Lennox BELLA-BPK-T User manual

HEARTH PRODUCTS
KITS AND ACCESSORIES
506033-13
REV. NC 12/2008
INSTALLATION INSTRUCTIONS FOR BRICK PANEL KITS
FOR USE WITH THE BELLA™ PELLET STOVE
BRICK PANEL KITS
BELLA™
1
Figure 2
Cat. # Model Description
H3484 BELLA-BPK-T Brick Panel Kit, Traditional
KIT CONTENTS (See Figure 1)
1 ea. Left Side Brick Panel (item 1)
1 ea. Right Side Brick Panel (item 2)
1 ea. Back Brick Panel (item 3)
1 ea. Left Brick Panel Bracket (item 4)
1 ea. Right Brick Panel Bracket (item 5)
2 ea. 10-24 x 3/8” Socket Head Screws (item 6)
1 ea. Instruction Sheet
GENERAL INFORMATION
All of these parts may scratch and bend, great care should be used in
handling them.
If you encounter any problems, need clarification of these instructions or
are not qualified to properly install this kit, contact you local distributor
or dealer. Read this instruction sheet in its entirety before beginning the
installation. Failure to understand and follow these directions may result
in damage to the brick panels.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND OP-
ERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO THESE
INSTRUCTIONS.
TURN OFF THE STOVE AND ALLOW IT TO COMPLETELY COOL BEFORE
PROCEEDING.
INSTALLATION INSTRUCTIONS
Step 1. Open front glass door and remove burn-pot.
Step 2. Locate the socket head screw in the inside of the firebox (see Figure
2)and remove with 5/32” allen wrench.
Step 3. Repeat step 2 on opposite side.
1
2
3
4
5
Figure 1 - Kit Contents
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
TOOLS NEEDED
5/32” Allen Wrench
6

Printed in U.S.A. © 2008 Lennox Hearth Products
P/N 506033-13 REV. NC 12/2008
Lennox Hearth Products reserves the right to make changes at any time, without notice, in design,
materials, specifications, prices and the discontinuance of colors, styles and products. Consult
your local distributor for fireplace code information.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
2
IMPORTANT NOTE: DO NOT OVERTIGHTEN SCREWS.
SECURE UNTIL SNUG ONLY!
Step 3. Place the right brick panel bracket on the right brick panel (see
Figure 3). The bracket should fit snug. Adjust the bent tabs to
ensure a snug fit between the bracket and the panel.
Figure 3
Step 4. Repeat step 3 using the left brick panel bracket and left brick
panel.
Step 5. Carefully place the back brick panel into the stove and rest the bot-
tom on the small ledge behind the ash pots (A in Figure 4).
Step 6. While holding the back brick panel in place, carefully place the right
side panel with attached bracket into the stove and rest the bottom
of the panel on the ledge to the right of the ash pot (B in Figure 4).
Step 7. Secure the brick panel bracket to the inside of the stove using one
(1) 10-24 x 3/8” socket head screw (see Figure 5).
Step 8. Repeat steps 6 and 7 on the left side of the stove.
Figure 4
Figure 5
1110 West Taft Avenue • Orange, CA 92865
DO NOT OVERTIGHTEN SCREWS! SNUG ONLY!
RIGHT BRICK PANEL WITH BRACKET
A
B
