GENERAL SYSTEM DESCRIPTION
The electronic locking system M300 is an electronic furniture lock. Using the system in applications for
which it is not intended may result in irreparable damage to it and render any claims null and void. It is
intended for usage in the home and ofce. This user manual tells you how to properly install and operate
the M300 system. For programming the furniture lock you will need the management software as well as
the required hardware of the SimonsVoss Technologies GmbH in Munich. With its easy handling, you can
adapt the M300 system to your personal requirements. It can be expanded from a stand-alone system to
a complex, convenient locking system and integrated into already existing locking systems of SimonsVoss
Technologies GmbH.
Wording and graphics have been prepared for you with care. However, no liability will be assumed for any
mistakes that may have occurred.
Copyright 2014 by LEHMANN Vertriebsgesellschaft mbH & Co. KG, D-32429 Minden.
All rights reserved. These instructions must not be reproduced in any way (print, photocopy, microlm or
other process) or processed, duplicated or distributed using electronic systems either in whole or in part
without written consent from LEHMANN Vertriebsgesellschaft mbH & Co. KG. The scope of items included
by the manufacturer in the system as well as technical specications are subject to change without notice.
FUNCTIONAL DESCRIPTION
The M300 electronic locking system provides you with a convenient means of locking and unlocking your
furniture electronically. The M300 system enables granting of selective access authorisations, so that
certain furniture can only be accessed by authorised persons. Complete locking systems with different
access levels can thus be realised with no problems.
Each control electronics of the M300 system works independently, without cable connection to other
control electronics and without mains voltage. You can easily program different transponders in each
control electronics. During normal operation, the control electronics only responds to the programmed
transponders.
Please note that the distance between the furniture locks must always be at least 50 cm. A distance
of at least 120 cm between the furniture locks is required, when several furniture locks are
authorised with one transponder.
For operation you will additionally need a transponder of SimonsVoss Technologies GmbH, which you
already own or which you can purchase from your supplier or dealer.
UUThe bolts can bear a maximum force of 5-10 N.
If this load is exceeded, the system may be permanently damaged.
UUWhen replacing the batteries, observe correct battery polarity and position!
UUDispose of used batteries properly!
UUDo not heat batteries, take them apart or short-circuit them!
UUNever throw batteries into open re!
UUThe batteries must not be charged!
UUKeep the batteries away from children!
UUAny persons swallowing batteries must seek immediate medical advice!
UUDamaged and/or leaking batteries may cause acid burns and/or poisoning!
SAFETY PRECAUTIONS

BDA-M300 GB -DE- (Rev-02) 23-06-2012
3
CARE AND MAINTENANCE
UUDo not spill any liquid over or into the individual components of the system and never immerse the
components in any liquid.
UUDepending on the structural conditions, electronic sources of interference and/or frequency overlays,
the transmission/reception range as well as the reception quality can be limited.
UUThe receiver should not be exposed to direct sunlight.
UUClean the system with a clean, soft, damp cloth only.
UUDo not use any cleaning agents that contain abrasives or solvents like glass, thinners, alcohol, gasoline
or ammonia, as these can damage the housing.
UUTreating any of the electronic and mechanical components improperly or in any way other than
described in this user manual may lead to malfunctions.
NOTE
Our locks and locking systems can be used together with mechanisms made by other manufacturers,
but their compatibility must be checked by the processor in each individual case. We cannot accept
any liability for damage or losses due to incompatibility.
TECHNICAL SPECIFICATIONS
U# The system does not require visual contact between the transponder and receiver.
U# The distance between the furniture locks must always be at least 50 cm.
U# Frequency: 25 KHz. National legislation about permissible radio frequencies must be observed.
U# The average transmission range of the transponder is approx. 30 cm. Depending on the structural
conditions, the transmission/reception range may be limited or signicantly increased.
U# Information about programming and commissioning of the system can be found in the system manual of
company SimonsVoss Technologies GmbH. www.simons-voss.com
U# Power supply for control electronics: Battery type: 3x AA, alkaline 1.5 V.
U# NiCd, NiMH or other rechargeable batteries as well as zinc-carbon or lithium batteries must not be
used!
U# Mechanical load limits:
- The main front lock has a maximum compressive force of 10 N.
- The two lateral lock bolts have a maximum compressive force of 5N each with even load.
Temperature range:
Operation: + 5°C to +40°C at 30% to 80% relative humidity, non-condensing.
Operation: -25°C to +70°C at 30% to 80% relative humidity, non-condensing.
Apart from that, the technical information and specications of SimonsVoss Technologies GmbH in
Munich apply. www.simons-voss.com

SYSTEM COMPONENTS / PACKAGE CONTENTS
DIMENSIONS
E-Box M300 SV 2 x Spax 3x30 3 x Spax 3x13 3 x 1.5 V AA M-Box M300
3-point
Operating instructions
2
4
3
Contents Page
General description, functional description and safety instructions.................... 2
Care and maintenance and technical specifi cations........................................... 3
System components / Package contents............................................................4
Getting started / Installation and battery replacement ........................................5
Functional check with transponder .....................................................................6
Information about installing and dismantling.......................................................7
Light signals and other signals............................................................................8
Operating instructions

M300 SV SimonsVoss / G2
BDA-M300GB -DE- (Rev-02) 23-06-2012
www.lehmann-locks.com
5 6
Display unit with cable
3

2
5
4
3
6
BDA-M300 GB -DE- (Rev-02) 23-06-2012
44
M300 Electronics

BDA-M300 GB -DE- (Rev-02) 23-06-2012
5
GETTING STARTED / INSTALLATION
The motor unit, electronics and display unit are not connected on delivery. Please perform steps 1 to 3 (see
below) one after the other to get a functional unit. Once the functional check was successful, disconnect
the display unit from the system again (gure 2), so that the system can be properly installed in the
furniture.
Before installing the system, insert the batteries in the control electronics and program the furniture lock
according to the SimonsVoss GmbH system manual. Once the programming operation is completed,
ensure proper functioning of the system.
Only install the furniture lock in the furniture when it is unlocked.
Use only LR6, AA, alkaline type batteries. Make sure that the polarity is correct!
NiCd, NiMH or other rechargeable batteries as well as zinc-carbon or lithium batteries must
not be used!

Assemble the electronic
housing and motor unit
together until they interlock.
2
Insert the plug of the display
unit into the socket of the
electronics in the correct
position.
3
Check components
for secure seating.
REPLACING BATTERIES
Clack

Loosen the screw.
Open the battery
compartment lid.
2
Insert / replace
the batteries. 3
Close the battery
compartment lid.
Fit the xing screw.

BDA-M300 GB -DE- (Rev-02) 23-06-2012
6
FUNCTIONAL CHECK WITH TRANSPONDER
Check the open/close function of the M300 before installation with the associated authorised
transponder.
A detailed overview of all optical signals can be found on page 8

Transponder:
Press button 2
Bolt retracts.
Open
Optical display
LED colour: GREEN
Pause
approx. 1 sec.

Transponder:
Press button 2
Bolt extends.
Close
Optical display
LED colour: RED
Pause
approx. 1 sec.

BDA-M300 GB -DE- (Rev-02) 23-06-2012
7
1
1
2
2
3
3
4
4
5
5
6
6
A A
B B
C C
D D
0513184-021
28,5
16
7532
14
76
3232
75
2
12,5
LichtesInnenmaß/Internalheight
A
B
Stangenlänge=A-53
barlength =A-53
Stangenlänge=B-53
barlength =B-53
min. 16mm
All specications in (mm)
INFORMATION ABOUT INSTALLATION
This M300 is a motor lock with 3-point locking. This means that three bolts will extend from the housing at
the same time. Push rods are usually attached to the two lateral lock bolts. This enables deecting of the
locking points. (See installation diagram).
The required push rods (locking rods) are not part of the packaging. However, you can get these via your
specialist stockist.
To determine the push rod length, please use the length calculation in the diagram.In this case based on
the example of a revolving door for furniture.
The display unit should be installed so that you have good visual contact. If you install the display unit se-
parately from the control electronics, the length of the connection cable between these system components
must not exceed 1 m.
For the correct mechanical connection of the M300 system to your furniture, please refer to the installation
instructions of your furniture manufacturer. If you have questions about the installation of the system, plea-
se contact a carpentry rm or your supplier before installation.
In some cases it might be required to dismantle the M300 again.
For this, please proceed as follows:

Remove the xing
screws on the motor
unit.
2
Unlock the motor unit and
electronics, as illustrated
and described in the diagram
below.
3Open the battery compartment
lid, remove the batteries and
remove the xing screws.
DISMANTLING THE M300
Pull the motor unit in
direction of the arrow
Press and hold
the T stick
1
1
2
2
3
3
4
4
5
5
6
6
A A
B B
C C
D D
0513184-021
28,5
16
7532
14
76
3232
75
2
12,5
A
B
min. 16mm
Rod length = A-53Rod length = B-53
Clear inside dimension

Postfach / P.O.B 2620
D - 32383 Minden
Phone [phone] - 0
[email protected]
LEHMANN Vertriebsgesellschaft mbH & Co. KG
BDA-M300 GB -DE- (Rev-02) 23-06-2012
8
LIGHT SIGNALS AND OTHER SIGNALS Light signals
short ash
long ash
lights up
Light signals during normal operation
Warning displays when closing
Warning displays when opening
Open
1 sec.
Pause Lock is open
Close
1 sec.
Pause Lock is closed
Battery warning level 1 based on the example “Close”
The lock is closed but the
batteries in the lock are almost
depleted. Replace the batteries
in a timely fashion.
1 sec.
Pause
Battery warning level 2 based on the example “Open”
The lock cannot be closed
again.
The batteries are depleted.
Replace the batteries.
1 sec.
Pause
Stop position of lock not reached
The closing operation could
not be completed.
Locking bolt is blocked.
Transponder battery warning
1 sec.
Pause 6 x
The lock is open but the
battery of the transponder
is depleted.
Please contact the service.
Unauthorised transponder
The transponder is not
authorised on this lock and
is rejected.
There is no closing operation.
www.lehmann-locks.com
