Lennox H7665 User manual

Leg Bolt Down Kit *
Cat. No. Where Used
H7665 Leg Bolt Down Kit, Manufactured Homes
* This Kit is Provided with the Bella Pellet Stove. It is sold separately for the
Grandview Wood Stove
1
TOOLS NEEDED
Ratchet and Socket of proper size to install, field provided, lag screws
INSTALLATION INSTRUCTIONS
Step 1. Secure the legs of the appliance to the floor using 1/4" diameter lag
screws. The lag screws (field provided) must be an adequate length to
extend through the hearth pad and into the floor. Install the brackets
and two lag screws as shown in Figure 2.
HEARTH PRODUCTS
KITS AND ACCESSORIES
506033-19
REV. NC 09/2011
INSTALLATION INSTRUCTIONS FOR LEG BOLT DOWN KIT FOR USE WITH THE
BELLA™ PELLET STOVE AND THE GRANDVIEW™ WOOD STOVE
MANUFACTURED HOME LEG BOLT DOWN KIT
BELLA™ / GRANDVIEW™
KIT CONTENTS (See Figure 1)
2 ea. Leg Bolt Down Brackets
1 ea. Instruction Sheet
GENERAL INFORMATION
If you encounter any problems, need clarification of these instructions or
are not qualified to properly install this kit, contact you local distributor
or dealer.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY
TO THESE INSTRUCTIONS.
TURN OFF THE STOVE AND ALLOW IT TO COMPLETELY COOL
BEFORE PROCEEDING.
Figure 1 - Kit Contents
Figure 2 - Manufactured Home Installations
Attach the provided brackets to the stove using a 5/16" bolt. Install lag
screws through the holes in the bottom of the brackets to secure the legs
to the floor as shown here.
Bracket
Lag Screw
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
Coastal Leg Lakeview Leg
Bella
Grandview GV230

2
Printed in U.S.A. © 2011 Lennox Hearth Products
P/N 506033-19 REV. NC 09/2011
Figure 4 - Manufactured Home Installation
Chassis
Floor
Lag Screws
Floor
Protector
IMPORTANT NOTE: See the Installation and Operation Manual, pro-
vided with the stove for additional requirements for manufactured
home installations.
Lennox Hearth Products reserves the right to make changes at any time, without notice, in design,
materials, specifications, prices and the discontinuance of colors, styles and products. Consult
your local distributor for fireplace code information.
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
1508 Elm Hill Pike, suite 108 • Nashville, TN 37210
G -
G.
I
I
Bolt Down Brackets
Leveling Legs
Figure 3 - Optional Leg Leveling Pad Kit
The leg leveling kit can be used in conjunction with the optional leg
leveling kit (H7638), as shown here. If ordered, install leveling legs per
instructions provided in kit.
