KI Extol Auditorium Seating Installation instructions

Required
Tools
Disassembly Instructions
Material Type:
Warning: This drawing format requires special non-standard fonts!!
Make sure the appropriate font files are installed!!!
TT Humanst 521 BT Light
O HelveticaLTStd-Cond
O HelveticaLTStd-LightCond
Extol Auditorium Seating
Page 1 of 2Rev. 0©2015 Krueger International, Inc. All Rights Reserved · P0033-0106
A .Steel B. Plastic C. Wood D. Foam E. Fabric F. Cast Iron G. Brass
KI · 1330 Bellevue Street · P.O. Box 8100 · Green Bay, WI 54308-8100 · 1-800-424-2432 · www.ki.com
Procedure:
1. Remove seat pivot caps to remove the screw, washer and
nut holding each side of the seat to the seat support column
and remove the seat assembly.
2. Remove the screws and nuts holding the backrest onto the
back supports and remove the backrest assembly.
3. Remove the screws holding the arm cap, cup holder and or
tablet onto the top of the seat support column and remove
the arm cap, cup holder and or tablets.
4. Remove the nuts holding the column onto the floor and
remove the column.
(Continued next page)
General Notes:
1. Disassembly time: 15-30 minutes
2. This procedure assumes basic familiarity with hand tools and
furniture terminology: no specialized training is required
3. All materials removed and disassembled shall be sorted and
segregated with like materials and disposed of or recycled
according to recycling availability or waste acceptance
4. For items to be recycled, refer to KI's End of Life Recycling
Matrix and KI's End of Life Recovery Options Matrix, available
at www.ki.com
All fasteners not explicity tagged or
shown are Material Type A: Steel
SCALE 0.040
Safety Glasses
Tin Snips
Power Drill
Channel Lock Pliers
Rubber Mallet
Claw Hammer
Cold Chisel
Gloves Pliers
Pry Bar
Putty Knife
Scissors
Utility Knife
Wood_Chisel
Flat Screwdriver
Philips Screwdriver
Torx Screwdriver
C
C
C
Allen Wrench
B
G
A
A
A
A
B
B
B
B
C
B

Required
Tools
Disassembly Instructions
Material Type:
Warning: This drawing format requires special non-standard fonts!!
Make sure the appropriate font files are installed!!!
TT Humanst 521 BT Light
O HelveticaLTStd-Cond
O HelveticaLTStd-LightCond
Extol Auditorium Seating
Page 2 of 2Rev. 0©2015 Krueger International, Inc. All Rights Reserved · P0033-0106
A .Steel B. Plastic C. Wood D. Foam E. Fabric F. Cast Iron G. Brass
KI · 1330 Bellevue Street · P.O. Box 8100 · Green Bay, WI 54308-8100 · 1-800-424-2432 · www.ki.com
All fasteners not explicity tagged or
shown are Material Type A: Steel
Procedure:
5. Remove the screws holding the backrest shroud onto the
backrest assembly and remove the shroud. Remove the
screws holding the backrest support brackets to the backrest
and remove the brackets.
6. Remove the seat shroud by removing the staples and fabric.
Unsnap the springs from the manifold. Unsnap the seat
collar from the seat pivots. Remove the screws from the
counter weight and name plate.
Safety Glasses Rubber Mallet
Gloves Pliers
Pry Bar
Utility Knife
Philips Screwdriver Allen Wrench
E
A
A
B
B
B
B
B
G
F
D
D
B
C
A
A
A
E
B
