KI Impress Guide

Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Repair & Replacement Instructions
Impress®Task Chair
Seat Replacement
March 2019
Impress Seat Removal
1. Place the Impress Task Chair upside
down on a hard, sturdy surface
(table) with the Impress seat resting
on the surface and the backrest
portion hanging down over the edge
of the table (Figure 1).
2. Remove the two rear exposed
1/4x 1” Phillips hex head washer
screws securing the seat to the
seat slider. Press the seat slider
mechanism lever down and slide the
seat-control mechanism forward until
the remaining two front mounting
screws are exposed on the seat
slider. Remove the two remaining
1/4x 1” Phillips hex head washer
screws securing the seat to the slider
(Figures 1 & 2).
Note: The seat slider must be
adjusted by activating lever to expose
the front or rear 1/4x 1” Phillips hex
head washer screws that secure the
seat to the seat slider.
3. Remove the damaged seat from
under the task chair. Place the chair
upright on the floor (Figure 3).
Figure 1
1/ x 1”
Phillips hex
washer head
screws
4
backrest
worksurface
seat
seat
slider
seat-control
mechanism
Figure 2
seat slider
mechanism
lever
seat-control
mechanism
1/4x 1”
Phillips hex
washer head
screw
seat
slider
Figure 3
damaged
seat

Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
1330 Bellevue Street • P.O. Box 8100 • Green Bay, WI 54308-8100 • Tel [phone] • www.ki.com
© 2019 Krueger International, Inc. All Rights Reserved • Code KI-RR-000024/KI/PDF/0319
Impress®Task Chair
Repair & Replacement Instructions
Impress Seat Replacement
1. Place the replacement seat upside
down on a hard, sturdy surface
(table). Position the seat so the back
is facing the edge of the table
(Figure 4).
2. Carefully place the Impress Task
Chair upside down on top of the
replacement seat with the back
portion of the chair hanging down
over the edge. Align the seat slider
mounting holes with the mounting
holes on the base of the seat
(Figure 4).
Note: The seat slider must be
adjusted by activating lever to expose
the front or rear mounting locations
of the seat slider.
3. Insert the two front or rear
1/4x 1” Phillips hex head washer
screws through the seat slider
mounting holes and into the seat.
Press the seat slider mechanism
lever down and slide the seat-control
mechanism until the remaining two
mounting holes are exposed. Secure
with the remaining two seat slider
mounting holes to the seat using
two 1/4x 1” Phillips hex head washer
screws (Figures 5 & 6).
4. Place the task chair upright on the
floor and test the function of the
chair.
Figure
4
replacement
seat
backrest
worksurface
seat-control
mechanism
seat
slider
Figure
5
1/4x 1”
Phillips hex
washer head
screw
seat-control
mechanism
seat
slider
seat slider
mechanism
lever
Figure 6
backrest
1/4x 1”
Phillips hex
washer head
screws
seat
seat
slider
seat-control
mechanism
