Lennox TK3-36PB User manual

INSTALLATION INSTRUCTIONS FOR TRIM KITS
FOR USE WITH MODELS MPE-33R AND MPE-36R ELECTRIC FIREPLACE
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Page 1 of 2
LENN
O
X HEARTH PR
O
DU
C
T
S
KITS AND ACCESSORIES
Cat. No. Model Description
H1538 TK3-36BL 3-pc. Black Trim Kit, MPE-36R,
H1539 TK3-36PB 3-pc. Brass Trim Kit, MPE-36R
H1540 TK3-36BS 3-pc. Stainless Trim Kit, MPE-36R
H3435 TK3-33BL 3-pc. Black Trim Kit, MPE-33R
H3436 TK3-33PB 3-pc. Brass Trim Kit, MPE-33R
H1932 TK3-33BS 3-pc. Stainless Trim Kit, MPE-33R
775,175M REV. B
12/2005
* KIT CONTENTS:
1 ea. Top Panel
1 ea. Left Side Panel
1 ea. Right Side Panel
6 ea. Magnets
* Note: Trim Kits with Brass and Stainless Finishes also include:
1 ea. Left Side Channel
1 ea. Right Side Channel
1 ea. Top Channel
Double-sided tape on panels
(If the kit you purchased includes channels and double-sided tape, they
should be used)
TOOLS REQUIRED:
None
INSTALLATION INSTRUCTIONS:
This kit contains trim panels used to finish the gaps between the wall-
board or optional mantel and the fireplace, providing the appliance a fin-
ished built-in look.
ENSURE FIREPLACE IS COOL TO THE TOUCH BEFORE STARTING IN-
STALLATION OF THE TRIM KIT
Step 1. Place 2 magnets on each side of the fireplace, placed at approxi-
mately 8” from the top and 8” from the base. See Figure 2.
Step 2.
 Brass and Stainless Trim Kits - Proceed to Step 3.
 Black Trim Kits - Proceed to Step 4.
Step 3. Place the side channels over the magnets (See Figure 3 ).
Ensure that the two side channels are flush with the bottom of the
fireplace. The wider side of the side channel should be on the front of
the fireplace face after installation.
Step 3. Peel off the backing on the double-sided tape on the backside
of each side trim panel (see Figure 4 ). Avoid touching the sticky
surface of the tape.
CAUTION: CAREFULLY SEPARATE THE MAGNETS BY TWISTING
THEM APART. BE VERY CAREFUL WHEN HANDLING, BECAUSE
THE MAGNETS ARE VERY POWERFUL AND CAN SNAP TO-
GETHER UNEXPECTEDLY AND POSSIBLY PINCH THE SKIN OR
FRACTURE THE MAGNETS.
Left Panel
Right Panel
Top Panel
*Side Channels
Magnets
~
8”
Figure 1
Figure 2
Ensure
Channel is
Flush with
Base
Side
Channel
Figure 3
Approximate
Magnet
Placement
*Top Channel

Printed in U.S.A Lennox Hearth Products 2004
P/N 775,175M REV. B, 12/2005 Page 2 of 2 1110 West Taft Avenue •Orange, CA 92865
LENNOX reserves the right to make changes at any time, without notice, in design, materials,
specifications, prices and also to discontinued colors, styles and products.
Consult your local distributor for fireplace code information.
Completed Trim Panel Installation
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Step 4. Install the side trim panels onto each side of fireplace face as
follows:
 Brass and Stainless Trim Kits – Place side trim over channels,
then press firmly so double sided tape adheres panels to chan-
nels (see Figure 5 ).
 Black Trim Kits – Place side trim panels over magnets on each
side of the fireplace face as shown in Figure 5.
Note: Magnets were installed on Step 1, Figure 2.
Step 5.
 Brass and Stainless Trim Kits - Peel off the backing on double-
sided tape on the backside of the top trim panel. Press fit the top
channel against the top trim panel as shown in Figure 6.
 Black Trim Kits – Proceed to Step 6.
Step 6. Place 2 magnets on the backside of the top trim panel as shown in
Figure 6.
Step 7. Place the Top Trim Panel over the Side Trim Panels as shown
in Figure 7.
 Brass and Stainless Trim Kits – The metal channel should
go behind the side trim panels. Squeeze top and side trim
pieces together.
 Black Trim Kits – The magnets act as support to hold the
trim panel in place.
Figure 4
Backing
Double
Sided
Tape
Figure 5
Backside of Side
Trim Panel
Figure 7
Right Side
Trim P
a
n
e
l
Magnet
Backside of Top
Trim Panel
♦
Black Trim kits do not include channels or doubl
e
-
sided
ta
p
e. See Note on
p
a
g
e 1.
♦Top Channel
Figure 6
♦Double-sided Tape
~ 3”
Typical
