Lennox 4.5HTSK User manual

GENERAL INFORMATION
HORIZONTAL TERMINATION
SHROUD KIT
The horizontal Termination Shroud Kit may be used as a decorative cover
for the square termination and to minimize exposure to the hot surface
of the termination.
This kit contains one termination shroud kit and these instructions.
HEARTH PRODUCTS
KITS AND ACCESSORIES
INSTALLATION INSTRUCTIONS FOR THE HORIZONTAL TERMINATION SHROUD KIT
(MODEL NUMBER 4.5HTSK) (CATALOG NUMBER H5820) FOR USE WITH SQUARE TERMINATIONS
WHICH MAY BE USED WITH DIRECT VENT GAS FIREPLACES
INSTALLATION INSTRUCTIONS
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Note - Shroud kit installation does not require the removal of the
square termination.
Step 1. Turn off the fireplace and allow the termination to cool before
proceeding.
Step 2. Loosen the four (4) screws on the existing square termination
(refer to Figure 1 ).
Step 3. Slide the body of the shroud over the termination screws that
have been loosened, setting it in place (refer to Figure 1 ).
P/N 750,246M
REV. B 04/2008
WARNING: THIS KIT MUST BE INSTALLED BY A QUALI-
FIED SERVICE TECHNICIAN OR OTHER QUALIFIED
AGENCY ACCORDING TO THE MANUFACTURER’S
INSTRUCTIONS, ALL CODES AND REQUIREMENTS OF
THE AUTHORITY HAVING jURISDICTION IN THE USA OR
CANADA. THE QUALIFIED AGENCY PERFORMING THIS
WORK ASSUMES RESPONSIBILITY FOR THIS INSTAL-
LATION.
WARNING: THE SHROUD KIT PROVIDES PROTECTION
FROM THE HIGH TEMPERATURES OF THE TERMINATION
ExCEPT AT THE TOP PORTION OF THE SHROUD KIT. THIS
AREA IS ExTREMELY HOT DUE TO THE DISCHARGING
FLUE GASES.
US

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Printed in U.S.A. © 2007 by LHP
P/N 750,246M REV. B 04/2008
The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
1110 West Taft Avenue
Orange, CA 92865
Figure 1
Step 4. Re-tighten the four (4) screws into place, securing the shroud body over the termination.
Step 5. Position the shroud top over the shroud body and screw it into the flanges located on both the shroud top and shroud body, using five (5)
screws (as shown Figure 1 ).
Note: The five (5) screws are to be attached from the bottom.
Step 6. Attach the bottom screen onto the body of the shroud, using the three (3) screws into each of the three flanges on the shroud body (see
Figure 1 ).
Step 7. If desired, paint shroud to any color.
Termination
Securing Screws
(Five) For Shroud
Body To Shroud Top.
Install From The
Bottom Up.
Screw Flanges
(Five Places)
Bottom Screen
Termination
Shroud - Top
Termination
Shroud - Body
Back Off These Two Screws
(Both Sides) And Slide
Shroud Body Into Place.
Securing Screws
(Three) For Bottom
Screen To Shroud Body.
Install From The Bottom Up.
