MASSEY FERGUSON 9125 User manual

9125 / 9145
Auger Header
Workshop Service Manual

Find manuals at https://best-manuals.com

4283389M1 01-i
MASSEY FERGUSON®
9125 / 9145
Auger Header
4283389M1
CONTENTS
SAFETY...............................................................................................................................................................................01
GENERAL INFORMATION ................................................................................................................................................02
ELECTRICAL ......................................................................................................................................................................03
HYDRAULICS .....................................................................................................................................................................04
GEARBOXES......................................................................................................................................................................05
REEL....................................................................................................................................................................................06
SICKLE ................................................................................................................................................................................07
AUGER ................................................................................................................................................................................08
HAY CONDITIONER...........................................................................................................................................................09
TROUBLESHOOTING........................................................................................................................................................10
SPECIFICATIONS ..............................................................................................................................................................11
INDEX..................................................................................................................................................................................12
Find manuals at https://best-manuals.com

01-ii 4283389M1
NOTES
Find manuals at https://best-manuals.com

4283389M1 01-1
Contents
Massey Ferguson®
9125 / 9145
Auger Header
WORKSHOP SERVICE MANUAL
4283389M1
01 - Safety
Contents
Safety Alert Symbol ....................................................................................................................................... 01-3
Safety Messages ........................................................................................................................................... 01-3
Informational Messages ................................................................................................................................. 01-4
Safety Signs ................................................................................................................................................... 01-4
Operator Manual ............................................................................................................................................ 01-5
A Word to the Operator .................................................................................................................................. 01-5
Prepare for Operation .................................................................................................................................... 01-6
Operation ....................................................................................................................................................... 01-7
Travel on Public Roads .................................................................................................................................. 01-9
Fire Prevention ............................................................................................................................................ 01-10
Maintenance ................................................................................................................................................ 01-11
Accumulators ............................................................................................................................................... 01-13
Cylinder Stops ............................................................................................................................................. 01-13
Find manuals at https://best-manuals.com

01-2 4283389M1
Contents
NOTES
Find manuals at https://best-manuals.com

4283389M1 01-3
Safety
SAFETY
SAFETY ALERT SYMBOL
FIG. 1: The safety alert symbol means ATTENTION!
BECOME ALERT! YOUR SAFETY IS INVOLVED!
Look for the safety alert symbol both in this manual and
on safety signs on this machine. The safety alert symbol
will direct your attention to information that involves your
safety and the safety of others.
SAFETY MESSAGES
FIG. 2: The words DANGER, WARNING or CAUTION
are used with the safety alert symbol. Learn to recognize
these safety alerts and follow the recommended
precautions and safety practices.
mDANGER: Indicates an imminently
hazardous situation that, if not avoided, will
result in DEATH OR VERY SERIOUS
INJURY.
mWARNING: Indicates a potentially
hazardous situation that, if not avoided,
could result in DEATH OR SERIOUS
INJURY.
mCAUTION: Indicates a potentially
hazardous situation that, if not avoided,
may result in MINOR INJURY.
FIG. 1
Saf
FIG. 2
WC1957
Find manuals at https://best-manuals.com

Safety
01-4 4283389M1
INFORMATIONAL MESSAGES
The words IMPORTANT and NOTE are not related to
personal safety, but are used to give additional
information and tips for operating or servicing this
equipment.
IMPORTANT: Identifies special instructions or
procedures which, if not strictly observed, could
result in damage to or destruction of the
machine, process, or its surroundings.
NOTE: Identifies points of particular interest for more
efficient and convenient repair or operation.
SAFETY SIGNS
mWARNING: DO NOT remove or obscure
Danger, Warning or Caution signs. Replace
any Danger, Warning or Caution signs that
are not readable or are missing.
Replacement signs are available from your
dealer in the event of loss or damage.
If a used machine has been purchased, make sure all
safety signs are in the correct location and can be read.
Replace any safety signs that can not be read or are
missing. Replacement safety signs are available from
your dealer.
Find manuals at https://best-manuals.com

4283389M1 01-5
Safety
OPERATOR MANUAL
FIG. 3: The Operator Manual is stored in the holder (1)
located on the windrower tractor. After using the Operator
Manual, return the manual to the storage location.
Right-hand and left-hand, as used in this manual, is
determined by facing the direction the machine will travel
when in use.
The photos, illustrations, and data used in this manual
were current at the time of printing, but due to possible
in-line production changes your machine can vary slightly
in detail. The manufacturer reserves the right to redesign
and change the machine as necessary without
notification.
mWARNING: In some of the illustrations or
photos used in this manual, panels or
guards may have been removed for clarity.
Never operate the machine with any panels
or guards removed. If the removal of panels
or guards is necessary to make a repair,
they MUST be replaced before operation.
A WORD TO THE OPERATOR
FIG. 4: It is YOUR responsibility to read and understand
the safety division in this manual before operating this
machine. Remember YOU are the key to safety. Good
safety procedures not only protect you, but also the
people around you.
Study the features in this manual and make them a
working part of your safety program. Keep in mind this
safety division is written only for this type of machine.
Practice all other normal and customary safe working
precautions, and above all REMEMBER - SAFETY IS
YOUR RESPONSIBILITY. YOU CAN PREVENT
SERIOUS INJURY OR DEATH.
This safety division is intended to point out some of the
basic safety situations may be found during the normal
operation and maintenance of this machine, and to
suggest possible ways of dealing with these situations.
This division is NOT a replacement for safety procedures
featured in other divisions of this manual.
NOTE: This manual covers general safety procedures
for this machine. This manual must always be
kept with the machine. Return the manual to the
storage location after use.
mCAUTION: Refer to the tractor Operator
Manual for other important safety
information.
FIG. 3
1
N309100
FIG. 4
S-1123
Find manuals at https://best-manuals.com

01-6 4283389M1
Safety
PREPARE FOR OPERATION
Emphasize the importance of using correct procedures
when working around and operating the machine. DO
NOT let unqualified persons to operate your machine.
Keep others, especially children, away from your area of
work. DO NOT permit others to ride on the machine.
Read and understand all operating instructions and
precautions in this manual before operating or servicing
the machine. Make sure you know and understand the
positions and operations of all controls.
Make sure the machine is in the proper operating
condition as stated in this Manual. Make sure the
machine has the correct equipment needed by local
regulations.
Make certain all controls are in neutral and the parking
brake is engaged before starting the machine. Make
certain all people are well away from your area of work
before starting and operating the machine.
mWARNING: Any time the engine is running
and the parking brake is disengaged, the
machine will turn if the steering wheel is
moved even though the travel control lever
is in neutral.
All equipment has a limit. Make sure you understand the
speed, brakes, steering, stability, and load characteristics
of the machine before you start. Check all controls in an
area clear of people and obstacles before starting your
work.
Be aware of the machine size and have enough space
available to allow for operation. Never operate the
machine at high speeds in crowded places.
mWARNING: An operator should not use
alcohol or drugs which can affect their
alertness or coordination. An operator
taking prescription or ‘over the counter’
drugs needs medical advice on whether or
not they can properly operate machines.
