Luminance Brands Kathy Ireland Home Summer Night CF742PFORB01 User manual

www.luminancebrands.com
Part No. F40BP73130001 Form No. BP7313-1
Revision: 051072021 U.L. Model No.: CF742PF
Net Weight: 11.7 Lbs.
42” Damp Location
Ceiling Fan Owner’s Manual
CF742PFORB01 - Oil Rubbed Bronze
CF742PFWW01 - Appliance White
Model Numbers
READ AND SAVE THESE INSTRUCTIONS
INDOOR/OUTDOOR
1-800-777-4440
Questions, problems, missing parts: Before returning to the store, Call Customer Service
SUMMER NIGHT R

Safety Instructions
2
TO REDUCE THE RISK OF FIRE, ELECTRICAL
SHOCK, OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
a. Use this unit only in a manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
b. Before servicing or cleaning unit, switch power
off at service panel and lock service panel
disconnecting means to prevent power from
being switched on accidentally. When the service
disconnecting means cannot be locked, securely
fasten a warning device, such as a tag, to the
service panel.
WARNING
!
Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned
off at the main fuse box or circuit breaker panel before
wiring, and do not operate fan without blades.
2. All wiring must be in accordance with the National
Electrical Code “ANSI/NFPA 70-2017” and Local
Electrical Codes. Use the National Electrical Code
if Local Codes do not exist. The ceiling fan must be
grounded as a precaution against possible electrical
shock. Electrical installation should be made or
approved by a licensed electrician.
3. The outlet box and joist must be securely mounted
and capable of reliably supporting at least 50 pounds.
Use only U.L. outlet boxes listed as “Acceptable for
Fan Support of 22.7 kg. (50 lbs.) or less”, and use
the mounting screws provided with the outlet box.
Most outlet boxes commonly used for support of light
fixtures are not acceptable for fan support and may
need to be replaced. Consult a qualified electrician
if in doubt.
4. The downrod furnished with the fan proves the
minimum recommended floor to fan blade clearance
for an 8 foot ceiling.
5. Follow the recommended instructions for the proper
method of wiring your ceiling fan. If you do not know
enough about electrical wiring, have your fan installed
by a licensed electrician.
NOTE: This fan is suitable for use with solid-state speed
controls.
NOTE: All set screws must be checked and re-tightened
where necessary before installation.
1. Read your owner’s manual carefully and keep it for
future reference.
2. Be careful with the fan and blades when cleaning,
painting, or working near the fan. Always turn off the
power to the ceiling fan before servicing.
3. Do not put anything into the fan blades while they are
turning.
4. Do not operate reverse switch until fan blades have
come to a complete stop.
U.L. Model No.: CF742PF
READ AND SAVE THESE INSTRUCTIONS
Table of Contents
Section Page
Safety Instructions ................................ 2
1. Unpacking Instructions ..........................3-4
2. Electrical Requirements .......................... 4
3. Ceiling Fan Assembly ...........................5-8
4. How to Hang Your Ceiling Fan ...................9-10
5. How to Wire Your Ceiling Fan ..................11-12
6. Final Assembly ................................ 13
Section Page
7. Using Your Ceiling Fan .......................... 14
8. Maintenance....................................15
9. Accessories ................................... 15
10. Energy Efficient Use of Ceiling Fans ............... 15
11. Repair Parts ...............................16-17
13. Troubleshooting .............................. 18
Ceiling Fan Limited Warranty ....................... 19
To reduce the risk of injury, install the fan so that the
blades are at least 7 ft. (2.1m) above the floor.
CAUTION
!
To reduce the risk of electrical shock, this fan must be
installed with an isolating wall control / switch.
To avoid fire, shock or injury, do not use a Luminance
Brands or any other brand of control not specifically
approved for this fan.
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use this product
by Luminance Brands Substitution of parts or
accessories not designated for use with this product
by Luminance Brands could result in personal injury
or property damage.
To reduce the risk of personal injury, do not bend
the blade flange when installing the blade flanges,
balancing the blades or cleaning the fan. Do not insert
foreign objects in between rotating fan blades.
WARNING
!

A
B
F
C
D
E
1. Unpacking Instructions
3
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
U.L. Model No.: CF742PF
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product
by Luminance Brands. Substitution of parts or
accessories not designated for use with this product
by Luminance Brands could result in personal injury
or property damage.
WARNING
!
Do not install or use fan if any part is damaged or
missing. Call Toll-Free for replacement parts:
1-800-777-4440
WARNING
!
1.1
Check to see that you have received the following parts:
NOTE: If you are uncertain of part description, refer
to exploded view illustration below.
NOTE: Place the parts from the loose parts bags
in a small container to keep them from being lost.
If any parts are missing, call 1-800-777-4440
for replacement parts before proceeding.
1.2
Remove the Fan Motor Assembly from the protective
plastic bag. Place the Fan Motor Assembly into the upper
styrofoam with the top of the Motor facing up.
The upper styrofoam serves as a holder for the Fan during the
first stages of assembly.
PACKAGE CONTENTS
6
10
1
2
7
3
4
5
8
9
Part Description Quantity
A Fan Motor Assembly 1
B Ceiling Cover 1
C Hanger Bracket 1
D Hanger Ball / 3.5” Downrod Assembly 1
E Flange Sets 5
F Blade Sets 5
HARDWARE BAG CONTENTS
Part Description Quantity
1 Threaded Studs, #8-32 x 1-1/4” 2
2 Knurled Knobs, #8-32 2
3 Lockwashers, External Tooth #8 2
4 Wire Connectors 3
5 Clevis Pin 1
6 Hairpin Clip 1
7 M5 x 13mm Flange Screw
(spare) 1
8 M5 x 10mm Washer Head Blade Screws 16
9 Wood Ball Pendant & Coupler 1
10 Blade Balance Kit 1

1. Unpacking Instructions (Continued)
THESE FAN MODELS ARE SUITABLE FOR DAMP LOCATIONS SUCH
AS COVERED PORCHES, COVERED PATIOS, AND COVERED DECKS...
ANYWHERE THERE IS A ROOF OVERHEAD.
This Manual Is Designed to Make it as Easy as Possible for You to
Assemble, Install, Operate and Maintain Your Ceiling Fan
Before assembling your ceiling fan, refer to section
on proper method of wiring your fan (page 11).
If you feel you do not have enough wiring knowledge
or experience, have your fan installed by a licensed
electrician.
WARNING
!
Tools Needed for Assembly
One Phillips Head Screwdriver One Stepladder
One Standard Screwdriver One Wire Stripper
Materials
Wiring outlet box and box connectors must be of type required
by the local code. The minimum wire would be a 3-conductor
(2-wire with ground) of following size:
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
4
U.L. Model No.: CF742PF
2. Electrical Requirements
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked “Acceptable
for Fan Support of 22.7 kg. (50 lbs.) or less”, and
use screws supplied with outlet box. Most outlet
boxes commonly used for support of light fixtures
are not acceptable for fan support and may need to be
replaced. Consult a qualified electrician if in doubt.
WARNING
!
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is turned
off at the main fuse box or circuit breaker panel before
wiring. All wiring must be in accordance with National
and Local codes and the ceiling fan must be properly
grounded as a precaution against possible electrical
shock.
WARNING
!
To avoid fire or shock, follow all wiring instructions
carefully.
Any electrical work not described in these
instructions should be done or approved by a licensed
electrician.
WARNING
!
Your new Ceiling Fan will require a Grounded Electrical Supply
Line of 120 Volts AC, 60 Hz, 15 Amp Circuit.
The Outlet Box must be securely anchored and capable of
withstanding a load of at least 50 Pounds.
If your Fan is to replace an Existing Ceiling Light Fixture, turn
Electricity OFF at the Main Fuse Box or Circuit Breaker Panel at
this time and remove the Existing Light Fixture. Please call Customer Service at 1-800-777-4440
if you have any questions about installation and operation of
this Ceiling Fan.
Controls (Sold Separately)
SW46 Wall Control (sold separately) may be used with this
42” SUMMER NIGHT Ceiling Fan.

CEILING
COVER
80" MOTOR
WIRES
5
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
U.L. Model No.: CF742PF
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is turned
off at the main fuse box or circuit breaker panel before
wiring. All wiring must be in accordance with National
and Local codes and the ceiling fan must be properly
grounded as a precaution against possible electrical
shock.
WARNING
!
3.1
Disconnect Electrical Power to the Branch Circuit at the Circuit
Breaker Panel or Main Fuse Box before attempting to install the
Ceiling Fan to the Outlet Box.
Figure 1
3. Ceiling Fan Assembly
3.2
Pass the Three 80” Motor Wires through the opening in the
Ceiling Cover.
Be sure the Ceiling Cover is oriented correctly (Figure 1).
HANGER
BALL/3.5"
DOWNROD
ASSEMBLY
80" MOTOR
WIRES
Figure 2
3.3
Separate, untwist and unkink the Three 80” Motor Wires.
Route the 80” Motor Wires through the Hanger Ball/Downrod
Assembly (Figure 2).

6
U.L. Model No.: CF742PF
DOWNROD
CLEVIS
PIN HAIRPIN
CLIP
MOTOR
COUPLER
HAIRPIN
CLIP
CLEVIS
PIN
Figure 3
3. Ceiling Fan Assembly (Continued)
3.4
Loosen the Two Set Screws in the Motor Coupler.
Place the Hanger Ball/3.5” Downrod Assembly into the Motor
Coupler, aligning the Clevis Pin Holes in the Downrod with the
Holes in the Motor Coupler (Figure 3).
The Clevis Pin MUST go through the Holes in the Motor
Coupler and the Holes in the Downrod.
Be sure to push the straight leg of the Hairpin Clip through the
Hole near the end of the Clevis Pin until the curved portion of
the Hairpin Clip snaps around the Clevis Pin.
The Hairpin Clip must be properly installed to prevent the
Clevis Pin from working loose.
Pull on the Hanger Ball to make sure the Clevis Pin is properly
installed.
SET SCREW
MOTOR COUPLER
SET SCREW
3.5
While pulling up on the Hanger Ball, retighten the Two Set
Screws (previously loosened) in the Motor Coupler to secure
the Hanger Ball/3.5” Downrod Assembly into place (Figure 4).
NOTE: The set screws must be properly installed as
described above, or fan wobble could result.
Figure 4
It is critical that the set screws are securely tightened.
Failure to verify that the set screws are properly
installed could result in the fan falling.
WARNING
!
It is critical that the clevis pin in the Motor Coupler
is properly installed. Failure to verify that the pin is
properly installed could result in the fan falling.
WARNING
!

7
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
U.L. Model No.: CF742PF
STYROFOAM
PARTIALLY ASSEMBLED
CEILING FAN
Figure 6
3.7
Carefully turn the partially assembled Ceiling Fan over and
place it on the styrofoam for Blades Assembly (Figure 6).
3.8
Remove the Shipping Spacers and the Spacer Attachment
Screws from the Motor before installation of Blade Assemblies
(Figure 7).
Discard the Spacers and Spacer Screws.
SPACER ATTACHMENT SCREW
SHIPPING SPACER
Figure 7
3. Ceiling Fan Assembly (Continued)
BLACK WIRE
6 TO 9
INCHES WHITE WIRE
HANGER BALL
1/2
INCH
BLUE WIRE
3.6
The Fan comes with Blue, Black and White Wires that are
80” long.
Measure up approximately 6 to 9-inches above top of Hanger
Ball/3.5” Downrod Assembly (Figure 5).
Cut off excess Wires and strip back insulation 1/2-inch from
end of Wires.
Figure 5

8
U.L. Model No.: CF742PF
3. Ceiling Fan Assembly (Continued)
BLADE
ASSEMBLY
M5 x 13 mm
FLANGE SCREWS
(2 preassembled in flange)
Figure 9
3.10
Attach One Blade Assembly to the Motor Hub using Two
M5 x 13mm Flange Screws Preassembled in Flange (Figure 9).
Make sure the Screws are NOT tightened.
Repeat this procedure for the other Four Blade Assemblies.
NOTE: The blade flanges have an interlocking
feature that must be fully engaged before
tightening the screws. Make sure all the flanges
are properly engaged and then tighten the flange
screws. If one of the flanges does not seat properly
on the motor hub, loosen the adjacent flange
screws, re-engage and reseat the flanges, then
tighten the screws again.
A spare M5 x 13mm Flange Screw is in the hardware bag,
if needed.
3.9
IMPORTANT: THE SIDE OF THE FAN BLADE
HAVING THE RIB LINE MUST BE FACING
UPWARDS AS SHOWN IN FIGURE 8.
Mount the Blade Flange to the Fan Blade using Three
M5 x 10mm Washer Head Blade Screws (supplied) (Figure 8).
Repeat this procedure for other Four Fan Blades and Blade
Flanges.
FAN
BLADE
BLADE FLANGE
M5 x 10mm WASHER HEAD
BLADE SCREW (3)
RIB LINE
(facing up)
Figure 8
To reduce the risk of personal injury, do not bend
the blade flange when installing the blade flanges,
balancing the blades or cleaning the fan. Do not insert
foreign objects in between rotating fan blades.
WARNING
!
A spare M5 x 10mm Washer Head Blade Screw is in the
hardware bag, if needed.

9
luminancebrands.com
Please contact 1-800-777-4440 for further assistance
U.L. Model No.: CF742PF
The outlet box and joist must be securely mounted and
capable of supporting at least 50 lbs. Use only a U.L.
outlet box listed as “Acceptable for Fan Support of
22.7 kg. (50 lbs.) or less”.
WARNING
!
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked “Acceptable
for Fan Support of 22.7 kg. (50 lbs.) or less”, and
use screws supplied with outlet box. Most outlet
boxes commonly used for support of light fixtures
are not acceptable for fan support and may need to be
replaced. Consult a qualified electrician if in doubt.
WARNING
!
Hanger bracket must seat firmly against outlet box.
If the outlet box is recessed, remove wall board until
bracket contacts box. If bracket and/or outlet box are
not securely attached, the fan could wobble or fall.
WARNING
!
4.1
Securely attach the Hanger Bracket to the Outlet Box using the
Two Screws supplied with the Outlet Box. (Figure 11).
TWO SCREWS
SUPPLIED WITH
OUTLET BOX HANGER BRACKET
ANTI-ROTATION TAB
OUTLET BOX
Figure 11
FLOOR
AT LEAST
7'
CEILING
Figure 10
4. How to Hang Your Ceiling Fan
To avoid possible electrical shock, be sure electricity
is turned off at the main fuse box or circuit breaker
panel before wiring.
NOTE: If you are not sure if the outlet box is grounded,
contact a licensed electrician for advice, as it must be
grounded for safe operation.
WARNING
!
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is turned
off at the main fuse box or circuit breaker panel before
wiring. All wiring must be in accordance with National
and Local codes and the ceiling fan must be properly
grounded as a precaution against possible electrical
shock.
WARNING
!
To reduce the risk of injury, install the fan so that the
blades are at least 7 ft. (2.1m) above the floor (Figure 10).
CAUTION
!

10
U.L. Model No.: CF742PF
4. How to Hang Your Ceiling Fan (Continued)
To avoid possible fire or shock, do not pinch wires
between the hanger ball/downrod assembly and
hanger bracket.
WARNING
!
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
WARNING
!
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD
ASSEMBLY
NOTE: CEILING COVER, SUPPLY WIRES AND FAN WIRES OMITTED
FOR CLARITY.
HANGER BRACKET
HANGER BALL
HANGER BALL
GROOVE
ANTI-ROTATION
TAB
Figure 12
4.2
Carefully lift the Fan and seat the Hanger Ball/
Downrod Assembly on the Hanger Bracket that was just
attached to the Outlet Box (Figure 12). Be sure the Groove in
the Ball is engaged with the Anti-Rotation Tab on the Hanger
Bracket (Figure 12).
NOTE: SUPPLY WIRES AND FAN WIRES OMITTED FOR CLARITY.
