Lennox H6977 User manual

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 1
REFLECTIONS REMOTE CONTROL
REPLACEMENT KIT
HEARTHPRODUCTS
KITS AND ACCESSORIES
INSTALLATION INSTRUCTIONS FOR THE REFLECTIONS REMOTE CONTROL
REPLACEMENT KIT (KIT NUMBERS: H1454 AND H6977)
P/N 750,251M
REV. A 01/2008
GENERAL INFORMATION
This Remote Control Replacement Kit is to be used to replace the
ReflectionsElectricFireplace’sRemoteControl. Thekitcomponentsare
shown below.
REPLACEMENT INSTRUCTIONS
Note: Depending on the type of control board in your fireplace, the
number of steps and components may vary. Following are the types of
control boards for identification:
IfyouhaveKitNumberH1094,itwillbenecessarytoreplacetheboard
andIRcables. Inthis case,completeallthe Stepsasoutlinedin these
instructions.
IfyouhaveKitNumbersH1454 or H6977,itisnotnecessary toreplace
the IR cables. In this case, skip Steps 11 through 21 and complete the
remaining process as outlined in these instructions.
Refer to the Reflections Fireplace Installation Instructions manual (No.
850,091M) for a visual aid on the following steps:
Step 1. Disconnect the electrical power to the fireplace.
Step 2. Remove the doors from the fireplace.
Step 3. Remove the reflective glass.
Step 4. Remove the logs.
Step 5. Remove the grate.
Step 6. Remove the ember bed.
Step 7. Remove the fireplace floor.
Step8. RemovetheDVDplayer. Makesuretolabelthe“VideoOut”and
“Sound Out” cables when disconnected from the DVD player.
Figure 1 (Kit Number H1094)
Plastic Holders Control Board
Figure 2
IR Cables
(Kit Number H1454 And/Or H6977)

2NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 3
Step 9. Locate the fireplace control board (Kit Number H1094) and
remove it, including the plastic holders (
Refer to Figure 1 ).
Step 10. Disconnect the IR cables (ribbon type cables). Refer to
Figure 2 .
Step 11. Locate the wire harness behind the right hand side frame.
Step12. Someearlyunitsmayhaveametalwireshield( Figure3 ). Slide
the shield upwards to align the slots to the screws and remove.
Step13. Pullthewireharnesscompletelyoutside thecavityandremove
theflexiblewireconduittoexposethewirescompletely(someearlyunits
may have binding tape). If provided, save the flexible conduit to re-use.
Step 14. Leave the A/V cables in place. These cables are not being
replaced with the Remote Control Kit.
Refer to Figures 4 and 5 .
Wire Shield
Figure 4
Bottom Side View
Figure 5
A/V Cables
Upper Side View

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 3
Step 15. Locate the TV IR cable and cut about five (5) inches from the
end (
see Figure 6 ).
Step 16. Twisttheconnector endofthe newIRcable totheends ofthe
old IR cable and wrap securely with duct tape. Refer to Figure 7 .
Note: Free all cables from one another and pull them individually, as
they are replaced.
Figure 6
Cut Wire Ties If Provided
Locate The TV IR Cable
Figure 7
Twist And Tape
Figure 8
Pull To Replace
Step17. PulltheTVIRcableuntilthenewcableisout. Unwrapthetape
and discard the old cable ( see Figure 8 ).
Step 18. Locate the Remote Control receiver through the rectangular
slotandpullthecablesoutandcuttheendsfree,enoughtowraptheend
of the new receiver. Then fish them through the rectangular hole while
pulling, to route through the frame cavity ( see Figure 9 . )
Step 19. Push the Remote Control receiver into the rectangular slot
( refer to Figure 10 ).
Figure 9
Pull Remote Receiver Cables Out

4NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 11
Step 20. Bundle the new cables and the A/V cables together and wrap
withmaskingtape,orroutthemthroughtheflexibleconduitifprovided.
See Figures 11 and 12 .
Step21. Tackthewire harness intothesideframeand replace thewire
harness shield, if provided ( see Figure 13 ).
Figure 12
Figure 13
New Cables Routed
Figure 10
Push The Remote Receiver Into The Rectangular Slot Bundle New Cables And A/V Cables Together With Tape
Tack Wire Harness Behind Side Frame

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 5
Step22. PlacetheControlBoardagainstthebackwallandattachusing
the top four (4) outermost holes with the screws and nuts provided.
Refer to Figures 14 and 15 .
Step 23. Plug all connectors into the new Control Board.
See Figure 15 .
Figure 14
Back Wall With Mounting Holes
Figure 15
Mount The Control Board Using The Screws And Nuts Provided
Back Wall With Mounting Holes
Attach With
Screws Here Attach With
Screws Here
Heater
Power Lamp TV/DVD Blower
Display
DVD
TV

6NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Figure 17
Strap The DVD Player
Figure 16
Attach A/V Cables And IR Transmitter Unit
DVD INSTALLATION INSTRUCTIONS
Refertothe DVD ReplacementKit Installation Instructionsmanual (No.
750,250M) for additional aid on the following steps:
Step 1. Before installing the DVD player, connect the new DVD player
to an electrical outlet and insert the DVD disc into the drawer.
Step2. DisconnecttheDVDplayerandbringitintothefireplacecavity.
Step 3. Proceed to connect the A/V cables as labeled. Connect the
power cord.
Step 4. Place a piece ofVelcro on the DVD playereye andattach the IR
transmitter unit to it (
see Figure 16 ).
Step5. Withthecontrolsfacingtotherighthandside,tilttheDVDplayer
sideways under the front frame, to insert it into position.
Step 6. Using the new remote control, test the fireplace for proper
operation.
Step 7. Strap the DVD player ( see Figure 17 ).
Step 8. Re-assemble the fireplace parts in reverse order.

NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE. 7
NOTE: THIS PAGE INTENTIONALLY LEFT BLANK.

8NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
Printed in U.S.A. © 2007 by LHP
P/N 750,251M REV. A 01/2008
The manufacturer reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
