LRS T9601 User manual

SERVER
V1
V2 V3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
PROG
PGR
CLR
ENT
www.pager
.net
UUssaaggee,, IInnssttaallllaattiioonn,, WWaaaannttyy aanndd SSeevviiccee IInnffoommaattiioonn
Long Range Systems, Inc.
44555500 EExxcceell PPaakkwwaayy,, SSuuiittee 220000
AAddddiissoonn,, TTXX 7755000011
880000..443377..44999966 ••wwwwww..ppaaggee..nneett
T9601
Paging System Transmitter
U S E R M A N U A L

Warranty
Long Range Systems, Inc. warrants this product against any defects that are due to faulty material or workmanship for
a two-year period after the original date of consumer purchase. This warranty does not include damage to the product
resulting from accident, misuse or improper electrical connection. If this product should become defective within the war-
ranty period, we will repair or replace it with an equivalent product, free of charge. LRS will return your product via UPS
ground shipping. All warranty claims must be initiated through our customer service department.
Customer Service: 800.437.4996
4550 Excel Parkway, Suite 200
Addison, TX 75001
This warranty gives you specific legal rights and you may also have rights that vary from state to state.
Copyright © August 2008, Long Range Systems, Inc. All Rights Reserved
This manual contains proprietary information of Long Range Systems, Inc. (LRS) and is intended for use only by its em-
ployees or customers. None of the material contained herein may be copied, reproduced, republished, downloaded, dis-
played, posted, or transmitted in any form or by any means, including but not limited to, electronic, mechanical,
photocopying, recording, or otherwise without the prior written permission of LRS. Additional copies of this manual may
be obtained by contacting LRS.
Screen displays, keyboard layouts, hardware descriptions, or software are proprietary to LRS and are subject to copy-
right and other intellectual property rights of LRS and shall be treated in accordance with the previous paragraph.
All attempts have been made to make the information in this document complete and accurate. LRS is not responsible
for any direct or indirect damages or loss of business resulting from inaccuracies or omissions. Specifications and other
information contained within this document are subject to change without notice.
Long Range Systems, Inc. reserves the right to make changes without further notice to any products herein. LRS, Inc.
makes no warranty, representation or guarantee regarding the suitability of its products for any particular purpose, nor
does LRS, Inc. assume any liability arising out of the application or use of any product or circuit, and specifically disclaims
any and all liability, including without limitation consequential or incidental damages. “Typical” parameters that may be
provided in LRS, Inc. data sheets and/or specifications can and do vary in different applications and actual performance
may vary over time. All operating parameters, including “Typicals”, must be validated for each customer application by
customer’s technical experts. LRS, Inc. products are not designed, intended, or authorized for use as components in sys-
tems intended to support or sustain life, or for any other application in which the failure of the LRS, Inc. product could
create a situation where personal injury or death may occur. Should Buyer purchase or use LRS, Inc. products for any
such unintended or unauthorized application, Buyer shall indemnify and hold LRS, Inc. and its officers, employees, sub-
sidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable attorney
fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unau-
thorized use, even if such claim alleges that LRS, Inc. was negligent regarding the design or manufacture of the part, de-
vice or system.
EU DECLARATION OF CONFORMITY
We, Long Range Systems hereby declare under our sole responsibility that the T9601 paging transmitters and on-site
pagers comply with the essential requirements in the European RE&TTE Directive 1999/5/EC of the European Parliament
of the Council of 9 March 1999 on radio equipment and telecommunication terminal equipment and the mutual recog-
nition of their conformity. The following standards were utilized
ETS 300 224: 1998 EN 301 489-2: 2002
EN61000-3-2: 1998 EN 61000-3-3: 1995
EN 60950: 1992 with A1, A2, & A3.
Long Range Systems 1T9601 User Manual

Table Of Contents
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Long Range Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General In ormation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation and Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Hardware Provided . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Bracket Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Keypad Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Basic Paging Operation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Paging a Manager Pager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Paging All Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting the Vibration Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Set the Vibration Strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
System Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setup All Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Station ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
System ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
System Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Set Simulatneous Manager Paging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setup Duty Pager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Set Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Set POCSAG Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Set Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Key Tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Maintenance Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
POCSAS Anti-Theft . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleaning the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Programming Pagers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Assign Manager Pager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
System Speci ications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
T9601 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
T9601 Quick Programming Funictions Guide . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Transmitter Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Pagers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Service Questions and Answers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cleaning & Charging Instructions or LRS Paging Equipment . . . . . . . . . . . . . 28
Long Range Systems 2T9601 User Manual

Long Range Systems
Long Range Systems is a provider of cutting-edge onsite paging solutions. We offer exceptional products and
services that satisfy our customer’s needs for years to come. Thorough familiarity with these instructions and
procedures will ensure proper operation and maintenance of the system.
NOTE: This guide should be kept eadily available fo manage s and key staff.
General Informat on
The T9601 is an onsite paging system used to increase efficiency in operations by alerting key staff of im-
mediate needs. The pagers used with the system can vibrate, beep or display LED messaging. The pager-
messaging mode is set using the keypad (e.g. vibration).
NOTE: The T9601 only works with LRS Star Pagers, and LRS rechargeable and battery operated al-
phanumeric pagers (1-line Alpha Pager (SP5), and 4-Line Alpha Pager)
Notice: Operation is subject to the following:
• This device may not cause interference
• This device will accept any interference including interference that may cause undesired oper-
ation of the unit.
Long Range Systems 3T9601 User Manual
1
2
3
4
800.437.4996
www.pager.net
1
4
STAR PAGER
LED’s
www.pager.net
www.pager.net
4-LINE ALPHA PAGER
1-LINE ALPHA PAGER (SP5)

Bas c Installat on and Setup
Hardware Provided
Each T9601 transmitter kit contains
(1) T9601 Setup Guide
(1) Transmitter keypad with Dry-Erase name board
(1) Dry Erase Marker
(1) Antenna
(1) 10VAC power adapter
(1) Thumbscrew
(1) Thumbscrew Clamp
(2) Mounting Brackets (1 – with foam pad, 1 – without foam pad)
(4) Screws
Installation Procedure
The following is the basic installation procedure
CAUTION::
• The t ansmitte equi es a dedicated powe supply
• Mounting the antenna nea any la ge metal objects will minimize the ope ating ange.
1. Unwrap all system components.
2. Twist the antenna into the silver connector located on the top of the transmitter unit.
3. Mount the power supply in a location where there is access to 110V power for charging (see pg.
5 “Mounting Your System”)
4. Insert the barrel connector end of the power supply into the connector hole located at the bottom
of the transmitter unit
5. Plug the power supply into a standard 110V outlet
6. The LCD screen on the transmitter will light up and display “tin” (time)
7. Press ENT to exit time setup
8. The screen will display a default time 12.00
OR
9. Enter the time hh (hour) mm (minutes) (ex. 10 00), and press ENT
10. Press PGR for AM or ENT for PM
11. The screen will display the time entered ex. 10.00
12. Upon completion of setup, make sure pagers are fully charged use
NOTE: Allow pagers to charge in charging base for at least 24 hours prior to the first use.
!
Long Range Systems T9601 User Manual

Mounting Your System:
Four captive nuts are located in a slider on the backside of the T9601 transmitter. These are used to
secure the mounting brackets to the unit. The brackets may be mounted in several configurations de-
pendent upon the mounting surface.
1. Position the non-foam padded mounting bracket so that the side with the two holes (laying flat on
the slider) are pointing towards the antenna end of the transmitter.
2. Align the holes with two of the captive nuts.
3. Insert the 2 screws into the holes. Do not fully tighten screws.
4. Repeat steps 1-3 with the foam-padded mounting bracket. The two holes should be pointing op-
posite the antenna end of the transmitter (foam padding should be facing the opposite bracket).
Long Range Systems 5T9601 User Manual
Captive Nuts
Captive Nuts
Mounting Bracket
Screws

5. Adjust the distance between the
brackets to fit the mounting surface.
6. Securely tighten all captive screws.
7. In a clockwise motion, turn the
thumbscrew into the non-foam
padded mounting bracket.
8. Attach and screw the thumbscrew
clamp foot to the thumbscrew.
9. Holding the transmitter steady, po-
sition the foam padded side of the
mounting bracket onto the bottom
of the mounting surface.
10. In a clockwise motion, screw the
thumbscrew onto the mounting sur-
face, such that the transmitter is po-
sitioned firmly onto the surface.
Long Range Systems 6T9601 User Manual
Thumbscrew Clamp Foot
Turn Clockwise to Tighten
Turn Counter-
Clockwise to
Loosen

Long Range Systems 7T9601 User Manual
Bracket Mounting Suggestions
The basic mounting suggestion is shown here.
Mounting Bracket without Foam
Padding
Thumbscrew
Thumbscrew Clamp Foot
Mounting Surface
Mounting Bracket with Foam
Padding

Transmitter/Keypad Elements
Power-Reset Button:
Used to reset pagers before reprogramming.
Dry-Erase Server Board:
Write the staff names on the label next to their pager number with a NON-PERMANENT, Dry-Erase
Marker or grease pencil.
Keypad Functions
Before using the keypad, read the following key descriptions
Function Keys:
The function keys are located on the last row of the transmitter keypad.
PROG – Used when altering system settings, functions, and programming pagers
PGR– Used when entering pager numbers above 16
CLR – Used to clear an entry
ENT – Used to enter changes to system settings, functions, and to send a page
Vibration Keys
V1, V2 and V3 select the number of vibrations a pager will respond with. This button is pressed be-
fore paging a pager. Sends message 1, 2 or 3 to Alpha pagers.
Number Keys:
Number keys 1 through 16 are “one touch” keys to instantly page pagers 1 – 16. Number 10 is also
0 when programming or paging pagers numbered above 16.
Long Range Systems 8T9601 User Manual

Bas c Pag ng Operat ons
The T9601 factory defaults are the most commonly used settings (System ID = 0, Vibration Mode = 1).
Paging
For pagers numbered 1 – 16
1. Press the pager number on the keypad unit
2. The unit will automatically send a page
For pagers numbered 17 and higher:
NOTE Pagers can be numbered up to 999
1. Press PGR
2. Enter the pager number (using #’s 1 – 9 and 10 [as zero])
3. Press ENT
When a page is sent and received:
• Star Pagers – will flash and vibrate
• Rechargeable and battery operated Alpha Pagers – will display “Kitchen <Station #>“ Example
Kitchen 1
Page A Manager Pager
1. Press PGR
2. Enter the manager pager number
3. Press ENT
When manager pager is set and a page is received:
• Rechargeable and battery operated Alpha Pagers – will display “Manager to Kitchen <Station
#>”
Example: Manage to Kitchen 1
All Call Page
If all pagers need to be called at once,
1. Press PGR
2. Press 0
3. Press the ENT
Alternate Method if “All Call” is enabled (See p. 10 “Set Up All Call”)
1. Press button “16” on transmitter keypad
When All Call Page is enabled and a page is received:
• Star Pagers will flash and vibrate
• Rechargeable and battery operated Alpha Pagers will display “All Page Kitchen <Station #>”
Example: All Page Kitchen 1
Long Range Systems 9T9601 User Manual

System Sett ngs
Setting the Vibration Mode
NOTE: The factory default setting for vibration mode is 1 vibration. (EX When a page is sent from
the transmitter, the pager will vibrate once)
To set the vibration mode:
1. Press PROG
2. Enter 9 - 2 - #
• 1 vibration # = 1
• 2 vibrations # = 2
• 3 vibrations # = 3
3. Press ENT
Set the Vibration Strength (Only Appicable to the SP5)
The strength of a pager’s vibration when paged can be set.
To adjust the vibration level, between 0 (minimum) and 9 (maximum)
1. Press PROG
2. Enter 9 - 4 - # (# = 0 – 9)
3. Press ENT
• No vibration # = 0
• Mid level vibration # = 5
• Maximum vibration # = 9
System Reset
In certian situations the T9601 may require a system reset before operating properly. When the system is
reset, the Restaurant ID (see pg. 11) and vibration mode (see pg. 10) will be set to factory default.
To reset the transmitter to factory default:
1. Press PROG
2. Enter 0-0-0 and press ENTER
Long Range Systems 10 T9601 User Manual

Setup All Call
‘All Call’ sends a page to all pagers at once. When ‘All Call’ is enabled, pressing the number “16” on the key-
pad will perform this function.
To enable:
1. Press PROG
2. Enter 9 - 3 - 5
3. Press ENT
To disable:
1. Press PROG
2. Enter 9 - 3 - 4
3. Press ENT
Station ID
When more than one transmitter is being used on the same System ID, a station ID can be set to identify
which transmitter the page came from. The station ID will display when a page is sent.
To set:
1. Press PROG
2. Enter 9 - 6 - # (# = Station ID 1 – 9)
3. Press ENT
System ID
The system ID is used to keep neighboring paging systems from interfering with each other. This setting
should only be cahnges at the advice of an LRS custmer support representative.
To change the ID:
1. Press PROG
2. Enter 9 - # - # (# = System ID 00 – 19) (EX 9 – 0 – 3, System ID = 3)
3. Press ENT
Set Simultaneous Manager Paging
This feature allows the manager to receive a message anytime a server is paged.
NOTE: This function works with LRS Alpha pagers only.
To turn on:
1. Press PROG
2. Enter 9 - 5 - 1
3. Press ENT
4. LCD screen on transmitter will display On
Long Range Systems 11 T9601 User Manual

When a simultaneous manager page is received:
• Rechargeable and battery operated Alpha Pagers – will display “Server # Kitchen <Station #>”
Example Server 5 Kitchen 1
To turn off:
1. Press PROG
2. Enter 9 - 5 - 2
3. Press ENT
4. The LCD screen on the transmitter will display Off
Setup Duty Pager
Duty pager is used to remind someone of a task that must be completed at specified intervals. A duty re-
minder page is sent to the assigned pager at preset time intervals. The system’s “time” must be set prior to
enabling duty pager.
To Enable:
1. Press PROG
2. Enter 9 - 8 - 0
3. Press ENT
• At dut (duty), enter the pager number
• Press ENT
• At INT, enter the time (interval) in minutes for the reminder page
• Press ENT
• At Str, enter the time of day the task begins hh (hour) mm (minute) (ex 10 00)
• Press ENT
• Press PGR for A (AM) or ENT for P (PM)
• At Stp, enter the time of day the task ends hh (hour) mm (minute) (ex 12 00)
• Press ENT
• Select A (AM) [by pressing PGR] or P (PM) [by pressing ENT]
When duty pager is set and an interval page is received:
• Star Pagers – will flash and vibrate
• Rechargeable and battery operated Alpha Pagers – will display “Reminder Message Kitchen
<Station #>” Example Reminder Message Kitchen 1
To Disable:
1. Press PROG
2. Enter 9 - 8 - 0
3. Press ENT
4. At dut (duty), enter “0”
5. Press ENT
Long Range Systems 12 T9601 User Manual

Restart Duty Timer
If a task is performed early, the timer can be reset to start the interval over.
To restart:
1. Press PROG
2. Enter 9-8-1
3. Press ENT
Set Time and Date
Time and date are not required for normal use; however, it should be set if duty pager is enabled, and if a
time is required for Alpha pagers.
NOTE: Time and date should be reset at each startup
To set time:
1. Press PROG
2. Enter 9 - 3 - 2
3. Press ENT
• At the tin (time) prompt, enter the hh (hour) and the mm (minute)
• Press ENT
• Press PGR for A (AM) or ENT for P (PM)
To set date:
1. Press PROG
2. Enter 9 - 3 - 3
3. Press ENT
• At the (month) prompt, type the mm (month)
• Press ENT
• At the (day) prompt, type the dd (day)
• Press ENT
AP
PROG PGR CLR ENT
Long Range Systems 13 T9601 User Manual
Select for P
Select for A

• At the (year) prompt, type the yy (year)
• Press ENT.
Send Time and Date to Alpha pagers
The T9601 automatically sends the date and time every minute. However, you can also manually send
time/date to all Alpha pagers using the transmitter keypad.
To send time/date:
1. Press PROG
2. Enter 9 - 3 - 1
3. Press ENT
Set POCSAG Start
In systems using both Alpha pagers and Star pagers, a start for the POCSAG (alpha) pagers must be set.
The default POCSAG start for alpha pagers is 50. Alpha pagers should be programmed using a number equal
to or above 50. Star (SP4) pagers should be programmed using a number below 50.
To setup:
1. Press PROG
2. Enter 8 - # - # (# is a number between 01 and 99)
3. Press ENT
Set Language
The T9601 provides the option to transmit preset messages to alphanumeric pagers in different languages.
The following languages are available English, Spanish, French, German, Italian, and Portuguese.
To set a language:
English (default)
1. Press PROG
2. Enter 9 - 5 - #
3. Press ENT
• English # = 3
• Spanish # = 4
• French # = 5
• German # = 6
• Italian # = 7
• Portuguese # = 8
Long Range Systems 1 T9601 User Manual

Key Tone
The default key tone for the T9601 is a ‘beep’ sound when keypad buttons are pressed. However, the key tone
‘beep’ sound can be disabled.
To enable:
1. Press PROG
2. Enter 9 - 8 - 6
3. Press ENT
To disable:
1. Press PROG
2. Enter 9 - 8 - 7
3. Press ENT
Long Range Systems 15 T9601 User Manual

Ma ntenance Checks
Range Test
Perform a range test to determine the effective range of the T9601.
NOTE: Be sure to remove pagers from the charging base before performing the range test.
1. Press PROG - 9 - 9 - 7 - ENT
2. The screen will display “tst” and then a “-” (dash) will appear
3. When the “-” (dash) begins scrolling across the screen, pagers will vibrate every 5 seconds (as long
as they are receiving the signal)
4. Take a pager and walk around the area to verify the pager operates in all areas (the pager will stop
vibrating when it is out of range)
5. Press ENT To stop the range test
Anti-Theft
Anti-theft is used to alert staff carrying alpha pagers that they are leaving the premises while still carrying
the pager.
NOTE: Anti-Theft only works with alphanumeric pagers.
To Turn On:
1. Press PROG
2. Enter 9 - 9 - 9
3. Press ENT
To Turn Off:
1. Press PROG
2. Enter 9 - 9 - 8
3. Press ENT
When Activated:
• The transmitter sends a signal to alpha pagers, and if the signal is not received, the pager will
emit a continuous beep sound until it is returned to the charging unit or is back within range.
• The LED screen on the alphanumeric pagers will display “OUT OF RANGE”.
Cleaning The System
Caution: Do not use any cleaning solutions containing chlo ide
When cleaning the T9601 system and its components (pagers, charging base), DO NOT use any cleaning
products that contain Chloride. These products will damage the material and will stain the surface.
NOTE: Be sure to unplug the T9601 system and charging base before cleaning.
To Clean:
• Using a damp cloth, wipe the exterior of the system’s components
Long Range Systems 16 T9601 User Manual

Programm ng Pagers
If a new pager number needs to be assigned to a pager, Star (SP5) and Alpha pagers can be reprogrammed
from the T9601 transmitter. If you would like to assign or reassign numbers to pagers, contact LRS to verify
your restaurant ID before proceeding.
To Program Pagers:
1. Be sure the POCSAG start is correct for programming pager types (see “Set POCSAG Start” pg. 14)
2. Pagers
• Remove rechargeable pagers from the charger (or reset by touching the silver nodes on the
pager to the reset terminal on the transmitter) and wait until it stops vibrating
• Turn battery powered pagers on and then off (or remove and reinstall the battery) and wait until
it stops vibrating and/or beeping
4. Press PROG
5. Enter the number you wish to assign to the pager (Choose # 1 - 999)
6. Press PROG
• Star pagers will slowly vibrate and light up then dim to off
• Alpha pagers will beep 4 times and then stop
7. Once programming is complete, page the pager to ensure it is programmed correctly
(See “Basic Paging Operations” p. 9)
Top View of the T9601
Long Range Systems 17 T9601 User Manual
Reset Terminals Marker Holder
Antenna

Assign Manager Pager
A manager pager can be assigned to notify a manager what station they are needed at when a page is re-
ceived. Only LRS alphanumeric pagers (rechargeable and battery operated) can be set as manager pagers.
Set Manager Pager
1. Press PROG
2. Enter 9 - 8 - 5
3. Press ENT
4. At Ngr (manager), enter the pager number
5. Press ENT
NOTE: Manager pager cannot be disabled. However, you can reassign manager pager to a differ-
ent pager number. To reassign, follow the steps for setting manager pager and enter a dif-
ferent pager number.
System Spec f cat ons
Notice: Operation is subject to the following:
• This device may not cause interference.
• This device will accept any interference including interference that may cause undesired oper-
ation of the unit.
T9601
Required Voltage One-110V outlet for the T9601 transmitter
(Batteries This option currently NOT available)
Operating Frequency 467.750MHz
Radiated Power <4900 micro-volts/meter
Operating Range Dependent upon the paging environment
Long Range Systems 18 T9601 User Manual

T9601 Qu ck Programm ng Funct ons Gu de
When programming functions:
1.Press PROG
2. Enter the Function Code
3. Press ENT
* Make sure POCSAG Start is set
Long Range Systems 19 T9601 User Manual
Function Function
Code Notes
Reset 0
System settings default to:
Station ID = 1
System ID = 0
Vibration 1, 2, or 3 9 2 # # = Vibration = 1, 2, or 3
POCSAG Start 8 # # ## = Start = 01 – 99
System ID (Restaurant ID) 9 ## ## = ID = 00 – 19
Time: Send to Pager 9 3 1 Sends Time and Date to Alpha Pagers
Set Time 9 3 2 At TIM enter hh mm (Hour, inute) Press ENT
Press A or P (A /P )
Set Date 9 3 3
At DTE enter mm ( onth), press ENT
dd (Day), press ENT
yy (Year), press ENT
Setup All Call 9 3 # # = 4= ON # = 5 = OFF
Vibration Strength 9 4 # (# = 1 – 9) # = 0 = OFF
# = 1 = inimum # = 9 = aximum
Simultaneous anager Paging 9 5 # # = 1 = ON # = 2 = OFF
Language 9 5 #
# = Language
• English = 3 • Spanish = 4 • French = 5
• German = 6 • Italian = 7 • Portuguese = 8
Station ID 9 6 # # = ID = 1 – 9
Firmware Version 9 7 5
Duty Pager Setup 9 8 0
At dut , enter pager #, and press ENT(Pager # = 0 disables)
At Int, enter interval time and press ENT
At Str, enter start time and press ENT
At Stp, enter stop time and press ENT
Duty pager Reset 9 8 1 Restarts interval timer on duty pager
anager Pager 9 8 5 At Mgr, enter the pager number
Press ENT
Enable/Disable Key Tone Beep 9 8 # # = 6 = ON # = 7 = OFF
Enable/Disable A paging 9 9 # # = 1 = ON # = 0 = OFF
Range Test 9 9 7 Enables Range Test (Press ENT to stop)
POCSAG anti theft ON/OFF 9 9 # # = 9 = ON # = 8 = OFF
All Call Paging Press PGR Enter “0” and Press ENT
One Touch Paging Press the
pager # Pager #’s (1 – 16)
High Number Paging Press PGR Enter pager # (1-999) and Press ENT
*Programming Pagers Press PROG Enter pager # (1-999) and Press PROG
