Mocka Hamptons Bedside Table 40 mm User manual

Phillips & Flathead screwdrivers and hammer required
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
1
X
Z
Y
W
safety
strap
x1
screw
x1
long
screw
x1
wall
anchor
x1
washer
x1
mocka.co.nz | mocka.com.au
B
ACDEF
GH
30 mm
12 mm
Hardware Supplied
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
bolt
x32
locking
nut x 32
dowel
x20
small
screw x24
I
L + R
slide rail
x6
L + R
slide rail
x6
long
screw x 12
Hamptons Bedside Table
40 mm
long
screw x 4
J
25 mm
small
screw x2
handle
x 3
P1
wedge
x6
WARNING: Any furniture that is not anchored to a wall has the potential to tip
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.

1
2
12
Hamptons Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
A
6
A
A
A
A
W
Y
1J
J
GG
A
AA
A
EEEE
EE
E
E
EEEE
G
G
G
G
G
G
34
Attach 3 x left slide rails (G) to panel [3] and secure with 6 x small screws (E).
Tighten with a screwdriver.
Attach 3 x right slide rails (G) to panel [4] and secure with 6 x small screws (E).
Insert 4 x bolts (A) into panels [3] and [4].
Insert 4 x bolts (A) into panels [1]. Attach panels [6] to panel [1] and secure with
2 x screws (J). Attach 1 x wall strap (W) to panel [1] using 1x screw(Y).
Tighten with a screwdriver.

1
3
34
Hamptons Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
C
3
4
C
B
B
B
B
C
C
5
5
Insert 4 x dowels (C) into panels [5]. Attach panels [5] to panels [3] and [4]
and secure with 4 x locking nuts (B). Tighten with a screwdriver.
2
AA
AA
AA
A
A
A
C
A
C
A
A
B
B
B
BC
C
13
13 14
14
Attach 12 x bolts (A) into panels [2] and [13]. Attach 4 x dowels (C) to panels [13]
and [14]. Insert 4 x locking nuts (B) into panels [14]. Tighten with a screwdriver.

1
4
56
Hamptons Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
3
4
2
Insert 4 x dowels(C) into panels [3] and [4].
panel [2] and secure with 4 x long screws (D).
D
D
D
D
C
C
C
C
C
C
C
C
B
B
B
B
Insert 4 x dowels (C) into panels [2], [13] and [14]. Attach panels [13] and [14] to
panel [2] and secure with 8 x locking nuts (B). Tighten with a screwdriver.
2
13
14
Attach panels [3] and [4] to
Tighten with a screwdriver.

1
5
78
Hamptons Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
3
4
Slide panel [7] between the grooves on panels [3] and [4] to form the
back of the unit as shown.
7
1
4
3
Tighten with a screwdriver.
Insert 4 x dowels (C) into panel [1]. Attach panels [1] to panel [3], [4] and
[7] and secure with 4 x locking nuts (B).
B
CC
CC
7
BBB

1
6
910
Hamptons Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
Drawers (x3) Drawers (x3)
Tighten with a screwdriver.
Insert 12 x bolts (A) into panels [8]. Attach panels [10] and [11] to panel
[8], secure with 12 x locking nuts (B).
Slide panels [9] between the grooves on panels [10] and [11] to form the base
of the drawer as shown.
10
B
B
AA
B
B
A
A
A
11
10
11
8
9

1
7
11 12
Hamptons Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
Drawers (x3)
F
9
F
F
F
12
Tighten with a screwdriver.
Attach panels [12] to panels [9], [10] and [11], secure with 12 x
medium screws (F).
10
11
Drawers (x3)
E
E
H
I
Attach 6 x slide rails (H) to panels [10] and [11] and secure with 12 x small
screws (E). Insert 3 x Handles and screws (I) into panels [8] .
8
10
11
E
H
E

1
8
13 14
Hamptons Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
mocka.co.nz | mocka.com.au
P1
P1
P1
P1
P1
P1
P1
7
Attach 6 x wedges (P1) to panel [7]
.
Tighten with a screwdriver.
X
Z
x1
wall
screw
wall
anchor
wall
screw
Washer
Strap
Once assembled lift furniture into place, do not drag. Use a drill to create
a small hole lining up with the top of the safety strap (W). Fasten to wall
using wall anchor (X), washer (Z) and screw. Ensure the unit is balaced
and steady before use. You’re done, enjoy!
