Luminance Brands HF1161BQ00 User manual

• Español - página 27
• Français - page 53
Part No. F40BP75810000 Form No. BP7581
Revision: 12032020 ETL Model No.: HF1161
READ AND SAVE THESE INSTRUCTIONS
1-800-777-4440
www.luminancebrands.com
Questions, problems, missing parts: Before returning to the store, Call Customer Service
60” DC Industrial Fan
Damp Location Owner’s Manual
10' MIN.
TO FLOOR
HF1161BQ00 - Barbeque Black
HF1161MS00 - Metallic Silver
HF1161SW00 - Satin White
Model Numbers
Net Weight: 18.3 Lbs.
PRO SERIES

Table of Contents
2
ETL Model No.: HF1161
Section Page
Safety Instructions ................................ 2
1. Unpacking Instructions ..........................3-4
2. Electrical Requirements .......................... 4
3. Industrial Fan Assembly .........................5-7
4. How to Hang Your Industrial Fan ..................8-9
5. How to Wire Your Industrial Fan . . . . . . . . . . . . . . . . .10-14
6. Final Assembly ................................ 15
7. Wall Control Installation........................16-18
8. Using Your Industrial Fan ......................18-19
Section Page
9. Maintenance .................................. 20
10. Accessories ................................. 20
11. Instructions to the User . . . . . . . . . . . . . . . . . . . . . . . . . 21
12. Repair Parts ...............................22-23
13. Troubleshooting .............................. 24
Ceiling Fan Limited Warranty ....................... 25
Spanish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
French ........................................ 53
READ AND SAVE THESE INSTRUCTIONS
Safety Instructions
TO REDUCE THE RISK OF FIRE, ELECTRICAL
SHOCK, OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
a. Use this unit only in a manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
b. Before servicing or cleaning unit, switch power
off at service panel and lock service panel
disconnecting means to prevent power from
being switched on accidentally. When the service
disconnecting means cannot be locked, securely
fasten a warning device, such as a tag, to the
service panel.
WARNING
!
Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned
off at the fuse box before wiring, and do not operate
fan without blades.
2. All wiring must be in accordance with the National
Electrical Code “ANSI/NFPA 70-2017” and Local
Electrical Codes. Use the National Electrical Code
if Local Codes do not exist. The ceiling fan must be
grounded as a precaution against possible electrical
shock. Electrical installation should be made or
approved by a licensed electrician.
3. The outlet box and joist must be securely mounted
and capable of reliably supporting at least 50 pounds.
Use only U.L. outlet boxes listed as “Acceptable for
Fan Support of 22.7 kg. (50 lbs.) or less”, and use
the mounting screws provided with the outlet box.
Most outlet boxes commonly used for support of light
fixtures are not acceptable for fan support and may
need to be replaced. Consult a qualified electrician if
in doubt.
4. Always properly connect the retention cable included
with this fan as shown in section 4 of this manual.
Follow the Instructions carefully.
5. The support beam or joist must be secure and capable
of supporting at least 50 pounds.
6. Follow the recommended instructions for the proper
method of wiring your ceiling fan. If you do not know
enough about electrical wiring, have your fan installed
by a licensed electrician.
NOTE: All set screws must be checked and re-tightened
where necessary before installation.
1. Read your owner’s manual carefully and keep it for
future reference.
2. Be careful of the fan and blades when cleaning,
painting, or working near the fan. Always turn off the
power to the ceiling fan before servicing.
3. Do not put anything into the fan blades while they are
turning.
To reduce the risk of electrical shock, this fan must be
installed with an isolating wall control/switch.
To reduce the risk of fire or electrical shock, this fan
should only be used with fan speed control, Model
No. MS338A, manufactured by Satellite Electronic
(Zhongshan) Co., Ltd.
To avoid fire, shock or injury, do not use an Luminance
Brands or any other brand of control not specifically
approved for this fan.
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product
by Luminance Brands. Substitution of parts or
accessories not designated for use with this product
by Luminance Brands could result in personal injury
or property damage.
To reduce the risk of personal injury, do not bend the
blades during installation, balancing the blades or
cleaning the fan. Do not insert foreign objects in between
rotating fan blades.
WARNING
!
To reduce the risk of injury, install the fan so that the
blades are at least 10 ft. (3.05m) above the floor.
CAUTION
!

3
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
1. Unpacking Instructions
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product
by Luminance Brands. Substitution of parts or
accessories not designated for use with this product
by Luminance Brands could result in personal injury
or property damage.
WARNING
!
Do not install or use fan if any part is damaged or
missing. Call Toll-Free for replacement parts:
1-800-777-4440
WARNING
!
1.1
Check to see that you have received the following parts:
NOTE: If you are uncertain of part description, refer
to exploded view illustration below.
NOTE: Place the parts from the loose parts bags
in a small container to keep them from being lost.
If any parts are missing, call 1-800-777-4440
for replacement parts before proceeding.
NOTE: Intermixing blades between fans can cause
excessive wobble. Keep blades in original sets of
three.
1.2
Remove the Fan Motor Assembly from the protective
plastic bag. Place the Fan Assembly into the upper
styrofoam with the top of the Motor facing up.
The upper styrofoam serves as a holder for the Fan
during the first stages of assembly.
10
9
1
2
4
5
6
7
8
11
12
13
14
3
HARDWARE CONTENTS
Part Description Quantity
1 Threaded Studs, #8-32 x .75” 2
2 Knurled Knobs, #8-32 2
3 External Tooth Lockwashers, #8 6
4 Wire Connectors, P3 3
5 Large Wire Connector, P4 1
6 Clevis Pin 1
7 Hairpin Clip 1
8 1/4-20 x 1/2” Phillips Hex Head Screws 7
9 Split Lockwashers 7
10 Flat Washers 7
11 #8-32 x 1/4” Pan Head Screws 4
12 Safety Wire Clamps 2
13 Eye Screw 1
14 Set Screw Wrench 1
A
B
C
D
E
F
G
H
PACKAGE CONTENTS
Part Description Quantity
A Fan Motor Assembly 1
B Motor Cover 1
C Ceiling Cover 1
D Hanger Bracket 1
E Hanger Ball / 6” Downrod Assembly 1
F Receiver with Hardware 1
G 3-Speed Wall Control with Hardware 1
H Fan Blade Assemblies 3

4
ETL Model No.: HF1161
Before assembling your ceiling fan, refer to section
on proper method of wiring your fan (page 10).
If you feel you do not have enough wiring knowledge
or experience, have your fan installed by a licensed
electrician.
WARNING
!
Tools Needed for Assembly
One Phillips Head Screwdriver
One 1/4” Blade Screwdriver
Materials
Wiring outlet box and box connectors must be of type
required by the local code. The minimum wire would be
a 3-conductor (2-wire with ground) of following size:
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
100-160 ft. Consult a licensed electrician
> 160 ft Not Recommended
IMPORTANT: Your Ceiling Fan will not function
properly, and may be damaged, if used with any
wall dimmer switch or control other than the
Luminance Brands Fan Wall Control Supplied with
this Fan.
2. Electrical Requirements
Your New Ceiling Fan will require a Grounded Electrical
Supply Line of 120 Volts AC, 60 Hz, 15 Amp Circuit.
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked “Acceptable
for Fan Support of 22.7 kg. (50 lbs.) or less”, and
use screws supplied with outlet box. Most outlet
boxes commonly used for support of light fixtures
are not acceptable for fan support and may need to be
replaced. Consult a qualified electrician if in doubt.
WARNING
!
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is turned
off at the main fuse box before wiring. All wiring
must be in accordance with National and Local codes
and the ceiling fan must be properly grounded as a
precaution against possible electrical shock.
WARNING
!
The Outlet Box must be securely anchored and capable
of withstanding a load of at least 50 Pounds.
If your Fan is to replace an Existing Ceiling Light
Fixture, turn Electricity Off at the Main Fuse Box at this
time and remove the Existing Light Fixture.
Please call Customer Service at 1-800-777-4440
if you have any questions about installation and
operation of this Ceiling Fan.
To avoid fire or shock, follow all wiring instructions
carefully.
Any electrical work not described in these
instructions should be done or approved by a licensed
electrician
WARNING
!
1. Unpacking Instructions (Continued)
THIS FAN IS SUITABLE FOR DAMP LOCATIONS SUCH AS COVERED PORCHES, COVERED PATIOS,
AND COVERED DECKS. ANYWHERE THERE IS A ROOF OVERHEAD.
One Wire Stripper
One Stepladder
This Manual Is Designed to Make it as Easy as Possible for
You to Assemble, Install, Operate and Maintain Your Ceiling Fan
The installed wire length between the wall control
and the fan should not exceed 160 ft. Exceeding this
length may result in improper or loss of control of the
fan.
CAUTION
!

5
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
3. Industrial Fan Assembly
LABEL
MOTOR ASSEMBLY
BLADE
ASSEMBLY
1/4-20 x 1/2" PHILLIPS
HEX HEAD SCREW
SPLIT LOCKWASHER
FLAT WASHER
Figure 2
3.2
Install One Non-reversible Blade Assembly on the top
of the Motor Assembly using Two 1/4-20 x 1/2” Phillips
Hex Head Screws, Two Split Lockwashers and Two Flat
Washers (supplied) (Figure 2).
Repeat this procedure for the remaining Two Blade
Assemblies.
Tighten each Blade Screw to secure each Blade
Assembly to the Motor Housing.
SET SCREWS (2)
MOTOR YOKE
ALLEN WRENCH
Figure 3
3.3
Using the Set Screw Wrench (supplied), remove
the Two Set Screws from the top of the Motor Yoke
(Figure 3).
Retain the Set Screws for future use (Figure 3).
THIS SIDE UP
LABEL
BLADE ASSEMBLY
Figure 1
3.1
CAUTION: The blade assemblies must be mounted
on the motor assembly so that the “THIS SIDE UP”
stamp is visible at the top of the motor (Figure 1).
To reduce the risk of personal injury, do not bend the
blade flanges when installing the blades, balancing
the blades, or cleaning the fan. Do not insert foreign
objects between rotating fan blades.
WARNING
!

6
ETL Model No.: HF1161
3. Industrial Fan Assembly (Continued)
CEILING
COVER
MOTOR
YOKE
Figure 5
3.5
Route the Three 80” Motor Wires and the Safety Cable
through the Ceiling Cover Center Hole and position the
Ceiling Cover over the Motor Yoke (Figure 5).
MOTOR YOKE
SAFETY
CABLE
MOTOR WIRES (3)
HANGER BALL/
DOWNROD
ASSEMBLY
Figure 6
3.6
Route the Three 80” Motor Wires and the Safety Cable
through the Hanger Ball/Downrod Assembly and seat
the Downrod in the Motor Yoke (Figure 6).
MOTOR COVER
#8 EXTERNAL TOOTH
LOCKWASHER
#8-32 x 1/4" PAN HEAD
SCREW
Figure 4
3.4
Separate, untwist and unkink the Three 80” Motor Wires
and the Safety Cable, then route them through the
Motor Cover Center Hole.
Align the Four Holes in the Motor Cover with the
Threaded Holes in the Motor Yoke.
Secure the Motor Cover to the Motor Assembly by
installing Four #8-32 x 1/4” Pan Head Screws and
#8 External Tooth Lockwashers (supplied) (Figure 4).

7
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
MOTOR
YOKE
HAIRPIN
CLIP
CLEVIS
PIN
Figure 7
3.7
Align the Clevis Pin Holes in the Downrod with the
Holes in the Motor Yoke. Install the Clevis Pin and
secure with the Hairpin Clip (Figure 7).
The Clevis Pin must go through the Holes in the Motor
Yoke. It is critical that the Clevis Pin in the Motor Yoke
is properly installed and securely tightened.
Failure to verify that the Pin is properly installed could
result in the Fan falling (Figure 7).
It is critical that the clevis pin in the motor coupling
is properly installed. Failure to verify that the pin is
properly installed (as shown in Figure 7) could result
in the fan falling.
WARNING
!
MOTOR YOKE
5/16-18 SET
SCREW (2)
ALLEN WRENCH
HANGER BALL/
DOWNROD ASSEMBLY
Figure 8
3.8
Reinstall the previously removed Two 5/16-18 Set
Screws in the Motor Yoke (Figure 8).
While pulling up on the Hanger Ball, securely tighten
both Set Screws against the Downrod using the Allen
Wrench, supplied.
It is critical that the set screws are securely tightened.
Failure to verify that the set screws are properly
installed (as shown in Figure 8) could result in the fan
falling.
WARNING
!
3. Industrial Fan Assembly (Continued)
3.9
The Fan comes with Brown, Blue, and Grey Wires that
are 80-inches long.
Before installing the Fan, measure up approximately
6 to 9-inches above top of Hanger Ball/Downrod
Assembly (Figure 9).
Cut off excess Wires and strip back insulation 1/2-inch
from end of Wires.
Please call Customer Service at 1-800-777-4440
if you have any questions about installation and
operation of this Ceiling Fan.
BROWN WIRE
6 TO 9
INCHES
BLUE WIRE
GREY WIRE
HANGER
BALL
1/2
INCH
SAFETY CABLE
Figure 9

8
ETL Model No.: HF1161
FLOOR
CEILING
AT LEAST
10'
Figure 10
Your support beam or joist must be secure and
capable of withstanding a load of at least 50 pounds.
WARNING
!
WARNING
!
The outlet box and joist must be securely mounted and
capable of supporting at least 50 lbs. Use only a U.L.
outlet box listed as “Acceptable for Fan Support of
22.7 kg. (50 lbs.) or less”.
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked “Acceptable
for Fan Support of 22.7 kg. (50 lbs.) or less”, and
use screws supplied with outlet box. Most outlet
boxes commonly used for support of light fixtures
are not acceptable for fan support and may need to be
replaced. Consult a qualified electrician if in doubt.
WARNING
!
4.1
Securely attach the Hanger Bracket to the Outlet Box
using the Two Screws supplied with the Outlet Box
(Figure 11).
Read and follow instructions carefully. Failure to
comply with instructions could result in risk of fire,
electric shock, fan falling and injury to persons.
WARNING
!
Hanger bracket must seat firmly against outlet box.
If the outlet box is recessed, remove wall board until
bracket contacts box. If bracket and/or outlet box are
not securely attached, the fan could wobble or fall.
WARNING
!
HANGER
BRACKET
ANTI-ROTATION
TAB
OUTLET
BOX
TWO SCREWS
SUPPLIED WITH
OUTLET BOX
Figure 11
4. How to Hang Your Industrial Fan
To reduce the risk of injury, install the fan so that
the blades are at least 10 ft. (3.05m) above the floor
(Figure 10).
CAUTION
!

9
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
7"
EYE SCREW
OUTLET BOX
Figure 12
4.2
Screw the Eye Screw (supplied) into the Joist
7-inches from the center of the Ceiling Outlet Box
(Figure 12).
Read and follow instructions carefully. Failure to
comply with instructions could result in risk of fire,
electric shock, fan falling and injury to persons.
WARNING
!
4. How to Hang Your Industrial Fan (Continued)
4.3
Carefully lift the Fan and seat the Hanger Ball/
Downrod Assembly into the Hanger Bracket that was
just attached to the Outlet Box (Figure 13).
Be sure the Groove in the Ball is lined up with the
Anti-rotation Tab on the Hanger Bracket (Figure 13).
NOTE: CEILING COVER, SUPPLY WIRES AND FAN WIRES
OMITTED FOR CLARITY.
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD
ASSEMBLY
HANGER
BRACKET
HANGER BALL
HANGER BALL
GROOVE
ANTI-ROTATION TAB
Figure 13
4.4
This Fan is equipped with the required Safety Cable.
This Cable must be affixed to the building structure
and securely clamped in such a manner to support the
weight of the Fan in the event the Eye Screw or other
parts fail.
Pass the end of the Safety Cable through the Two
Cable Clamps (supplied) (Figure 14). Pass the end of
the Safety Cable through the Eye Screw and then back
through the Two Cable Clamps.
NOTE: Leave approximately 3” but no more than 5”
of slack on this safety cable to allow for possible fan
movement. Do not exceed more than 5” total slack.
After verifying that the Cable Clamps are positioned
properly on the Safety Cable, tighten the Nuts on the
U-bolts.
CAUTION: It is important to note the proper
installation position of the cable clamps as
illustrated in Figure 14. To obtain maximum holding
power, install U-bolt section of clip on the short end
of the cable and saddle on long end of the cable.
Improper installation reduces the efficiency of the
connection by as much as 40 percent.
EYE
SCREW
CABLE CLAMP
TO FAN
U-BOLT
SAFETY CABLE
Figure 14

10
ETL Model No.: HF1161
To avoid possible fire or shock, do not pinch the
antenna wire between the hanger bracket and the
receiver.
WARNING
!
TO MOTOR W
TO MOTOR U
AC IN L
AC IN N
RECEIVER
G
G
TO MOTOR V
G
G
HANGER
BRACKET
HANGER
BALL
Figure 15
5.2
Place the Electronic Receiver into the opening of the
Hanger Bracket above the Hanger Ball. Continue to
insert the body of the Receiver (flat side facing up) into
the opening, orient as shown. Be careful not to pinch
any Wires between the Receiver body and the Bracket
or Ball (Figure 15).
If you feel that you do not have enough electrical
wiring knowledge or experience, have your fan
installed by a licensed electrician.
5.1
CAUTION: To reduce the risk of electrical shock,
disconnect the electrical supply circuit before
installing the fan or receiver.
Disconnect Electrical Power to the Branch Circuit at the
Circuit Breaker or Fuse Box before attempting to Wire
the Ceiling Fan.
5. How to Wire Your Industrial Fan
To avoid possible electrical shock, be sure electricity
is turned off at the main fuse box before wiring.
NOTE: If you are not sure if the outlet box is grounded,
contact a licensed electrician for advice, as it must be
grounded for safe operation.
WARNING
!
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product
by Luminance Brands. Substitution of parts or
accessories not designated for use with this product
by Luminance Brands could result in personal injury
or property damage.
WARNING
!
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is turned
off at the main fuse box before wiring. All wiring
must be in accordance with National and Local codes
and the ceiling fan must be properly grounded as a
precaution against possible electrical shock.
WARNING
!

11
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
5. How to Wire Your Industrial Fan (Continued)
P4 WIRE
CONNECTOR
TO MOTOR W
TO MOTOR U
AC IN L
AC IN N
TO MOTOR V
G
G
G
G
RECEIVER GROUND
WIRES (2)
HANGER BRACKET
GROUND WIRE
HANGER BALL
GROUND WIRE
SUPPLY GROUND
CONDUCTOR
Figure 16
5.3
NOTE: Make all wiring connections using the
wire connectors supplied in the parts bag and
the receiver hardware bag. Make sure that all
connections are tight, including ground, and that
no bare wire is visible at the wire connectors,
except for the supply circuit ground wire.
Gather and twist the Hanger Ball Green Ground Wire,
the Hanger Bracket Green Ground Wire and the
Receiver’s Two Ground Wires to the Supply Ground
Conductor (this may be a bare wire or wire with Green
Colored insulation).
Securely connect Wires with a P4 Wire Connector
(supplied in parts bag) (Figure 16).
P3 WIRE
CONNECTOR
TO MOTOR W
TO MOTOR U
TO MOTOR V
G
G
G
G
RECEIVER
WHITE WIRE
AC IN L
AC IN N
SUPPLY
WHITE WIRE
Figure 17
5.4
Securely connect the Receiver White Wire (AC IN N)
to the Supply White Wire (neutral) using the P3 Wire
Connector (supplied in parts bag) (Figure 17).

12
ETL Model No.: HF1161
5. How to Wire Your Industrial Fan (Continued)
5.5
Securely connect the Receiver Black Wire
(AC IN L) to the Supply Black Wire (hot) using the
P3 Wire Connector (supplied in parts bag) (Figure 18).
P3 WIRE
CONNECTOR
TO MOTOR W
TO MOTOR U
TO MOTOR V
G
G
G
G
AC IN N
RECEIVER
BLACK WIRE
SUPPLY
BLACK
WIRE
AC IN L
Figure 18
P2 WIRE CONNECTOR
TO MOTOR W
TO MOTOR U
FAN MOTOR
GREY WIRE
G
G
G
G
AC IN N
AC IN L
TO MOTOR V
RECEIVER
GREY WIRE
Figure 19
5.6
Securely connect the Receiver Grey Wire
(TO MOTOR V) to the Fan Motor Grey Wire using
the P2 Wire Connector (supplied with receiver)
(Figure 19).

13
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
5. How to Wire Your Industrial Fan (Continued)
5.7
Securely connect the Receiver Brown Wire
(TO MOTOR U) to the Fan Motor Brown Wire using
the P2 Wire Connector (supplied with receiver)
(Figure 20).
P2 WIRE CONNECTOR
G
G
G
G
AC IN N
AC IN L
TO MOTOR V
RECEIVER
BROWN WIRE
FAN MOTOR BROWN WIRE
TO MOTOR W
TO MOTOR U
Figure 20
5.8
Securely connect the Receiver Blue Wire
(TO MOTOR W) to the Fan Motor Blue Wire using
the P2 Wire Connector (supplied with receiver)
(Figure 21).
NOTE: Failure to properly connect the receiver
wires will damage the device and render it
non-operable.
P2 WIRE CONNECTOR
G
G
G
G
AC IN N
AC IN L
TO MOTOR V
FAN MOTOR BLUE WIRE
TO MOTOR U
RECEIVER
BLUE WIRE
TO MOTOR W
Figure 21

14
ETL Model No.: HF1161
5. How to Wire Your Industrial Fan (Continued)
WIRE
CONNECTORS
(Tucked Inside
Outlet Box)
Figure 22
5.9
After Connections have been made, turn Wires and
Connectors upward and carefully push them into the
Outlet Box.
Slide the Receiver completely onto the Hanger Ball,
nestled in the Hanger Bracket (Figure 22).
GND
SUPPLIED
WALL CONTROL
BLACK
BLACK
WHITE
BROWN
BROWN
GREY
HANGER BALL
GREEN WIRE (GROUND)
FROM HANGER BALL
TWO-CONDUCTOR
CABLE
(WITH GROUND)
BLACK
(HOT)
WHITE
SUPPLY
GROUND
TO
120-VOLT
SUPPLY
WHITE
BLUE
GREY
BLUE
GREEN WIRE (GROUND)
FROM HANGER BRACKET
HANGER BRACKET
GREEN GROUND
GREEN GROUND
Figure 23
5.10
Wiring Schematic for reference (Figure 23).
NOTE: See Section 7 (page 16) for Wall Control
Installation.
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not
operate fan until blades are in place. Noise and fan
damage could result.
WARNING
!

15
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
6. Final Assembly
#8 EXTERNAL
TOOTH
LOCKWASHER (2)
CEILING
COVER
1-1/4"
THREADED
STUD (2)
#8-32 KNURLED
KNOB (2)
Figure 25
To avoid possible fire or shock, make sure that the
electrical wires are completely inside the outlet box and
not pinched between the ceiling cover and the ceiling.
WARNING
!
6.2
Lift the Ceiling Cover up to the Threaded Studs and
turn until Studs protrude through the Ceiling Cover
Holes (Figure 25).
Secure the Ceiling Cover in place by sliding a
Lockwasher over each of the Threaded Studs and
installing the two Knurled Knobs (supplied) (Figure 25).
Tighten the Knurled Knobs securely until the Ceiling
Cover fits snugly against the ceiling and the hole in the
Ceiling Cover is clear of the Downrod.
THREADED
STUDS (2)
HANGER
BRACKET
Figure 24
6.1
Screw the Two #8-32 x .75” Threaded Studs into the
Threaded Holes on the bottom of the Hanger Bracket
with your fingers (Figure 24).

16
ETL Model No.: HF1161
7. Wall Control Installation
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is turned
off at the main fuse or circuit breaker box before
wiring. All wiring must be in accordance with National
and Local codes and the ceiling fan must be properly
grounded as a precaution against possible electrical
shock.
WARNING
!
EXISTING
WALL CONTROL
HOT BLK
NEUTRAL
BLACK
GROUND
LOAD
BLACK
RECEIVER LOCATED WITHIN
THE CEILING COVER
GND
WlALL BOX WIRES
EXISTING WALL SWITCH
BLACK WIRES
Figure 27
SINGLE-POLE INSTALLATION
CAUTION: To reduce the risk of electrical shock,
disconnect the electrical supply circuit before
installing the fan or receiver.
NOTE: Make all wiring connections using
wire connectors (supplied). Make sure that all
connections are tight, including ground, and that no
bare wire is visible at the wire connectors, except
for the ground wire.
7.1
Disconnect Electrical Power to the Branch Circuit at the
Circuit Breaker or Fuse Box before attempting to install
the Industrial Fan Wall Control into the Wall Box.
Remove Faceplate and Screws from Existing Wall
Switch (Figure 26).
Pull the Wall Switch out from the Wall Box (Figure 26).
Figure 26
7.2
Remove the Wire Connector of the Existing Wall
Switch Black Wire from the Wall Box Black “HOT” Wire
(Figure 27).
Remove the Wire Connector of the Existing Wall Switch
Black Wire from the Wall Box Black “LOAD” Wire
(Figure 27).
NOTE: Do not attempt to disconnect any Wires not
already connected to Existing Wall Switch.
The included wall control is ONLY designed to operate
the HF1161. It cannot be used to control any other DC
or AC fan.
The wall control is rated to operate up to 3 HF1161 DC
fans at once. Using more than 3 fans will damage the
control.
CAUTION
!
WALL BOX
EXISTING WALL
SWITCH
SCREWS (2)
FACEPLATE
SCREWS (2)

17
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
7. Wall Control Installation (Continued)
ON/OFF SWITCH
(pulled out to the OFF position)
OFF
Figure 28
7.3
Before installing the Supplied Wall Control, place the
Wall Control in the Power “OFF” Mode by pulling the
“ON/OFF” Switch out, located at the bottom of the Wall
Control (Figure 28).
Check to see that all connections are tight and that no
bare wires are visible at the wire connectors.
WARNING
!
Do not connect any neutral (white) wire to this control.
Incorrect wiring will damage this control.
WARNING
!
7.4
Securely connect a P2 Wire Connector (supplied with
the wall control) to the Wall Control Black (AC IN L)
Wire and the Wall Box “HOT” Wire (Figure 29).
Securely connect a P2 Wire Connector (supplied with
the wall control) to the Wall Control Black (TO MOTOR
L) Wire and the Wall Box “LOAD” Wire (Figure 29).
Securely connect a P2 Wire Connector (supplied with
the wall control) to the Wall Control Green Ground Wire
and the Wall Box Bare Copper or Green Ground Wire
(Figure 29).
Leave the Wall Control in Power “OFF” Mode until Fan
installation is completed (Figure 29).
WALL CONTROL WALL BOX
BLACK
BLACK "LOAD"
BARE COPPER
OR GREEN
GREEN
BLACK
P2 WIRE CONNECTOR
ON/OFF SWITCH
(pulled out to OFF position)
OFF
AC IN L
TO MOTOR L
B
L
A
C
K
"
H
OT"
G
Figure 29

7.5
Screw the Wall Control into Wall Box using the supplied
Screws (Figure 30).
Install the Wall Plate using the Two Screws provided
with the Wall Control.
Place the Wall Control in the Power “ON” Mode by
pushing in the “ON/OFF” Switch, located at the bottom
of the Wall Control (Figure 30).
7.6
After completing installation, test run Fan in normal
operation manner. Inspect Fan for any possible shake
or wobble, which may be caused by binding, as a result
of a “Tight Safety Cable”.
18
ETL Model No.: HF1161
To reduce the risk of fire or electrical shock, do not
use this fan with any control device other than the one
supplied.
Your ceiling fan will not function properly, and may
be damaged, if used with any control other than the
Luminance Brands Fan Wall Control Supplied with this
fan.
WARNING
!
7. Wall Control Installation (Continued)
SCREWS (2)
SCREWS (2)
OFF
WALL CONTROL
WALL PLATE
ON/OFF SWITCH
(pushed in to
ON position)
Figure 30
Fan installation must be completed, including the
installation of the fan blades, before testing the wall
control.
WARNING
ON/OFF SWITCH
(pulled out to the OFF position)
ON/OFF SWITCH
(pushed in to the ON position)
OFF
Figure 31
8. Using Your Industrial Fan
Your Wall Control has full control of your Industrial Fan.
8.1
The Wall Control has an “ON/OFF” Switch, located at
the bottom of the Wall Control (Figure 31).
Power “OFF” Mode: Pull the “ON/OFF” Switch out
from the Wall Control.
Power “ON” Mode: Push the Wall Control “ON/OFF”
Switch inward.
!
If this should happen, Turn Power Supply OFF at the
Circuit Breaker or Fuse Box.
Re-check Safety Cable Installation per Section 4.4
of this manual to correct Safety Cable binding problem.

19
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
ETL Model No.: HF1161
8. Using Your Industrial Fan (Continued)
POWER BUTTON
WALL CONTROL
Figure 32
8.2
To turn the Industrial Fan OFF from the Wall Control,
press the Power Button ( ) (Figure 32).
FAN SPEED LIGHTS
WALL CONTROL
FAN SPEED BUTTON
Figure 33
8.3
To turn ON and set the Industrial Fan Speed on
the Wall Control, press the Fan Speed Button ( )
(Figure 33).
Press One Time for Low Speed: At Low Speed, One
Fan Speed Light will illuminate.
Press Two Times for Medium Speed: At Medium
Speed, Two Fan Speed Lights will illuminate.
Press Three Times for High Speed: At High Speed,
Three Fan Speed Lights will illuminate.
WALL CONTROL
FAN AIRFLOW BUTTON
Figure 34
8.3
To set the Industrial Fan Direction on the Wall Control,
press the Fan Airflow Button ( ) (Figure 34).
The Fan must be operating at any Speed for the
Reverse Button to function. The Blades will turn in the
opposite direction and reverse the Airflow.
During Summer Months, run the Fan Counter-Clockwise,
as you look up at it, to direct Airflow Downward.
During the Winter Months, run the Fan Clockwise,
as you look up at it, to direct Airflow Upward.
Reverse Switch Information
Season Blade Rotation Direction
Summer Counter-Clockwise
Winter Clockwise

20
ETL Model No.: HF1161
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product
by Luminance Brands. Substitution of parts or
accessories not designated for use with this product
by Luminance Brands could result in personal injury
or property damage.
WARNING
!
See your local Luminance Brands dealer,
www.luminancebrands.com or our catalog for these
accessories:
• Downrod Extension Kits
10. Accessories
The use of any other control not specifically approved
for this fan could result in fire, shock and personal
injury.
WARNING
Do not use water when cleaning your ceiling fan.
It could damage the motor or the blades and create the
possibility of an electrical shock.
WARNING
!
IMPORTANT CARE INSTRUCTIONS
for your Ceiling Fan
Periodic cleaning of your new Ceiling Fan is the only
maintenance that is needed.
When cleaning, use only a soft brush or lint free cloth to
avoid scratching the finish.
Abrasive cleaning agents are not required and should
be avoided to prevent damage to finish.
9. Maintenance
!
