LAZER BULLET 2.0 User manual

Lazer Bullet 2.0
USER MANUAL

For a video guide to help with the following steps please
go to the following URL and click on how to videos:
www.youtube.com/user/LazerSport
1
The Lazer Bullet 2.0 helmet has a
ventilation on demand feature called
Airslide. This system allows the
user to control the amount of airow
through the helmet. With the system
closed, the helmet allows little airow
and has optimized aerodynamic
performance. With the Airslide
opened the helmet allows a lot of
airow and optimized ventilation.
A) To open the Airslide system,
place your hand on the honeycomb
structure, gently press down and slide
the system upwards until it can go no
further.
The entire honeycomb structure
should slide up (diagram 1A), opening
ventilation holes inside the helmet.
B) To close the Airslide stystem,
place your hand on the honeycomb
structure, gently press down and slide
the system downwards until it can go
no further ((diagram 1B).
The entire honeycomb structure
should slide down, closing all
ventilation holes inside the helmet.
1. How to use the Airslide?
LAZER BULLET 2.0
1A)
1B)

2
2. How to customize your Bullet 2.0?
The Lazer Bullet 2.0 helmet has the
option of being customized with
another decorative cap on top of the
helmet (2B).
A) To change this cap, close the
Airslide system as shown in 1B.
Then reach inside the helmet and
push with your ngers on the Airslide
cap through the front ventilation hole
on the helmet, this should release the
Airslide cap from the helmet.
B) Now grab the cap covering the
back of the helmet with two ngers on
the part that says LAZER and gently
pull it away from the helmet towards
the rear.
C) To install a new cap, place the new
cap aligned with the free space on
top of the helmet and gently press
downward until you hear a popping
sound.
Then align the Airslide cap with the
opening in the helmet and gently
apply pressure until you hear a
popping sound.
Make sure that both caps are installed
correctly and that the caps align
perfectly with the helmet, apply more
gentle pressure if needed.
Attention: Always install both
caps on the Bullet 2.0 before use.
Lazer does not recommend using
the helmet without these caps
installed.
LAZER BULLET 2.0
2A)
2C)
2B)

3
LAZER BULLET 2.0
The Lazer Bullet 2.0 helmet can
accept the Inclination Sensor
system to help you nd your perfect
aerodynamic position. This body
posture meter can help track your
current head position and via sound
and/or vibration guide you to your
perfect position.
A) To install the Inclination sensor,
rst mount the sensor to it’s
baseplate.
Then mount the baseplate to the back
of the helmet using the mushroom
install mounts on the baseplate, and
push these into the snap baskets that
are located at the rear of the helmet.
B) To remove the Inclination Sensor,
grab the sensor and baseplate and
gently pull it away from the helmet.
Once the mushroom install mount
release from the snap baskets, the
Sensor unit is free to move.
C) Switch the inclination sensor on by
pressing on the ON button.
To set your inclination sensor up,
connect it to the computer and use
the provided software.
Please read the Inclination Sensor
manual for more detailed instructions.
3. How to install the Inclination Sensor?
3B)
3C)
3A)

LAZER BULLET 2.0
The Lazer Bullet 2.0 helmet can
accept the LifeBEAM sensor to
measure your pulse rate when riding.
This system can connect via Ant+ or
Bluetooth to any device you want to
use during riding, so you can always
monitor your pulse rate throughout
the ride.
A) To install the LifeBEAM sensor
rst snap the LifeBEAM accessory
mount (4A) into the helmet, by
pushing the mushroom install mounts
into the snap baskets located at the
rear of the helmet.
B) Once this accessory mount is
installed, attached the LifeBEAM
sensor box to this accessory by
looping the rubber sensor housing to
the accessory mount attached to the
helmet.
C) Then install the sensor in the
front of the helmet, where it can
make contact with the skin on your
forehead. When this is done, run the
cable through the helmet towards
the back, and attached the cable
to the sensor box using the the jack
attached to the cable and the socket
foreseen in the sensor box.
Switch on the Sensor box, connect a
device to the sensor box via Ant+ or
Bluetooth signal, and put the helmet
on your head. After 10 seconds you
should start seeing your pulse rate on
your device and you are ready to go.
Please read the LifeBEAM manual
for more detailed instructions.
4. How to install the LifeBEAM Sensor?
4
4B)4A)
4C)

LAZER BULLET 2.0
The Lazer Bullet 2.0 helmet
comes included with a magnetic
panoramic lens which can be used
to protect you from the elements and
increase aerodynamic performance.
A) To install the magnetic
panoramic lens simply snap the lens
onto the front of the helmet as shown
in diagram A.
B) The lens can also be magnetically
docked on the back of the helmet
either while riding or while o the bike.
To dock the lens simply align the lens
with the helmet as shown in diagram
Band snap the central magnet of the
lens onto the central magnet of the
helmet.
5. How to use the magnetic panoramic lens?
5A)
5

LAZER BULLET 2.0 5. How to use the magnetic panoramic lens?
5B)
6

Lamorinièrestraat 33-37
2018 Antwerp - Belgium
www.lazersport.com
For other and more helmet
instructions, please refer to
the owner manual included
with the helmet.
Thank you for choosing the Lazer helmet.
You have made an excellent choice that
will help to reinforce your safety while
cycling: the sport for which this helmet
has been designed. Lazer helmets
conform to the strict criteria
of international standards.
Wearing a helmet may reduce the
seriousness of injuries to the head that
may occur during a sports accident.
For this reason, it is important to
use this protective gear properly.
Instructions for use and care
1) No helmet can protect the wearer
against all possible impacts.
2) The helmet is designed to be retained
by a strap under the lower jaw.
3) To be eective, a helmet must t and be
worn correctly. To check for correct
t, place helmet on head and make any
adjustments indicated. Securely fasten
retention system. Grasp the helmet and
try to rotate it to the front and rear.
A correctly tted helmet should be
comfortable and should not move forward
to obscure vision or rearward to expose
the forehead.
4) No attachments should be made to the
helmet except those recommended by
the helmet manufacturer.
5) The helmet is designed to absorb shock
by partial destruction of the shell and liner.
This damage may not be visible. Therefore,
if subjected to a severe blow, the helmet
should be destroyed and replaced even
if it appears undamaged.
6) The helmet may be damaged and
rendered ineective by petroleum and
petroleum products, cleaning agents,
paints, adhesives and the like, without
the damage being visible to the user.
7) A helmet has a limited lifespan in use and
should be replaced when it shows obvious
signs of wear.
8) This helmet should not be used by children
while climbing or doing other activities
where there is a risk of hanging or
strangulation if the child gets trapped
whilst wearing the helmet.
9) This helmet is designed only for the
following activity: cycling, roller skate,
skateboard. It is not designed to be used
with mopeds or any other type of sport,
mechanical or not.
