Lennox Shadowdance LSVFSD-30 User manual

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 1
Middle Log
Left Top Twig
Left Top Log Right Top Log
Rear Log
Left Front Log
Front Ember Bed
Right Front Log
Rear Ember Bed
Center Top Log
750,239M
REV. B 11/2007
LOG PLACEMENT INSTRUCTIONS FOR
SHADOWDANCE™ SERIES GAS LOGS SETS
HEARTH PRODUCTS
KITS AND ACCESSORIES
Cat. No Model Description
H5137 LSVFSD-18 Shadowdance™ 18" Log Set
H5138 LSVFSD-24 Shadowdance 24" Log Set
H5139 LSVFSD-30 Shadowdance 30" Log Set
WARNINGS
•Do not attempt to install the logs until the ap-
pliance installation has been completed, the
gas line connected and tested for leaks and the
initial burner operation has been checked out.
•Iflogsarenotinstalledaccordingtotheloginstalla-
tioninstructions,flameimpingementandimproper
combustion could occur and result in soot and/or
excessive production of carbon monoxide (CO), a
colorless, odorless, toxic gas.
•The size and position of the log set was engi-
neered to give the appliance a safe, reliable and
attractive flame pattern. Any attempt to use a
differentlog setwiththeShadowdanceseriesgas
train models, LSVFSD-NG OR LSVFSD-LP will
void the warranty and will result in incomplete
combustion, sooting, and poor flame quality.
•Do not add extra logs or ornaments such as pine
cones, vermiculite or rock wool. Using these
added items can cause sooting.
•Do not place any lava rock on logs or burners.
This may cause sooting. Only place lava rock
on floor of fireplace.
•All warnings and precautions in the installation
and operation manual provided with the appli-
ance apply to these instructions.
GENERAL INFORMATION
This log placement instructions addendum has been prepared to assist in
the placement of new or replacement log sets. The information provided
here is to be used in conjunction with the Installation and Operation
manual. Please read the Care and Operation Instructions completely
before completing the procedures detailed in this placement guide. If
you encounter any problems, need clarification of these instructions
or are not qualified to properly install this log set, contact you local
distributor or dealer.
Read this instruction sheet in its entirety before beginning the
installation.
RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READ IMPORTANT WARNINGS BEFORE PROCEEDING.
TM
*The twig indicated is included in the 24" and 30" log sets only.
• The 30" log set also includes 2 ember chunks (shown in
Figure 9).
*
LOG SET

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
2
LOG PLACEMENT INSTRUCTIONS
1. Place rear ember bed as shown in Figure 1.
Figure 1 - Install Rear Ember Bed
Install
Ember bed
from behind
top burner
Top Burner
Rear Ember Bed
2. Place rear log onto the two rear grate locating pins as shown
in Figure 2 (the locating pins are outlined in Figure 1).
Locating
Pins
Rear Log
Rear Locating Pins
On Grate Assembly
3. Place middle log onto left middle grate locating pin and the
rear ember bed locating pin as shown in Figure 3.
Middle Log
Locating Pins
4. Place left and right front logs onto front grate locating pins as
shown in Figure 4.
Locating Pins Indicated by Arrows
Right Front Log
Left Front Log
5. Place left top log onto rear log and middle log locating pins
as shown in Figure 5.
6. Place the center top log onto the rear log locating pin and
middle log locating pin as shown in Figure 6.
Left Top Log Locating Pins
Center Top Log
Locating Pins
Figure 2 - Install Rear Log
Figure 3 - Install Middle Log
Figure 4 - Install Left and Right Front Logs
Figure 5 - Install Left Top Log
Figure 6 - Install Center Top Log
Position Ember Bed All the Way
Forward in Gas Train Assembly

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE. 3
7. Place the right top log onto rear log locating pin and the right
front log locating pin as shown in Figure 7.
Right Top Log
Locating Pins
8. Place Left Top Twig (24" and 30" models only) onto corre-
sponding notch on rear log as shown in Figure 8. The front
of the Left Top Twig should be up against and behind the left
top log.
Left Top Twig
Front Ember Bed
Figure 7 - Install Right Top Log
Figure 8 - Install Left Top Twig
Left Top Log
9. Place the front ember bed log as shown in Figure 8.
Figure 9 - Completed Installation
18" Gas Log Set
24" Gas Log Set
30" Gas Log Set

4
Printed in U.S.A. © 2007 by Lennox Hearth Products
P/N 750,239M REV. B 11/2007
Lennox™ reserves the right to make changes at any time, without notice, in design, materials,
specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
1110 West Taft Avenue • Orange, CA 92865
