RAMP MODULES
Laird RAMP (Range Amplified MultiPoint) modules are designed to provide robust wireless communications for
any number of applications requiring a wireless transport for serial data. RAMP modules feature a Frequency
Hopping Spread Spectrum (FHSS) protocol for excellent interference and multipath immunity. RAMP modules
server/client architecture allows for more than 16 million clients to be addressed and communicating within the
network.
The RM024 RAMP module improves upon Laird’s 2.4 GHz RAMP predecessors by lowering power consumption
through the use of three different sleep mode options, an improved link budget, the ability for close proximity
operation at low power, and the inclusion of a switchable antenna output (RM024-xxxx-M-yy versions only).
The RM024 is available in two versions:
RM024-S125-x-xx/RM024-P125-x-xx –Contains 125 mW maximum conducted output power which is
approved for North American and similar markets.
RM024-S10-x-xx/RM024-P10-x-xx –Contains 10 mW maximum conducted output power which is
approved for European and similar markets.
These modules are identical except for output power, transmit power consumption, and the number of RF
channels available. Differences between the two versions, where applicable, are denoted based on part number.
This document contains information about the hardware and software interface between a Laird RM024
transceiver and an OEM host. Information includes the theory of operation, specifications, interface definitions,
and mechanical drawings.
Note: Unless mentioned specifically by name, the RM024 modules are referred to as module, radio, or
transceiver. Individual naming is used to differentiate product specific features. The host
(PC/microcontroller/any device to which the RM024 module is connected) is referred to as OEM
host or host.
Key Features
Retries and acknowledgements
Configurable network parameters
Multiple generic I/O
280 kbps or 500 kbps RF data stream
Idle current draw of 9.5 mA, sleep current of <1 uA (varies depending on sleep mode)
Software-selectable interface baud ranging from 1200 bps to 230.4 kbps
Upgradable FW through serial port
Low cost, low power, and small size ideal for high volume, portable, and battery powered applications
All modules are qualified for Industrial temperatures (-40°C to 85°C)
Advanced configuration available using Laird’s Command Interface
Easy-to-use Laird Configuration and Test Utility software
Switchable antenna output, either integrated antenna or external antenna through U.FL (RM024-S125-M,
RM024-P125-M, RM024-S10-M, and RM024-P10-M radios only)

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
5
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Detailed Specification
Table 1: Specifications table
General
Form Factor
SMD-ANT+U.FL, Pluggable-ANT+U.FL, SMD-U.FL, Pluggable-U.FL
Antenna
Dual antenna with integrated antenna and U.FL or
External antenna through U.FL connector
Serial Interface Data Rate
Baud rates from 1200 to 230400. Non-standard baud rates are also
supported.
Channels
FCC –42 or 78 selectable channels
CE –42 selectable channels
Security
Channelization, System ID, Vendor ID, and Extended System ID
Minimum Flash (EEPROM) Memory
Endurance
1000 Write/Erase cycles
Transceiver
Frequency Band
2400-2483.5 MHz
RF Data Rate (Raw)
280 kbps or 500 kbps selectable
Hop Bin Spacing
900 kHz over 79 hops
1500 kHz over 43 hops
RF Technology
Frequency Hopping Spread Spectrum
Modulation
MSK
Maximum Output Power
Conducted1
FCC –+5 to +21 dBm (selectable)
CE –+3.5 to +10 dBm (not selectable)
Supply Voltage
2.3-3.6 V ± 50 mV ripple
Current Draw
RM024 Version
FCC (125 mW)
CE (10 mW)
Tx Burst
136 mA
40 mA
Rx Active
36 mA
36 mA
Idle Current
9.5 mA
9.5 mA
PM2/Cyclic Sleep
0.9 µA
0.9 µA
PM3/Deep Sleep
0.38 µA
0.38 µA
Receiver Sensitivity (1% PER)
-95 dBm at 280 kbps RF data rate
-94 kBm at 500 kbps RF data rate
Range
(based on external 2.0 dBi antenna
at 280 kbps RF data rate)2
Outdoor (line-of-sight)
Indoor (estimated)
FCC
4 km (2.5 miles)
400 m (1300 feet)
CE
1.0 km (0.6 miles)
100 m (328 feet)
Environmental
Temperature (Operational)
-40°C to 85°C
Temperature (Storage)
-50°C to 150°C
Physical
SMD-Multi Antenna Dimensions
25.4 mm x 39 mm x 3.6 mm (1.0” x 1.54” x 0.14”)
SMD-U.FL Dimensions
25.4 mm x 32.4 mm x 3.6 mm (1.0” x 1.28” x 0.14”)
Pluggable-Multi Antenna
Dimensions
26.7 mm x 39.6 mm x 11.3 mm (1.05” x 1.56” x 0.44”)
Pluggable-U.FL Dimensions
26.7 mm x 33 mm x 10.6 mm (1.05” x 1.29” x 0.42”)

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
6
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Certifications
FCC –Part 15.247
KQL-RM024
Industry Canada (IC)
2268C-RM024
CE
Yes –RM024-x10-x versions
RoHS
Yes
Brazil (Anatel)4
None
1. Maximum output stated, step measurements for power could vary by +/- 2.0 dBm.
2. Range distances are estimates and vary with the installation environment. Measurements were taken
at 4.1 miles with a 5 dBi antenna for FCC modules.
3. See Regulatory Information in this guide.
4. Contact your sales representative for more details.
Pin Definitions
Table 2: RM024 pins
SMT Pin
Pluggable Pin
Type
Signal Name
Functions
1
7
O
GIO-0
Generic Output / Hop_Frame
2
6
O
GIO_1
Generic Output
3
8
DNC
Do Not Connect
4
17
O
GIO_2
RS485 Driver Enable
5
19
O
GIO_3
PWM Output
6
3
I
RXD
Asynchronous serial data input to transceiver
7
2
O
TXD
Asynchronous serial data output from transceiver
8
10
GND
GND
Signal Ground
9
1
PWR
Vcc
2.3 –3.6 V ±50 mV ripple (must be connected)
10
-
PWR
Vpa
2.3 - 3.6 V ±50 mV ripple (must be connected on
SMT version)
11
-
GND
GND
Signal Ground
12
9
I
Force 9600
/Sleep Interrupt
Force 9600 –When pulled logic Low and then
applying power or resetting, the transceiver’s
serial interface is forced to a 9600, 8-N-1 rate.
Sleep Interrupt –When taken Low, this pin wakes
the radio from any of the three sleep modes.
Note: Pulling this pin to GND disables some
modes of operation, therefore it should
not be permanently pulled Low during
normal operation.
13
14
I
GIO_4
Generic Input
14
5
I
µP_Reset
Reset –Controlled by the RM024 for power-on
reset if left unconnected. After a stable power-on
reset, a logic low pulse resets the transceiver.
15
11
I
CMD/Data
When logic Low, the transceiver interprets
incoming OEM host data as command data. When

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
7
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
SMT Pin
Pluggable Pin
Type
Signal Name
Functions
logic High, the transceiver interprets OEM host
data as transmit data.
16
15
O
In Range
When logic Low, the client is in range and
synchronized with a server. This is always Low on a
server.
17
16
I
RTS
Request to Send –Floats high if left unconnected.
When enabled in EEPROM, the module will not
transmit Serial UART data to the OEM Host unless
this pin is Low.
18
12
O
CTS
Clear to Send –CTS is used for hardware flow
control indication to the OEM Host. CTS toggles
high when the Serial UART RX input buffer reaches
the CTS On threshold and remains high until the
buffer recedes below the CTS Off threshold.
19
18
GIO_8
Generic Input
20
13
GIO_5
Reserved for future use. Do not connect.
21
4
GIO_6
Reserved for future use. Do not connect.
22
20
I
GIO_7
Analog to Digital input
Tips:
All I/O directions are referenced to Vcc.
All inputs are weakly pulled High via a 20 k Ohm pull-up resistor and may be left floating during normal
operation.
Minimum connections: VCC, VPA, GND, TXD, and RXD.
Signal direction is with respect to the transceiver.
Leave unused pins disconnected.
Input Characteristics
Table 3: Input characteristics
Signal Name
High Min.
High Max.
Low Min.
Low Max.
µP_Reset
0.8 v
Vcc
0 v
0.6 v
RTS
2.31 v
Vcc
0 v
.99 v
AD_In
N/A
Vcc
0 v
N/A
All other inputs
70% Vcc
Vcc
0 v
30% Vcc
Output Characteristics
Table 4: Output characteristics
Signal Name
High Min.
High Max.
Low Min.
Low Max.
Sink Current
GO_0
2.5 v
3.3 v
0 v
0.4 v
20 mA
GO_1
2.5 v
3.3 v
0 v
0.4 v
20 mA
PWM_Output
N/A
3.3 v
0 v
N/A
4 mA

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
8
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Signal Name
High Min.
High Max.
Low Min.
Low Max.
Sink Current
All other outputs
2.5 v
3.3 v
0 v
0.4 v
4 mA
Block Diagram
Figure 1: RM024 block diagram
Timing Specifications
Table 5: Timing specifications
Parameter
Server/Client
Min.
Typ.
Max.
Notes
Power on to CTS Low
5 ms
10 ms
N/A
The first boot after a FW
upgrade requires more than the
typical amount of time for CTS
to toggle Low.
EEPROM Read
800 µs
1 ms
2 ms
Measured from last byte of
command to first byte of
response:
870 µs for 1 byte;
1.1 ms for 80 bytes;
1.4 ms for 256 bytes
EEPROM Write
20 ms
30 ms
40 ms
Measured.
EEPROM writes cause the radio
to resynchronize.
Power on to In Range
Client only
13 ms
600 ms
1700 ms
Maximum time assuming all
beacons are heard; RF
interference could extend the
maximum time indefinitely.
Hop Period In Range
13.19 ms

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
9
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Parameter
Server/Client
Min.
Typ.
Max.
Notes
Hop Period Out of
Range
Client only
38.4 ms
Reset Pulse
250 ms
PWM Output Period
39.3846 µs
Restore Default
EEPROM Command
10 ms
38 ms
Restore command also initiates
a soft reset, so monitoring CTS
is the best indication of a
completed command.
Non-specific AT
Command
1 ms
10 ms
Some AT Commands could wait
indefinitely for a response.
Write Flash
For FW upgrade.
Read Flash
RF Hop Frame
The RM024 hops every 13.19 milliseconds and can be configured for two different RF data rates to provide
options for range or throughput. During each hop, the RM024 reserves a certain amount of time for overhead
such as the synchronization beacon, internal messaging, and user data transmission. The diagrams below outline
the various transmissions that occur during a hop. These transmissions are transparent to the user sending data,
but may be useful for applications that require critical timing. User data is only transmitted during the data slots
and after the Interface Timeout or RF Packet Size criteria has been met. Data transmission only begins at the
beginning of a data slot. When configured for Full Duplex, data slot 1 is reserved for the server and data slot 2 is
shared by all clients for transmissions.
Figure 2: RF hop frame diagram

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
10
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
HARDWARE INTERFACE
Pin Descriptions
RXD and TXD
The RM024 accepts 3.3 VDC TTL level asynchronous serial data from the OEM host via the RXD pin. Data is sent
from the transceiver, at 3.3 volt levels, to the OEM host via the TXD pin. Pins should be left floating or high when
not in use. Leaving the RXD tied low results in the radio transmitting garbage serial data across the RF.
Force 9600 /Sleep Interrupt
When pulled logic Low before applying power or resetting, the transceiver’s serial interface is forced to 9600,
8-N-1 (8 data bits, no parity, 1 stop bit) regardless of the actual EEPROM setting. RTS is ignored, the interface
timeout is also set to three milliseconds, and the RF packet size is set to the default size for the selected RF data
rate. To exit, the transceiver must be reset or power-cycled with the test pin logic High or disconnected. When
in Force 9600 mode, the radio’s receiver is disabled.
When enabled in the EEPROM, the 9600 Boot option causes the 9600 pin to be ignored on cold boot (power-up),
command boot (0xCC 0xFF), and brown-out conditions. Therefore, the 9600 pin is only observed on warm boots
(reset pin toggled). This can be helpful so that brown-out conditions don’t cause the baud rate to change if the
9600 pin happens to be low at the time. When 9600 Boot option is disabled, the 9600 pin is used for all boot
conditions. 9600 Boot option is enabled by default.
Force 9600 is also used to wake the radio from sleep. When the pin is taken low, the radio wakes. The
transceiver does not sleep if the pin is low when the sleep command is issued.
Note: Because this pin disables some modes of operation, it should not be permanently pulled Low during
normal operation.
µP_RESET
µP_Reset provides a direct connection to the reset pin on the RM024 microprocessor and is used to force a hard
reset. For a valid reset, reset must be asserted Low for an absolute minimum of 250 nanoseconds (ns).
Command/Data
When logic High, the transceiver interprets incoming serial data as transmit data to be sent to other
transceivers. When logic Low, the transceiver interprets incoming serial data as command data. When logic Low,
data packets from the radio are not transmitted over the RF interface, however, incoming packets from other
radios are still received. Enabling CMD/Data RX Disable in the EEPROM causes incoming RF packets to be queued
by the receiving radio while CMD/Data is low. When CMD/Data goes high, the data is sent over the serial
interface.
In_Range
The In_Range pin is driven low when a client radio’s frequency hopping is synchronized with that of a server.
In_Range is always driven low on a server. Following boot, In_Range transitions low in approximately 12
milliseconds on a server. For a client, the In_Range takes an average of 500 milliseconds; this time is dependent

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
11
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
on the signal strength of the received beacon, the presence and strength of interference, and randomness of the
sync function. It can vary from 150 milliseconds to over 1500 milliseconds.
GO_0/Hop_Frame
The Hop Frame indicator functionality is disabled by default and controlled by the Control 1, Bit-6 EEPROM
setting. When enabled, this pin transitions logic Low at the start of a hop and transitions logic High at the
completion of a hop. The OEM host is not required to monitor hop frame.
RTS and Handshaking
With RTS mode disabled, the transceiver sends any received data to the OEM host as soon as it is received.
However, some OEM hosts are not able to accept data from the transceiver at all times. With RTS enabled in
EEPROM, the OEM host can prevent the transceiver from sending data by de-asserting RTS (High). Once RTS is
re-asserted (Low), the transceiver sends packets to the OEM host as they are received.
Note: Leaving RTS de-asserted for too long can cause data loss once the transceiver’s transmit buffer
reaches capacity.
CTS Handshaking
If the transceiver buffer fills up and more bytes are sent to it before the buffer can be emptied, data loss occurs.
The transceiver prevents this loss by de-asserting CTS high as the buffer fills up and asserting CTS low as the
buffer is emptied. CTS should be monitored by the host device and data flow to the radio should be stopped
when CTS is high.
DE/RE
When enabled, RS485 Data Enable uses the DE/RE pin to control the DE pin on external RS-485 circuitry. When
the transceiver has data to send to the host, it asserts DE/RE High, sends the data to the host, and then takes
DE/RE low.
PWM Output
PWM output can be configured to output on any of three pins (SMT Pins 5, 6, or 7). The PWM Output can
optionally produce a pulse width modulation for RSSI with a period of 39.3846 µS.
MECHANICAL CONSIDERATIONS
Mechanical Drawing
The pluggable versions of the RM024 consist of the surface mount RM024 on a pluggable adapter board.
RM024 –C versions, which only feature an U.FL connector and no integrated antenna, are the same dimensions
as in the mechanical drawings below (Figure 3 and Figure 4) with the stub for the antenna connector removed.
For the surface mount units, this means the module is 32.38 mm long. For the pluggable units, the module is
33.02 mm long.
Note on Mechanical Drawings:
All dimensions are in millimeters
PC board material is 0.79 mm thick FR4
Provide clearance of at least 1.5 mm around the module to be free of other components and features
Module should not exceed 260˚C during reflow soldering

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
12
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Figure 3: RM024 mechanical drawings

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
13
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Figure 4: RM024 mechanical drawings
The pluggable RM024 uses a single row header with two mil spacing. The Mill Max 831-43-010-10-001000 is
used on the RM024 development kit as a mating connector.

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
14
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Figure 5: Moisture Content Warning

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
15
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
REFLOW PARAMETERS
Laird’s surface mount modules are designed to be easily manufactured, including reflow soldering to a PCB.
Ultimately, it is the responsibility of the customer to choose the appropriate solder paste and to ensure oven
temperatures during reflow meet the requirements of the solder paste. Laird’s surface-mount modules conform
to J-STD-020D1 standards for reflow temperatures.
IMPORTANT: During reflow, modules should not be above 260°C and not for more than 30 seconds.
Figure 6: Recommended reflow temperature
Temperatures should not exceed the minimums or maximums presented in Figure 6.
Table 6: Reflow temperatures
Specification
Value
Unit
Temperature increase/decrease rate (maximum)
3
°C/Second
Temperature decrease rate (goal)
2-3
°C/Second
Soak temperature increase rate (goal)
.5-1
°C/Second
Flux soak period (minimum)
60
Seconds
Flux soak period (maximum)
90
Seconds
Flux soak temperature (minimum)
150
°C
Flux soak temperature (maximum)
190
°C
Time above liquidus (maximum)
60
Seconds
Time above liquidus (minimum)
20
Seconds
Time in target reflow range (goal)
30
Seconds
Time at absolute peak (maximum)
30
Seconds
Liquidus temperature (SAC305)
217
°C
Lower target reflow temperature
225
°C
Upper target reflow temperature
250
°C
Absolute peak temperature
260
°C

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
16
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
ORDERING INFORMATION
Product Part Numbers
RM024 Part Number
Form Factor
Maximum Tx Power
Antenna
EERPOM Product ID
RM024-S125-C-30
SMT
125 mW
U.FL Jack
RM024125C30
RM024-S125-M-30
SMT
125 mW
U.FL or Chip
RM024125M30
RM024-P125-C-30
Pluggable
125 mW
U.FL Jack
RM024125C30
RM024-P125-M-30
Pluggable
125 mW
U.FL or Chip
RM024125M30
RM024-S10-C-30
SMT
10 mW (CE)
U.FL Jack
RM02410C30
RM024-S10-M-30
SMT
10 mW (CE)
U.FL or Chip
RM02410M30
RM024-P10-C-30
Pluggable
10 mW (CE)
U.FL Jack
RM02410C30
RM024-P10-M-30
Pluggable
10 mW (CE)
U.FL or Chip
RM02410M30
Developer Kit Part Number
Description
DVK-RM024-CE
RM024 Developer Kit, Pluggable, 3.3V TTL Serial, 10 mW, Multiple Antennas,
CE Approved
DVK-RM024-FCC
RM024 Developer Kit, Pluggable, 3.3V TTL Serial, 125mW, Multiple Antenna
REGULATORY INFORMATION
FCC/IC Requirements for Modular Approval
Agency Identification Numbers
Product Family
US/FCC
Canada/IC
RM024
KQL-RM024
2268C-RM024
RM024 Family
Part Number *
Form Factor
Tx Output
Antenna
RM024-S125-C-XX
Surface Mount
125 mW
U.FL
RM024-S125-M-XX
Surface Mount
125 mW
U.FL or Chip
RM024-P125-C-XX
Pluggable
125 mW
U.FL
RM024-P125-M-XX
Pluggable
125 mW
U.FL or Chip
RM024-S10-C-XX
Surface Mount
10 mW
U.FL
RM024-S10-M-XX
Surface Mount
10 mW
U.FL or Chip
RM024-P10-C-XX
Pluggable
10 mW
U.FL
RM024-P10-M-XX
Pluggable
10 mW
U.FL or Chip
*The last two slots (XX) in the Part Number column are used for custom setups. They can be values ranging from 01-99, aa-zz.
Currently, these values are -30, for FW version 3.0.

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
17
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Antenna Information
The RM024 family is designed to operate with the antennas listed below and a maximum gain of 9 dBi. The
required antenna impedance is 50 ohms.
Manufacturer
Manufacturer Part
Number
Laird Part Number
Type
Gain (dBi)
Laird
WIC2450-A
0600-00042
Chip
2
Laird
NZH2400-MMCX
2150-00006
Microstrip
1
Laird
ID2450-RS36
CAF95990
Panel
9
Laird
IG2450-RS36
CAF94722
Omni
6
Nearson
S151-6-PX-2450S
0600-00040
Dipole
2
Note: The OEM is free to choose another vendor’s antenna of like type and equal or lesser gain as an antenna
appearing in the table and still maintain compliance. Reference FCC Part 15.204(c)(4) for further
information on this topic.
To reduce potential radio interference to other users, the antenna type and gain should be chosen so
that the equivalent isotropically radiated power (EIRP) is not more than that permitted for successful
communication.
Power Exposure Information
In general, there are two agency classifications for RF radiation exposure in wireless applications:
Mobile –A mobile device is defined as a transmitting device designed to be used in such a way that a
separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating
structures and the body of the user or nearby persons. The RM024 is fully modular approved for mobile and
fixed applications. Reference FCC Part 2.1091 for further details on mobile devices.
Portable –Portable is a classification of equipment where the user, in general, is within 20 cm of the
transmitting antenna. Portable equipment is further broken down into two classes; within 2.5 cm of human
contact and beyond 2.5 cm. The RM024 does not hold a portable approval classification due to its peak
output power and modular approval restrictions. Further RF evaluation is required by customers who want
to use the RM024 in portable applications. Contact a qualified test house or a Laird Technologies
representative for further information on this topic. Reference FCC Part 2.1093 for further details on
portable devices.
A Maximum Permissible Exposure report has been created which shows the minimum distances for Public and
Occupational use of the RM024.
Note: Occupational Limit Minimum Distance = 4 cm
Public Limit Minimum Distance = 9 cm
A full MPE report is available upon request.
OEM Responsibilities
WARNING:The OEM must ensure that FCC labeling requirements are met. This includes a clearly visible label on
the outside of the OEM enclosure specifying the appropriate Laird FCC identifier for this product as
well as the FCC notice below.

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
18
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
Note: Contains FCC ID: KQL-RM024
IC: 2268C-RM024
The enclosed device complies with Part 15 of the FCC Rules and Industry Canada License Exempt
RSS Standard(s). Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference received, including
interference that may cause undesired operation
Label and text information should be in a size of type large enough to be readily legible, consistent with the
dimensions of the equipment and the label. However, the type size for the text is not required to be larger than
eight pt.
CAUTION: The OEM should have their device which incorporates the RM024 tested by a qualified test house to
verify compliance with FCC Part 15 Subpart B limits for unintentional radiators.
WARNING: This device has been tested with an U.FL connector and the antennas listed in the table above.
When integrated into the OEM’s product, these fixed antennas require professional installation preventing end-
users from replacing them with non-approved antennas. Any antenna not listed in the above table must be
evaluated for compliance with FCC Part 15.203 for unique antenna connectors. Contact Laird Technology for
assistance.
WARNING: This equipment has been approved for mobile applications where the equipment should be used at
distances greater than 20 cm from the human body. Operation at distances of less than 20 cm requires
additional RF exposure evaluation and possible testing, including SAR requirement according to FCC RF Exposure
guideline.
CAUTION: Any changes or modifications not expressly approved by Laird Technology could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does not cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to correct the interference by one or more of the following
measures:
Re-orient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment to an outlet on a circuit that is different from that to which the receiver
is connected.
Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
“THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES AND INDUSTRY CANADA LICENSE-EXEMPT RSS
STANDARD(S). OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.”

RM024 –RAMP Wireless Module
Hardware Integration Guide
Embedded Wireless Solutions Support Center:
http://ews-support.lairdtech.com
www.lairdtech.com/ramp
19
© Copyright 2015 Laird. All Rights Reserved
Americas: [phone]
Europe: [phone]
Hong Kong: [phone]
CE Requirements for Modular Approval
RM024 Part Numbers Approved for CE
Part Number *
Form Factor
Tx Output
Antenna
RM024-S10-C-XX
Surface Mount
10 mW
U.FL
RM024-S10-M-XX
Surface Mount
10 mW
U.FL or Chip
RM024-P10-C-XX
Pluggable
10 mW
U.FL
RM024-P10-M-XX
Pluggable
10 mW
U.FL or Chip
*The last two slots (XX) in the Part Number column are used for custom setups. They can be values ranging from 01-99, aa-zz.
Currently, these values are -30, for FW version 3.0.
The part numbers listed above are approved for use in CE markets with antennas having a maximum gain of
2.0 dBi. Antennas having a gain greater than the maximum allowed are strictly prohibited for use with this
device. The required antenna impedance is 50 ohms.
CE Tested Antenna List
Manufacturer
Manufacturer Part Number
Laird Part Number
Type
Gain (dBi)
Laird
WIC2452-A
MAF95029
Chip
2
Laird
NZH2400-MMCX
2150-00006
Microstrip
1
Nearson
S181FL-6-PX-2450S
Dipole
2
Laird
WCP2400
WCP2400
Dipole
2
Note: The OEM is free to choose another vendor’s antenna of like type and equal or lesser gain as an
antenna appearing in the table and still maintain compliance. Antennas listed in this table have been
test with the RM024.
RELATED DOCUMENTS AND FILES
Additional RM024 technical documents and software downloads are available from the Laird RM024 product
page under the Documentation tab and Software Downloads tabs.
