Kohler K-4709 Assembly instructions

Homeowners Guide
Cleansing Seat with Heater
Français, page “Français-1”
Español, página “Español-1”
K-4709
1054180-5-H

IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE
USING
When using electrical products, especially when children are present,
basic safety precautions should always be followed, including the
following:
IMPORTANT! Risk of product damage. Do not install this product
in a location exposed to excessive moisture where condensation
might form on the product surface. Provide adequate ventilation
when bathing to avoid damage to the electronic components due to
high humidity levels.
IMPORTANT! Risk of product or property damage. Pushing or
pulling on the water connection may cause water leakage.
IMPORTANT! Risk of product damage. Do not apply excessive
force to the spray wands.
IMPORTANT! Risk of product damage. In areas where water may
freeze in the pipes, make arrangements to keep the pipes warm.
Any water remaining in the seat may freeze during winter storage.
Allow the unit to warm to room temperature before reinstalling or
using.
IMPORTANT! Risk of product damage. Do not supply electrical
power to the unit until the plumbing installation work has been
completed, as it may cause the product to malfunction.
NOTE: The thermal protectors may trip during storage or
transportation in warm weather causing the unit to not operate.
Allow the unit to cool to room temperature before installation or
operation.
DANGER: To reduce the risk of electrocution:
Do not place or store this product where it can fall or be pulled
into a bath or sink.
Do not place in or drop into water or other liquid.
Do not reach for a product that has fallen into water. Unplug
immediately.
1054180-5-H 2 Kohler Co.

IMPORTANT SAFEGUARDS (cont.)
WARNING: To reduce the risk of burns, electrocution, fire,
or injury to persons:
Close supervision is necessary when this product is used by or
near children, the elderly, or invalids. Adjust the temperature of
the seat for the elderly, those who are incapacitated, or persons
with sensitive skin.
Use this product only for its intended use as described in this
manual. Only use attachments recommended by Kohler Co.
Never operate this product if it has a damaged cord or plug, if it
is not working properly, if it has been dropped, damaged, or
dropped into water. Return the product for examination and
repair.
Keep the cord away from heated surfaces.
Never block the air openings of the product or place it on a soft
surface, such as a bed or couch, where the air openings may be
blocked. Keep the air openings free of lint, hair, and the like.
Never use while sleeping or drowsy.
Never drop or insert any object into any opening or hose.
Do not use outdoors or where aerosol spray products are being
used or where oxygen is administered.
Connect this product to a properly grounded outlet only. See the
“Grounding Instructions” section.
This product conforms to applicable provisions of US 21 CFR,
Chapter 1, Subchapter J, Radiological Health.
SAVE THESE INSTRUCTIONS
Kohler Co. 3 1054180-5-H

Grounding Instructions
WARNING: Risk of electric shock, fire, or personal injury.
This product must be grounded and connected only to a
dedicated, nominal 120 VAC, 60 Hz circuit protected by a
minimum 15 A Ground-Fault Circuit-Interrupter (GFCI) or
Residual Current Device (RCD).
This product should be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current. This product is
equipped with a cord having a grounding wire with a grounding
plug. The plug must be plugged into an outlet that is properly
installed and grounded.
DANGER: Risk of electric shock. Improper use of the
grounding plug can result in a risk of electric shock.
If repair or replacement of the cord or plug is necessary, do not
connect the grounding wire to either flat blade terminal. The wire
with insulation having an outer surface that is green with or
without yellow stripes is the grounding wire.
Check with a qualified electrician or service personnel if the
grounding instructions are not completely understood, or if in
doubt whether the product is properly grounded.
Do not use an extension cord with this product.
Grounded
Outlet
Grounding
Plug
1054180-5-H 4 Kohler Co.

Remote and Panel Diagram
N
L
I
J
D
G
C
G
Q
P
O
F
M
K
H
E
C
B
A
ENERGY-SAVE
LIGHT
POWER
AIR SPEEDAIR TEMP.
SEAT TEMP.H20 TEMP.
NOZZLE
BACKWARD
STOP
PULSATE
OSCILLATE
REAR
FRONT
TESERP
D
Remote
Panel
NOZZLE
FORWARD
DEODORIZER
Kohler Co. 5 1054180-5-H

Operation
NOTE: The remote control must be charged to operate. The remote
control charges when attached to the docking station.
A – Preset 1: Setting the Presets: While seated, adjust the seat
features to your preferences. Press and hold the preset icon for 3
seconds to save activated features at the current settings. Using
the Presets: While seated, press the preset icon to activate features
at your stored settings. If the preset icon is pressed while the seat
is not occupied, the seat will gradually (approximately 2 minutes)
change to your preset temperature.
B – Preset 2: Same as Preset 1.
C – Front: Activates the front wash feature and adjusts the front
wash water pressure.
D – Rear: Activates the rear wash feature and adjusts the rear
wash water pressure.
E – Oscillate: Activates wand movement forward and backward.
Press the icon a second time to stop movement.
F – Pulsate: Alternates the water flow rate. Press the icon a
second time to stop pulsating flow and return to the previously
selected flow rate.
G – Stop: Stops the front wash, rear wash, or air speed features.
H – Nozzle Backward: Retracts the wand.
I – Nozzle Forward: Extends the wand.
J – Deodorizer: Activates or deactivates the deodorizer.
K – H2O Temp: Changes the water spray temperature from low,
to medium, to high, to OFF.
L – Seat Temp: Changes the seat temperature from low, to
medium, to high, to OFF.
M – Air Temp: Changes the heated air temperature from low, to
medium, to high, to OFF.
N – Air Speed: Changes the heated air speed from low, to
medium, to high.
O – Energy Save: When activated, after 24 hours of inactivity the
power indicator LED changes from green to amber, and the seat
temperature changes to low. After 48 hours of inactivity the
heated seat turns off. Once the seat is activated, the power
indicator LED light will change to green, the temperature changes
to the previous user setting, and the timer restarts the energy
save mode.
1054180-5-H 6 Kohler Co.

Operation (cont.)
P – Power: Turns the seat controls on or off.
Q – Light: Turns the night light feature on or off. The lights are
sensor-activated and the room must be sufficiently dark for the
lights to activate.
Care and Cleaning
For best results, keep the following in mind when caring for your
KOHLER product:
IMPORTANT! Do not immerse product in water.
•Always test your cleaning solution on an inconspicuous area
before applying to the entire surface.
•Use a soft, dampened sponge or cloth to wipe surfaces clean.
Remove the cleaner quickly after applying. Rinse and dry any
overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Never use an abrasive material such as a brush or scouring pad
to clean surfaces.
For detailed cleaning information and products to consider, visit
kohler.com/clean. To order Care & Cleaning information, call
1-800-456-4537.
Kohler Co. 7 1054180-5-H

Cleaning the Spray Wands
NOTE: The spray wands can only be extended for cleaning when
the seat is not activated or occupied.
Raise the lid and seat.
Press the ″FRONT″icon on the panel to extend the wand forward
for cleaning.
Clean the spray wand with a soft-bristled brush and hot water.
Press the ″FRONT″icon again to retract the wand.
Repeat the steps above for the ″REAR″spray wand.
Spray
Wand
1054180-5-H 8 Kohler Co.

Cleaning the Filter Screen
NOTE: Clean the filter screen every 6 months or when there is a
reduction in the maximum water flow from the spray wand.
Turn off the water at the supply stop.
Disconnect the water supply hose from the seat connection.
Using long-nosed pliers, carefully remove the filter screen from
the inlet.
Clean the filter screen with a soft-bristled brush.
Reinstall the filter screen.
CAUTION: Risk of product damage. Do not cross-thread the hose
connection to the inlet.
Reconnect the water supply hose to the inlet, one-quarter turn
past hand tight.
Turn on the water supply.
Check all connections for leaks, and make any adjustments as
needed.
Filter Screen
Kohler Co. 9 1054180-5-H

Removing the Seat
For Cleaning
IMPORTANT! When removing the seat for cleaning, take care to
avoid exerting any force on the hose connections.
Press the release button.
Slide the seat forward to access the area around the mounting
plate. Avoid putting pressure on the hoses.
Clean the area as needed.
To reinstall, slide the seat back until it engages the mounting
plate.
For Servicing
Turn off the water at the supply stop.
Flush the toilet to relieve any pressure from the supply hose.
Unplug the power cord from the electrical outlet.
Disconnect the water supply hose from the T-valve.
Press the release button.
Slide the seat forward to disengage from the mounting plate.
When servicing is complete, reinstall the seat and reconnect all
components.
Mounting Plate
Release Button
1054180-5-H 10 Kohler Co.

Draining the Tank
NOTICE: Drain the water from the tank if the seat will not be used
for long periods of time, or there is the possibility of freezing
temperatures.
Turn off the water supply and unplug the unit.
Flush the toilet to relieve any pressure from the water supply
hose.
Press the drain button until all water is drained from the tank.
Troubleshooting
This troubleshooting guide is for general aid only. A Kohler Co.
Authorized Service Representative (ASR) or qualified electrician should
correct any electrical problems.
For warranty service, contact the Customer Care Center using the
numbers located on the back page of this manual.
General Features
Symptoms Probable Causes Recommended Action
1. The seat
features are not
working.
A. A power failure
has occurred. A. Wait until power is restored.
B. The power cord is
unplugged. B. Plug the power cord into a GFCI or RCD
electrical outlet.
Drain Hole Drain Button
Kohler Co. 11 1054180-5-H

Troubleshooting (cont.)
General Features
Symptoms Probable Causes Recommended Action
C. The LED power
indicator is off. C. Press the ″Power″ icon.
2. Power light is
not on. A. Power cord may be loose or
disconnected.
A. Check the power
cord connection.
B. The Ground-Fault
Circuit-Interrupter
(GFCI) or Residual
Current Device
(RCD) is tripped.
B. Reset the GFCI or
RCD.
C. The circuit breaker
has been tripped. C. Reset the circuit breaker.
D. None of the above
actions correct the
symptom.
D. Contact a Kohler
Service
Representative.
3. The seat is
loose. A. The mounting plate fasteners are
loose.
A. Tighten the fasteners.
Refer to the
Installation Guide.
Cleansing Features
Symptoms Probable Causes Recommended Action
1. There is no
water flow. A. The water supply stop is closed. A. Open the water supply stop.
B. The seat sensor is
not detecting the
user.
B. See activating the
seat information in
the ″Operation″
section.
2. The water
pressure is low. A. The filter screen is clogged. A. Clean or replace the filter screen. See the
″Cleaning the Filter
Screen″section.
3. Water stops
flowing from
the spray wand
before
cleansing is
complete.
A. Washing
automatically stops
one minute after
pressing a spray
icon.
A. Press the ″FRONT″
or ″REAR″icon to
restart cleansing.
B. The seat sensor
does not detect the
user.
B. See activating the
seat information in
the ″Operation″
section.
1054180-5-H 12 Kohler Co.

Troubleshooting (cont.)
Cleansing Features
Symptoms Probable Causes Recommended Action
4. Dripping
sounds are
heard before
and after using
the cleansing
features.
A. The unit is running
through the pre- or
post- use cleansing
cycle.
A. No action needed.
Deodorizer Feature
Symptoms Probable Causes Recommended Action
1. The deodorizer
feature does
not work.
A. The user pressed
the ″Stop″icon. A. The deodorizer reactivates when the
seat sensor detects
the next user.
B. The seat sensor is
not detecting the
user.
B. Shift your position
on the seat.
2. Odor is not
removed. A. The ″Deodorizer″ is not activated. A. The deodorizer activates when the
seat sensor detects a
user.
B. Some people are
more sensitive to
odor.
B. None
Air (Dryer) Feature
Symptoms Probable Causes Recommended Action
1. The dryer
stops during
use.
A. The dryer
automatically stops
ten minutes after
pressing the ″AIR
SPEED″icon.
A. Press the ″AIR
SPEED″button to
restart.
Seat Sensor
Symptoms Probable Causes Recommended Action
1. The wash,
deodorizer, or
air features run
when the icon
is pressed
while seat is
not occupied.
A. The seat sensor is
covered by an
object or the seat is
wet.
A. Remove any water or
object from the seat
sensor area.
Kohler Co. 13 1054180-5-H

Troubleshooting (cont.)
Seat Sensor
Symptoms Probable Causes Recommended Action
2. Even though
the seat is
occupied, the
spray feature
does not work.
A. The user is not
detected by the
seat sensor.
A. Shift your position
on the seat.
Remote Control
Symptoms Probable Causes Recommended Action
1. The remote
control does
not operate the
seat.
A. The batteries are
low. A. Replace the batteries.
B. The batteries are
not installed
correctly.
B. Reinstall the
batteries.
C. The seat reception
window(s) is/are
covered with dust,
water, or another
object.
C. Clean the seat
window(s) or remove
the object that is
covering the
window(s).
2. The remote
control lights
flicker.
A. The batteries are
low. A. Replace the batteries.
Warranty
KOHLER Intelligent Toilet and C3 Cleansing Seat Three-Year Limited
Warranty
Kohler Co. warrants that its toilets with integrated cleansing
functionality (″Intelligent Toilets″) and electric cleansing seats will be
free of defects in material and workmanship during normal residential
use for three years from the date the product is installed. This
warranty applies only to intelligent toilets and electric cleansing seats
installed in the United States of America, Canada and Mexico (″North
America″).
If a defect is found in normal residential use, Kohler Co. will, at its
election, repair, provide a replacement part or product, or make
appropriate adjustment where Kohler Co.’s inspection discloses any
such defect. Damage caused by accident, misuse, or abuse is not
covered by this warranty. Improper care and cleaning will void the
warranty*. Proof of purchase (original sales receipt) must be provided
1054180-5-H 14 Kohler Co.

Warranty (cont.)
to Kohler Co. with all warranty claims. Kohler Co. is not responsible
for labor charges, installation, or other incidental or consequential costs
other than those noted above. In no event shall the liability of Kohler
Co. exceed the purchase price of the intelligent toilet or electric
cleansing seat.
If the intelligent toilets or electric cleansing seats are used
commercially or are installed outside of North America, Kohler Co.
warrants that the intelligent toilet or electric cleansing seat will be free
from defects in material and workmanship for one (1) year from the
date the product is installed, with all other terms of this warranty
applying except duration.
If you believe that you have a warranty claim, contact your Home
Center, Dealer, Plumbing Contractor or E-tailer. Please be sure to
provide all pertinent information regarding your claim, including a
complete description of the problem, the product, model number, the
date the product was purchased, from whom the product was
purchased and the installation date. Also include your original invoice.
For other information, or to obtain the name and address of the service
and repair facility nearest you, write Kohler Co., Attn: Customer Care
Center, Kohler, Wisconsin 53044 USA, or by calling 1-800-4-KOHLER
(1-800-456-4537) from within the USA and Canada, and
001-800-456-4537 from within Mexico, or visit www.kohler.com within
the USA, www.ca.kohler.com from within Canada, or
www.mx.kohler.com in Mexico.
THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. KOHLER CO. AND/OR SELLER DISCLAIM ANY
LIABILITY FOR SPECIAL, INCIDENTAL OR CONSEQUENTIAL
DAMAGES.
Some states/provinces do not allow limitations of how long an
implied warranty lasts or the exclusion or limitation of such
damages, so these limitations and exclusions may not apply to you.
This warranty gives the consumer specific legal rights. You may also
have other rights that vary from state/province to state/province. This
warranty is to the original consumer purchaser only, and excludes
product damage due to installation error, product abuse, or product
misuse, whether performed by a contractor, service company, or the
consumer.
This is Kohler Co.’s exclusive written warranty.
* Never use cleaners containing abrasive cleansers, ammonia, bleach,
Kohler Co. 15 1054180-5-H

Warranty (cont.)
acids, waxes, alcohol, solvents or other products not recommended for
stainless steel or polypropylene plastic. This will void the warranty.
1054180-5-H 16 Kohler Co.

Guide du propriétaire
Siège nettoyant avec réchauffeur
MESURES DE SÉCURITÉ
IMPORTANTES
LIRE TOUTES LES INSTRUCTIONS
AVANT UTILISATION
Lors de l’utilisation de produits électriques, et en particulier en
présence d’enfants, toujours observer les mesures de sécurité
fondamentales, notamment:
IMPORTANT! Risque d’endommagement du produit. Ne pas
installer ce produit dans un emplacement exposé à un excès
d’humidité et où de la condensation pourrait se former sur la
surface du produit. Fournir une ventilation adéquate lors des bains
afin d’éviter d’endommager les composants électroniques en raison
de niveaux d’humidité élevés.
IMPORTANT! Risque d’endommagement du produit ou de
dommages matériels. Des fuites d’eau pourraient se produire si l’on
pousse ou tire sur le raccord d’eau.
IMPORTANT! Risque d’endommagement du produit. Ne pas
appliquer de force excessive sur les baguettes de vaporisation.
IMPORTANT! Risque d’endommagement du produit. Prendre les
mesures nécessaires pour maintenir les tuyaux au chaud dans les
régions où l’eau pourrait geler dans les tuyaux. Toute l’eau qui reste
dans le siège pourrait geler pendant l’entreposage en hiver. Laisser
le dispositif se réchauffer à la température ambiante avant de le
réinstaller ou de l’utiliser.
IMPORTANT! Risque d’endommagement du produit. Ne pas
fournir d’alimentation électrique au dispositif avant d’avoir effectué
le travail d’installation de la plomberie, étant donné que cela
pourrait créer des problèmes de fonctionnement.
REMARQUE: Les protecteurs thermiques pourraient se déclencher
pendant l’entreposage ou le transport par temps chaud, et le
Kohler Co. Français-1 1054180-5-H

MESURES DE SÉCURITÉ IMPORTANTES (cont.)
dispositif ne fonctionnera pas. Laisser le dispositif se refroidir à la
température ambiante avant de l’installer ou de l’utiliser.
DANGER: Pour réduire le risque d’électrocution:
Ne pas placer ou entreposer ce produit dans un endroit où il
pourrait tomber ou d’où il pourrait être tiré et tomber dans une
baignoire ou un lavabo.
Ne pas placer et ne pas laisser tomber ce dispositif dans de l’eau
ou un autre liquide.
Ne pas essayer de récupérer un produit qui est tombé dans de
l’eau. Débrancher le dispositif immédiatement.
AVERTISSEMENT: Pour réduire le risque de brûlures,
d’électrocution, d’incendie ou de blessures personnelles:
Il est nécessaire de superviser de près lorsque ce produit est
utilisé par des enfants, des personnes âgées ou invalides, ou
lorsqu’il se trouve dans leur proximité. Ajuster la température du
siège pour les personnes âgées, les personnes frappées
d’incapacité, ou les personnes dont la peau est sensible.
Utiliser ce produit uniquement pour l’usage auquel il est destiné,
tel que décrit dans ce manuel. Uniquement utiliser des accessoires
recommandés par Kohler Co.
Ne jamais faire fonctionner ce produit si son cordon ou sa prise
sont endommagés, s’il ne fonctionne pas correctement, s’il est
tombé, s’il est endommagé, ou s’il est tombé dans de l’eau.
Retourner le produit pour le faire examiner et réparer.
Tenir le cordon à distance de surfaces chauffées.
Ne jamais bloquer les ouvertures d’air du produit et ne jamais le
placer sur une surface molle, comme un lit ou un divan, à un
emplacement ou les ouvertures d’air pourraient être bloquées.
S’assurer de l’absence de peluches, de cheveux ou d’autres
éléments similaires sur les ouvertures d’air.
Ne jamais utiliser ce dispositif lorsque l’on dort ou si l’on se sent
somnolent.
Ne jamais faire tomber ou insérer un objet quelconque dans une
ouverture ou un tuyau.
Ne pas utiliser ce dispositif à l’extérieur et ne pas le faire
fonctionner en présence de produits aérosols ou si l’on administre
de l’oxygène.
1054180-5-H Français-2 Kohler Co.

MESURES DE SÉCURITÉ IMPORTANTES (cont.)
Connecter ce produit à une prise mise à la terre de manière
adéquate uniquement. Voir la section “Instructions de mise à la
terre”.
Ce produit est conforme aux conditions applicables de l’US 21
CFR, Chapitre 1, Sous-chapitre J, Hygiène radiologique.
CONSERVER CES INSTRUCTIONS
Kohler Co. Français-3 1054180-5-H

Instructions de mise à la terre
AVERTISSEMENT: Risque de choc électrique, d’incendie,
ou de blessures corporelles. Ce produit doit être mis à la
terre et connecté uniquement à un circuit nominal dédié de
120 V c.a., 60 Hz protégé par un disjoncteur de fuite de terre
(GFCI) ou par un dispositif à courant résiduel (RCD) de 15 A
minimum.
Ce produit doit être mis à la terre. En cas de court-circuit
électrique, la mise à la terre réduit le risque de choc électrique en
fournissant un câble d’échappement pour le courant électrique.
Ce produit est équipé d’un cordon muni d’un câble de mise à la
terre avec une fiche de mise à la terre. Cette fiche doit être
branchée dans une prise installée et mise à la terre de manière
adéquate.
DANGER: Risque de choc électrique. L’utilisation incorrecte
de la fiche de mise à la terre peut résulter en risque de choc
électrique.
S’il est nécessaire de remplacer le cordon ou la fiche, ne pas
brancher le câble de mise à la terre à l’une des bornes à lame
plate. Le câble avec isolation dont l’extérieur est vert avec ou sans
rayures jaunes est le câble de mise à la terre.
Vérifier auprès d’un électricien qualifié ou d’un dépanneur si les
instructions de mise à la terre ne sont pas bien comprises ou en
cas de doute sur la mise à la terre adéquate du produit.
Ne pas utiliser de cordon de rallonge avec ce produit.
Prise mise
à la terre
Fiche de mise
à la terre
1054180-5-H Français-4 Kohler Co.
