Lumel P20Z User manual

1
TRANSDUCER
OF RMS CURRENT OR AC VOLTAGE
P20Z
USER’S MANUAL

2

3
CONTENTS
1. APPLICATION .................................................................... 5
2. TRANSDUCER SET .............................................................. 5
3. BASIC REQUIREMENTS and OPERATIONAL SAFETY....................... 5
4. INSTALLATION .................................................................. 7
5. TECHNICAL DATA................................................................ 9
6. EXECUTION CODES............................................................ 12
7. MAINTENANCE and GUARANTEE............................................ 13

4

5
1. APPLICATION
The P20Z transducer is destined for a continuous conversion of the
RMS current or ac voltage without a constant component into a con-
stant-current or constant-voltage standard signal.
The transducer output signal is galvanicaly isolated from the input sig-
nal and supply. The transducer housing is made of a plastic. On the
transducer outside, there are inseparable screw or socket-plug termi-
nal strips.
2. TRANSDUCER SET
The set of the P20 transducer is composed of:
1. P20Z transducer 1 pc.
When unpacking the transducer, please check whether the type
and execution code on the data plate correspond to the order.
3. BASIC REQUIREMENTS and OPERATIO-
NAL SAFETY
In the safety service scope, the transducer meets the requirements of
the EN 61010-1 standard.
Observations concerning the operational safety
lAll operations concerning transport, installation, and commissioning
as well as maintenance, must be carried out by qualified, skilled
personnel, and national regulations for the prevention of accidents
must be observed.

6
lBefore switching the transducer on, one must check the correctness
of connection to the network.
lDo not connect the transducer to the network through an
autotransformer.
lBefore removing the transducer housing, one must switch the
supply off and disconnect measuring circuits.
lThe removal of the meter housing during the guarantee contract
period may cause its cancellation.
lThe P20Z transducer is destined to be installed and used
in industrial electromagnetic environment conditions.
lOne must remember that in the building installation a switch or a
circuit-breaker should be installed. This switch should be located
near the device, easy accessible by the operator, and suitably
marked.

7
4. INSTALLATION
4.1 Fitting.
The P20Z transducer is adapted to be mounted on a 35 mm rail acc.
to EN 60715.
The overall drawing and the fitting way are presented on the fig.1.
Fig.1 Overall drawing and transducer fitting way.
4.2. External connection diagrams
One must carry out external connections with wires of maximal diameters:
– 2,5 mm2for socket-plug executions,
– 1,5 mm2for screw executions.

8
Fig. 2. External connection diagrams of the P20Z transducer
Direct measurement of voltage Indirect measurement of voltage
by means of a voltage transformer
Direct measurement of current
Indirect measu-
rement of current
by means of a
current trans-
former

9
5. TECHNICAL DATA
Basic parameters:
- input voltage 60, 100, 150, 250, 400, 500, 600 V~
- input current 1 A (X/1 A~), 5 A (X/5 A~)
- output signal 0... 5 mA Rload. £2000 W
0... 20 mA Rload. £500 W
4... 20 mA Rload. £500 W
0...10 V Rload. 500 W
- response time 0.3 sec
- accuracy class 0.2
- transducer preheating time 15 min.
Consumption:
- in supply circuit £4 VA
- in voltage circuit £0.6 VA
- in current circuit £0.2 VA
Supply voltage 85...253 V or 20...40 V d.c. or a.c.
Protection level ensured
by the housing IP 50
Protection level ensured
from the terminal side IP 20
Weight 0.125 kg
Overall dimensions 22.5 ´120 ´100 mm
Fitting on a 35 mm rail
Maximal wire section 2.5 mm2
for executions with screw terminals
1.5 mm2
for executions with self-locking
terminals

10
Reference and rated operating
conditions:
- input signal 0...0.01...1.2 In; 0...0.01...1.2 Un
- frequency of the
input signal 45...65...500 Hz
- supply 85...253 V a.c.,90...300 V d.c.
20...40 V a.c.,20...60V V d.c.
- admissible peak factor:
- current 2
- voltage 2
- ambient temperature - 20...23...55°C
- storage temperature - 25... +85°C
- relative humidity 95% (inadmissible condensation)
- external magnetic field 0...40...400 A/m
- short duration overload (5 s):
- voltage input 2 Un (max.1000 V)
- current input 10 In
- working position any
Additional errors:
In multiplicity of the class index:
- from ambient
temperature changes < 0.5 k/10 K
- external magnetic field < 1 k
- frequency
of the input signal < 1 k/100 Hz
Standards fulfilled by the transducer
Electromagnetic compatibility:
- immunity acc. to EN 61000-6-2
- emission acc. to EN 61000-6-4

11
Safety requirements:
Acc.to the EN 61010-1 standard
lIsolation ensured by the housing: double,
lIsolation between circuit: basic,
lPollution degree 2,
For voltages in relation to earth, up to 300 V
- installation category III,
For voltages in relation to earth, up to 600 V
- installation category II,
Altitude above sea level < 2000 m

12
6. EXECUTION CODES
Execution codes of the P20Z transducer
Transducer P20Z - XX X X X XX X
Input range:
0... 60 V............................. 01
0... 100 V............................. 02
0... 150 V............................. 03
0... 250 V............................. 04
0... 400 V............................. 05
0... 500 V............................. 06
0... 600 V............................. 07
0... 1 A ............................. 08
0... 5 A ............................. 09
Output range:
0... 5 mA.....................................1
0... 20 mA.....................................2
4... 20 mA.....................................3
0... 10 V.....................................4
Supply voltage:
85...253 V a.c.,90...300 V d.c.........1
20...40 V a.c.,20...60V V d.c..........2
Kind of terminals:
inseparable screws ...................................... 1
Socket-plug screws...................................... 2
Kind of execution:
standard ..............................................................00
Custom-made .....................................................XX
Próby odbiorcze
Without extra quality requirements ............................. 8
With an extra quality inspection certificate.................. 7
Acc. to customer’s requirements*................................X
*after agreeing with the manufacturer.
Table 1

13
Example of order:
When ordering, please respect successive code numbers.
7. MAINTENANCE and GUARANTEE
The P20Z transducer does not require any periodical maintenance.
In case of some incorrect operations:
After the dispatch date and in the period stated in the guarantee card:
One should return the instrument to the Manufacturer’s Quality In-
spection Dept. If the instrument has been used in compliance with the
instructions, we warrant to repair it free of charge.The disassembling
of the housing causes the cancellation of the granted guarantee.
After the guarantee period:
One should turn over the instrument to repair it in a certified service
workshop.
Spare parts are available for the period of five years from the date of
purchase.
Our policy is one of continuous improvement and we reserve
the right to make changes in design and specifications of
any products as engineering advances or necessity requires
and revise the above specifications without notice.
The code: P20Z-09 3 1 1 00 8 means:
P20Z – transducer of RMS current and a.c. voltage
09 – with current input:0... 5 A,
3 – output range: 4... 20 mA,
1 – supply voltage: 85...253 V a.c.,90...300 V d.c
1 – kind of terminals:inseparable screws,
00 – standard execution
8 – without extra quality requirements
