MASSEY FERGUSON MF 9316S User manual

MF 9316S / 9316D
OPERATOR’S MANUAL
Rotary Disc Header
FROM MASSEY FERGUSON

Find manuals at https://best-manuals.com

Operator's Manual
Rotary Disc Header
9316S
9316D
North America
4205 River Green Parkway, Duluth GA 30096 USA
© AGCO 2019
Original Operator's Manual
July 2019
700750336B
NA
English
Find manuals at https://best-manuals.com

CALIFORNIA
Proposition 65 Warning
WARNING: Diesel engine exhaust and some of its constituents are known to the State of
California to cause cancer, birth defects, or other reproductive harm.
WARNING: Battery posts, terminals and related accessories contain lead and lead compounds,
chemicals known to the State of California to cause cancer, birth defects, or other reproductive
harm. Wash hands after handling.
Congratulations on your selection of an AGCO®Product. We believe you
have exercised excellent judgment in the purchase of your AGCO®
machine. We are most appreciative of your patronage.
Your Dealer has performed the pre-delivery service on your new
machine.
He will discuss with you the operating and maintenance instructions
given in this manual, and instruct you in the correct and varied
applications of this machine. Call on him at any time when you have a
question or need equipment related to the use of your machine.
We recommend that you carefully read this entire manual before
operating the machine. Also, time spent in becoming fully acquainted
with its performance features, adjustments, and maintenance schedules
will be repaid in a long and satisfactory life of the product.
This equipment is covered by a written warranty which will be provided
to you by your AGCO®Dealer at time of purchase.
AGCO®reserves the right to make changes or add improvements to its products at any time
without incurring any obligation to make such changes to products manufactured previously. AGCO
®, or its dealers, accept no responsibility for variations which may be evident in the actual
specifications of its products and the statements and descriptions contained in this publication.
Find manuals at https://best-manuals.com

Rotary Disc Header
1 Safety .................................................................... 7
1.1 Introduction ......................................................... 9
1.1.1 Safety symbol ................................................... 9
1.1.2 Safety messages ................................................. 9
1.1.3 Information messages ............................................. 9
1.1.4 Safety signs ..................................................... 9
1.1.5 A word to the operator ............................................ 10
1.1.6 This manual .................................................... 11
1.2 Operation .......................................................... 12
1.2.1 Prepare for operation ............................................. 12
1.2.2 General information .............................................. 12
1.2.3 Personal protective equipment ...................................... 13
1.2.4 Seat instructions ................................................ 13
1.2.5 Shield and guards ................................................ 14
1.2.6 Exhaust warning .................................................14
1.2.7 Flying debris ................................................... 15
1.2.8 Handrails ...................................................... 15
1.2.9 Agricultural chemicals ............................................. 15
1.3 Travel on public roads ............................................... 16
1.4 Maintenance ........................................................17
1.4.1 General maintenance information .................................... 17
1.4.2 Fire prevention and first aid ......................................... 18
1.4.3 High pressure leaks .............................................. 19
1.4.4 Accumulator safety .............................................. 20
1.4.5 Replacement parts ............................................... 20
1.4.6 Weld on the machine precautions .................................... 20
1.5 Safety and informational signs ....................................... 21
1.5.1 Safety and informational signs ...................................... 21
1.5.2 Operators manual ............................................... 22
1.5.3 Explosion hazard ................................................ 22
1.5.4 Shear hazard ................................................... 23
1.5.5 Shear hazard ................................................... 23
1.5.6 Crush hazard ................................................... 23
1.5.7 Flying objects hazard ............................................. 23
1.5.8 Entanglement hazard ............................................. 24
1.5.9 California Proposition 65 ........................................... 24
1.5.10 Reflector red ................................................... 24
1.5.11 Reflector orange ................................................ 24
1.5.12 Reflector yellow ................................................. 25
1.5.13 Tie down ...................................................... 25
2 Introduction .............................................................. 27
2.1 Introduction ........................................................ 29
2.1.1 Units of measurement ............................................ 29
2.1.2 Replacement parts ............................................... 29
2.1.3 Intended use ................................................... 29
2.1.4 Proper disposal of waste .......................................... 29
2.2 Machine identification ...............................................30
2.2.1 Serial number plate .............................................. 30
2.2.2 Serial number description .......................................... 30
2.3 Description ......................................................... 32
Table of contents
Rotary Disc Header
700750336B
Find manuals at https://best-manuals.com

2.3.1 Cutterbed ..................................................... 32
2.3.2 Conditioner .................................................... 32
2.3.3 Swathboard .................................................... 33
2.3.4 Forming shields ................................................. 33
2.3.5 Component location .............................................. 33
2.3.6 Component access .............................................. 33
3 Operation ................................................................ 35
3.1 Checklists .......................................................... 37
3.1.1 Daily checklist .................................................. 37
3.1.2 Before each season checklist ....................................... 37
3.1.3 End of season checklist ........................................... 37
3.2 Connect the tractor ................................................. 38
3.2.1 Connect the lift arms ............................................. 38
3.2.2 Connect the center link ........................................... 39
3.2.3 Connect the hydraulic hoses and the electrical harness .................... 39
3.2.4 Install the forming shields .......................................... 40
3.2.5 Prepare the header for operation ..................................... 41
3.3 Disconnect the tractor ............................................... 42
3.3.1 Release the flotation pressure .......................................42
3.3.2 Remove the forming shields ........................................ 42
3.3.3 Disconnect the hydraulic hoses and the electrical harness .................. 43
3.3.4 Disconnect the center link ......................................... 43
3.3.5 Disconnect the lift arms ........................................... 44
3.4 Field operation ......................................................45
3.4.1 Crop conditioning ................................................ 45
3.4.2 Cuto quality and windrow formation ................................. 45
3.4.3 Ground speed .................................................. 45
3.4.4 Hay drying time ................................................. 45
3.4.5 Engage the header ............................................... 46
3.4.6 Unplug unwanted material from the header ............................. 46
3.4.7 Header speed .................................................. 47
3.4.8 Header lift ..................................................... 47
3.4.9 Header flotation ................................................. 47
3.4.10 Header height .................................................. 48
3.4.11 Adjust the skid shoes or the gauge rollers .............................. 48
3.4.12 Header angle ................................................... 48
3.5 Conditioner adjustments ............................................ 50
3.5.1 Conditioner .................................................... 50
3.5.2 Conditioner spacing .............................................. 50
3.5.3 Adjust the conditioner roll spacing with the adjustment nuts .................50
3.5.4 Adjust the conditioner roll spacing with the quick change shims .............. 51
3.5.5 Adjust the conditioner spacing indicator ................................51
3.5.6 Adjust the conditioner roll timing ..................................... 52
3.5.7 Conditioner pressure ............................................. 53
3.5.8 Adjust the conditioner pressure ..................................... 53
3.6 Swathboard ........................................................ 54
3.6.1 Adjust the swathboard ............................................ 54
3.7 Forming shield adjustments ......................................... 55
3.7.1 Adjust the windrow forming shields .................................. 55
3.7.2 Adjust the deflector .............................................. 55
3.7.3 Adjust the windrow forming deck height ............................... 55
4 Maintenance ............................................................. 57
4.1 Service schedule .................................................... 59
4.2 Lubrication details .................................................. 60
Table of contents
Rotary Disc Header
700750336B
Find manuals at https://best-manuals.com

4.2.1 Inspection during lubrication ........................................ 60
4.2.2 Lubrication fittings ............................................... 60
4.2.3 Cutterbed drive gearboxes ......................................... 62
4.2.3.1 Gearbox plug location ................................... 62
4.2.3.2 Examine the gearbox oil level .............................. 62
4.2.3.3 Change the gearbox oil .................................. 63
4.2.4 Conditioner gearboxes ............................................ 64
4.2.4.1 Plug location - conditioner gearboxes ........................ 64
4.2.4.2 Examine the gearbox oil level .............................. 65
4.2.4.3 Change the gearbox oil .................................. 66
4.2.5 Cutterbed ..................................................... 66
4.2.5.1 Cutterbed oil level ...................................... 66
4.2.5.2 Change the cutterbed oil ................................. 67
4.3 Replace a bearing ................................................... 69
4.4 Sensors ............................................................ 70
4.4.1 Electrical sensor location .......................................... 70
4.4.2 Adjust the electrical sensors ........................................ 70
4.5 Cutterbed inspection ................................................ 71
4.6 Knives ..............................................................72
4.6.1 Knife wedging under disc .......................................... 72
4.6.2 Knife inspection ................................................. 72
4.6.3 Disc rotation ................................................... 73
4.6.4 Replace a knife ..................................................73
4.6.5 Knife type ..................................................... 73
4.6.6 Knife hardware inspection .......................................... 74
4.7 Discs ............................................................... 75
4.7.1 Disc maintenance ............................................... 75
4.7.2 Replace a disc .................................................. 75
4.7.3 Lifters ........................................................ 76
4.7.4 Replace the lifters ............................................... 76
4.8 Adjust the auger stripper plate ....................................... 77
4.9 Belts ............................................................... 78
4.9.1 Belt maintenance ................................................ 78
4.9.2 Adjust the conditioner belt ......................................... 78
4.9.3 Replace the conditioner belt ........................................ 78
4.9.4 Adjust the center cage belt ......................................... 80
4.9.5 Replace the center cage belt ........................................81
4.9.6 Adjust the auger belt ............................................. 83
4.9.7 Replace the auger belt ............................................ 83
5 Troubleshooting .......................................................... 85
5.1 Header troubleshooting ............................................. 87
5.2 Cutterbed troubleshooting .......................................... 88
5.3 Conditioner troubleshooting ......................................... 90
5.4 Crop conditioning and windrow formation ............................ 91
5.5 Cuto quality ....................................................... 92
6 Specifications ............................................................ 95
6.1 Specifications ...................................................... 97
6.1.1 Dimensions and weights .......................................... 97
6.1.2 Header specifications ............................................. 97
6.1.3 Cutterbed specifications ........................................... 97
6.1.4 Cutterbed bolt torque ............................................. 97
6.1.5 Maximum roading speed .......................................... 98
6.1.6 Conditioner specifications .......................................... 98
6.1.7 Lubrication specifications .......................................... 98
Table of contents
Rotary Disc Header
700750336B
Find manuals at https://best-manuals.com

7 Accessories .............................................................. 101
7.1 Accessories and options ............................................ 103
7.1.1 Electric swathboard actuator ....................................... 103
7.1.2 Gauge rollers .................................................. 103
7.1.3 Crop divider kit ................................................. 103
7.1.4 Crop divider wheel .............................................. 104
7.1.5 Filler pan ..................................................... 104
7.1.6 Quick coupler kit ................................................104
7.1.7 Conditioner roll gap adjustment kit ...................................105
8 Assembly ............................................................... 107
8.1 General information ................................................ 109
8.1.1 Shipping damage and missing parts .................................. 109
8.1.2 Safety precautions .............................................. 109
8.2 Assembly .......................................................... 110
8.2.1 Examine the cutterbed lubricant in shipping position ...................... 110
8.2.2 Prepare the header for assembly .................................... 110
8.2.3 Install the lift arms .............................................. 112
8.2.4 Install the forming shields ......................................... 112
8.2.5 Install the curtain magnets ........................................ 113
8.2.6 Install the warning lamp .......................................... 114
8.2.7 Finish the assembly ............................................. 114
8.3 Checklists ......................................................... 115
8.3.1 Pre-delivery checklist ............................................ 115
8.3.2 Delivery checklist ............................................... 115
9 Index ....................................................................117
Table of contents
Rotary Disc Header
700750336B
Find manuals at https://best-manuals.com

1 Safety
1.1 Introduction ............................................................. 9
1.1.1 Safety symbol ....................................................... 9
1.1.2 Safety messages ..................................................... 9
1.1.3 Information messages ................................................. 9
1.1.4 Safety signs ........................................................ 9
1.1.5 A word to the operator ................................................ 10
1.1.6 This manual ........................................................ 11
1.2 Operation .............................................................. 12
1.2.1 Prepare for operation ................................................. 12
1.2.2 General information .................................................. 12
1.2.3 Personal protective equipment .......................................... 13
1.2.4 Seat instructions .................................................... 13
1.2.5 Shield and guards ................................................... 14
1.2.6 Exhaust warning .................................................... 14
1.2.7 Flying debris ....................................................... 15
1.2.8 Handrails .......................................................... 15
1.2.9 Agricultural chemicals ................................................ 15
1.3 Travel on public roads ................................................... 16
1.4 Maintenance ........................................................... 17
1.4.1 General maintenance information ........................................ 17
1.4.2 Fire prevention and first aid ............................................ 18
1.4.3 High pressure leaks .................................................. 19
1.4.4 Accumulator safety .................................................. 20
1.4.5 Replacement parts ...................................................20
1.4.6 Weld on the machine precautions ........................................ 20
1.5 Safety and informational signs ...........................................21
1.5.1 Safety and informational signs .......................................... 21
1.5.2 Operators manual ................................................... 22
1.5.3 Explosion hazard .................................................... 22
1.5.4 Shear hazard ....................................................... 23
1.5.5 Shear hazard ....................................................... 23
1.5.6 Crush hazard ....................................................... 23
1.5.7 Flying objects hazard ................................................. 23
1.5.8 Entanglement hazard ................................................. 24
1.5.9 California Proposition 65 ...............................................24
1.5.10 Reflector red ....................................................... 24
1.5.11 Reflector orange .................................................... 24
1.5.12 Reflector yellow .....................................................25
1.5.13 Tie down .......................................................... 25
Table of contents
Rotary Disc Header 7
700750336B
Find manuals at https://best-manuals.com

Table of contents
8 Rotary Disc Header
700750336B
Find manuals at https://best-manuals.com

1.1 Introduction
1.1.1 Safety symbol
The safety symbol tells you about a potentially
hazardous area!
Look for the safety symbol in this manual and on
the machine. The safety symbols tell you that
there is important safety instructions in the
manual.
GUID-4C201302-DBD2-4BFB-8D98-1DDED263BD6E-high.jpg [High]
Fig. 1
1.1.2 Safety messages
The words DANGER, WARNING or CAUTION are
used with the safety symbol. Learn these safety
messages and obey the recommended
precautions and safety instructions.
DANGER:
If you do not obey the recommended
precautions and safety instructions,
DEATH OR INJURY will occur.
WARNING:
If you do not obey the recommended
precautions and safety instructions,
DEATH OR INJURY can occur.
CAUTION:
If you do not obey the recommended
precautions and safety instructions,
INJURY can possibly occur.
GUID-73F05026-C37B-415A-8140-AD939A283378-high.jpg [High]
Fig. 2
1.1.3 Information messages
The words important and note are not related to personal safety, and are used to give information about
the operation and servicing of the machine.
IMPORTANT: Identifies special instructions or procedures which, if not followed, can cause damage to the
machine, the process, or the area around the machine.
NOTE: Information to make procedures easier.
1.1.4 Safety signs
WARNING:
Do not remove the safety signs. Replace safety signs that you cannot read, are damaged,
or are missing.
Clean the machine surface with a weak soap and water solution before you replace the safety signs.
Replacement safety signs are available from your dealer.
[V]
GUID-5D9F270E-D748-4741-82B1-BE49B78685F2 [V5]
GUID-E54F7740-C021-42A8-8784-4287BE4356C8 [V4]
GUID-9A909F52-D57E-4C30-8CC7-6FDB6D7E9982 [V3]
GUID-2FB17168-6A01-47C5-B298-234AF171520B [V7]
1. Safety
Rotary Disc Header 9
700750336B

Always make sure that safety signs are in the correct locations and that you can read the safety signs.
Illustrations of safety sign locations are in this section.
Keep the safety signs clean. If necessary, use a weak soap and water solution.
1.1.5 A word to the operator
It is your responsibility to read and understand the
safety section in this manual and the manual for all
implements before you operate this machine. You
are responsible for your safety. Good safety
procedures prevent injury to you and the persons
around you.
Make the information in the safety section of this
manual a part of your safety procedure. This safety
section is written only for this type of machine.
Safety is your responsibility. You can prevent injury
and death.
This safety section gives basic safety examples
that can occur during the operation and
maintenance of your machine. This safety section
is not a replacement for safety instruction in other
sections of this manual.
Injury or death can occur if the safety instruction is
not obeyed.
Learn how to operate the machine and how to use
the controls correctly.
Do not operate the machine if you do not know
how to operate the machine. Do not let persons
operate the machine that do not know how to
operate the machine.
Follow all safety instructions in the manuals and on
the safety signs on the machine, the implements,
and the attachments.
Use only approved attachments and implements.
Make sure that your machine has the correct
equipment that is necessary by the local
regulations.
WARNING:
Do not use alcohol or drugs that can
have an eect on alertness or
coordination. If you use prescription
or 'over the counter' drugs, get
medical advice about the safe
operation of machines.
CAUTION:
If attachments or implements used
with this machine have a dierent
operator manual, see that operator
manual for other important safety
instructions.
GUID-AC91CCF6-1FF8-4A85-97A1-2D1562806825-high.jpg [High]
Fig. 3
GUID-F38BCC9A-5A98-41F3-BA3C-2C5AB224EDFB [V6]
1. Safety
10 Rotary Disc Header
700750336B

CAUTION:
See the engine operation and maintenance manual for other important safety instructions.
CAUTION:
See the windrower tractor operator manual for other important safety instructions.
1.1.6 This manual
This manual covers general safety practices for this machine. The operator manual must always be kept
with the machine.
Right-hand and left-hand, as used in this manual, are determined by facing the direction the machine will
travel when in use.
The photos, illustrations, and data used in this manual were current at the time of printing, but due to
possible in-line production changes, your machine can vary slightly in detail. The manufacturer reserves the
right to redesign and change the machine as necessary without notification.
WARNING:
In some of the illustrations and photos used in this manual, shields or guards may have
been removed for clarity. Never operate the machine with any shields or guards removed.
If the removal of shields or guards is necessary to make a repair, they must be replaced
before operation.
The Operator Manual is stored in the holder on the machine. After using the Operator Manual, return the
manual to the storage location.
GUID-F180C720-C8A9-4411-AA97-B6147E05E2A0 [V1.3.2]
1. Safety
Rotary Disc Header 11
700750336B

1.2 Operation
1.2.1 Prepare for operation
Read and understand the operating instructions and precautions in this manual before you operate or
perform service on the machine.
Make sure that you know and understand the positions and operations of all controls. Make sure that all
controls are in neutral and the parking brake is applied before you start the machine.
WARNING:
If the engine is running and the parking brake is not applied, the machine will turn if the
steering wheel is moved when the travel control lever is in neutral.
Make sure that all persons are a sucient distance from your area of work before you start or operate the
machine. Do checks on the controls and learn all controls in an area clear of persons and objects before
you start work with the machine. Know the dimensions of the machine and have sucient space available
for operation. Do not operate the machine at high speeds around persons, buildings, other equipment, etc.
Always use correct procedures when you do tasks around and operate the machine. Do not let children or
persons who do not know how to operate the machine operate the machine. Keep other persons away
from your area of work. Do not let other persons ride on the machine.
Make sure that the machine is in the good mechanical condition. Make sure that the machine has the
correct equipment as necessary by local regulations.
All equipment has a limit. Make sure you understand the speed, brakes, steering, stability, and load
characteristics of this equipment before you start.
1.2.2 General information
When parking, park the machine on a solid level
surface and lower the header to the ground. Put all
controls in neutral, and apply the parking brake.
Stop the engine and take the key with you.
WARNING: Whole body crushing
hazard. A loss of hydraulic pressure or
movement of the mechanism can
cause the raised machine component
to fall.
Personal injury or death can occur.
Install the lift cylinder stops before
working on the machine to prevent
movement.
Make sure the machine is in the proper operating
condition according to the Operator Manual.
Always operate the machine with the control
console turned on.
Do not dismount from moving machinery.
Stay o slopes too steep for operation.
Be aware of the size of the machine and have
enough space available to allow for operation.
GUID-E77631FB-0DC0-4637-9090-88018315176E-high.jpg [High]
Fig. 4
Stay o slopes too steep for operation. Keep the header as low as possible while going down hills. Never
suddenly reverse the wheels to stop or back up.
Where possible avoid operating the machine near ditches, embankments, and holes. Reduce ground speed
when operating on rough, slippery, or muddy surfaces and when turning or crossing slopes.
[V]
GUID-A9D74CBD-C409-4BEA-B8C1-A3DA5AE3C5EC [V5]
GUID-37023B41-C0ED-4F86-A909-1F42C1FE5D97 [V4]
1. Safety
12 Rotary Disc Header
700750336B

DANGER: Machine electrical shock
and electrocution hazard.
Personal injury or death can occur.
Keep the machine clear of overhead
electrical power lines.
GUID-DB0A93E4-AEB5-49D5-AC5F-DD1454F1CFC6-high.jpg [High]
Fig. 5
1.2.3 Personal protective equipment
Put on all personal protective equipment (PPE) and
protective clothes that are supplied to you or that
are necessary for the conditions and by applicable
laws. PPE includes equipment to prevent injury to
your eyes, lungs, ears, head, hands and feet.
Always keep hands, feet, hair, and your clothes
away from parts that move. Do not put on loose
clothing, jewelry, watches, or other items that can
tangle in parts that move. Tie up long hair that can
also tangle in moving parts.
GUID-1AEEBD1D-C71B-432C-9D23-52467D7C0BBF-high.jpg [High]
Fig. 6
1.2.4 Seat instructions
Put on the seat belt before you operate the
machine. Always sit in the seat and have the seat
belt on while you operate the machine. Replace
the seat belts when they become worn or broken.
Do not use a seat belt loosely. Make sure that
there is some tension on the seat belt. Do not
wear the seat belt in a twisted condition or
pinched between the structural parts of the seat.
Put on the seat belt if the instructional seat is
used. Use the instructional seat only to train new
operators or to find a problem. The instructional
seat is only for short periods of use.
Do not let children use the instructional seat or be
in the cab. Do not let other persons use the
instructional seat or be in the cab.
Drive the machine at slower speed and on level
ground when the instructional seat is used. Do not
start, stop, or turn quickly when the instructional
seat is used. Do not drive on highways or public
roads when the instructional seat is used.
GUID-5BA328EA-7732-4CE8-97B2-6511151E943C-high.jpg [High]
Fig. 7
GUID-7FEFA67B-E06F-4EFE-A23E-738FE96997E9 [V3]
GUID-F38524AD-E24F-4FCC-9154-E5357EFDE9D2 [V3]
1. Safety
Rotary Disc Header 13
700750336B

1.2.5 Shield and guards
WARNING: Entanglement hazard.
Belts and components that rotate.
Severe personal injury or death can
occur.
Do not open, remove, or put your
hand behind shields if the engine is
running. Stop the machine before
doing service to the machine.
GUID-6163F2D6-39D6-48BF-871C-AC346EE022D2-high.jpg [High]
Fig. 8
All shields and guards must be in the correct position and in good condition. Keep away from the
components that rotate.
DANGER: Entanglement hazard.
Rotating components.
Severe personal injury or death can
occur.
Do not make adjustments or repairs
to components while they are
moving. Stop the machine before
doing service to the machine.
Do not operate the machine with the drive shaft
shields open or removed.
Keep away from the components that turn.
Make sure guards that turn are free.
GUID-CEB32148-1F4C-457C-ADF7-595DFC51AC25-high.jpg [High]
Fig. 9
Do not make adjustments to the roll tension with the header engaged.
When you make adjustments to the roll pressure, stop the header. Lower the header to the ground and
engage the parking brake. Set the engine to low idle.
1.2.6 Exhaust warning
WARNING: Inhalation hazard. Exhaust
gases.
Death or serious illness can occur.
Do not operate the engine in a closed
building unless the exhaust is
ventilated to the outside.
Do not tamper with or modify the exhaust system
with unapproved extensions.
GUID-55072A39-D882-4355-8ABA-05660F3F6EDA-high.jpg [High]
Fig. 10
GUID-9398BDE6-F83A-4855-B266-E86D0B48B9D7 [V10]
GUID-AC6BA923-B398-43F4-BFAE-5130AFED6FC5 [V4]
1. Safety
14 Rotary Disc Header
700750336B

1.2.7 Flying debris
WARNING:
Be careful when you operate along
the side of a road or structures. Rocks
and other materials can be thrown
from the machine during operation
and can cause injury.
If there are rocks and unwanted
objects in a field, tilt the header up.
This will lift the knives and reduce
other materials thrown by the knives.
Stay away from the machine during operation.
Some materials can be thrown from the machine
during operation and cause injury. GUID-1D480E10-339B-427D-9D05-37E84CC7A29A-high.jpg [High]
Fig. 11
1.2.8 Handrails
WARNING: Falling hazard.
Personal injury or death can occur.
Use appropriate safety precautions
when working o the ground.
Point your body in the direction of the ladder and
use the handrails when you are on the machine
ladders. Always keep three points of contact with
the ladder.
GUID-B4BF5956-B0F7-43A5-85C1-706D96BCA02B-high.jpg [High]
Fig. 12
1.2.9 Agricultural chemicals
Agricultural chemicals are very dangerous. Incorrect procedures with fertilizer, fungicides, herbicides,
insecticides and pesticides can cause injuries to plants, animals, soil and other persons property.
Always read and follow all manufacturers instructions before you open chemical containers.
Read and follow instructions each time you use a chemical.
Use the same precautions when you do adjustments, do servicing, clean or store the machine as used
when you put chemicals into the hoppers or tanks.
Tell all persons who are near chemicals of the possible dangerous results and the safety precautions that
are necessary.
Stay upwind and away from smoke from a chemical fire.
Keep or discard all chemicals that are not used as specified by the chemical manufacturer.
GUID-3910D764-BEA7-4A1B-80BF-946E438C6212 [V5]
GUID-DAAB4281-F045-467E-97A1-20DFD2BB692C [V4]
GUID-A494D2FA-1956-40C4-9743-052166A2A431 [V4]
1. Safety
Rotary Disc Header 15
700750336B

1.3 Travel on public roads
Make sure you understand the speed, brakes,
steering, stability, and load characteristics of this
machine before you travel on public roads.
Use good judgment when traveling on public
roads. Maintain complete control of the machine
at all times. Never coast down hills.
The maximum speed of farm equipment is
governed by local regulations. Adjust travel speed
to maintain control at all times. See the
specifications for the maximum speed for this
machine.
Familiarize yourself with and obey all road
regulations that apply to your machine. Consult
your local law enforcement agency for local
regulations regarding movement of farm
equipment on public roads. Use head lamps,
flashing warning lamps, tail lamps and turn signals,
day and night, unless prohibited by local law.
Make sure all the flashers are operating prior to
driving on the road. Make sure reflectors are
correctly installed, in good condition, and wiped
clean. If applicable, make sure the Slow Moving
Vehicle (SMV) emblem is clean, visible, and
correctly mounted on the rear of the machine.
Be aware of other trac on the road. Keep well
over to your own side of the road and pull over,
whenever possible, to let faster trac pass.
Be aware of the overall width, length, height, and
weight of the machine. Be careful when
transporting the machine on narrow roads and
across narrow bridges.
GUID-657D3002-48DB-436B-9B56-D3750095397D-high.jpg [High]
Fig. 13
Watch for overhead wires and other obstructions.
Avoid contact with electrical power lines. Contact
with electrical power lines can cause electrical
shock, resulting in very serious injury or death.
GUID-DB0A93E4-AEB5-49D5-AC5F-DD1454F1CFC6-high.jpg [High]
Fig. 14
GUID-9F5833EA-33BD-4C88-AA79-9433C36B3EF6 [V1.1.4]
1. Safety
16 Rotary Disc Header
700750336B

1.4 Maintenance
1.4.1 General maintenance information
Before you do maintenance, lubricate, do
servicing, clean, or make adjustments:
• Park the machine on a solid, level surface.
• Make sure that all the controls are in the
neutral position and apply the parking brake.
• Make sure that the machine and the
attachments are lowered to the ground.
• Stop the engine and take the key with you.
• Look and Listen! Make sure that all parts that
move are stopped.
• Put chocks in front of and behind the wheels of
the machine before you do work on or below
the machine. GUID-DB4C2E27-9DAC-4734-83E4-BC4BB5C26EAF-high.jpg [High]
Fig. 15
Do not pull the crop or other object from the machine while the engine is in operation. Parts that move can
pull you into the machine before you can move out of the way.
After you do work on the machine, remove all tools from the machine.
Make sure that electrical connectors are clean before you connect them.
Do a check for loose, broken, missing, or damaged parts. Make sure that the machine is in good repair.
Make sure that all guards and shields are in position.
Do not do the servicing, examine or adjust chains
or belts while the engine is in operation.
GUID-7D1C9640-D737-4F38-8886-F1D2280DF613-high.jpg [High]
Fig. 16
Do not operate the machine with the drive shaft
shields open or removed. Entanglement in drive
shafts that rotate can cause injury or death.
Stay clear of components that rotate.
Make sure that guards that rotate can rotate freely.
A loose yoke can come o a shaft and result in
injury to persons or damage to the machine.
When you install a quick disconnect yoke, the
spring activated locking pins must move freely and
be in the groove on the shaft. Pull on the driveline
to make sure that the quick disconnect yoke can
not be pulled o the shaft. GUID-CEB32148-1F4C-457C-ADF7-595DFC51AC25-high.jpg [High]
Fig. 17
[V]
GUID-93C8628D-B392-4191-80DB-7D54BDAAF61B [V20]
1. Safety
Rotary Disc Header 17
700750336B

Remove spilled oil, antifreeze or fuel immediately
from the steps, platform, and other access areas.
Keep all access areas clean of unwanted materials.
GUID-3B306DB1-0777-4FA6-86F1-895652B4C1DB-high.jpg [High]
Fig. 18
When you do work on the machine, make sure
that the header is lowered.
When it is necessary for the header to be in the up
position, lift the header to the full up position, stop
the engine, and take the key with you.
The header down valve on the windrower lift
cylinder keeps the header from lowering.
GUID-353ABA0B-44F7-4320-8E22-3E3CA612BD91-high.jpg [High]
Fig. 19
1.4.2 Fire prevention and first aid
Be prepared for emergencies.
Keep a first aid kit available for use on small cuts
and scratches.
Keep one or more fire extinguishers of the correct
type. Examine fire extinguishers regularly as stated
by the manufacturer. Make sure that the fire
extinguishers are charged and in operating
condition.
Crop material is flammable, there is a risk of fire.
Use a water type fire extinguisher or other water
source for a fire in crop.
For fires in material other than crop, such as oil or
electrical components, use a dry chemical fire
extinguisher with an ABC rating.
Keep fire extinguishers easy to access where fires
can occur.
Frequently remove crop material from the machine
and examine for components that are too hot. Do
checks on the machine each day for noises that
are not usual. Unusual noises can indicate a worn
out component that can cause too much heat.
If flame cutting, welding, arc welding, or grinding
is to be done on the machine or attachments, clear
GUID-FF34ACC9-D080-4CD5-9528-F426605803FF-high.jpg [High]
Fig. 20
GUID-9D716526-CF1A-4CD9-89A6-FD350D1B1E7A [V7]
1. Safety
18 Rotary Disc Header
700750336B
