L.L.Bean OTNQ3 User manual

1 of 3 6/27/17
Pntd Frmhs 2 Shelf End Table
Painted Farmhouse 2 Shelf End Table - OTNQ3 &
OTNQ4
Thank you for purchasing our 2 Shelf End Table. It is helpful to have a second person availble during the assembly of this product.

2 of 3 6/27/17
Pntd Frmhs 2 Shelf End Table
STEP 1
Identify and count all parts using diagram above.
STEP 2
Identify and count hardware.
Lay out parts on a non-abrasive surface to avoid scratching finish.
1
F
8
M6*45MM
BOLT
E
QTY.DRAWING DESCRIPTIONNO.

3 of 3 6/27/17
Pntd Frmhs 2 Shelf End Table
STEP 3
Position Top Assembly (A) upside down on non-
abrasive surface. Attach 2 Post (B) using 2 M6 *
45MM Bolts (E). Use Wrench (F) to install Bolts.
Do not over tighten Bolts at this time.
Assemble Loose.
STEP 4
Align Shelf (D) with slots in Post (B). Attach 2
additional Post (B) using 2 M6 * 45MM Bolts (E).
Use Wrench (F) to install Bolts.
Do not over tighten Bolts at this time.
Assemble Loose.
STEP 5
Position Bottom Panel (C) between the 4 Post (B).
Attach Bottom Shelf (C) to Post using 4 M6 *
45MM Bolts (E). Use Wrench (F) to install and
tighten all Bolts.
At this point tighten all assembly Bolts.
STEP 6
Position assembled case upright.
CARE: Clean with mild soap and wipe dry.
