LSIS S100 Series Programming manual

0.4~22kW(200V/400V)
AC Variable Speed Drive
S100 Troubleshooting Manual
Safety Instructions
Read this manual carefullybefore servicing or inspecting this equipment.
Keepthis manual within easy reach for quick reference.

1
Quick Reference Table
The following table listed situations frequently encountered while working with inverters. Refer to
the typical situations to quickly and easily locate solutions to your questions.
Situation
Reference
The motor is too noisy.
P. 30
I want to review recent fault trip and warning histories.
P. 15
The motor is producing too much heat.
P. 27
The cooling fan is not working.
P. 31
I want to know how I can keep the inverter when I am not using it.
P. 42
ERR message is displayed on the keypad.
P. 18
I want to initialize all parameters.
P. 13
I want to terminate the inverter.
P. 42
I want to review the input/output module.
P. 35
I want to change the fan when it exceeded the replacement period.
P. 39
I want to change the carrier frequency.
P. 12
I cannot set the parameters.
P. 26
The motor is not working.
P. 26
The motor stops when it is connected to the load or accelerated.
P. 28

2
Contents
INTRODUCTION 3
PRODUCT IDENTIFICATION 4
ASSOCIATION MANUAL 4
SAFETY INFORMATION 5
REVISION RECORD 7
1BASIC CHECKLIST 8
1.1 Before You Think It Failed 8
1.2 Basic Operations 10
1.3 Change Parameter 12
1.3.1Change Carrier Frequency 12
1.3.2InitializeAll Parameters 13
1.3.3Read and Write Parameters 14
1.4 Monitor Fault Trip 15
2TROUBLESHOOTING 17
2.1 Trips and Warnings 17
2.1.1Failure/Warning List 18
2.1.2Troubleshooting FaultTrips 20
2.2 Troubleshooting Other Faults 26
3MAINTENANCE 32
3.1 Regular Inspection List 32
3.1.1Daily Inspections 32
3.1.2Annual Inspections 33
3.1.3Bi-Annual Inspections 34
3.1.4Check Input/Output Module 35
3.1.5Replace Cooling Fan 39
3.2 Storage and Disposal 42
3.2.1Storage 42
3.2.2Disposal 42

3
Introduction
Manual Composition
2.1 Trips and Warnings
2.1.1 Failure/Warning List
2.1.2 Troubleshooting Fault Trips
2.2 Troubleshooting Other Faults
3.1 Regular Inspection List
3.1.1 Daily Inspections
3.1.2 Annual Inspections
3.1.3 Bi-annual Inspections
3.1.4 Check Input/Output Module
3.1.5 Replace Cooling Fan
3.2 Storage and Disposal
3.2.1 Storage
3.2.2 Disposal
This section explains troubleshooting
fault trips and other common faults.
If problems are not solved, please
contact your vendor or LSIS.
This section provides information on
how to maintain the inverters on a
regular basis for different time
periods.
When there is a problem in the
inverter, please check the
input/output module. This is the basic
method to check the hardware.
This section covers check points
when there is a problem in the
inverter.
Then check the parameter settings
using basic operations and the trip
records.
1.1 Before You Think It Failed
1.2 Basic Operations
1.3 Change Parameter
1.3.1 Change Carrier Frequency
1.3.2 Initialize all Parameters
1.3.3 Read and Write Parameters
1.4 Monitor Fault Trip
1 Basic Checklist
2 Troubleshooting
3 Maintenance

4
Product Identification
Association Manual
S100 user manual can be downloaded through LSIS homepage.
Link: http://www.lsis.com/support/download/
Model name
Power source
specifications
Output spec.
Input voltage
1 - Single phase 200V
2 - 3 phase 200V
4 - 3 phase 400V
Series Name
Filter
MotorCapacity

5
Safety Information
Read and follow all safety instructions in this manual precisely to avoid unsafe operating conditions,
property damage, personal injury, or death.
Safety symbols in this manual
Danger
Indicates an imminently hazardous situation which, if not avoided, will result in severe injury or
death.
Warning
Indicates a potentially hazardous situation which, if not avoided, could result in injury or death.
Caution
Indicates a potentially hazardous situation that, if not avoided, could result in minor injury
or property damage.
Safety information
Danger
Do not open the cover of the equipment while it is on or operating. Likewise, do not operate
the inverter while the cover is open. Exposure of high voltage terminals or charging are to the
external environment may cause an electric shock. Do not remove any covers or touch the
internal circuit boards (PCBs) or electrical contacts on the product when the power is on or
during operation. Doing so may cause serious injury, death or serious property damage.
Do not open the cover of the equipment even when the power supply to the inverter has been
turned off unless it is necessary for maintenance or regular inspection. Opening the cover
may lead to an electric shock even when the power supply is off.
The equipment may hold charge long after the power supply has been turned off. Use a multi-
meter to make sure that there is no voltage before working on the inverter, motor, or motor
cable.

6
Warning
This equipment must be grounded for safe and proper operation.
Do not supply power to a faulty inverter. If you find that the inverter is faulty, disconnect the
power supply and have the Inverter repaired.
The Inverter becomes hot during operation.Avoid touching the Inverter until it has cooled
down to avoid burns.
Do not allow external objects, such as screws, metal chips, debris, water, or oil to get inside
the Inverter. Allowing external substances inside the Inverter may cause the Inverter to
malfunction or ignite fire.
Do not operate the Inverter with wet hands. Doing so may cause electric shock.
Caution
Do not modify the interior structure/components of the Inverter. Doing so will void the
warranty.
The Inverter is designed for 3-phase motor operation. Do not use the Inverter to operate 3-
phase motor.
Do not place heavy objects on top of electric cables. Doing so may damage the cable and
cause an electric shock.

7
Revision Record
Version
Date
Changed main contents
Reference Page
V1.0
2016.06
1. First edition
-

1. Basic Checklist
8
1 Basic Checklist
1.1 Before You Think It Failed
Items
Check Point
Result
Installed
Environment /
Input/Output
voltage
Is the installed location appropriate?
Does the environment meet the inverters operating conditions?
Does the power source match the inverter’s rated input?
Is the rated output of the inverter sufficient to supply the equipment?
Power Terminal
Wiring
Is the circuit breaker installed on the input side of the inverter?
Is the circuit breaker correctly rated?
Are the power source cables correctly connected to the R/S/T terminals
of the inverter?
(Caution: Connecting the power source to the U/V/W terminals may
damage the inverter)
Are the motor output cables connected in the correct phase rotation
(U/V/W)?
(Caution: Motors will rotate in reverse direction if three phase cables are
not wired in the correct rotation)
Are the cables used to connect power terminals correctly rated?
Is the inverter grounded properly?
Are the power terminal screws and the ground terminal screws tightened
to their specific torques?
Are the overload protection circuits installed correctly on the motors (if
multiple motors are running using one inverter)?
Is the inverter separated from the power source by a magnetic contactor
(if a braking resistor is in use)?
Are advanced-phase capacitors, surge protection and electromagnetic
interference filters installed correctly?
(These devices MUST NOT be installed on the output side of the
inverter)

1. Basic Checklist
9
Items
Check Point
Result
Control Terminal
Wiring
Are STP (shielded twisted pair) cables used for control terminal wiring?
Is the shielding of the STP wiring properly grounded?
If 3-wire operation is required, are the multi-function input terminals
defined prior to the installation of the control wiring connections?
Are the control cables properly wired?
Are the control terminal screws tightened to their specified torques?
Is the total cable length of all control wiring less than 165ft (50m)?
Is the total length of safety wiring less than 100ft (30m)?
Are optional cards connected correctly?
Miscellaneous
Is there any debris left inside the inverter?
Are there any cables (contacting adjacent terminals) creating a potential
short circuit risk?
Are the control terminal connections separated from the power terminal
connections?
Have the capacitors been replaced if they have been in use for more
than 2 years?
Has a fuse been installed for the power source?
Are the connections to the motor separated from other connections?

1. Basic Checklist
10
1.2 Basic Operations
Display keys
Refer to the following illustration to identify part names and functions.
Key
Key name
Function Description
❶
7-segment display
Displays running condition and parameter information.
❷
SET lamp
Flickers when setting parameter or the [ESC] key is multi-functioning.
❸
RUN lamp
Turns on when running and flickers when accelerating or
decelerating.
❹
FWD lamp
Turns on when motor is operating in forward direction.
❺
REV lamp
Turns on when motor is operating in reverse direction.
The following table describes how the numbers and alphabets are displayed on the keypad.
0
0
A
A
K
K
U
U
1
1
B
B
L
L
V
V
2
2
C
C
M
M
W
W
3
3
D
D
N
N
X
X

1. Basic Checklist
11
0
0
A
A
K
K
U
U
4
4
E
E
O
O
Y
Y
5
5
F
F
P
P
Z
Z
6
6
G
G
Q
Q
-
-
7
7
H
H
R
R
-
-
8
8
I
I
S
S
-
-
9
9
J
J
T
T
-
-
Operation Keys
Key
Key name
Function Description
[RUN]
Run command.
[STOP/RESET]
STOP: Stops during operation.
RESET: Trip release after trip occurs.
, ,
[▲], [▼]
Movement among codes or increases/decreases the parameter value.
,
[◀], [▶]
Movement among groups or digits when setting parameter.
[ENT]
Changes the parameter setting or saves the changed parameter value.
[ESC]
Used during Jog operation. Coverts local/remote mode.
While editing, cancels input.
Caution
The [STOP/RESET] key only works when the function is set. Install a separate emergency stop
switch.

1. Basic Checklist
12
1.3 Change Parameter
1.3.1 Change Carrier Frequency
The following example demonstrates how to configure carrier frequency by modifying CN.4 from
15Hz to 5 Hz. It is possible to configure the parameters for different codes in any other group in the
same method.
Step
Instructions
Keypad Display
1
Shift to CN group 4 code.
2
Press [ENT] key.
Display shows 15 which is the current CN.4 code parameter value.
3
Press [▼] key multiple times until it becomes 5 (wanted value).
4
Press [ENT] key.
The set parameter flickers.
5
Press [ENT] key again to save.
Display shows CN.4. The parameter value has changed.
C N . 4
15
5
0 5
Cn. 4
05
5
15
Cn. 4

1. Basic Checklist
13
D r . 0
9
3
03
93
D r . 9 3
Adjust motor operational noise by changing the carrier frequency settings. Power transistors (IGBT)
in the Inverter generate and supply high frequency switching voltage to the motor. Carrier
frequency is the switching speed in this process. If the carrier frequency is set high, it reduces
operational noise from the motor. If the carrier frequency is set low, it increases operational noise
from the motor.
Below demonstrates the advantages and disadvantages according to the sound of the Inverter
during operation.
Item
Carrier Frequency
LOW
HIGH
Motor noise
↑
↓
Heat
↓
↑
Noise
↓
↑
Current
leakage
↓
↑
1.3.2 Initialize All Parameters
The following shows the procedure how to initialize all parameters using Drive group 93.
Step
Instructions
Keypad Display
1
Shift to DR group 0.
2
Press [ENT] key.
Display shows 9 which is the current value.
3
Press [▼] until it becomes 3.
4
Press [◀] to shift to the tens digit.
5
Press [▲] or [▼] until it becomes 9.
6
Press [ENT] key.
Displays dr.93.

1. Basic Checklist
14
0
1
D r . 9 3
Step
Instructions
Keypad Display
7
Press [ENT] once more.
dr.93 code is currently set to 0(No-do not initialize).
8
Press [▲] and change to 1(All Grp-initialize all group) then press [ENT].
The set parameter flickers.
9
Press [ENT] again.
Initializing has started. Once it returns to dr.93 the process has been
completed.
Note
Following parameter initialization, all parameters are reset to factory default values.
Ensure that parameters are reconfigured before running the Inverter again after an initialization.
1.3.3 Read and Write Parameters
Group
Code No.
Function Display
Setting Value
Unit
CNF*
46
Parameter Read
1
Yes
-
47
Parameter Write
1
Yes
-
48
Parameter Save
1
Yes
-
*Only used when connected to LCD loader.
Read and Write Setting Details
Code
Description
CNF-46
Parameter Read
Copies the parameter in the Inverter into the keypad. The existing parameters
saved in the keypad are all deleted.
CNF-47
Parameter Write
Copies the parameter saved in the keypad into the Inverter. The existing parameters
in the Inverter are all deleted. In case of error during parameter writing motion, the
saved data can be directly used. If there is no data saved on the keypad, EEP Rom
Empty will be displayed.
CNF-48
Parameter Save
Enables parameters that are set in communication unchanged even if the Inverter
power is turned Off/On. This is because the parameters set in communication are
saved temporarily in the RAM area. Without setting Yes on this code, when the
Inverter power is turned Off/On the data is not saved.

1. Basic Checklist
15
1.4 Monitor Fault Trip
The following shows an example procedure how to monitor trips in Operation group.
Step
Instructions
Keypad Display
1
Check display of the keypad.
OCT occurred.
2
Press [ENT], then press [▲].
Display shows the frequency (30Hz) at the moment trip occurred.
3
Press [▲].
Display shows the current (5A) at the moment trip occurred.
4
Press [▲].
Display shows the operating condition at the moment trip occurred. ACC
means acceleration. This shows that trip occurred during accelerating.
5
Press [STOP/RESET].
Inverter resets and releases the trip. Display shows the set frequency
value.
Multiple Failures at the same time
It is possible to review the information of maximum 3 Trips when multiple trips occurred at the
same time.
OCT
3 0 . 0 0
5 . 0
ACC
3 0 . 0 0
OCT
3 0 . 0
0
Over
Current
Trip
Current
Accelerating
Frequency
ACC
5 . 0
3 0 . 0
OLT
OVT
OCT
3 0 . 0
3Trips
occurred
Overvoltage
Overcurrent
Overload

1. Basic Checklist
16
Check Trip History
The table below is an example how to monitor trip history.
Group
Code
Code Description
Set value
Set range
Initial Value
Unit
Function
Group 2
Pr91
Fault History 1
-
~
Pr95
Fault History 5
-
Pr96
Delete Fault History
-
0 ~ 1
0
It is possible to save maximum 5 Trip information that occurred while operating. The figure below
demonstrates how to review each Trip information.
Delete Trip History
Change parameter
value to 1 then
press [ENT]
PR.96
PR. 0
1
PR.91
PR. 0
OVT
PR.95
LVT

2. Troubleshooting
17
2 Troubleshooting
This chapter explains how to troubleshoot when the protective functions, fault trips, warning signals,
or a fault occurs while operating the inverter. If the inverter does not work as expected after
following the suggested troubleshooting steps, please contact the LSIS Customer Service Center.
2.1 Trips and Warnings
The Inverter will stop operating or send out a warning signal when it detected a fault. The keypad
will show brief information of the trip and warning signal. If the model is using the LCD keypad, the
LCD will show detailed information.
Up to 5 failures can be saved and can be found in code Pr.90. When there are more than 2 trips,
the keypad display will show in the order of priority. The LCD will show in the order the fault
occurred. Failure history is saved by either resetting the Inverter or when the inverter turns off due
to low voltage failure. If the number of failures exceeds 5, the last 5 messages will be deleted
automatically.
The following is how the fault conditions are categorized:
•Level: After the fault is corrected, the trip or warning signal disappears. The fault is not saved
in the fault history.
•Latch: After the fault is corrected, the trip or warning signal disappears once the Inverter is
reset.
•Fatal: After the fault is corrected, the trip or warning signal disappears when conducted the
following procedure. Turn off the Inverter and wait until the charge indicator light goes off. Then,
turn on the Inverter. If the Inverter still failed, please contact the supplier or LSIS Customer
Service Center.

2. Troubleshooting
18
2.1.1 Failure/Warning List
The following table shows a list of faults and warning signals that can occur while operating S100.
Category
LCD Display
Details
Page
Critical
Latch
Over Current1
Trip from to overcurrent
P. 20
Over Voltage
Trip from overvoltage
P. 22
External Trip
Trip from external signals
-
NTC Open
Trip from temperature sensors
P. 25
Over Current2
Trip from ARM short current
P. 21
Option Trip-x*
Option Trip
-
Over Heat
Inverter overheat
P. 24
Out Phase Open
Trip from output phase open
P. 23
In Phase Open
Trip from input phase open
P. 23
Inverter OLT
Trip from Inverter Overload
P. 23
Ground Trip
Trip from ground fault
P. 22
Fan Trip
Trip from fan operation
P. 24
E-Thermal
Trip from overheat of motor
P. 22
Pre-PID Fail
Trip due to Pre-PID failure
-
IO Board Trip
Trip from IO Board connection
P. 24
Ext-Brake
Trip from External brake
-
No Motor Trip
Trip due to no motor
-
Low Voltage2
Low voltage during operation
-
ParaWrite Trip**
Trip from writing parameters
-

2. Troubleshooting
19
Category
LCD Display
Details
Page
Level
Low Voltage
Trip due to low voltage
P. 21
BX
Trip from Emergency stop
-
Lost Command
Trip from lost command
-
Safety A(B) Err
Safety contact A(b) trip
-
Fatal
EEP Err
External memory error
-
ADC Off Set
Analog input error
-
Watch Dog-1
Trip from CPU watchdog
-
Watch Dog-2
-
Minor Failure
Over Load
Trip from Motor overload
P. 20
Under Load
Trip from Motor under load
P. 20
Warning
Lost Command
Warning for los command
-
Over Load
Warning for Motor overload
-
Under Load
Warning for Motor under load
-
Inverter OLT
Warning for Inverter overload
-
Fan Warning
Warning for fan operation
-
DB Warn %ED
Warning for braking resistance %
-
Retry Tr Tune
Warning for TR turning retrial
-
*Only occurs when using the Option Board
**Only occurs when using LCD loader
