Kohler KT001-MF User manual

Installation Guide
产品安装使用说明书
KOHLER CHINA INVESTMENT CO., LTD NO.158, JIANG CHANG SAN ROAD,
JINGAN DISTRICT, SHANGHAI, PRC POST CODE: 200436
上海市静安区市北工业园区江场三路158号邮编：200436
1426810 -T01-B
Aquifer Kit Water Filtration KT001-MF
奥珂芬厨房微滤净水器
K-27829T-KT001-01R
K-27829T-KT001-01R
Polypropylene Filter
扫码购滤芯
滤芯型号：
K-27830T-01R
年月 日
更换时间记录
更换周期 6-12个月
K-27829T-KT001-01R
Aativated Carbon Filter
。
扫码购滤芯
滤芯型号：
K-27830T-01R
6-12
*使用本产品前请仔细阅读本说明书并且严格按照说明书操作，并请妥善保管以备需要。
© Copyright Kohler China Investment Co., Ltd.
© 版权为科勒（中国）投资有限公司所有
FREE SERVICE HOT LINE: 800 820 2628 MOBILE:[phone] (China area only)
免费服务热线：800 820 2628 手机用户：400 820 2628（仅限中国地区）

BEFORE YOU BEGIN 安装之前
ROUGHING-IN & Structure Drawing 尺寸图 & 结构图
This document contains important information and details
concerning product installation, operation and maintenance.
Please read it carefully prior to installation and obey all the
instructions during operation.
•Do not use with water that is microbiologically unsafe or
of unknown quality without adequate disinfection before
or after the system.
•Make certain that installation and connectors must
comply with local plumbing codes.
•Installation and maintenance must be done by qualified
plumbing professionals designated by dealers
authorized by Kohler.
•For cold water use only (Temperature Range: 5-38˚C);
This filter must be protected from freezing, which can
cause cracking of the filter and water leakage. Drain
filter when room temperature drops below 5˚C.
•Pressure Range: 100-700 kPa, If water pressure
exceeds 700 kPa, please install pressure limiting valve.
Otherwise, the ultrafiltration membrane may not achieve
best filtration effect due to long time overpressure.
(Please consult plumbing professionals or dealers
authorized by Kohler for water pressure measurement).
• Do not install where water hammer conditions may
occur. If water hammer conditions exist you must install
a water hammer arrester.
• Do not install in direct sunlight outdoors or where
blowtorch or other high temperature sources are nearby.
• The filter must be installed with the inlet, outlet and self-
cleaning ports as labeled. Make sure not to reverse
connections.
• Before your installation make sure cold water valve is
turned off under the sink.
• Water filtration faucet is not supplied with the product.
you will need to purchase a water filtration faucet with a
1/4" adapter.
UNIT: mm
单位：毫米
Reference Value
参考值
Kohler reserves the right to change marked dimensions without prior notice.
科勒公司保留随时变更图中标示尺寸的权利，无需另行通知。
-1-
1426810 -T01-B
此说明书包括重要的安装、使用、维护方面的内容及细节，请
在安装和使用本系统之前请阅读并遵守此用户安装使用说明。
•本系统禁止过滤有微生物污染或未经消毒的水质不明的水。
•确保所有管路安装过程及连接件符合当地管道施工标准规
范。
•本系统必须委托科勒授权的安装维护人员进行安装及维护。
•本系统必须安装在冷水管道（工作水温为 5-38 摄氏度）；
当室温低于 5摄氏度时应该检查水路，并排干净水器停用，
防止水在净水器内部结冰膨胀。
•本系统最佳过滤效果工作水压为 0.1-0.4MPa ，如果安装处
水压超过 0.7MPa ，必须加装减压阀。（测量水压请咨询科勒
业维修人员 ）
•本系统应尽量避免长期安装在有强水锤的地方，如存在水
锤现象必要时请加装水锤消除器。
•本系统禁止放置在阳光直射、室外或高温（喷灯等）作业
器材周围。
•请按照进出水及自清洗口方向标识进行净水器安装。
•安装前请确保关闭橱盆下的冷水供水阀。
•本系统无专配净水龙头，请消费者自行选购净水龙头，并
保证净水龙头进水口连接尺寸为 2分管快接接头。
240 125
396
聚丙烯滤芯
PP Filter
前置滤壳
Filter Housing
顶盖
Top Cover
基座 I
Main Base I
活性炭棒
Activated Carbon
后置滤壳
Filter Housing
基座II
Main Base II
授权的专

-2-
1426810 -T01-B
GETTING STARTED 准备安装
Main Base
Filter Cartridge Level1
Filter Cartridge Level2
Packaging List
Main Parts Included:
装箱清单
本系列产品的主体部件清单：
所备工具及物料（自备）
主体基座
第一级滤芯
第二级滤芯
Other Parts Included:
Water SupplyT- Valve (1 pcs)
1/4" PE Tubing (2 pcs)
Pipe Clip (2 pcs)
Screw (2 pcs)
Plastic Expand Wall Plug (2 pcs)
Installation Guide & Service Parts Page
&Compliance Certification
本系列产品的配件清单：
供水三通阀（1个）
2分PE 软管（2根）
快接管插片（2个）
螺丝（2个）
入墙膨胀管（2个）
说明书，维修零件图与合格证
Tools &materiel required (not included)
Assorted
Screwdrivers
各式螺丝刀
UtilityKnifeor
Tubecutter
美工刀或切管器
Thread
Sealant Tape
食品级生胶带
Towels
擦布
Pencil
铅笔
Adjustable
Wrench
活动扳钳
Measure Tape
卷尺
Drill
电钻
4 7 85 6 9
1
2
3

-3-
1426810 -T01-B
INSTALLATION 安装步骤
Step 1 Pre-install Water Filtrattion Faucet
Note: Please pre-install Water filtration faucet of Kohler brand
or other brands on the sink. (Refer to Water filtration Faucet
Installation Manual for tools and detailed installation steps of
water filtration faucet. For water filtration faucet other than
Kohler brand, please make sure the inlet with a 1/4"
adapter). (Figure 1)
1. Make sure cold water supply line under the sink is turned
off.
2. Disconnect cold water line from threaded stub on bottom
of tap faucet.
3. Screw the water supply adapter - female threaded stub to
the cold water supply valve male threads as shown.
Hand it tighten and snug with wrench. Screw the female
threaded tap faucet stub to the water supply adapter.
(Figure 2)
1. 关闭原有的冷水供水阀并确认。
2. 已连接的自来水龙头进水管螺纹端口从冷水供水阀上拆
开。
3. 将三通转接内螺纹端口接到冷水供水阀外螺纹上，用活动
扳手拧紧；再将自来水龙头进水管内螺纹接头接到三通转
接外螺纹接口，用活动扳手拧紧。（图 2）
10
11
12
9
3
Figure 1
图 1
Figure 2
图 2
步骤一：选配净水龙头及接头安装
注意：请使用者确保在橱盆台面上安装固定好科勒牌或者自
行选配的净水龙头；（净水龙头安装所需工具及步骤请参照净
水龙头安装使用说明书，如非科勒牌的净水龙头，请确保净
水龙头连接口为 2分管快接接头。）（图 1）
Step 2 Mount the Filtration System
•Align the mounting holes of the filter head at the
determined mounting loaction, and mark it with a
permanent marker (hole spacing 200mm, height from the
ground > 430mm). Predrill the mounting holes, and
partially thread the Screws into the side panel of the
cabinet. Make sure there is a 4.5mm clearance between
the screw head and the side plate. Slide the filter head
over the Screws, and finish the installation. (Figure 3)
步骤二：把机器挂墙
•先确定机头的固定位置，用记号笔标记打孔位置，孔间距
200mm，离地高度 >430mm, 预先在标记位置上钻孔，将螺
丝部分旋入橱柜侧板，确保螺钉头部与侧板之间预留
4.5mm 的间隙，挂上机头，完成机头安装。（图 3）
Figure 3
图 3
4.5
200
>430

1426810 -T01-B-4-
Step 4 Installing or Replacing Filter Cartridge
NOTE: Before changing the filter, please make sure the cold
water valve is turned off.
•Remove and discard the dustproof cap (sanitary
protective cap) and Rubber stopper from the cartridge;
•Verify both O-Rings are present and positioned correctly
in the grooves;
•Push the filter cartridge Leve1 (Align the Color matching
icon) into the filter base on the left side and the filter
cartridge Leve2 (Align the Color matching icon) on the
right side, then turn cartridge clockwise until it fully
installed. (Figure 7)
步骤四：安装更换两级滤芯
注意：每次更换滤芯之前，请关闭冷水进水阀。
•去掉滤芯头部的防尘盖和橡胶塞。
•检查所有涉水部件的 O型圈无缺失脱落且在原有位置。
•把第一级和第二级滤芯根据本体上的颜色分别装入其左侧
和右侧，顺时针旋转直到到位。（图 7）
Step 3 Making connections
•Insert the 1/4" PE tubing in to the system inlet port (IN)
and the water supply T-valve for inletwater; Insert the
another 1/4" PE tubing into the filter outlet port (OUT)
and the end of the Water filtration faucet. (Figure 4)
步骤三：管路连接
•用PE 软管连接供水三通阀和设备进水口（IN），另一根 PE
软管连接设备出水口（OUT）和净水龙头接头端。（图 4）
Note: Cut tubing straight with a utility knife, make sure there
are no cuts, nicks, flat spots or sharp edges as figure 4, If
any of these are present, cut the tubing again; Do not kink
tubing. (Figure5)
注意：用切割器切软管时切口应垂直管轴无毛刺，如管口粗糙
不平请重新切割；不要弯折软管。（图5）
Note: It may be difficult to release the tubing due to water
pressure when replacing service parts. In this case, please
shut off the cold water supply valve, turn on the Water
filtration faucet to depressurize and then try to release the
tubing again. (Figure 6)
注意：在更换配件需拔出软管时，系统通水后因水压原因拔管
比较困难，可以把冷水阀门关闭，净水龙头打开泄压再拔出软
管。（图6）
Figure 4
图 4
净水龙头
Water Filtration Faucet
净水管
Pure water Tubing
冷水供水阀
Cold Water Supply valve
供水三通阀
Water Supply T-valve
进水管
Inlet Tubing
Insert the clip
插入管夹
123
To Attach Tubing
插管
Push tubing in as far
as it can go
插入软管一直到底
Tubing must be inserted past
O-ring and hit backstop
确保软管通过O型圈，插到底
To Release Tubing
拔出软管
2
Pull out clip
拔出管夹
3
1
Push in collect to release tubing.
With collect held, pull tubing straight out.
按压卡环同时向外拔出软管
Figure 5
图 5
Figure 6
图 6
Figure 7
图 7
Correct Cut
正确切管
Incorrect Cut
不正确切管
Write the date
on the label.
更换滤芯后请在
此处写上更换日期
适用于科勒厨房净水器
K-27829T-KT001-01R
前置过滤棉滤芯
PolypropyleneFilter
有效拦截悬浮物、泥沙、铁锈、胶体
等固体杂质。
扫码购滤芯
滤芯型号：
K-27830T-01R
年月 日
更换时间记录
更换周期 6-12个月
适用于科勒厨房净水器
K-27829T-KT001-01R
高效活性炭滤芯
AativatedCarbonFilter
有效去除余氯、消毒副产物、异味、
有机物等有害物质
。
扫码购滤芯
滤芯型号：
K-27830T-01R
更换周期 6-12个月
年月 日
更换时间记录
Cap
防尘盖
Rubber stopper
橡胶塞
O-Rings
密封圈

-5-
1426810 -T01-B
Step 5 Test System
•Turn on the water filtration faucet.
•Slowly turn on the cold water supply valve, Run water to
flush trapped air.
NOTE: It is normal for there to be Residual air in the
System causing bubbles (temporary cloudiness) in the
water.
•Turn on the cold water supply valve and the water
filtration faucet, run water for a minimum of 20 minutes to
flush, The system installation is now complete and ready
to serve filtered water.
•Turn off the water filtration faucet, Keep the cold water
supply valve turned on for 10 minutes. Check all fittings
and tubings for leaks. If it leaks, see Troubleshooting.
• Complete the installation and cleanup.
步骤五：系统测试
•打开净水龙头。
•缓慢开启冷水进水阀门，排出空气。
注意：出水中有一些气泡引起的（暂时的暗色）是由于管
路中的残余空气引起的正常现象。
•打开净水龙头，持续冲水 20 分钟以上，本系统安装完成可
正常使用。
•关闭净水龙头后，保持冷水阀门打开，等待10分钟，检查
所有连接部件及管件有没有漏水情况，如有漏水情况，查
看常见故障排除表。
•完成安装并清理现场。
10min
Flush
冲洗
TROUBLE SHOOTING GUIDE
No. Symptom
1
2
Probable Cause Solution
Leaks at quick connect fittings.
Tubing is not pushed to the backstop.
Tubing is not straight and smooth.
Reinsert tubing into push-in fitting as
far as it will go.
Recut tubing.
4
5
6
7
No water flow from the water
filtration faucet.
Water flow from the water filtration
faucet becomes small.
Filtered water tastes strange or like
chlorine bleach.
The main water line valve is closed.
The tubing is crimped or sharp
bended.
The filtration cartridge is blocked.
Service life of carbon block cartridge
runs out.
Check and open it.
Keep the tubing straight.
Replace the cartridge.
Replace the cartridge.
3Leaks at quick tubing. Tubing is cracke or scratched Simply cut that portion away and
reinsert tubing into push-in fitting.
常见问题及处理
1
2
4
5
6
7
3
序号 故障现象 故障原因 解决办法
把软管重新插到底。
把裂开部分切掉重新插入快速接头。
更换滤芯。
更换滤芯。
把软管放直。
打开进水阀。
重新切平。
软管未插紧。
管子端口有毛刺或未切平。
软管有刮伤或裂痕。
进水阀关闭。
软管被弯折。
滤芯长时间堵塞。
活性炭滤芯失效。
快速接头漏水。
软管漏水。
净水龙头不出水。
净水龙头出水变很细小。
经过滤后的水有氯味或者口感有异味。

-6-
1426810 -T01-B
OPERATION INSTRUCTIONS 使用说明
Important Information in Using the System:
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after
thesystem.
•Before prolonged periods of non-use (suchasduringa
vacation) it is recommended that the cold water supply
valve be turned off. If it is more than one week, please
flushthe filter thoroughly for at least 5 minutes before
reusing it;
•If leaks occur and persist on system, please first turn off
the water supply valve. Call Kohler-Free Technical
Support line directly or your local distributor authorized by
Kohler;
•Please replace filter when prompted by the indicator.
系统使用注意事项：
本系统禁止过滤有微生物危害或没有经过消毒的不明水质的
水。
•如中途长时间（如假期外出）下使用，建议尽量关闭进水
阀门；超过 1周未使用，再次使用时请放水冲洗至少 5分
钟后再次使用。
•如发现系统漏水，请第一时间关闭进水总阀门，并联系科
勒公司或当地授权经销商上门。
•当使用时间达到建议更换周期后，请更换对应型号滤芯。
K-27830T-01R
K-27829T-KT001-01R
Replace cycle (6-12 months)
滤芯建议更换寿命（6-12 个月）
System Model
整机型号
Filter Cartridge
更换滤芯组
NOTE: Filtration performance varies depending on local
water quality and domestic water consumption.
注意： 本产品各级滤芯实际可使用寿命根据各地水质优劣及
家庭用水量不同会有变化。
PERFORMANCE DATA SHEET
In line with the requirements of the "Sanitary Standard for Hygienc Safety and Function Evaluation on Treatment
Devices of Drinking water --General Device"2001
符合《生活饮用水水质处理器卫生安全与功能评价规范 --一般水质处理器》（ 2001）的要求
Municipal tap Water →PolypropyleneFilter →Activated Carbon Filter →Purified Water
市政原水 →聚丙烯熔喷PP滤芯→压缩活性炭滤芯→ 净水
Aquifer Kit Water Filtration KT001-MF
奥珂芬厨房微滤净水器
2.0L/min
3000 L
P300 / P310
XIAMEN FILTERTECH.IND.CORP / 302-303, 307-308 Siming yuan, Tong'an District, Xiamen
厦门百霖净水科技有限公司 / 厦门市同安区工业集中区思明园 302-303、307-308 号
闽卫水字[2020] 0033号
Q31/0106000060C001 / 《科勒牌家用和类似用途饮用水过滤产品》
KOHLER CHINA INVESTMENT CO.,LTD/NO.58,Jiang Chang San Road,Jing'an District,Shanghai
科勒（中国）投资有限公司/上海市静安区市北工业园区江场三路158号
Municipal Tap Water
符合GB5749要求的市政自来水
0.1~0.7 MPa / 5~38°C
Kohler P300 Water Filtration / Kohler P310 Water Filtration
科勒牌 P300型厨房净水器 /
K-27829T-KT001-01RSKU
产品性能参数表
Description
产品描述
Name
产品名称
Model
产品型号
MOH Certificated System Capacity
额定总净水量
MOH Certificated Flow Rate
净水流量
Operation Pressure/Operation Temperature
工作压力/工作温度
Inlet Water Quality
进水水质
Outlet Water Quality
出水水质
Company Name & Address
产品责任单位及地址
Water Treatment Process
水处理工艺
Actual Production Factory & Address
实际生产企业及地址
Product Standard & Name
产品执行标准号&名称
Official Certification, No
卫生许可批件文号
P300：蓝色&绿色贴纸Appearance Difference
系列外观差异
第
P310：粉红&黄色贴纸
科勒牌 P310型厨房净水器
System function information:
This micro-filtration system use polypropylene filter and
activated carbon filter as purification unit to remove
Turbidity, Organic matters from municipal tap water.That
will help you to improve drinking water quality.
•产品功能：
此微滤系统以聚丙烯熔喷滤芯、压缩活性炭滤芯为净化单位，
对市政自来水中的浊度、有机物进行去除，帮助进一步提高
饮用水水质。

-7-
1426810 -T01-B
MAIN PARTS OR COMPONENTS 主要成分或部件
Main Parts or Components
主要成分或部件名称
Model
型号
P300 and P310
P300 型和 P310 型
滤芯名称
Unit Name
处理单元名称 型号规格
Amount
数量
Filtering Effect
过滤效果
Life Limit
使用年限
Polypropylene Filter
(前置过滤棉滤芯)
聚丙烯滤壳 Φ94mm × 311mm
1
一支
Effectively intercept
solid impurities such
as suspended solids,
sediment, rust, colloids, etc.
有效拦截悬浮物、泥沙、铁
锈、胶体等固体杂质
12
months
12 个月
Polypropylene melt-blown
聚丙烯熔喷 PP 滤芯
Φ63mm × 254mm
Aperture: 10µm
孔径：10µm
Polypropylene cap
聚丙烯端盖
Top: Φ 73mm × 45mm
上：Φ 74.5mm × 39.5mm
Bottom: Φ73mm × 45mm
下：Φ 74.5mm × 39.5mm
Activated Carbon Filter
(高效活性炭滤芯)
聚丙烯滤壳 Φ94mm × 311mm
1
一支
Effectively remove harmful
substances such as residual
oxygen, disinfection by-
products, odors, organic
matter, etc.
有效去除余氧、消毒副产物、
异味、有机物等有害物质。
12
months
12 个月
Compressed activated carbon
压缩活性炭
Φ63.5mm × 254mm
Aperture: 5µm
孔径：5µm
Polypropylene cap
聚丙烯端盖
Top: Φ 73mm × 45mm
上：Φ 73mm × 45mm
Bottom: Φ74.5mm × 39.5mm
下：Φ 74.5mm × 39.5mm
Polypropylene filter housing
PP filter
Polypropylene filter housing
Specifications
压缩活性炭滤芯
聚丙烯熔喷PP滤芯
Filter Name
碘吸附值≥ 1050mg/g
Iodine sorption value：
≥1050mg/g

1426810 -T01-B
微信扫码，了解更多产品详情
追 溯 码
