L.L.Bean
StudioFuton
Thank you for purchasing our Studio Futon. We have found it helpful to have a secondperson
present inat least one step ofthe assembly. It is important to follow these instructions as the correct
sequencing and positioning of the legs during assembly is crucial for the proper operation of the futon
frame.

2
Identify all parts using the diagrams below.
Hardware Needed:
Carriage bolt (8) Washer (8) Wing Nuts (8)
Parts Needed:
Futon Body (A)
Seat legs (B)
Back legs (C)

CHOKING HAZARD: ADULT ASSEMBLY REQUIRED
3
1. Identify futon body (A) and seat legs (B) of the frame. There is a face plate on one side of the futon
body. This is the front of the frame. The bottom side of the futon body will have three (3) wooden
support braces attached. Lay the futon body bottom side up on a protected surface to protect the top
side of the frame.
2. The seat legs have one end that is wider than the other. Place
one seat leg on the inside of the outer support brace found
on the right side of the futon body. The narrower edge of the
seat leg should be facing towards the hinges and the wider
edge will rest against the face plate at the front of the frame.
Make sure the holes in the seat leg line up with the holes in
the support brace.
3. Starting from the inside , thread a carriage bolt through each of the two
holes in the seat leg and through the corresponding holes in the support
brace. Secure each with a washer and wing nut, but leave loose. Once
both carriage bolts have been threaded through the seat leg, go back and
tighten the wing nuts completely. The washers and wing nuts should be
facing the outside edge of the frame if installed correctly. Repeat steps 2
and 3 to attach the leg on the left side of the frame.
4. Carefully turn the frame over so that it is resting on the legs
installed in step 2 and step 3. Fold the back section of the
frame forward so it is resting on the seat portion of the frame.
5. Locate the back legs (C) of the frame.
6. The back legs have one end that has a large hole. Place one back
leg on the outside of the outer support brace found on the right
side of the futon body. The side of the back leg with the large
hole should be facing towards the hinges. Make sure the small
holes in the back leg line up with the holes in the support brace.

CHOKING HAZARD: ADULT ASSEMBLY REQUIRED
4
7. Starting from the outside , thread a carriage bolt through each of
the two holes in the back leg and through the corresponding holes
in the support brace. Secure each with a washer and wing nut, but
leave loose. Once both carriage bolts have been threaded through
the back leg, go back and tighten the wing nuts completely. The
washers and wing nuts should be facing the inside of the frame if
installed correctly. Repeat steps 6 and 7 to attach the leg to the left
side of the frame.
8. The futon frame is now assembled.
HELPFUL TIP: At this point the frame should fold and unfold easily. If this is difficult, refer back to
steps 2 through 7 to make sure the carriage bolts and legs were installed in the correct positions (to
allow for the necessary clearance).
9. To use the frame as a couch it is important to secure it
into the upright position. There are two large wooden
dowels attached to the back of the frame. Insert these
dowels partway into the large holes in the back legs of
the frame.
CARE: Clean with a soft, clean cloth.
L.L.Bean
www.llbean.com
Product Support 1 800 341 4341
