Lennox Elite series User manual

1
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE
SURROUND KITS
MODELS RAVENNA™ AND DESIGNER™
INSTALLATION INSTRUCTIONS FOR INSTALLING SURROUND KITS FOR USE
WITH THE RAVENNA AND DESIGNER GAS FIREPLACE INSERTS
775261M
REV. B, 05/2012
HEARTH PRODUCTS
KITS AND ACCESSORIES
KIT CONTENTS (See Figure 1)
1 ea. Surround Panel Set (Item #1)
1 ea. Surround Trim Set (Item #2)
2 ea. Elbowed Retainers (Item #3)
1 ea. Instruction Sheet
TOOLS NEEDED
Flat Bladed Screwdriver
Surround Panel Kits
Description
RDV, DBV * RDV, DBV,
RDV IPI/TCC *
RDV, DBV,
RDV IPI/TCC **
Cat. No. Cat. No. Cat. No.
29" H x 41" W, w/Black Trim (1 pc.) 75362 H8553 H8520
29" H x 41" W, w/Black Trim 75068 H8554 H8521
29" H x 48" W, w/Black Trim 75069 H8555 H8522
33" H x 41" W, w/Black Trim 75070 H8556 H8523
33" H x 48" W, w/Black Trim 75071 H8557 H8524
Note: RDV = Ravenna (millivolt), DBV = Designer, RDV IPI/TCC = Ravenna (electronic)
* Surround Kits WITH a hole for mounting burner on/off switch
** Surround Kits WITHOUT a hole for mounting burner on/off switch
1
GENERAL INFORMATION
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Read this instruction sheet in its entirety before beginning the installation.
All of these parts may scratch and bend, great care should be used
in handling them.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
TURN OFF THE APPLIANCE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
INSTALLATION INSTRUCTIONS
Installation of the surround assembly is required prior to installing the
face kit (sold separately).
Step 1. Remove the speed nuts from the parts bag and install (with the
flat surface forward) on the six holes in the surround brackets,
three on each side of the insert (See A in Figure 2). A flat bladed
screwdriver may help in installing the nuts.
Step 2. Install all surround panels and trim with the insert positioned in
the fireplace but a few inches in front of its final location.
Step 3. If the insert face is to be installed on the insert, the sight obstruc-
tor that comes with the face must be installed prior to installing
the surround panels. With the curved edge down and the bent
top edge positioned toward the insert, slide the tabs at the ends
of the obstructor in the slots on the surround brackets (see C in
Figure 2).
Figure 1 - Kit Contents
1
1
1
2
2
2
3
3
* 3 ea. spring clips and 6
ea. speed nuts (located in
parts bag in firebox)
*
*
*
*
fire-parts.com

2
Step 4. Install the side surround panels by lining up the holes in the tabs
on the side surround panels in front of the holes on the surround
brackets. Next insert two slotted 1/4" truss screws for each side
surround panel and secure loosely.
Step 5. Fasten top surround panel with the remaining two truss screws.
Tighten all six truss screws after adjusting the surround panels
to eliminate space between side and top surround panels.
Step 6. Assemble the surround trim by inserting the elbowed retainer in
the rectangular slot in the ends of the longest piece of trim and
secure by tightening the screw in the retainer. Slide the mitred
ends of the two side trim pieces onto the elbowed retainer and
secure by tightening the retainer screw.
Shown with brushed nickel traditional face (sold separately)
Figure 3 - Completed Installation
Printed in U.S.A. © 2010 Lennox Hearth Products
P/N 775261M REV. B 05/2012
Lennox Hearth Products reserves the right to make changes at any time, without notice, in
design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE.
1508 Elm Hill Pike, suite 108 • Nashville, TN 37210
Figure 2
The face (kit sold separately) has two hooks on each side that slide over and
hang on the surround brackets at (C). The face can slide slightly from side to
side to center the face on the glass.
Surround Brackets
A
B
C
Step 7. The fastened trim pieces should now be horseshoe shaped. Slide
the trim down over the surround panels so the edge of the sur-
round panel fits just behind the rounded edge of the trim.
Step 8. Install three spring clips (found in parts bag in firebox) in each
piece of trim by inserting them between the rear of the surround
and the channel of the trim. The spring clips will push the trim
tight to the surround.
If you have a gold or nickel face, be sure to clean the face with a soft
cloth and household glass cleaner prior to burning the insert. Finger-
prints left on the face while burning will usually remain on the face
permanently.
