KI Uniframe Convertible Bench User manual

Operating Instructions
Uniframe® Convertible Bench
September 2018
Tabletop Operation
To Flip Down for Bench
1. Lift up and pull at the center of the
table top closest to the bench to
unlock, then rotate the tabletop down
until table apron rests against vertical
leg support and the worksurface
becomes the backrest. (Figures 1 &
2, Details A & B).
To Flip Up for Table
1. Lift up on front edge of table apron at
the center and rotate up until top is
horizontal and drops into the locked
position (Detail A).
Bench Storage/Transport Position
1. To store or transport unit, lift up
on bench, rotating the bench to the
vertical position (Figure 3 &
Detail C).
Locking Casters
1. Lock casters to use bench/table.
Unlock casters to transport table
(Figure 1).
Figure 1 - Single Table Position
locking caster
tabletop
Detail A - Table-to-Bench Position
tabletop
apron
support
leg
Figure 2 - Bench P
osition
tabletop
Detail B - Bench P
osition
tabletop
apron
Figure 3 - Storage/Transport Position
bench
Detail C - Bench-to-Storage P
osition
bench

Uniframe®Convertible Bench
Operating Instructions
Ganging Tables
1. To gang tables together, first
make certain that the tabletops are
locked into the upright position
and move tables together, with
benches to the outside. Align the
feet of the table bases and locate
the sliding foot ganger on the foot
(Figures 4 & 5).
Note: There will be
approximately a 1/2" gap
between tabletops when
ganged to avoid finger pinching.
Caution: Keep hands from
between tops and legs when
moving tables together.
2. Lift up and slide the ganger from
the stored position of one table
foot, engaging onto the foot of the
second unit, interlocking the hole
in the ganger over the acorn nut
on the second table leg. Repeat
procedure at other end of the
table (Figure 6).
1330 Bellevue Street • P.O. Box 8100 • Green Bay, WI 54308-8100 • Tel [phone] • www.ki.com
© 2018 Krueger International, Inc. All Rights Reserved • Code KI-61587R5/KI/PDF/0918
Figure 4 - Ganging of T
ables
tabletops
bench
sliding foot
ganger
bench
Figure 5 - Ganger Stored Position
support
leg acorn
nut
support
leg
support
leg
acorn
nut
sliding
foot
ganger
sliding
foot
ganger
Figure 6 - Ganger Engaged Position
sliding foot
ganger
sliding
foot
ganger
Storage Position
1. When tables are to be separated,
lift up and slide the ganger back
to the stored position at both
ends of table pair, then move
tables apart (Figure 5).
