METHVEN Minimalist 17-6250 User manual

AS3662
WMKT21090
www.methven.com
Installation Guide
Illustration may not reflect actual product shape.
17-6250
Use of this product in non-domestic applications voids warranty.
All pipe work must be thoroughly flushed prior to the installation of the mixer.
NEFA inline filters must be installed on both hot and cold supplies.
Do not remove the ceramic cartridge from the mixer when installing.
Damage caused by hydrostatic testing is not covered by our warranty.
IMPORTANT
Please read all of the instructions before installation
Minimalist
Pull-out Hand Shower
The more
stars the more
water efficient
www.waterrating.gov.au
A joint government and industryprogram
Licence No. 0095
When testedin accordance with Standard AS/NZS 6400
litres per minute
WATER
RATING
9

Installation Guide
PARTS
NOV 2010 97-9882
THE METHVEN GUARANTEE
The warranty statement shall apply to all tapware & showers supplied by Methven
For more information visit www.methven.com
THIS WARRANTY ISSUED BY: Methven Australia Pty Ltd, Melbourne Australia
We recommend that this product is installed by a licensed plumber.
Methven Australia Pty Ltd
ABN 15 104 813 390
Melbourne, Australia
www.methven.com
1. Install handset holder (A) into bench/ bath and tighten in position with rubber
washer and brass lock nut provided.
2. Feed the hex nut end of the hose down through the handset holder and
position the chrome plated wedge and conical nut into the bath holder.
3. Attach handset to the conical nut end of the hose.
31
210
Stilo Handset
80-7604
Bath Sleeve
w/nut - wash l/wedge
81-7023
Hose Classic
Chrome
81-1106
TECHNICAL DRAWING IMAGE
Hex nut Conical nut
(A)
