LRS T9550 LCK User manual

Usage, Installation, Warranty and Service Information
Long Range Systems, LLC
4550 Excel Parkway, Suite 200
Addison, TX 5001
800.43 .4996 •www.pager.net
800.437.4996
1234
5 6 78
9
101112
0
PGRPROG
ENTER
Long Range Systems
www.pager.net
T9550LCK
Long Range Systems
T9550 LCK
Paging System Transmitter
USER MANUAL

Table Of Contents
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Long Range Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Basic Installation and Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Provided . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Transmitted/Keypad Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Keypad Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Basic Paging Operation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Paging All Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setting the Vibration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
System Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Set Restaurant ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Maintenance Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Range Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Check the Transmitter Battery Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Battery Charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Programming Pagers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
T9550 LCK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rechargeable Pagers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Transmitter Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Pagers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Service Questions and Answers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Long Range Systems 1T9550 LCK User Manual

Long Range Systems
Long Range Systems is a provider of cutting-edge onsite paging solutions. We offer exceptional products and
services that satisfy our customer’s needs for years to come. Thorough familiarity with these instructions and
procedures will ensure proper operation and maintenance of the system.
NOTE: This guide should be kept readily available for managers and key staff.
General Information
The T9550 LCK is an onsite paging system used to increase efficiency in operations by alerting key staff of
immediate needs. The pagers used with the system can vibrate once, twice or three times.
NOTE: The T9550 LCK only works with LRS Star Pagers
Long Range Systems 2T9550 LCK User Manual
1
2
3
4
800.437.4996
www.pager.net
1
4
Long Range Systems
800.437.4996
1234
5678
9
10 11 12
0
PGR PROG
ENTER
Long Range Systems
www.pager.net
T9550LCK
STAR PAGER
LED’s

Basic Installation and Setu
Hardware Provided
Each T9550 LCK transmitter kit contains:
(1) Transmitter keypad
(1) Antenna
(1) Dry-Erase Server Board
(1) 10VAC 2A power supply/charger
(1) Velcro strip for mounting
Installation Procedure
The following is the basic installation procedure
CAUTION:
• Do not connect any other devices to the transmitter.
• The transmitter requires a dedicated power supply.
• Mounting the keypad antenna near any large metal objects will minimize the operating range.
NOTE: The keypad should be charging whenever not in use.
1. Unwrap all system components.
2. Locate the silver connector located on the top of the transmitter unit. Twist the antenna (about 3"
long) onto the connector.
3. Plug the power adapter/charger into a standard 110V outlet, and insert the barrel connector end
into either of the side holes on the transmitter unit.
4. Press (hold for 5 seconds) and release the power-reset button located on the side of the trans-
mitter unit. The keypad display will light.
5. Within 5-10 seconds, the display light will disappear signifying that the transmitter is charging
(The display screen will be blank).
6. Upon completion of setup, allow the keypad to fully charge for at least 12 hours before use. Be sure
that pagers are also fully charged.
Mountin :
The transmitter unit can be mounted onto a wall surface.
• Use the Velcro mounting strip to mount the transmitter unit. Be sure to mount the unit close to a
standard 110 V power outlet.
Portable Use:
The transmitter is rechargeable and can be used without the power supply.
• Disconnect the power supply from the transmitter unit to operate under battery power. Be sure to
plug the power supply back into the transmitter when not in use to recharge the battery.
!
Long Range Systems 3T9550 LCK User Manual

Transmitter/Keypad Elements
Power-Reset Button:
Used when the transmitter’s battery is either depleted or low and needs to be charged. When pressed
and released, the power-reset button ensures proper charging.
Dry-Erase Server Board:
Write the staff names on the label next to their pager number with a NON-PERMANENT, Dry-Erase
Marker or grease pencil.
Keypad Functions
Before using the keypad, read the following key descriptions:
Number Keys:
The number keys 1 through 12 are “one touch” keys to instantly send a message to pagers num-
bered 1 – 12.
Function Keys:
The function keys are located on the last row of the transmitter keypad.
PGR – Used when entering pager numbers above 12.
0– Used when entering pager numbers above 12 that contain a zero and when calling all
pagers at once.
PROG – Used to alter messaging modes and to check the battery level.
ENTER – After entering pager numbers above 12, press ENTER to send the page.
LongRangeSystems
800.437.4996
1234
5678
9
101112
0
PGRPROG
ENTER
LongRangeSystems
www.pager.net
T9550LCK
Jerry
Thomas
Susan
CONDOR
CLASS2TRANSFORMER
[phone]
INPUT:AC12OV60Hz19w
OUTPUT:AC9V1800mA
P/N:A91A8
RoHS
UU
LL
LISTED
C
MODEL:48A-9-1800
EIA3630635S
MADEINCHINA
Antenna
Dry-Erase
Server Board
Power-Reset
Button
Keypad
Function Keys
120VAC
Electrical
Supply
Power
Supply/Charger
Long Range Systems 4T9550 LCK User Manual

Basic Paging O erations
NOTE: The T9550 LCK factory defaults are the most commonly used settings. (All units are set to
vibe 1 time as the default.)
Pa in
For pagers numbered 1 – 12:
1. Press the pager number
2. The unit will automatically send a page
For pa ers numbered 13 and hi her:
1. Press PGR
2. Enter the pager number (using the 0 – 9 keys)
3. Press the ENTER key
Pa e All Call
If all staff pagers need to be called simultaneously:
1. Press PGR
2. Press 0 - 0 - 0
3. Press the ENTER key
Long Range Systems 5T9550 LCK User Manual

SYSTEM SETTINGS
Settin the Vibration Mode
Vibration mode determines the number of times a pager will vibrate when paged.
NOTE: The factory default setting for vibration mode is 1 vibration. (EX: When a page is sent from
the transmitter, the pager will vibrate once)
To set the vibration mode, use the followin steps:
• 1 vibration: Press PROG
Enter 9 - 2 - 1 and press ENTER
• 2 vibrations: Press PROG
Enter 9 - 2 - 2 and press ENTER
• 3 vibrations: Press PROG
Enter 9 - 2 - 3 and press ENTER
• Page a pager (see pg. 6) to ensure that the pager vibrates the number of times programmed
System Reset
If the transmitter’s battery has been completely depleted, it may require a system reset before operating
properly. When the system is reset, the Restaurant ID (see pg. 7) and vibration mode (see pg. 7) will be set
to factory default.
To reset the transmitter to factory default:
1. Press PROG
2. Enter 0 - 0 - 0 and press ENTER
Set Restaurant ID
NOTE: The T9550 LCK is shipped factory defaulted in the most commonly used configuration.
• The Restaurant ID factory default setting is 0.
Your system may or may not be shipped with the factory default setting ID = 0. However, this ID# is often used,
except in cases where neighboring establishments both use LRS systems and would interfere with each
other. Contact LRS to verify your Restaurant ID. (It is not recommanded to change system ID without speak-
ing to LRS service departments.)
To chan e the ID:
1. Press PROG
2. Enter 9 - 0 - # (EX: 9 – 0 – 3, Restaurant ID = 3)
3. Press ENTER
Long Range Systems 6T9550 LCK User Manual

Long Range Systems 7T9550 LCK User Manual
Maintenance Functions
Ran e Test
Perform a range test to determine the furthest point a pager will receive the signal of the T9550LCK.
NOTE: Be sure to remove pagers from the charging base before performing the range test.
1. Press PROG
2. Enter 9 - 1- 2 and press ENTER
3. When the “0” begins scrolling across the screen, pagers will vibrate every 5 seconds (as long as
they are receiving the signal)
4. Take a pager and walk around the area to verify that the pagers operate in all areas
5. When a pager stops vibrating every 5 seconds, it is out of range and is no longer receiving a sig-
nal from the transmitter
Check the Transmitter Battery level
1. Disconnect barrel end of the power adapter from the transmitter unit.
2. Press PROG and then ENTER.
The unit will show a number from 0 to 5:
• If plugged in – it does not matter.
• If the unit shows 4 or above – the charge is adequate for normal use.
• If the unit shows 3 – it is ok for short term use (1 - 2 hours).
• If the unit shows 2 or less (including blank) – it must be recharged before use.
Battery Char e
If the battery power has been completely depleted:
1. Plug the power supply/charger into the transmitter unit.
2. After 10 seconds press and release the power-reset button located on the side of the transmitter.
The display will light.
3. Within 5-10 seconds, the display light will disappear and the screen will remain blank. This is an
indication that the battery is charging.
4. Allow the keypad to charge for at least 12 hours.
5. Check the battery level to ensure that the battery is fully charged (see pg. ).

Programming Pagers
Only LRS’s Star Pagers can be reprogrammed from the T9550 LCK transmitter. If you would like to assign
or reassign numbers to pagers, contact LRS to verify your restaurant ID before proceeding.
The followin is the basic procedure for pro rammin pa ers:
1. Be sure to set the LCK for the restaurant ID in use (See “Restaurant ID” pg. 7).
2. Remove the pager from the charger and wait until it stops vibrating. (Note: remove only one pager
at a time during programming)
3. Press PROG
4. Enter the number you wish to assign to the pager (Choose #: 1 – 99).
5. Press PROG
6. After the pager completes one glow mode cycle, page it to ensure that it’s programmed correctly
(See “Basic Paging Operations” pg. 6).
7. Repeat Steps 2 through 6 for each pager to program.
System S ecifications
Notice: Operation is subject to the followin :
• This device may not cause interference.
• This device will accept any interference including interference that may cause undesired oper-
ation of the unit.
T9550 LCK
Required Voltage: One-110V outlet for the transmitter keypad.
Operating Frequency: 467.750MHz
Radiated Power: <4900 micro-volts/meter
Operating Range: Dependent upon the paging environment.
Rechar eable Pa er
Required voltage: (1) 110V outlet for 10VAC pager charger adapter.
Batteries: Rechargeable Nickel Metal Hydride (NiMH).
Battery life of pager: Approximately 4 hours (dependant on usage). Recharge time: 12 hours mini-
mum from completely “dead”.
Long Range Systems 8T9550 LCK User Manual

Troubleshooting
Transmitter Unit
The Li ht On The Keypad Display Does Not Come On When A Key Is Pressed
• Perform a battery charge (see pg. ), and check for a light after 30-minutes.
• If the display still does not light, check the charging power supply by plugging the power/charg-
ing supply used for the pager charger into the transmitter unit.
• If the display light comes on, there may be a problem with the T9550LCK power/charging sup-
ply. Call LRS Customer Support to order a new power supply.
• If the display still does not light, there may be a problem with the transmitter unit. Call LRS Cus-
tomer Support for assistance.
The Keypad Display Is Functionin Properly But The Pa er Does Not Receive the Pa e
• Perform a system reset (see pg. 7).
• Complete the steps for paging a pager (see pg. 6).
• If the pager still does not receive the page, call LRS Customer Support for assistance.
Pa ers
Pa er Char e Li hts Do Not Come On
Pager charger should display a single red charge light when they are placed in the charger, and are charg-
ing correctly. If the red charge light is not visible on some or all charging slots, review the following recom-
mendations to determine and solve the problem.
• Make sure the pagers are completely inserted into the charging slot.
• The power supply may be defective. Try plugging the power supply used for the transmitter
into the pager charger.
• You may have more pagers charging on one power supply than recommended. Only 25 pagers
can be charged on one 10V power supply. If you have more than 25 pagers, you should call LRS
to order additional chargers.
• You may have a jumper wire that is not properly connected. Look on the side of your chargers
and verify that all wires are connected properly. If they are connected, then the metal contacts
on your pager may be dirty. Using a damp rag, clean the 2 metal contacts on the back of each
pager.
• Be sure that your staff is not disconnecting the power supply at anytime or that you do not have
the charger connected to a circuit that automatically shuts off after hours. The charging base
should be plugged into a power outlet that is “ON” at all times (Be sure the pager is not in the
charger backwards).
• If none of these recommendations solve your problem, call LRS Customer Support to deter-
mine the problem at 00-437-4996.
Long Range Systems 9T9550 LCK User Manual

Service Questions and Answers
Should your paging system ever fail or should you need additional paging equipment, call Long Range Sys-
tems at ( 00) 437-4996.
Normal Business Hours
Monday – Friday :30 am to 5:00 pm Central Time.
Weekend or Evenin Emer encies:
• Long Range Systems provides 24/7 live technical support.
• Please keep in mind that replacement options are limited on weekends and holidays.
Long Range Systems 10 T9550 LCK User Manual

Warranty
Long Range Systems, LLC permits a one-year manufacturer’s warranty following the original consumer purchase date
of any LRS system. Any individual components or products purchased will receive a 30-day manufacture warranty. This
warranty covers any defects due to faulty material or workmanship, but does not include damage to the product result-
ing from accident, misuse or improper electrical connection. If the product or system should become defective within the
warranty period, we will repair or replace with equivalent equipment, free of charge. We will pay transportation charges
to return your product via standard FedEx Ground shipping, provided the product is shipped prepaid to:
Long Range Systems, LLC
4550 Excel Pkwy, Suite 200
Addison, TX 75001
No return or replacement can be received without prior authorization from the LRS Customer Support department or with-
out the proper RMA# posted on the outside of the shipping container. Contact Customer Support at 00.437.4996 or
www.pager.net. This warranty gives you specific legal rights and you may also have rights that vary by state.
Copyright © 2013, Long Range Systems, LLC All Rights Reserved
This manual contains proprietary information of Long Range Systems, LLC (LRS) and is intended for use only by its em-
ployees or customers. None of the material contained herein may be copied, reproduced, republished, downloaded, dis-
played, posted, or transmitted in any form or by any means, including but not limited to, electronic, mechanical,
photocopying, recording, or otherwise without the prior written permission of LRS. Additional copies of this manual may
be obtained by contacting LRS.
Screen displays, keyboard layouts, hardware descriptions, or software are proprietary to LRS and are subject to copy-
right and other intellectual property rights of LRS and shall be treated in accordance with the previous paragraph.
All attempts have been made to make the information in this document complete and accurate. LRS is not responsible
for any direct or indirect damages or loss of business resulting from inaccuracies or omissions. Specifications and other
information contained within this document are subject to change without notice.
Long Range Systems, LLC reserves the right to make changes without further notice to any products herein. LRS, LLC
makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor
does LRS, LLC assume any liability arising out of the application or use of any product or circuit, and specifically disclaims
any and all liability, including without limitation consequential or incidental damages. “Typical” parameters that may be
provided in LRS, LLC data sheets and/or specifications can and do vary in different applications and actual performance
may vary over time. All operating parameters, including “Typicals”, must be validated for each customer application by
customer’s technical experts. LRS, LLC products are not designed, intended, or authorized for use as components in sys-
tems intended to support or sustain life, or for any other application in which the failure of the LRS, LLC product could
create a situation where personal injury or death may occur. Should Buyer purchase or use LRS, LLC products for any
such unintended or unauthorized application, Buyer shall indemnify and hold LRS, LLC and its officers, employees, sub-
sidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney
fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unau-
thorized use, even if such claim alleges that LRS, LLC was negligent regarding the design or manufacture of the part, de-
vice or system.
EU DECLARATION OF CONFORMITY
We, Long Range Systems hereby declare under our sole responsibility that the T9550 LCK paging transmitters and on-
site pagers comply with the essential requirements in the European RE&TTE Directive 1999/5/EC of the European Par-
liament of the Council of 9 March 1999 on radio equipment and telecommunication terminal equipment and the mutual
recognition of their conformity. The following standards were utilized:
ETS 300 22 : 1998 EN 301 89-2: 2002
EN61000-3-2: 1998 EN 61000-3-3: 1995
EN 60950: 1992 with A1, A2, & A3.
Long Range Systems 11 T9550 LCK User Manual
XU-000 061113
