Lennox WS-PED User manual

WOODSTOVE PEDESTAL KITS
INSTALLATION INSTRUCTIONS FOR INSTALLING PEDESTAL KITS FOR
USE WITH COUNTRY COLLECTION™ FREESTANDING WOODSTOVES
P/N 506033-16
Rev. A, 05/2009
HEARTH PRODUCTS
KITS AND ACCESSORIES
KIT CONTENTS
Please ensure that all these parts are included
1 ea. Pedestal Assembly
2 ea. 3/8”-16 x 3/8” Hex Bolts
2 ea. 3/8” Flat Washers
1 ea. Instruction Sheet
1
Pedestal Kits (all models)
Cat. No. Model Where Used
71108 WS-PED S160, SA160
71113 WL-PED SS210, ST210, S260, ST310
TOOLS NEEDED
9/16” Open End Wrench or Ratchet with 9/16” Socket
GENERAL INFORMATION
If you encounter any problems, need clarification of these instructions or
are not qualified to properly install this kit, contact you local distributor
or dealer.
Read this instruction sheet in its entirety before beginning the installa-
tion.
ALL WARNINGS, PRECAUTIONS AND INSTRUCTIONS IN THE INSTAL-
LATION AND OPERATION MANUAL PROVIDED WITH THE APPLIANCE
APPLY TO THESE INSTRUCTIONS.
Check the contents of the kits upon receipt and check for any damaged
or missing parts. If there is hidden damage, notify your freight company
or Lennox Hearth Products dealer immediately.
CAUTION: Wear gloves during installation in case of sharp
edges on the stove.
Manufactured (Mobile) Homes
In manufactured homes, this appliance must be bolted to the floor and
properly grounded to the chassis. An outside air kit (order Cat. No. 71112)
is also required. See the Installation and Operation Manual for details and
additional requirements for manufactured home installations. Also see
See steps 5, 6 and 7 on Page 2.
INSTALLATION INSTRUCTIONS
Step 1. Remove the stove and pedestal from the cartons, if packaged,
upon receipt and check for any damaged or missing parts.
Step 2. Carefully put the stove on pedestal with the open end of the
pedestal facing the rear (see Figure 1).DO NOT LEAVE THE
STOVE UNATTENDED UNTIL IT IS BOLTED SECURELY
TO THE PEDESTAL. IT COULD FALL CAUSING SERIOUS
INJURY OR DAMAGE.
Step 3. Line up the holes in the brackets on the pedestal with the
threaded holes in the bottom of the stove. Using a 9/16” wrench
or socket, secure the stove to the pedestal with the two 3/8” long
bolts and 3/8” standard washers. Be sure to see that the stove
is mounted squarely on the pedestal before tightening the two
bolts securely.
Step 4. When installing a pedestal on this stove you MUST plug the four
leg mounting bolt holes, located on the bottom of the stove in the
four corners, with the bolts that were used to mount the shipping
legs.FAILURETOINSTALLTHESEFOURBOLTSPROPERLY
WILL RESULT IN REDUCED CONTROL OF THE STOVE’S
COMBUSTION SYSTEM! Caution: The two rear bolts should
not be installed more than two full rotations to prevent lifting
the bricks off the bottom of the stove.
Figure 1
FRONT
REAR
Pedestal
DRAFT
5/01/2009
NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.

2
Printed in U.S.A. © 2009 Lennox Hearth Products
P/N 506033-16 REV. A 05/2009
NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
Lennox Hearth Products reserves the right to make changes at any time, without notice, in
design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
1110 West Taft Avenue • Orange, CA 92865
MANUFACTURED HOME REQUIREMENTS
Step 5. Install the Outside Air Kit per the instructions provided in kit
(order cat. no. 71112).
Step 6. In Manufactured (mobile) Home installations the stove must
be bolted to the floor through the pedestal base, on both sides,
using 1/4” Ø lag screws (not provided). The lag screws must be
of an adequate length to extend through the hearth pad and into
the floor. Seal any irregularities with silicone sealer.
Step 7. If installed in a manufactured (mobile) home, the heater must be
grounded to the chassis with a #8 AGW copper wire or equiva-
lent.
SEE THE INSTALLATION AND OPERATION MANUAL FOR ADDITIONAL
REQUIREMENTS FOR MANUFACTURED (MOBILE) HOME INSTALLA-
TIONS.
