MASSEY FERGUSON MF 5650 Series Instruction manual

MF
5650
HP
175
Combines
Workshop Manual
Models: MF 5650 Advanced - MF 5650 Advanced SR
INNOVATION - COMMITMENT - PROXIMITY - VISION - RELIABILITY - LEADERSHIP - SUPPORT - TECHNOLOGY

0-1
MF 5650
Workshop Manual - MF 5650
Machine models applied
MF 5650 Combines
Variations
- With tangential trail (Grain version) - Fig.. 1.
- With trail system and separation by double rotor: Rice
version, SR - Figs. 2 and 3.
- Traction 4x2 and 4x4.
- With wheel double or tracks.
Published by AGCO do Brasil.
Canoas - Rio Grande do Sul - Brazil
Publishing Code: CDMOI5650E01
Edition: 02/10
AGCO do Brasil
