Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Repair & Replacement Instructions
Uniframe® Tables
Latch Removal & Installation
February 2018
Required Tools
• Hammer
• 5/32 Pin Punch
Latch Removal & Installation
1. Open the table half-way to gain
access to the broken table latch
(Figure 1).
2. Move under the table and locate the
broken table latch (Figure 2).
3. Where the latch rod goes through
the slot plug, remove the rubber cap
from the latch rod handle using your
finger tips (Figure 3).
4. From inside the apron, use a hammer
to gently tap the slot plug free from
the apron and save for re-installation
on page 6, step 11 (Figure 4).
5. Using a 5/32” pin punch and hammer,
tap out the 5/32” roll pin from the 21/2”
clevis pin on the outer leg. Once the
roll pin has been removed, slide the
clevis pin out of the table latch and
leg brackets (Figure 5).
Figure
1
Uniframe
table
Figure 3
latch
rod
rubber
cap
slot
plug
table
latch
Figure
5
5/ pin punch
32”
hammer
5/”roll pin
32
2 /”
1
2
clevis pin
Figure 2
table
latch
Figure 4
latch
rod
slot
plug
hammer
apron
2
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Uniframe®Tables - Latch Removal & Installation
Assembly Instructions
6. With the clevis pin removed from
the table latch and leg brackets,
move the latch to the left of the leg
brackets away from the apron slot
and push the latch rod through the
apron slot in the frame (Figure 6).
7. Slide the table latch off the latch rod
(Figure 7).
8. Slide the new table latch onto the
latch rod, making sure the hook is
pointed down and away from the
table. Slide new table latch until it
rests on the “U” section of the latch
rod as illustrated in figure 8.
9. To allow the latch rod to rest inside
the frame, move the table latch to
the left side of the brackets away
from the apron slot (Figure 9).
10. Move table latch between the
leg brackets (Figure 10). Align
the holes in the table latch with
the holes in the leg brackets and
insert a 21/2” clevis pin through the
brackets and latch. Once the clevis
pin is in place, use a hammer and
punch to tap a 5/32” roll pin into the
clevis pin until it is approximately
halfway through the clevis pin
(Figure 11).
Figure
6
table latch
latch rod
leg
bracket
apron
slot
Figure
7
table
latch
latch rod
latch
hook
Figure
8
table latch
latch
rod
Figure
9
table
latch
latch rod
leg
bracket
apron
slot
Figure 10
latch
rod leg
bracket
table
latch
align table
latch & leg
bracket
holes
Figure 11
hammer
5/ roll pin
32”
2 /”
1
2
clevis pin
5/”roll pin
32
5/ pin punch
32”
3
Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Uniframe®Tables - Latch Removal & Installation
Assembly Instructions
11. Re-install the slot plug (removed in
step 4) by snapping it into the slot
of the apron (Figure 12).
12. At the latch rod handle near the slot
plug, re-install the rubber cap from
the latch rod using your finger tips
(Figure 13).
13. Inspect the table latch for proper
function. Table latch should strike
the catch along the angled plane
of the latch, resulting in the latch
lifting upward until the latch slot
falls over the catch. If the latch
strikes the catch either high or low,
adjustments will need to be made
with the set screws located at the
other end of the latch (Figure 14).
Figure 12
latch
rod
slot
plug
apron
Figure 13
latch
rod
rubber
cap
slot
plug
table
latch
Figure 14
table
latch
table
catch
1330 Bellevue Street • P.O. Box 8100 • Green Bay, WI 54308-8100 • Tel 1-800-424-2432 • www.ki.com
© 2018 Krueger International, Inc. All Rights Reserved • Code KI-RR-000011/KI/PDF/0218
Uniframe®Tables - Latch Removal & Installation
Repair & Replacement Instructions
