Welcome
This document provides information about Technical Report (TR)-069 protocol support for the 6800i Series (6863i, 6865i,
6867i, and 6869i) SIP IP Phones.
TR-069 Protocol Support
The IP Phones support the TR-069 protocol. This protocol is a bi-directional HTTP-based protocol that provides a means of
communication between Customer-Premises Equipment (CPE) (e.g. IP phones) and Auto Configuration Servers (ACSs)
over DSL/broadband connections. It includes both safe auto configuration and the control of other CPE management
functions within an integrated framework.
Service providers can, through TR-069, use one common platform to manage (through the internet) all of their customer
premise devices, regardless of the device or manufacturer. If TR-069 is enabled on the phones, when the remote ACS
boots the phones, they contact the ACS and establish the configuration automatically.
In addition to configuring the phone with TR-069, you can also do the following:
•Reboot the phone
•Reset to factory defaults
•Update the firmware of the device
•Backup/restore configuration
•Upload the log file
An Administrator can configure the TR-069 parameters using the configuration files only. For more information about the
TR-069 parameters, see “TR-069 Parameter Descriptions” on page 3.
Pre-Staging SIP Phones
There are two options available to enable TR-069 support for the phones:
a) An Administrator can provide a configuration file (that can be taken from the TFTP site or during RCS provisioning)
with parameters that are specified in “TR-069 Parameter Descriptions” on page 3.
b) The phones can be branded and the branded default configuration file can contain all the necessary parameters.
After phones (with correct firmware) receive this configuration file, they will start a bootstrap procedure and connect to
the ACS server.
Note:
Implementation of the TR-069 protocol follows TR-104 and TR-106 standards to the extent of data sets applicable to SIP
IP phones.

TR-069 Protocol Support
241-001562-00 REV00 – 10.2014
TR-069 Functionality Support
XML-Remote Procedure Call (RPC) is a protocol which uses XML to encode its calls and HTTP as a transport mechanism to
make requests to Internet-based servers. The following table identifies the XML-RPC methods supported for the TR-069
functionality on the phones in Release 4.0.0.
XML-RPC Method CPE Requirement Supported in this Release 4.0.0
GetRPCMethods Required Yes
SetParameterValues Required Limited to parameters specified in “TR-069 Parameter Descriptions” on page 3.
Note:
Users are limited to parameters that are specified by Mitel. Please contact Mitel for a list
of these parameters.
GetParameterValues Required Limited to parameters specified in “TR-069 Parameter Descriptions” on page 3.
GetParameterNames Required Yes
SetParameterAttributes Required Yes
GetParameterAttributes Required Yes
AddObject Required No
DeleteObject Required No
Reboot Required Yes
Download Required Yes
Upload Optional Yes
FactoryReset Optional Yes
GetQueuedTransfers Optional No
GetAllQueuedTransfers Optional No
ScheduleInform Optional No
SetVouchers Optional No
GetOptions Optional No

TR-069 Protocol Support
41-001562-00 REV00 – 10.2014 3
Limitations
The following is a list of limitations with TR-069:
•TR-111 Part 1 is not supported (only Part 2 - STUN)
•The current release does not have support for the following RPC function calls:
–AddObject
–DeleteObject
–GetQueuedTransfers
–GetAllQueuedTransfers
–ScheduleInform
–SetVouchers
–GetOptions
•Inform Retry Policy with increasing intervals is not supported (only constant intervals are supported)
•Active Notification is supported only for limited list of parameters
•A subset of Mitel configuration parameters are supported through TR-069
•Only a TR-069 active session is supported (single IP address)
•CPE Identification is made based on OUI + Product Class + MAC (not serial number)
•Each Voice Profile has only 1 line
•VoiceService.X_Aastra_GlobalVoiceProfile corresponds to Mitel Sip Global Settings and has only 1 line object
•VoiceService.1.VoiceProfile.{1} corresponds to Mitel SIP settings per line i and has only 1 line object
•Constant number of lines mapped to the number of Voice Profile (profile remove is not supported)
Behaviors
The following is a list of behaviors with TR-069:
•Web and phone UI are still available for configuration and can override what was configured through TR-069
•The phones will notify ACS though the Active notification process for a limited subset of parameters (as defined)
•Loading of new configuration through TR-069 will require a CPE reboot
TR-069 Parameter Descriptions
An Administrator can enable/disable and configure the TR-069 protocol using the following parameters in the configura-
tion files:
•tr69
•tr69 server
•tr69 server port
•tr69 server path
•tr69 username
•tr69 password
•tr69 connection request path
•tr69 connection request port
