MISSION UNDER WINDOW BOOKCASE
Thank you for purchasing our Mission Under Window Bookcase. Assembly of this product
requires a Phillips screwdriver and a hammer.
DH29070201

STEP 1
Read through these instructions thoroughly. We
have found this to be of great value when first
assembling this product.
STEP 2
Remove all parts and hardware from packing
material. Place wooden parts on non-abrasive
surface (like carpet or carton) to prevent damage to
finish. Identify all parts using diagram at right.
PARTS
(2) Side Assembly (A)
(1) Fixed Shelf (B)
Top Shelf (C)
(1) Adjustable Shelf (D)
STEP 3
Identify and count hardware using diagram at right.
Assembly of this product requires a Phillips
screwdriver and a hammer. We have found it
helpful to have a second person assist with
assembly.
STEP 4
Lay one side assembly (A) on edge and attach fixed
shelf (B) to bottom end with two 1 1/4" screws.
Thread screws into countersunk holes in side
assembly and into edge of shelf.
STEP 5
Attach top shelf to side assembly with two 1 1/4"
screws. Thread screws into predrilled holes in side
assembly and into pre drilled holes in cleats on
underside of top shelf.
DH29070201

STEP 6
Attach second side assembly using same techniques
as in STEPS 4 and 5.
STEP 7
Stand unit upright. Tighten ALL screws securely.
Tap wooden plugs into holes in side assemblies with
hammer to conceal screws.
STEP 8
Place shelf pins in holes in side assemblies at
desired height of adjustable shelf. Insert adjustable
shelf (D) into unit, ensuring that shelf pins engage
grooves in underside of shelf.
CARE
Dust as needed with soft cloth. Clean with damp
cloth and mild solution of dish soap. Polish with
soft cloth and polish that contains no pigment or
silicone.
www.llbean.com
Product Support 1 800 341 4341
