MASSEY FERGUSON 9183 User manual

© AGCO Corporation, 2011 All rights reserved.
Part Number 4283362M2 (English)
Printed in U.S.A.
January 2011
Massey Ferguson®
9183 / 9190 / 9192
Rotary Disc Header
SERVICE MANUAL
4283362M2
CONTENTS
SAFETY..................................................................................................................................................................01
GENERAL INFORMATION ....................................................................................................................................02
DRIVES - 3.96 M (13 FT)........................................................................................................................................03
DRIVES - 4.9 M (16 FT)..........................................................................................................................................04
CUTTERBAR AND KNIVES...................................................................................................................................05
ELECTRICAL .........................................................................................................................................................06
HYDRAULICS ........................................................................................................................................................07
HAY CONDITIONER - 3.96 M (13 FT) ...................................................................................................................08
HAY CONDITIONER - 4.9 M (16 FT) .....................................................................................................................09
TROUBLESHOOTING............................................................................................................................................10
SPECIFICATION ....................................................................................................................................................11
ADJUSTMENTS .....................................................................................................................................................12

4283362M2 01-i
Contents
Massey Ferguson®
9183 / 9190 / 9192
Rotary Disc Header
SERVICE MANUAL
4283362M2
01 - Safety
Contents
SAFETY
Safety Alert Symbol ....................................................................................................................................... 01-1
Safety Messages ........................................................................................................................................... 01-1
Informational Messages ................................................................................................................................. 01-1
Safety Signs ................................................................................................................................................... 01-2
A Word to the Operator .................................................................................................................................. 01-2
Operator Manual ............................................................................................................................................ 01-3
Prepare for Operation .................................................................................................................................... 01-4
Operation ....................................................................................................................................................... 01-5
General Information ................................................................................................................................. 01-5
PPE (Personal Protection Equipment) .................................................................................................... 01-6
Seat Instructions ...................................................................................................................................... 01-6
Shield and Guards ................................................................................................................................... 01-6
Exhaust Warning ..................................................................................................................................... 01-7
Flying Debris ........................................................................................................................................... 01-7
Handrails ................................................................................................................................................. 01-8
Agricultural Chemicals ............................................................................................................................. 01-8
Travel On Public Roads ................................................................................................................................. 01-9
Maintenance ................................................................................................................................................ 01-10
General Information ............................................................................................................................... 01-10
Fire Prevention and First Aid ................................................................................................................. 01-12
Checking for High Pressure Leaks ........................................................................................................ 01-13
Cylinder Stops ............................................................................................................................................. 01-14
INDEX ............................................................................................................................................................. 01-15
Find manuals at https://best-manuals.com

01-ii 4283362M2
Contents
NOTES
Find manuals at https://best-manuals.com

4283362M2 01-1
Safety
SAFETY
SAFETY ALERT SYMBOL
FIG. 1: The safety alert symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS INVOLVED!
Look for the safety alert symbol both in this manual and
on safety signs on this machine. The safety alert symbol
will direct your attention to information that involves your
safety and the safety of others.
SAFETY MESSAGES
FIG. 2: The words DANGER, WARNING or CAUTION
are used with the safety alert symbol. Learn to recognize
these safety alerts and follow the recommended
precautions and safety practices.
mDANGER: Indicates an imminently
hazardous situation that, if not avoided, will
result in DEATH OR VERY SERIOUS
INJURY.
mWARNING: Indicates a potentially
hazardous situation that, if not avoided,
could result in DEATH OR SERIOUS
INJURY.
mCAUTION: Indicates a potentially
hazardous situation that, if not avoided,
may result in MINOR INJURY.
INFORMATIONAL MESSAGES
The words IMPORTANT and NOTE are not related to
personal safety, but are used to give additional
information and tips for operating or servicing this
equipment.
IMPORTANT: Identifies special instructions or
procedures which, if not strictly observed, could
result in damage to or destruction of the
machine, process, or its surroundings.
NOTE: Identifies points of particular interest for more
efficient and convenient repair or operation.
FIG. 1
Saf
FIG. 2
WC1957
Find manuals at https://best-manuals.com

Safety
01-2 4283362M2
SAFETY SIGNS
mWARNING: DO NOT remove or obscure
Danger, Warning or Caution signs. Replace
any Danger, Warning or Caution signs that
are not readable or are missing.
Replacement signs are available from your
dealer in the event of loss or damage. The
actual location of the safety signs is
illustrated at the end of this section.
Keep signs clean by wiping off regularly. Use a cleaning
solution if necessary.
If parts have been replaced or a used machine has been
purchased, make sure all safety signs are in the correct
location and can be read. Illustrations of safety sign
locations are located at the rear of this section.
Replace any safety signs that can not be read or are
missing. Clean the machine surface thoroughly with a
cleaning solution before replacing signs. Replacement
safety signs are available from your dealer.
A WORD TO THE OPERATOR
FIG. 3: It is YOUR responsibility to read and understand
the safety section in this manual and the manual for all
attachments before operating this machine. Remember
YOU are the key to safety. Good safety practices not only
protect you, but also the people around you.
Study the features in this manual and make them a
working part of your safety program. Keep in mind that
this safety section is written only for this type of machine.
Practice all other usual and customary safe working
precautions, and above all REMEMBER - SAFETY IS
YOUR RESPONSIBILITY. YOU CAN PREVENT
SERIOUS INJURY OR DEATH.
This safety section is intended to point out some of the
basic safety situations that may be encountered during
the normal operation and maintenance of your machine.
This section also suggests possible ways of dealing with
these situations. This section is NOT a replacement for
other safety practices featured in other sections of this
manual.
Personal injury or death may result if these precautions
are not followed.
Learn how to operate the machine and how to use the
controls properly.
Do not let anyone operate the machine without instruction
and training.
For your personal safety and the personal safety of
others, follow all safety precautions and instructions found
in the manuals and on safety signs affixed to the machine
and all attachments.
Use only approved attachments and equipment.
FIG. 3
S-1123
Find manuals at https://best-manuals.com

4283362M2 01-3
Safety
Make sure your machine has the correct equipment
needed by the local regulations.
mWARNING: An operator should not use
alcohol or drugs which can affect their
alertness or coordination. An operator on
prescription or 'over the counter' drugs
needs medical advice on whether or not
they can properly operate machines.
mCAUTION: If any attachments used on this
equipment have a separate Operator
Manual, see that manual for other important
safety information.
mCAUTION: See the engine Operation and
Maintenance Manual for other important
safety information.
mCAUTION: See the windrower tractor
Operator Manual for other important safety
information.
OPERATOR MANUAL
This manual covers general safety practices for this
machine. The Operator Manual must always be kept with
the machine.
Right-hand and left-hand, as used in this manual, are
determined by facing the direction the machine will travel
when in use.
The photos, illustrations, and data used in this manual
were current at the time of printing, but due to possible
in-line production changes, your machine can vary slightly
in detail. The manufacturer reserves the right to redesign
and change the machine as necessary without
notification.
mWARNING: In some of the illustrations and
photos used in this manual, shields or
guards may have been removed for clarity.
Never operate the machine with any shields
or guards removed. If the removal of
shields or guards is necessary to make a
repair, they MUST be replaced before
operation.
FIG. 4: The Operator Manual is stored in the holder (1)
on the machine. After using the Operator Manual, return
the manual to the storage location.
FIG. 4
1
N309100
Find manuals at https://best-manuals.com

Safety
01-4 4283362M2
PREPARE FOR OPERATION
Read and understand all operating instructions and
precautions in this manual before operating or servicing
the machine.
Make sure you know and understand the positions and
operations of all controls. Make certain all controls are in
neutral and the parking brake is applied before starting
the machine. Make sure the steering wheel is centered
and locked.
mWARNING: Any time the engine is running
and the parking brake is disengaged, the
machine will turn if the steering wheel is
moved even though the travel control lever
is in neutral.
Make certain all people are well away from your area of
work before starting and operating the machine. Check
and learn all controls in an area clear of people and
obstacles before starting your work. Be aware of the
machine size and have enough space available to allow
for operation. Never operate the machine at high speeds
in crowded places.
Emphasize the importance of using correct procedures
when working around and operating the machine. Do not
let children or unqualified persons operate the machine.
Keep others, especially children, away from your area of
work. Do not permit others to ride on the machine.
Make sure the machine is in the proper operating
condition as stated in the Operator Manual. Make sure
the machine has the correct equipment required by local
regulations.
All equipment has a limit. Make sure you understand the
speed, brakes, steering, stability, and load characteristics
of this equipment before you start.
Find manuals at https://best-manuals.com

4283362M2 01-5
Safety
OPERATION
General Information
FIG. 5: When parking, park the machine on a solid level
surface and lower the header to the ground. Put all
controls in neutral, center and lock the steering wheel,
and apply the parking brake. Stop the tractor engine and
take the key with you.
mWARNING: Do not leave the machine
unattended with the header raised. Lower
the header fully before leaving the machine.
A sudden loss of hydraulic pressure can
cause the header to drop without warning.
Make sure the machine is in the proper operating
condition according to the Operator Manual.
Always operate the machine with the control console
turned on.
Do not dismount from moving machinery.
Stay off slopes too steep for operation.
Be aware of the size of the machine and have enough
space available to allow for operation.
FIG. 6: Stay off slopes too steep for operation. Keep the
header as low as possible while going down hills. Never
suddenly reverse the wheels to stop or back up.
Where possible avoid operating the machine near
ditches, embankments, and holes. Reduce ground speed
when operating on rough, slippery, or muddy surfaces
and when turning or crossing slopes.
FIG. 7: Avoid contact with electrical power lines. Contact
with electrical power lines can cause electrical shock,
resulting in very serious injury or death.
FIG. 5
D-7084
FIG. 6
D-8482
FIG. 7
D-15022
Find manuals at https://best-manuals.com

Safety
01-6 4283362M2
PPE (Personal Protection Equipment)
FIG. 8: Wear all personal protective equipment (PPE)
and protective clothing issued to you or called for by job
conditions and country/local regulations. PPE includes,
but is not limited to, equipment to protect eyes, lungs,
ears, head, hands and feet when operating, servicing or
repairing equipment.
Always keep hands, feet, hair, and clothing away from
moving parts. Do not wear loose clothing, jewelry,
watches, or other items that could entangle in moving
parts. Tie up long hair that can also entangle in moving
parts.
Seat Instructions
Securely fasten the seat belt before operating the
machine. Always remain seated and have the seat belt
fastened while operating the machine. Replace the seat
belts when they become worn or broken.
Never wear a seat belt loosely or with slack in the belt
system. Never wear the seat belt in a twisted condition or
pinched between the seat structural members.
When using the instructional seat, if equipped, securely
fasten the seat belt. The instructional seat is to be used
only to train new operators or diagnose a problem. The
instructional seat is only intended for short periods of use.
Extra riders, especially children, are not permitted on the
machine.
When the instructional seat is used the machine must be
driven at a slower speed and on level ground. Avoid quick
starts, stops, and sharp turns. Avoid driving on highways
or public roads.
Shield and Guards
FIG. 10: All shields and guards must be in the correct
operating position and in good condition.
Do not open, remove, or reach around shields while the
engine is operating. Entanglement in rotating belts and
components can cause serious injury or death. Stay clear
of rotating components.
All curtains must be in the correct operating position and
in good condition.
FIG. 8
S-1127A
FIG. 9
WC1953A
FIG. 10
71389544C
Find manuals at https://best-manuals.com

4283362M2 01-7
Safety
FIG. 11: Do not operate the machine with the drive shaft
shields open or removed. Entanglement in rotating drive
shafts can cause serious injury or death. Stay clear of
rotating components.
Make sure rotating guards turn freely.
Do not make adjustments to the roll tension with the
header engaged.
When making adjustments to the roll pressure, turn off the
header. Lower the header to the ground and engage the
parking brake. Set the engine to low idle.
Exhaust Warning
FIG. 12: Never operate the engine in a closed building
unless the exhaust is vented outside.
Flying Debris
FIG. 13: Never stand near the machine during operation.
Debris can be thrown from the machine during operation
possibly resulting in injury.
mWARNING: Be careful when operating
along the side of a road or building. Rocks
or other debris can be thrown from the
machine during operation possibly
resulting in injury.
Tilt the header back in fields where stones
and foreign objects are present. This will
raise the cutting knives and minimize
debris being thrown by the rotating knives.
FIG. 11
WC1941
FIG. 12
WC1949
FIG. 13
D-8278
Find manuals at https://best-manuals.com

Safety
01-8 4283362M2
Handrails
FIG. 14: Face the ladder and use the handrails when
getting on or off the machine.
Agricultural Chemicals
Agricultural chemicals can be very hazardous. Improper
use of fertilizer, fungicides, herbicides, insecticides and
pesticides can injure people, plants, animals, soil and
other people's property.
Always read and follow all manufacturers' instructions
before opening any chemical container.
Even if you think you know the instructions, read and
follow instructions each time you use a chemical.
Use the same precautions when adjusting, servicing,
cleaning or storing the machine as used when installing
chemicals into the hoppers or tanks.
Inform anyone who comes in contact with chemicals of
the potential hazards involved and the safety precautions
required.
Stand upwind and away from smoke from a chemical fire.
Store or dispose of all unused chemicals only in a manner
as specified by the chemical manufacturer.
FIG. 14
WC1940

4283362M2 01-9
Safety
TRAVEL ON PUBLIC ROADS
FIG. 15: Make sure you understand the speed, brakes,
steering, stability, and load characteristics of this machine
before you travel on public roads.
Use good judgment when traveling on public roads.
Maintain complete control of the machine at all times.
Never coast down hills.
The maximum speed of farm equipment is governed by
local regulations. Adjust travel speed to maintain control
at all times.
Familiarize yourself with and obey all road regulations that
apply to your machine. Consult your local law
enforcement agency for local regulations regarding
movement of farm equipment on public roads. Use
headlights, flashing warning lights, taillights and turn
signals, day and night, unless prohibited by local law.
Make sure all the flashers are operating prior to driving on
the road. Make sure reflectors are correctly installed, in
good condition, and wiped clean. Make sure the Slow
Moving Vehicle (SMV) emblem is clean, visible, and
correctly mounted on the rear of the machine.
Always travel with the header as low as possible. Do not
drive with header up and the lift cylinder stops in the
locked position. See Cylinder Stops in this section for
more information.
Be aware of other traffic on the road. Keep well over to
your own side of the road and pull over, whenever
possible, to let faster traffic pass.
Be aware of the overall width, length, height, and weight
of the machine. Be careful when transporting the machine
on narrow roads and across narrow bridges.
FIG. 16: Watch for overhead wires and other
obstructions. Avoid contact with electrical power lines.
Contact with electrical power lines can cause electrical
shock, resulting in very serious injury or death.
FIG. 15
s-1025
FIG. 16
D-15022

Safety
01-10 4283362M2
MAINTENANCE
General Information
FIG. 17: Before doing any unplugging, lubricating,
servicing, cleaning, or adjusting:
• Park the machine on a solid level surface.
• Put all controls in neutral and center and lock the
steering wheel.
• Turn off the control console, if equipped.
• Stop the engine and take the key with you.
• Look and Listen! Make sure all moving parts have
stopped.
• Put blocks in front of and behind the wheels of the
machine before working on or under the machine.
Do not pull crop or any other object from the machine
while the machine engine is running. Moving parts can
pull you in faster than you can move away.
Check all nuts and bolts periodically for tightness,
especially wheel mounting hardware.
Do not attempt to service or adjust the machine until all
moving parts have stopped.
After unplugging, lubricating, servicing, cleaning, or
adjusting the machine make sure all tools and equipment
have been removed.
Make sure electrical connectors are clean and free of dirt
or grease before connecting.
Check for loose, broken, missing, or damaged parts.
Make sure the machine is in good repair. Make sure all
guards and shields are in position.
Check the disc and knife bolts regularly for tightness,
especially after striking foreign objects. See Cutterbar in
the Specifications section for correct knife bolt torque.
FIG. 18: Never service, check or adjust drive chains or
belts while the engine is running.
FIG. 17
D-8518
FIG. 18
wc1943

4283362M2 01-11
Safety
FIG. 19: Do not operate the machine with the drive
shafts shields open or removed. Entanglement in rotating
drive shafts can cause serious injury or death.
Stay clear of rotating components.
Make sure rotating guards turn freely.
A loose yoke can slip off a shaft and result in injury to
persons or damage to the machine.
When installing a quick disconnect yoke, the spring
activated locking pins must slide freely and be seated in
the groove on the shaft. Pull on the driveline to make sure
the quick disconnect yoke can not be pulled off the shaft.
FIG. 20: When working on the machine, make sure the
header and reel are lowered all the way.
When it is necessary for the header or the reel to be in the
raised position, raise the header or reel all the way and
engage the cylinder stops. See Cylinder Stops in this
section for more information.
mWARNING: Always install the header lift
cylinder stops when working near the
header. Do not rely on the hydraulic system
to keep the header raised. A sudden loss of
hydraulic pressure could cause the header
to lower unexpectedly.
FIG. 21: Remove spilled oil, antifreeze or fuel
immediately from operator's ladder and platform and
other access areas.
Keep all access areas clean and free of obstructions.
FIG. 19
wc1941
FIG. 20
WC1954
FIG. 21
Wc1939

Safety
01-12 4283362M2
Fire Prevention and First Aid
FIG. 22: Be prepared for emergencies.
Keep a first aid kit handy for treatment of minor cuts and
scratches.
Always carry one or more fire extinguishers of the correct
type. Check fire extinguishers regularly as instructed by
the manufacturer. Make sure fire extinguishers are
properly charged and in operating condition.
Due to the nature of the crops this machine will operate in,
the risk of fire is of concern. Use a water type fire
extinguisher or other water source for a fire in crop.
For fires involving anything other than crop, such as oil or
electrical components, use a dry chemical fire
extinguisher with an ABC rating.
Mount fire extinguishers within easy reach of where fires
can occur.
Frequently remove accumulated crop material from the
machine and check for overheated components. Check
the machine daily for any noises that are not normal.
Such noises could indicate a failed component that can
cause excess heat.
If any flame cutting, welding, or arc welding is to be done
on the machine or attachments, make sure to clear any
crop material or debris from around the area. Make sure
the area below the work area is clear of any flammable
material as falling molten metal or sparks can ignite the
material.
FIG. 23: If fire occurs stand upwind and away from
smoke from the fire.
FIG. 22
S-1131
FIG. 23
Wc1946

4283362M2 01-13
Safety
Checking for High Pressure Leaks
FIG. 24: Fluid leaking from the hydraulic system or the
fuel injection system under high pressure can be very
hard to see. The fluid can go into the skin causing serious
injury.
Fluid injected into the skin must be surgically removed
within a few hours. If not removed immediately, serious
infection or reaction can develop. Go immediately to a
doctor who knows about this type of injury.
FIG. 25: Use a piece of cardboard or wood to search for
possible leaks. Do not use your bare hand. Wear leather
gloves for hand protection and safety goggles for eye
protection.
Relieve all pressure before loosening any hydraulic lines.
Relieve the pressure by lowering raised equipment,
shutting off accumulator valve, if equipped, and shutting
off the engine. Tighten all connections securely before
applying pressure.
FIG. 24
WC1938
FIG. 25
D-5842A

Safety
01-14 4283362M2
CYLINDER STOPS
Both header lift cylinders have cylinder stops. The
cylinder stops are activated by one lever outside the cab
door.
FIG. 26: To engage the cylinder stops (1), raise the
header completely. Move the lever (2) toward the cab and
then pull back toward the rear of the machine to engage
the cylinder stops. Make sure the cylinder stops are
completely engaged in both header lift cylinders.
FIG. 27: To disengage the cylinder stops, raise the
header completely. Move the lever (1) toward the cab and
then push forward toward the header to disengage the
cylinder stops. Make sure the cylinder stops are
completely disengaged from both header lift cylinders.
FIG. 26
1
2
LA19997
FIG. 27
1
LA19996
1

4283362M2 01-15
Index
INDEX
A
A Word To The Operator ..................................... 01-2
Agricultural Chemicals Safety .............................. 01-8
C
Cylinder Stops .................................................... 01-14
E
Exhaust Warning .................................................. 01-7
F
Fire Prevention and First Aid ............................. 01-12
Flying Debris ........................................................ 01-7
H
Handrails .............................................................. 01-8
High Pressure Leaks .......................................... 01-13
I
Informational Messages ....................................... 01-1
M
Maintenance, Safety Information ....................... 01-10
O
Operation Safety .................................................. 01-5
Operator Manual .................................................. 01-3
P
Personal Protection Equipment ........................... 01-6
Prepare For Operation ......................................... 01-4
S
Safety Alert Symbol ............................................. 01-1
Safety Signs ......................................................... 01-2
Seat Instructions .................................................. 01-6
Shield and Guards ............................................... 01-6
T
Travel On Public Roads ....................................... 01-9

01-16 4283362M2
Index
NOTES

4283362M2 02-i
Contents
Massey Ferguson®
9183 / 9190 / 9192
Rotary Disc Header
SERVICE MANUAL
4283362M2
02 - General Information
Contents
GENERAL INFORMATION
Introduction .................................................................................................................................................... 02-1
Units of Measurement .................................................................................................................................... 02-1
Replacement Parts ........................................................................................................................................ 02-1
Machine Identification .................................................................................................................................... 02-1
Serial Number Definition ................................................................................................................................ 02-2
Description ..................................................................................................................................................... 02-3
Header Skid Shoes ................................................................................................................................. 02-6
Cutterbed ................................................................................................................................................. 02-6
Augers ..................................................................................................................................................... 02-6
Hay Conditioner ....................................................................................................................................... 02-6
Swathboard ............................................................................................................................................. 02-6
Forming Shields ...................................................................................................................................... 02-6
Component Location ...................................................................................................................................... 02-7
Component Access ........................................................................................................................................ 02-8
Lubrication Chart ........................................................................................................................................... 02-9
Lubrication Details ....................................................................................................................................... 02-12
Lubrication Points (3.96 m (13 ft) Rotary Header) ................................................................................. 02-12
Lubrication Points (4.9 m (16 ft) Single Conditioner) ............................................................................. 02-15
Lubrication Points (4.9 m (16 ft Double Conditioner) ............................................................................ 02-18
Cutterbed Drive Gearboxes ................................................................................................................... 02-20
Motor Shaft Splines ............................................................................................................................... 02-23
Hay Conditioner Gearcase .................................................................................................................... 02-23
Cutterbed ............................................................................................................................................... 02-24
General Maintenance Information ............................................................................................................... 02-27
Bolt Torque Values ................................................................................................................................ 02-27
Bearing Replacement ............................................................................................................................ 02-28
INDEX ............................................................................................................................................................. 02-29
