*使用产品前请仔细阅读本说明书并且严格遵照说明书操作, 并请妥善保管以备需要。
安装使用说明书
Installation Guide
KOHLER Central-Filter LISON Series
21729T-PP020-01R/21729T-PP010-01R
©版权为 科勒(中国)投资有限公司 所有
© All Copyright for KOHLER (China) investment Co., Ltd.
135671 -T01-B

1356717-T01-B -3-
目录
一、 ........……………………………………………………3
二、 性能介绍………………………………..…………………………3
三、 结构示意图……………………………………………………….4
四、 包装内清单……………………………………………………….4
五、 注意事项………………………………………………………..
..
..
…5
六、 安装指南………………………………………………………… 6
七、 安装/更换滤芯…………………………………………….……7
八、 常用故障诊断及解决方法…………………………….….8
九、 帮助………………………………………………………………… 8
十、 产品保修服务……………………………………………. ..
..
…… 9
十一、 主要技术参数……………………………………………….… 10
TABLE OF CONTENTS
1. KOHLER WATER SOLUTION INTRODUCTION
2. PERFORMANCE INTRODUCTION
3. SCHEMATIC DIAGRAM
4. PACKING LIST
5. CONSIDERATION
6. INSTALLATION INSTRUCTION
7. FILTER CARTRIDGE REPLACEMENT
8. COMMON FAILURE DIAGNOSIS
9.
PRODUCT WARRANTY SERVICE
10.
HELP
11. PRODUCT SPECFICATIONS
一、
科勒牌管道净水器以市政自来水为原水，经滤芯过滤净
化处理后，制得符合卫生部《生活饮用水质处理器卫生
安全与与功能评价规范—一般水质处理器》(2001)要求
的饮用水。
二、
性能介绍
适用水质范围: 市政自来水，符合GB5749-2006
氯余除去效长，量通大
采用表面孔分布更均匀，吸附面积更广，性能更强，
效率更高的炭纤维材质。
1.PRODUCT FUNCTION
Thank you for choosing KOHLER Water product, LISON series
is complying with the (Sanitary Standard for Hygienic Safety
and Function Evaluation on Treatment Device of Drinking
Water Filter - General Devices) (2001 Edition) on drinking
water purification.
2. PERFORMANCE INTRODUCTION
Applicable range: Municipal Tap Water
Large flux, long effect removal of residual chlorine by
KOHLER ACF media is an optimized design with uniform
surface area, wider adsorption area, higher performance
and higher efficiency.
可随时访问 www.KOHLER.com.cn或关注微信公众号以了
解更多关于科勒净水
Visit our website at www.KOHLER.com.cn or follow Wechat
MP for more information/products
微信扫一扫
关注科勒净水
产品功能
产品功能

1356717-T01-B -4-
三、结构示意图
3. SCHEMATIC DIAGRAM
四、包装内清单
净水器
1X
滤芯
1X
扳手
1X
说明书
1X
合格证
1X
螺纹连接件
2X
固定支撑板
1X
选配
4.PACKING LIST
CENTRAL-FILTER UNIT 1X
FILTER CARTRIDGE 1X
WRENCH 1X
USER GUIDE 1X
COMPLIANCE CERTIFICATION 1X
FITTING CONNECTOR 2X
FIXED BRACKET 1X Optional
滤瓶盖(含Ø1”旁通阀、减压
钮 )/CAP (Ø1”Bypass,Air releaser)
O型密封圈/O-RING
滤瓶/HOUSING
螺纹接头 (Ø1” NPT转 ؾ”外螺
纹)/FITTINGS (1”NPT to G3/4)
扳手/WRENCH
滤芯/FILTER

-5-
五、注意事项
Δ警告
Δ 本产品需避免霜冻，否则会发生破裂泄露。
Δ
O型圈对滤瓶起密封作用，请确保将其正确放置于
滤瓶瓶口凹槽处，否则会发生漏水。
Δ 该产品滤瓶一般使用寿命约为5年。为保证过滤效
果，请务必选择KOHLER牌该产品匹配的滤芯使
用并定期更换滤芯。
‼注意
‼本产品仅适用家用室内并安装在冷水管道上、建议
安装于水表后。
‼ 本产品最大工作压力为0.4MPa，
若家中管道压力大于0.4MPa，请务必在产品前加
装减压阀以确保产品工作正常。
‼ 若长时间停用本产品，如假期等。建议彻底、反复
冲洗5~6分钟后再开始适用。
‼ 如发现后端出水有腐败发霉沉淀的现象，请立即关
闭水龙头，并与服务商联系。
‼ 请使用Teflon生料带（优质生料带）缠绕在密封接
头处以确保密封性。切勿使用管材专用料（管外壁
涂料）、黏贴物或类似的化合物，因其所含成分会
导致滤瓶材质破损、开裂。
‼ 请勿将产品放置或安装在明火或发热的物体旁。
‼ 请在安装时佩戴护目眼镜。
维护保养
使用水源应符合市政自来水要求；
请勿将产品放置在阳光直射处；
建议6~8个月更换滤芯（可视使用频率及水质而延长
或缩短）；
请用肥皂和清水清洁滤瓶及配件， 清洁时请取出滤芯，
禁用洗涤剂和强挥发性溶剂清洗。
5. CONSIDERATION
ΔPRECAUTIONS
Δ
This filter must be protected from freezing, which
can cause cracking of the filter and water leakage.
Δ
Because of the product’s limited service life and to
prevent costly repairs or possible water damage, we
strongly recommend that the housing be replaced
every five years. If the cap of the housing has been in
use for longer than this period, it should be replaced
immediately. Date the top of any new cap to indicate
the next recommended replacement date.
‼CAUTION
‼For household and cold water use only.
‼
Your water filter housing will withstand up to 100PSI
water pressure. If your house water supply pressure
is higher than 100PSI, install a pressure reducing
valve before the unit is installed.
‼
After prolonged periods of non-use (such as during
a vacation), it is recommended to thoroughly flush
the filter. Let water run for 5~6 minutes before using.
‼ Please use the Teflon sealant to wrap around the
sealing joint to ensure the tightness. Do not use
special materials for pipes (external wall coating),
adhesive or similar compounds, because their
ingredients will cause damage and cracking of filter
bottles.
‼Please do not place or place products in open fires
or heated objects.
‼
Please wear safety glasses to protect eyes when
drilling.
MAINTENANCE HINTS
sure always using municipal water supply.
Please keep product be installed or stand in a cool
area that is not in direct sunlight.
Changing your filter regularly ensures that you have
healthier, clear water.
Clean product, housing and O-ring with a mild detergent.
Do not use abrasive cleaners. Rinse well.
1356717-T01-B

1356717-T01-B-6-
六、安装指南
选择自来水管路上的一个合适的位置来安装净水器。
也要考虑这个位置在更换滤芯时是容易且可操作的。
只连接冷水管道。
测量现有管道的直径，以确定需要什么尺寸的配件或
阀门（不包括在内）。
所需工具及物料（需自备）:
扳手/尺/电钻/防护镜/生胶带;
关闭供水管道水源及打开最近的水龙头以放尽管道内
的压力和余水。
用生料带按照顺时针方向缠绕螺纹连接件5~10圈。将
螺纹连接件拧入滤瓶盖，再用扳手拧牢（切勿过紧，
确保至少一圈螺纹可见。）
遵照滤瓶盖上箭头（FLOW）所指的水流方向（切勿
装反!），将进出水连接件与管道连接。
备注:
需根据安装环境、条件决定具体操作步骤（视实际情
况可能需要更多的连接件！）
推荐在进水和出水处安装阀门以利于维护！
打开进水开关。慢慢将瓶盖上的旁通阀逆时针方向转
动二分之一圈以确保管道冷水进入。然后按下瓶盖上
的红色减压钮释放瓶内空气，打开最近的水龙头冲洗
5分钟。
6. INSTALLATION INSTRUCTIONS
Choose a location on the water line to install the filter.
Select a location that will be easily accessible when
changing filter cartridges.
Connect to cold water line only.
Measure the diameter of the existing pipe to determine
what size fittings and/or valves (not included) will be
required.
You should prepare tools for installation (adjustable
wrench, tape measure, E-drills, safety glasses, plumbers
tape)
Turn-off water supply line and turn on nearest faucet and
drain lines completely.
Apply plumbers tape to fittings and cap and lines, measure
overall length of configured housing cap, hang housing cap
on pipes, make all connections and tighten fittings.
(DO NOT OVERTIGHEN)
Follow the arrow direction (FLOW) of the filter cap (do not
install the reverse), connect the inlet and outlet connector
to the pipe.
Remarks:
The specific operation steps should be decided according
to the installation environment and conditions.
It is recommended to install valves in inlet and outlet to
facilitate maintenance!
Slowly turn on the water supply and turn off bypass, Press
the red pressure-relief button on top of the cap to release
any trapped air, flush for 5 minutes by keeping the nearest
faucet turned on.
Turn off faucet and ensures no leakage.
关闭水龙头后检查，确保无漏水现象。

1356717-T01-B-7-
七、滤芯安装/ 更换
滤芯的使用寿命取决于当地水质情况及处理水量。具
体的更换周期请参考规格说明，若出水量明显减少或
净水效果明显下降时，请尽快更换滤芯。
顺时针方向旋转二分之一圈旁通阀至停止过滤（此时
水流直接经过滤瓶盖以确保正常供水）使用扳手旋转
拧下滤瓶，后视情况清洗其内部。
取下O型圈，清洁以备用。
将滤芯取出后按指引处置，用硅脂润滑O型圈后
装回凹槽处，并用手指压平。
将新滤芯装入滤瓶中。
将滤瓶瓶身适当拧入瓶盖中。（切勿过紧！）
将旁通阀逆时针慢慢旋转二分之一圈令原水经过
滤芯以确保过滤。按下减压钮以释放瓶内空气。
打开最近的水龙头适当冲洗5分钟后即可使用
（在离开安装现场前，务必确保无泄漏）
备注：安装或更换滤芯情况需根据客户安装滤瓶
的实际情况决定。如滤瓶无法移动以及其下方无
操作空间，可能会需要移出滤瓶再拆卸或更换滤
芯。
7.FILTER CARTRIDGE REPLACEMENT
The cartridge’s life depends on the local water quality and
the amount of water it purifies. Please refer to the
specification for the specific replacement cycle. Please
replace the filter if the amount of water is significantly
reduced or the effect of water treatment is significantly
reduced.
Rotate 1/2 laps clockwise to turn on bypass, use the
wrench to unscrew filter housing, rinse it after remove the
housing.
Remove and wipe clean O-ring, lubricate O-ring with
silicone grease, return O-ring and seat securely.
Insert new Filter over standpipe in bottom of housing,
attach housing to cap and hand tighten, using the wrench
tighten (DO NOT OVERTIGHEN)
Slowly turn off bypass, Check for leaks between cap and
housing, Press red pressure relief button to release
trapped air. Open the faucet and flush for 5 minutes.
(Ensures no leakage before you left field).
Note: Installation or replacement of filter element
should be decided according to the actual situation
of filter installation.

1356717-T01-B-8-
八、常见故障诊断
故障现象 故障可能的原因 故障解决方法
净水器瓶盖与瓶身
之间泄露
O型圈破损或位置
不对
1. 关闭供水水源，按下瓶盖上的红色减压钮以释放管道内压力和空气，再拧拆
下滤瓶
2. 清洁O型圈及其凹槽，若O型圈变形、磨损严重，请更换新的。用食品级硅脂
润滑O型圈后正确置于其凹槽内。拧上滤瓶盖，切勿过紧
3. 打开供水水源。若依旧泄露或出现其他泄露，请关闭供水水源后联系KOHLER
当地服务处的专业人员以维修
净水器进出水口连
接件的泄露
接头没拧紧 1. 关闭供水水源，按下瓶盖上的红色减压钮以释放管道内压力和空气，将螺纹连
接件旋转二分之一圈以紧固
2. 打开供水水源。若依旧泄露或出现其他泄露，请关闭供水水源后联系KOHLER
当地服务处的专业人员以维修
出水仍然有漂白水
味
1.滤芯未安装到位 1.关闭供水水源，按下瓶盖上的红色减压钮以释放管道内压力和空气，检查滤芯是
否破损和磨损，并按正确方法安装
2.旁通阀开启 2.按使用说明，关闭旁通即可
后端出水明显变小 滤芯已堵塞
请更换滤芯
8.COMMON FAILURE DIAGNOSIS
Problem Desc. Possible Causes Solutions
Leakage between
cap and housing
O-ring breakage
or position
misalignment
1.Turn-off the water supply, press the red relief button on the cap to release the
pressure and air in the pipe, and then unscrew the filter housing.
2.Lubricate O-ring and clean groove, return O-ring and seat securely. If the O-ring
is deformed and worn seriously, please replace with new one, attach housing to cap
and hand tighten, using the wrench tighten. DO NOT OVERTIGHEN.
3.Turn on water supply. If there is still leakage or other leaks, please turn off the water
supply and contact the KOHLER local service.
Leakage of Cap
inlet and outlet
connectors
Fittings are not
tightened
1.Turn-off the water supply, press the red relief button on the cap to release the
pressure and air in the pipe, rotate the threaded connector 1/2 times to tighten it.
2.Turn on water supply. If there is still leakage or other leaks, please turn off the water
supply and contact the KOHLER local service.
The filtered water
still has bad smell
Filter cartridge is
not installed in
place
pressure and air in the pipe, Checkif the filter cartridge is damaged and worn,
and install it in the correct way
Bypass is turn on
Flow rate decreases
significantly
Filter cartridge is
seriously blocked
Replace the filer cartridge.
九、帮助 9. HELP
问题
/Question
说明
GUIDE
产品是否可以当软
水机使用
Whether this water
filter can be used
as a water softener
本产品是设计用来净化家中的自来水，并无
软化水的功能。如果您欲享受软水的呵护，
强烈建议您配置科勒软水机，您可以关注微
信公众号或科勒净水零售点以获得软水机产
品信息。
This central-filter is designed to reduce sediment and
filter tap-water only. To get the soft-waterplease
consider installing a softener system that is certified
to conditioning the hardness of water!
哪里可以购买到替
换滤芯
Where can I buy
a replacement
filter
您可以关注微信公众号或科勒净水的各个零
售点购买到替换滤芯。
滤芯对应的型号是:
10寸轻量款产品适用21731T-R1-01R
10寸轻量款产品适用21731T-R1-01R
20寸超量款产品适用21732T-R1-01R,
Replacement Filter Cartridge：
LIGHT USER (10”): 21731T-R1-01R
HEAVY USER (20”): 21732T-R1-01R

1356717-T01-B-9-
十、产品保修服务指南
科勒为其产品在正常家庭使用情况下提供自购买
之日起3年的保修(但必须以付款收据作为凭证)，
有关详细的保修条件，请参阅包装盒内的单独保
修卡，如果您需要服务或者更多信息，又或者有
任何疑问，您可以关注我们的科勒净水公众号，
又或者在 上咨询我们的在线
支持，或致电科勒客服热线（400 820 2628）。
www.kohler.com.cn
记得定期更换滤芯以获得健康、清澈的净化水！
科勒净水将持续为您提供值得信任的安全用水方
案。
10.PRODUCT WARRANTY SERVICE
Kohler warrants this water product to be free of
defects in material and workmanship during normal
residential use for three years from date of purchase.
please refer to Warranty Sheet in packing for more
detail conditions.
Visit our website at www.KOHLER.com.cn or follow
Wechat MP for more information/products, or still
have questions? Or to locate retailers or visit
www.KOHLER.com.cn or call 400 820 2628
REMEMBER…
Change your filter about every 6 months for healthier,
clear water or when flow rate decreases significantly.
温馨提示
弃置产品时，请遵从垃圾分类指引，不要将其与一般生活垃圾放在一起，应将其交给政府指定的回收中心。这
样有利于环保。
科勒热线电话: 800 820 2628/400 820 2628 KOHLER Hotline: [phone] 820 2628
追溯码

1356717-T01-B -01-
十一、主要技术参数 11.PRODUCT SPECIFICATIONS
产品名称
Product Name
科勒中央净水器丽笙系列/ KOHLER Central-Filter LISON Series 配套滤芯 /CARTRIDGE
科勒牌TW010/HP010/PP010
型管道净水器
CENTRAL-FILTER FOR LIGHT USER:
MODEL: TW010/HP010/PP010
21731T-R1-01R
科勒牌TW020/HP020/PP020
型管道净水器
CENTRAL-FILTER FOR HEAVY USER:
MODEL: TW020/HP020/PP020
21732T-R1-01R
主要成分或部件
Key Media/Parts
聚丙烯滤壳 (1套）
HOUSING
聚丙烯/PP
复合滤芯(1套）
轻量款：
Ø182x422mm
轻量款：
4.18kg 超量款：
5.06kg
超量款：
Ø182x683mm
FILTER
Wet-forming AC element
湿式成型活性炭净水滤芯/ 5μm孔径/活性炭纤维
5MICRON/ACF
折纸/Pleated element 20μm孔径/涤纶纺粘热轧无纺布
20MICRON/Nonwoven fabric
产品尺寸
Product Dimension
LIGHT USER:
Ø182x422mm
HEAVY USER:
Ø182x683mm
产品毛重 Weight
LIGHT USER: 4.18kg HEAVY USER: 5.06kg
原水水质
Water source Reqr.
出水水质
Outlet Water Quality
符合GB5749-2006的市政自来水
符合《生活饮用水质处理器卫生安
全与功能评价规范—一般水质处理器》
(2001)的要求
Meet GB5749-2006 municipal tap water
Complied with “Sanitary Standard for Hygienic
Safety and Function Evaluation on Treatment
Device of Drinking Water Filter - General Devices)
(2001)”
轻量款：
6~12个月
超量款：
9~15个月
净水流量
Rated Purify Flow rate
TW010型: 0.8m³/h；HP010型: 1.0m³/h；
PP010型: 1.2m³/h；
TW020型: 1.4m³/h；HP020型: 1.5m³/h；
PP020型: 1.6m³/h
LIGHT USER:
[email protected];[email protected];[email protected]
HEAVY USER:
[email protected];[email protected];[email protected]
额定总净水量
Total Capacities
TW010型: 24m³；HP010型: 27m³；
PP010型: 30m³；
TW020型: 50m³；HP020型: 55m³；
PP020型: 60m³；
LIGHT USER: TW010-6340.8 gals;HP010-7133.4
gals;PP010-7926 gals
HEAVY USER: TW020-13210 gals;HP020-14530
gals;PP020-15852 gals
产品责任单位
Responsible by
科勒(中国)投资有限公司
上海市静安区江场三路158号
KOHLER CHINA INVESTMENT CO., LTD
No.158, Jiang Chang San Road, JING’AN, Shanghai
卫生许可批件文号
MOH#
闽卫水字(2018)第0132号 Water #0132 of Fujian HFPC (2018)
产品执行标准 Q31/0106000060C001
《科 勒牌 家 用 和 类 似 用 途 饮 用 水 过 滤 产 品》
实际生产企业及地址
De facto MFGer &Add.
欧兰普电子科技(厦门)有限公司
厦门火炬高新区(翔安)产业区翔
岳路35#厂房南楼西侧1-4层
Comefresh Electronic Industry Co.,Ltd
No.35, Xiang Yue Road, Torch Hi-tech Industrial
Zone, Xiang An, Xiamen
注意事项
NOTE
1.首次使用或长期停用后恢复使用时
按说明书要求进行冲洗;
2.按说明书要求定期冲洗、更换滤芯
1. Rinse according to the instructions after first use
or long-term discontinuation.
2. Regularly rinse and replace the filter cartridge as
required by the instructions.
滤芯寿命参考*
Cartridge Life Reference*
Filter LIGHT USER:
6~12 months
HEAVY USER:
9~15 months
*说明/
NOTE
净水流量等与当地水压、水质有关；
滤芯寿命与当地水质、家庭用水量有
关；
Flow rate dependent upon the local water
pressure, water quality.
Filter cartridge life is dependent upon local water
quality and household water consumption.
原水->折纸->湿式成型活性炭净水滤芯->净水
Raw Water->Pleated element->Wet-forming AC element->Purified Water
水处理工艺
Water Treatment Process
工作压力 Working Pressure
水温使用范围 Temperature
0.2~0.4MPa
4~38℃
