
Product Code: 14/1411
59692350 (01/20)
001
3

123
45
7
1.
2.
CHEM
MAX 50°C
MAX
6
89
CHEM
MAX 2L
1.
2.
A
1

16
29
6
12
17
25 24
26
23
7
10
27
34
35 36
33
1
2
3
4
5
1115 13
18
21 14
20
22
28
19
8
9
30
31 32
B
2

C
3

4
Contents
General notes
Read these original instruc-
tions and the enclosed safety
instructions before using the device for the
first time. Act in accordance with them.
Keep both books for future reference or for
future owners.
If the operating instructions and safety
instructions are not observed, the device
can be damaged and dangers could
arise for users and other persons.
Notify the dealer immediately in the case
of shipping damage.
Check the package contents when un-
packing for missing accessories or for
damage.
Environmental protection
The packing materials can be recy-
cled. Please dispose of packaging in
accordance with the environmental regula-
tions.
Electrical and electronic appliances
contain valuable, recyclable materials
and often components such as batter-
ies, rechargeable batteries or oil, which - if
handled or disposed of incorrectly - can
pose a potential threat to human health and
the environment. However, these compo-
nents are required for the correct operation
of the appliance. Appliances marked by this
symbol are not allowed to be disposed of
together with the household rubbish.
Notes on the content materials (REACH)
Current information on content materials
can be found at: www.kaercher.com/
REACH
Intended use
This spray retraction device is intended
for wet cleaning of carpets.
This device is suitable for commercial
use, e.g. in hotels, schools, hospitals,
factories, shops, offices, and rental com-
panies.
Overview of the device
Quick Start Guide
Illustration A
1Connect the spray / suction hose to the
device, connect the spray / suction hose
to the angle piece
2Mix cleaning solution, fill fresh water
tank
3Selecting operating modes
4Cleaning
5Emptying the fresh water tank
6Empty the wastewater container
7Fill the fresh water tank(without deter-
gent), rinse the device
8Clean the fluff filter, clean the fresh wa-
ter filter
9Allow the device to dry
Description of the device
Illustration B
1Manual nozzle for upholstery cleaning
(Puzzi 10/1 only)
2Cable hooks
3Adapter for accessories (Homebase)
4Holder for accessories
5Mains cable
6Quick Start Guide
7Fresh water tank
8Fresh water filter
9Spray switch
10 Suction switch
11 Casing
12 Type plate
13 Steering roller
14 Spray hose connection
General notes .................................... 12
Environmental protection ................... 12
Intended use ...................................... 12
Overview of the device....................... 12
Start-up .............................................. 13
Operation ........................................... 13
Cleaning methods .............................. 14
Transport............................................ 15
Storage .............................................. 15
Care and service................................ 15
Troubleshooting guide........................ 16
Warranty............................................. 16
Accessories and spare parts.............. 16
EU Declaration of Conformity ............ 16
Technical data .................................... 17

5
15 Socket for additional brush wash head
PW 30/1 (Puzzi 10/2 Adv only)
16 Suction hose connection
17 Defoaming agent container (Puzzi 10/2
Adv only)
18 Cover
19 Storage compartment for detergent tabs
(Puzzi 10/2 Adv only)
20 Device carrying handle including suc-
tion pipe holder
21 Floor nozzle for carpet cleaning
22 Carpet adapter
23 Floor nozzle latch
24 Suction pipe
25 Nozzle mouthpiece
26 Union nut
27 Handle
28 Angle piece
29 Lever on the manifold
30 Spray hose
31 Suction hose
32 Spray / suction hose
33 Wastewater container, removable
34 Wastewater container carrying handle
35 Cover seal
36 Fluff filter
Start-up
1. Check the power cord, extension cable
and hoses for damage before each start-
up.
Installing accessories
1. Fit the suction pipe onto the floor nozzle
and hand-tighten the union nut on the
floor nozzle.
2. If necessary, slide the handle onto the
suction pipe and hand-tighten in the de-
sired position.
3. Fit the angle piece onto the suction pipe
and hand-tighten the union nut on the
angle piece.
4. Connect the suction hose to the suction
hose connection on the device. Insert
the spray hose coupling into the spray
hose connection on the device and latch
into place.
5. Connect the suction hose to the angle
piece. Connect the spray hose coupling
to the angle piece and latch into place.
Mixing the cleaning solution
DANGER
Danger from detergents
Risk of injury and damage
Observe all instructions that are included
with the detergents used.
Note
Warm water (maximum 50 °C) increases
the cleaning effect. Check the temperature
resistance of the surface to be cleaned.
Note
Use detergents sparingly to conserve the
environment.
1. Mix fresh water and detergent in a clean
container (concentration as specified for
the detergent). Dissolve the detergent in
the water.
Filling the fresh water tank
1. Pour the cleaning solution into the fresh
water tank. The filling level must not ex-
ceed the "MAX" mark.
Defoaming agent
Note
Foam is generated in the wastewater con-
tainer when cleaning previously sham-
pooed carpets. Foaming can be prevented
by adding defoaming agents.
1. Puzzi 10/1 only: Add defoaming agent
(special accessory) to the wastewater
container.
2. Puzzi 10/2 Adv only: Open the defoam-
ing agent container. Fill with defoaming
agent (special accessories).
Replacing the carpet adapter
1. Press the floor nozzle latch on one side.
2. Swing out and remove the carpet adapt-
er.
3. Insert a new carpet adapter and engage
the latch.
Operation
Working with accessories
Puzzi 10/2 Adv only:
Note
An additional power socket is provided for
connecting additional electrical devices.

6
DANGER
Danger of electric shock
Risk of injury and damage.
The socket is only intended for the direct
connection of the PW 30/1 additional brush
washer head to the Puzzi 10/2 Adv. Any
other use of the socket is prohibited.
Switching on the device
1. Connect the mains plug.
2. Press the suction switch to switch on the
suction turbine.
3. Press the spray switch to switch on the
spray pump.
Cleaning mode
ATTENTION
Danger from cleaning solution
Risk of damage
Before using the device, check the object to
be cleaned for colour fastness and water
resistance in an inconspicuous place.
1. Press the lever on the angle piece to
spray the cleaning solution.
2. Run over the surface to be cleaned in
overlapping paths. Pull the nozzle back-
wards (do not push).
3. When work is interrupted, the floor noz-
zle can placed in the device carrying
handle.
Switching off the device
1. Switch off the spray switch and the suc-
tion switch.
2. Pull out the mains plug.
Empty the wastewater container
1. Switch off the suction switch and the
spray switch when the wastewater con-
tainer is full.
2. Remove the cover.
3. Remove the wastewater container from
the device and empty it.
Emptying the fresh water tank
1. Switch off the device.
2. Briefly operate the lever on the angle
piece to relieve pressure.
3. Disconnect the angle piece from the
spray / suction hose.
4. Hang the suction hose in the fresh water
tank.
5. Press the suction switch to switch on the
suction turbine.
6. Suck the fresh water tank empty and
switch off the device.
7. Remove the cover.
8. Remove the wastewater container from
the device and empty it.
Flushing the device
1. Connect the angle piece (with suction
pipe and floor nozzle) to the suction
hose.
2. Connect the spray hose coupling to the
angle piece and latch into place.
3. Pour approximately 2 litres of tap water
into the fresh water tank. Do not add de-
tergents.
4. Press the spray switch to switch on the
spray pump.
5. Hold the floor nozzle over a drain.
6. Operate the lever on the angle piece and
flush the device for 1 to 2 minutes.
7. Switch off the device.
Each time after use
1. Flush the device.
2. Drain the wastewater container and
clean it under running water.
3. Empty the fresh water tank.
4. Clean the exterior of the device with a
damp cloth.
5. To avoid unpleasant smells, remove all
water from the device before long down-
times.
6. Let the device dry thoroughly: Remove
the cover or move it to the side.
Storing the device
1. Store the device in a dry room and se-
cure it against unauthorised use.
Cleaning methods
Normal soiling
1. Spray and vacuum up the cleaning solu-
tion in one step.
Note
Repeated vacuuming without spraying
shortens the drying time.

7
Heavily soiling or stains
1. Apply cleaning solution with the suction
turbine switched off and let it work for 10
to 15 minutes.
2. Clean the area as with normal soiling.
3. If necessary, clean the area again with
clear, warm water to further improve the
cleaning result.
Upholstery cleaning
1. Puzzi 10/1 only: Fit the manual nozzle
instead of the floor nozzle.
2. Use less detergent for sensitive fabrics
and spray the surface at a distance of
approx. 200 mm. Then only vacuum.
Cleaning tips
Spray heavily soiled areas in advance
and allow the cleaning solution to work
for 5 to 10 minutes.
Always work from light to shadow (from
window to door).
Always work from the cleaned to the un-
cleaned area.
The more sensitive the covering (orien-
tal bridges, Berber, upholstery fabric) the
lower the concentration of detergent.
Carpets with jute backs can shrink and
bleed in colour if the work is too wet.
Brush wet pile carpets in the direction of
the pile after cleaning when wet (e.g.
with a fibre brush or scrubber).
Impregnating with Care Tex RM 762 af-
ter wet cleaning prevents the textile cov-
ering from being quickly soiled again.
To avoid pressure points or rust stains,
do not walk on or furnish the cleaned ar-
ea until after it has fully dried.
Detergent
For further information, please request the
product information sheet and the EU safe-
ty data sheet for the relevant cleaning
agent.
Transport
몇CAUTION
Failure to observe the weight
Risk of injury and damage
Be aware of the weight of the device during
transportation.
1. Place the suction pipe on the carrying
handle for transport and place the spray
/ suction hose on the device. Wind up
the mains cable and hang it in the cable
hook.
Illustration C
2. When transporting the device in vehi-
cles, secure it to prevent it from slipping
or overturning in accordance with the re-
spective valid guidelines.
Storage
몇CAUTION
Failure to observe the weight
Risk of injury and damage
Be aware of the weight of the device during
storage.
The device may only be operated indoors.
Care and service
DANGER
Danger of electric shock
Injuries due to touching live parts
Switch off the device.
Remove the mains plug.
Clean the fluff filter
1. Remove the cover.
2. Remove the wastewater container from
the device.
3. Clean the fluff filter regularly with a
brush.
Clean the fresh water filter
1. Unscrew the fresh water filter.
2. Clean the fresh water filter under run-
ning water.
Clean the nozzle
1. Unscrew the union nut.
2. Clean the nozzle mouthpiece.
Carpet and upholstery
cleaning
RM 760 powder
RM 760 tabs
RM 764 liquid
Defoaming agent RM 761
Carpet impregnator RM 762

8
Troubleshooting guide
DANGER
Danger of electric shock
Injuries due to touching live parts
Switch off the device.
Remove the mains plug.
The device is not working
1. Check the socket and the power supply
fuse.
2. Check the mains cable and the mains
plug of the device.
3. Switch on the device.
No water emitted from the nozzle
1. Fill up the fresh water tank.
2. Check the couplings on the spray hose
for correct seating.
3. Clean or replace the nozzle mouthpiece.
4. Clean the filter in the fresh water tank.
5. Spray pump defective, contact customer
service.
Single-sided spray jet
1. Clean the nozzle mouthpiece.
Poor suction performance
1. Check that the cover is seated correctly.
2. Clean the seal on the cover and the con-
tact surface on the device.
3. Clean the fluff filter.
4. Check the suction hose for clogging;
clean if necessary.
Spray pump is loud
1. Refill the fresh water tank.
Heavy foaming in the wastewater con-
tainer
1. Add defoaming agent in the wastewater
container or fill up the defoaming agent
container.
Customer Service department
If the malfunction cannot be corrected, the
device must be checked by the Customer
Service department.
Warranty
The warranty conditions issued by our rele-
vant sales company apply in all countries.
We shall remedy possible malfunctions on
your appliance within the warranty period
free of cost, provided that a material or
manufacturing defect is the cause. In a war-
ranty case, please contact your dealer (with
the purchase receipt) or the next author-
ised customer service site.
(See overleaf for the address)
Accessories and spare parts
Only use original accessories and original
spare parts. They ensure that the appliance
will run fault-free and safely.
Information on accessories and spare parts
can be found at www.kaercher.com.
EU Declaration of Conformity
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements in the
EU Directives, both in its basic design and
construction as well as in the version
placed in circulation by us. This declaration
is invalidated by any changes made to the
machine that are not approved by us.
Product: Spray retraction device
Type: 1.100-xxx
Type: 1.193-xxx
Currently applicable EU Directives
2006/42/EC (+2009/127/EC)
2011/65/EU
2014/30/EU
Harmonised standards used
EN 50581
EN 55014-1: 2017
EN 55014-2: 2015
EN 60335-1
EN 60335-2-68
EN 61000-3-2: 2014
EN 61000-3-3: 2013
EN 62233: 2008
National standards used
-
The signatories act on behalf of and with
the authority of the company management.
Documentation supervisor: S. Reiser
Chairman of the Board of Management
Director Regulatory Affairs & Certification
H. Jenner S. Reiser

9
Technical data
Subject to technical modifications.
Electrical connection
Mains voltage V 220-240
Mains voltage (AU) V 240
Mains voltage (AR) V 220
Phase ~ 1
Power frequency Hz 50-60
Degree of protection IPX4
Protection class II
Blower motor nominal power W 1200
Power (tot.) W 1450
Spray pump power W 80
Power rating of the device socket (max.) W 250
Device performance data
Fresh water filling quantity l 10
Wastewater filling quantity l 9
Air quantity (max.) l/s 74
Vacuum (max.) kPa
(mbar)
25,4 (254)
Spray pressure MPa 0,2
Spray pressure (max.) MPa 0,3
Spray volume l/min 2
Cleaning solution temperature (max.) °C 50
Dimensions and weights
Typical operating weight kg 11,0
Length x width x height mm 705 x320 x 435
Ambient conditions
Ambient temperature (max.) °C +40
Determined values in acc. with EN 60335-2-68
Sound pressure level LpA dB(A) 71
Uncertainty KpA dB(A) 1
Hand-arm vibration value m/s2<2,5
Uncertainty K m/s20,2
Mains cable
Power cord type mm2 H05VV-F 2x1,0
Part number (EU) 6.650-363.0
Part number (GB) 6.650-380.0
Part number (AU) 6.650-385.0
Part number (AR) 6.650-382.0
Cable length m 7,5

Accessories
4.762-014.0
Hard surface
adapter
240
4.130-001.0 * DN 32 110
4.130-010.0 DN 32 0,25
5.070-010.0
Container for
detergent
6.980-078.0 DN 20-26
6.980-077.0
6.980-080.0
10

advantages.
vielen Vorteilen.
avantages.
Registre su producto y aproveche de muchas ventajas.
Bewerten Sie Ihr Produkt und sagen Sie uns Ihre Meinung.
Rate your product and tell us your opinion.
Évaluer votre produit et dites-nous votre opinion.
Reseñe su producto y díganos su opinión.
www.kaercher.com/welcome
www.kaercher.com/dealersearch
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28-40
71364 Winnenden (Germany)
Tel.: [phone]
Fax: [phone]
DANKE!
THANK YOU!
MERCI! GRACIAS!
!
