Manutan Rapid Racking Vertiracks VR27 User manual

Vertiracks
Assembly instruction
AIS018
All manuals and user guides at all-guides.com
all-guides.com

1Assemble upright frame Ato rear beam B
starting at the top using bolts Gto fix in place.
2Fit middle rear beams Cto upright frames A.
3Fit base tray Dinto bottom of upright frames A.
4Add top dividers E.
5Add bottom dividers F(used only with
product VR27).
6Fix to floor with fixing K.
NB. All bolts Gand Htorque to 60Nm
VERTIRACKS Multiple packages
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIS018
A
Tools required: Spanners, Electric Drill and Masonry Drill
A
B
D
E
F
G
H
VR15 Starter rack with
VR15E Extension rack
C
We advise the use of protective
gloves and goggles, or eyeglasses
when assembling this product.
H
VR27 Starter rack with
VR27E Extension rack
G
K
G
K
K
H
G
J
G
ASSEMBLY
If you have any problems with this product or its assembly, please contact your local distributor or
call our helpline on 01285 686868 where a team of experts will be pleased to help.
All manuals and user guides at all-guides.com

Uprights
COMPONENTS
VERTIRACKS Multiple packages
IMPORTANT - ASSEMBLY INSTRUCTIONS
AIS018
ABRear beams
VR27 and VR27E - 2700mm
VR15 and VR27 - 1350 mm
VR15E and VR27E - 1300 mm
CMiddle rear beams
VR15 and VR27 - 1350 mm
VR15E and VR27E - 1300 mm
DBase tray
VR15 - 1350mm W x 550mm D
VR27 - 1350mm W x 580mm D
VR15E - 1300mm W x 550mm D
VR27E - 1300mm W x 580mm D
ETop dividers
FBottom dividers GEnd frame nuts
and bolts
M10 x 80 mm
JUpright
VR15 and VR15E - 1500mm
Rapid Vertirack, Component Check
VR15 VR15E VR15D VR27 VR27E VR27BD VR27D
Uprights ‘A’ ---21--
Uprights ‘H’ 21-----
Top Rear Beams ‘B’ 11-11- -
Middle Rear Beams ‘C’ 11-22- -
Base Tray ‘D’ 11-11- -
Top Dividers ‘E’ 33133 - 1
Bottom Dividers ‘F’ ---331-
End Fame Nuts 12 6 - 16 8 - -
& Bolts ‘G’
Divider Nuts & Bolts ‘H’ 66-99- -
HDivider nuts and bolts
M10 x 25 mm
KFloor fixings
M10 x 80 mm
If you have any problems with this product or its assembly, please contact your local distributor or
call our helpline on 01285 686868 where a team of experts will be pleased to help.
