REFRACTORY BRICK PANEL KITS
MODEL SHORELINE™
INSTALLATION INSTRUCTIONS FOR INSTALLING REFRACTORY BRICK PANEL
KITS FOR USE WITH THE SHORELINE™ GAS FIREPLACE INSERT
775,263M
Rev. A, 06/2010
HEARTH PRODUCTS
KITS AND ACCESSORIES
CAUTION
Before you install the refractory brick panels and log
set, the insert should be installed in the fireplace, the
venting attached, the gas line connected and tested
for leaks and the initial burner operation checked.
NOTE: DIAGRAMS AND ILLUSTRATIONS ARE NOT TO SCALE
IMPORTANT NOTE: A refractory brick panel kit is required for proper
operation (sold separately). Never operate this appliance without
all the refractory brick panels properly installed.
TOOLS NEEDED
5/32” Allen Wrench
KIT CONTENTS (See Figure 2):
Please ensure that all these parts are in the packaging.
1 ea. Front Bottom Panel ( A )
1 ea. Rear Panel (B)
1 ea. Left Side Panel (C)
1 ea. Right Side Panel (D)
1 ea. Top Panel (E)
2 ea. Mounting Brackets (F) (see note in Figure 2)
1 ea. Instruction Sheet
GENERAL INFORMATION
All of these parts may scratch and bend, great care should be used
in handling them.
If you encounter any problems, need clarification of these instructions
or are not qualified to properly install this kit, contact you local distribu-
tor or dealer.
Read this instruction sheet in its entirety before beginning the installation.
ALL WARNINGS AND PRECAUTIONS IN THE INSTALLATION AND
OPERATION MANUAL PROVIDED WITH THE APPLIANCE APPLY TO
THESE INSTRUCTIONS.
TURN OFF THE FIREPLACE INSERT AND ALLOW IT TO COMPLETELY
COOL BEFORE PROCEEDING.
B
A
D
C
E
Figure 2
Shoreline Refractory Brick Panel Kits
Cat. No. Model Description
H7987 SHR-BRK-STD Brick Panel Set, Tan
H7988 SHR-BRK-RED Brick Panel Set, Red
H7989 SHR-BRK-ARCHSTONE Brick Panel Set, Architectural
(shown)
Figure 1
NOTE: The Mounting
Brackets will be
provided in some
panel kits only. If the
brick panel kit does
not include brackets,
use the brackets that
came pre-installed
in the firebox of the
insert.
F
Standard
Brick
Red
Brick
Architectural
Stone
fire-parts.com

Printed in U.S.A. © 2010 Lennox Hearth Products
P/N 775,263M REV. A 06/2010
Lennox Hearth Products reserves the right to make changes at any time, without notice, in
design, materials, specifications, prices and also to discontinue colors, styles and products.
Consult your local distributor for fireplace code information.
1508 Elm Hill Pike, Suite 108 • Nashville, TN 37210
INSTALLATION INSTRUCTIONS
Step 1. Start with the front bottom panel A. Set the front bottom panel
in place with detail side facing up as shown. See Figure 3.
Step 4. Slide the top panel in place with the detailed side down. Make sure
panel is positioned all the way back and resting on side panels. Top
panel should be flush in front with the side panels. See Figure 6.
Step 3. Position and slide the side panels against the rear panel. Make
sure panels are behind brackets to hold them in at the top. The
side panels will hold the rear brick panel against the back of the
firebox. See Figure 5.
NOTE: If your brick panel set came packaged with brackets,
you should first replace the pre-installed brackets before
installing the side panels.
B
C D
A
Step 2. Next place the rear panel (B). It will set on the bracket mounted
to the blower mounting plate on the back of the firebox, with the
rounded edge facing up. See Figure 4.
E
Figure 3
Figure 4
Figure 5
Figure 6
F
